Installation and Maintenance Instructions
Zip FlushMaster Pearl &
Zip FlushMaster Mk.2
41091 Zip FlushMaster Pearl
Compact Recessed Sensor & Solenoid
DC WS004. With 64mm body
®
Water Saver Urinal Flushing System
Keeps Urinals Clean & Reduces Water Wastage
Instructions for Models: WS003; WS004; WS006; WS007 and 99168 Sensor.
41095 Zip FlushMaster MK2
Recessed sensor & Solenoid
DC WS003. With 105mm body
WS004
WS003
®

Page 2 of 12 Zip FlushMaster Pearl Installation & Maintenance Instructions - 82902 - January 2012 v1.00
You may need these accessories ( see page 3 for package contents).
Table of Contents
Key Features ................................................. 3
Read These Warnings First ............................ 3
Check Your Package...................................... 3
Installation Procedure .................................... 3
Set Up Water Discharge ................................ 4
Install Sensor................................................. 6
Connect Latching Valve Cable........................ 7
Connect Optional Power Pack........................ 8
Set Flush Timing............................................ 8
Completing Installation .................................. 9
Maintenance Instructions............................... 10
Problem Solving............................................. 11
Contact Details .............................................. 12
99168 Pearl Water Saver Sensor only (64mm body)
99021 Zip FlushMaster Cistern Autosyphon 1.00 inch BSP/ 25 mm
99022 Zip FlushMaster Cistern Autosyphon 1.25 inch BSP/ 32 mm
99023 Zip FlushMaster Cistern Autosyphon 1.50 inch BSP/ 38 mm
99024 Zip FlushMaster Direct Injection Airbreak 1.00 inch BSP / 25 mm
99025 Zip FlushMaster Direct Injection Airbreak 1.25 inch BSP/ 32 mm
99026 Zip FlushMaster Direct Injection Airbreak 1.50 inch BSP/ 38 mm
Fixing
bracket
99031 Zip FlushMaster AC Power Pack
Accessories
99039 -Restrictaflow
41092 Mk 2 Retrofit Sensor DC (105mm body) WS006 ( Valve assy not included )
41093 Mk 2 Retrofit Sensor AC (105mm body) WS007 ( Valve assy not included )

Zip FlushMaster Pearl Installation & Maintenance Instructions - 82902 - January 2012 v1.00 Page 3 of 12
Key Features
One of the world’s most effective, ceiling recessed, urinal flushing systems.
Battery operation (FlushMaster only) for simple, inexpensive installation.
Optional power pack for connection to 220-240 volt AC power.
Variable flush cycle to meet your needs precisely.
Read These Warnings First
Read all instructions before attempting to install this system.
Never attempt to install this system without reading all instructions.
Designed for indoor use only do not expose to elements of nature.
All plumbing connections must be made in accordance with AS3500.
Supply pressure 350kPa - 700kPa
Installation Procedure
1. Set up water discharge
2. Install sensor
3. Connect latching valve cable
4. Set flush timing
Check Your Package
Product Code 41091
Zip FlushMaster WS004
Ceiling recessed sensor
complete with latching
valve, 6V Battery and
brass fittings with
restrictaflow.
64mm Body
Zip FlushMaster package includes.
Product code 41095
Zip FlushMaster Mk.2 WS003
Ceiling recessed sensor,
complete with latching valve, 6
V Battery and brass fittings with
restrictaflow
105mm Body
Product code 90281
Latching valve and brass fittings
with flow restrictor

Page 4 of 12 Zip FlushMaster Pearl Installation & Maintenance Instructions - 82902 - January 2012 v1.00
Set Up Water Discharge
Single stall
1.5 to 2.5 Litre
Discharge Capacity
Twin stall
3.0 to 5.0 Litre
Discharge Capacity
Triple stall
4.0 to 7.5 Litre
Discharge Capacity
Single stall Twin stall
Single trough
Maximum trough
length 600 mm
Twin trough
Maximum trough
length 1200 mm
Single trough
1.5 to 2.5 litre
discharge capacity
Single trough
3.0 to 5.0 litre
discharge capacity
Single trough
4.0 to 7.5 litre
discharge capacity
Typical Installation with Cistern
Typical Installation with Direct Injection
Flow restrictor Installation Notes:
-The Restrictaflow must be fitted between
the isolating valve (not supplied) and the
latching valve (see page 5).
-The Restrictaflow is designed to save water
and to reduce the flow, particularly
when used on single stall installations.
-The Restrictaflow may be drilled out (in
0.5mm increments) or removed when
servicing multiple stalls and a higher
flow is required, or when there is
insufficient water pressure.
-The Restrictaflow is normally required
with operating pressures greater than
700kPa.
-An Isolating valve must be supplied
and installed in accordance with AS/
NZS3500

Zip FlushMaster Pearl Installation & Maintenance Instructions - 82902 - January 2012 v1.00 Page 5 of 12
Set Up Water Discharge Continued
Autosyphon Installation
More than one cistern can be fed from a single latching valve, but for
accurate balancing, do not connect together more than two cisterns.
The balance of water can be achieved by keeping the supply pipe length to
each cistern as equal in length as possible.
If this is not practical fit a flow restrictor of equal rating at the entry to each
cistern.
Remove the existing filling mechanism from the cistern, including the float
and aspirin washer, to permit unrestricted inlet of the water. The flow of
water into the cistern is controlled by the latching valve.
Remove the existing manual flushing mechanism from the cistern, and fit
the syphon to the outlet hole as shown in the diagram. Connect the sparge
pipe to the protruding thread from the syphon.
Note: To adjust the auto syphon height within the cistern, add a second
locking nut to the inside of the cistern and wind second nut up or down.
Adjust the height of the syphon so that the flush triggering level remains
below the level of the cistern overflow pipe.
An air gap must always remain between the cistern water level and the inlet
water pipe level, to prevent backflow.
Airbreak Installation
The air break must be fitted in a vertical position. Fitting in a position other
than vertical will result in leakage.
Fit the air break to the top of the urinal sparge pipe (in place of a cistern), as
shown in the diagram.
Do not use sealing tape in the joints. Both the air break and the latching
valve use compression connections fittings. Sealing tape is not required.
Supply and install a half-inch pipe from the top of the air break, to the outlet
side of the latching valve.
Securely fix the piping to the wall as per AS/NZS3500 to prevent possible
tampering and vandalism.
Adjust the timing of the flush to ensure an adequate flush, by setting the
flush cycle switches on the sensor (see page 9).
Restrictor installation:
Fit the Restrictaflow between the tap and the latching valve (see below). The
Restrictaflow must be connected to the valve port
marked IN.
Latching valve
IN
OUT
Water level
Auto syphon
Outlet hole Sparge pipe
Overflow pipe
Air gap
Latching valve
Air break fitting
Sparge pipe
Must be vertical
Water Flow
water flow
water flow
Restrictaflow
outlet to airbreak Flow
From stop valve
NOTE: The valve must be in-
stalled with the INLET and OUTLET
ports oriented with the water flow
(as shown above). The valve body
is marked IN and OUT. Incorrect
assembly will result in damage to
the diaphragm.

Page 6 of 12 Zip FlushMaster Pearl Installation & Maintenance Instructions - 82902 - January 2012 v1.00
Install Sensor
Position the ceiling sensor not more than 500 mm from the urinal wall. Sensor coverage from a 2700 mm ceiling is
approximately 2400 x 3600 mm.
For a single stall urinal, position the sensor above the centre of the stall. Position the sensor slots at right angles to the
urinal wall.
For a double stall urinal, position the sensor midway between the stalls. Position the sensor slots at right angles to the
urinal wall.
For a triple stall urinal, position the sensor above the centre of all three stalls. Position the sensor slots parallel to the
urinal wall. For more than three stalls, use additional sensors.
Warning. Do not connect battery or power pack until all plumbing connections are completed. The power must be
connected last as connection activates the system test mode (see page 8).
To install a ceiling recessed sensor:
WS004 and 99168, will require a 64 mm diameter hole in the ceiling.
WS003; WS006 and WS007 will require a 105mm diameter hole in the ceiling
Use inbuilt clips to fasten sensor housing in place when inserted into hole. (see diag below)
Typical Installation with Ceiling Resessed Sensor
Urinal wall
surface
2400 mm
< 500 mm
Two or three
Stalls
3600 mm
1800 mm
3600 mm
Urinal wall
surface
< 500 mm
Ceiling
Sensor
Sensor
Slots
Ceiling
Sensor
Sensor
Slots
2400 mm
1200 mm
One or Two
Stalls
BB
A
A
AA
Step 1. Insert sensor with clips ‘A’
in the upright position
Step 2 . Ensure clips ‘A’ are in
the folded down position

Zip FlushMaster Pearl Installation & Maintenance Instructions - 82902 - January 2012 v1.00 Page 7 of 12
Connect Latching Valve Cable
Run the latching valve cable to the sensor in conduit or within the building wall
and ceiling.
Do not extend the cable as this will affect correct operation.
Locate plug on cable from the latching valve and detach it from circuit board.
The plug should be lifted directly upwards.
Fasten the latching valve cable to the plug on the circuit board by first
removing the plug from the board. Lift plug directly upwards and hold plug so
fixing screws are facing you.
Secure the brown cable into the right hand screw terminal and tighten.
Secure the blue cable into the left hand screw terminal and tighten.
Push the plug into the socket on the circuit board, positioned so screws face
towards the centre of the board.
Finally, insert the cable from the battery pack into the circuit board inlet
socket.
Once the power is connected, the system operates in test mode.
Ceiling Recessed Sensor
Thread 150 mm of cable through the cable gland
in the ceiling sensor lid, before making the final
connection
BLUE
WIRE BROWN
WIRE Orientate plug to inlet
socket with care
Cable from
latching valve
Battery holder
Cable gland
(Supplied)
Orientate plug from
power to circuit board
inlet socket
Delay button
Fill button
Solenoid valve connection
Battery/ power connection - 6VDC

Page 8 of 12 Zip FlushMaster Pearl Installation & Maintenance Instructions - 82902 - January 2012 v1.00
Set Flush Timing
FlushMaster WS003 ; WS004 ; WS006 ; WS007 and 99168 sensors:
On application of the power, the board closes the valve and defaults to the
preset settings. It waits for aproximately 2 minutes before starting to sense if
anyone is present. On detection of a user, the LED on the front of the sensor
will flash.
Preset Values
The FlushMaster Pearl board is shipped with the following Preset Values:
Janitorial Flush: Set at 12 Hours
Delay Time: Set at 45 seconds
Fill Time: Set at aprox 5 seconds.
Connect Optional Power Pack
AC Power Pack product code 99031:
Locate battery holder and battery supplied with the system.
If connected, remove the battery cable plug from the circuit board.
Connect power pack to 220-240 volt 10 amp AC power point.
Carefully align the power pack outlet cable plug to circuit board inlet socket.
Firmly insert the cable plug from the power pack into the inlet socket. See
diagram on page 7.
Connect to
circuit board
Fixing
bracket
(supplied)
Connect to
power point
Fill button
Delay button

Zip FlushMaster Pearl Installation & Maintenance Instructions - 82902 - January 2012 v1.00 Page 9 of 12
Set Flush Timing continued
NOTE: Orient the PCB so the switches are positioned on the left hand side as
you look at it. This is critical for correct setup.
Setting Fill Time
The board will continue to run the preset defaults until the values have been
setup. The values can be set individually at any time except whilst the unit is
filling the cistern.
To set the Fill Time, the installer pushes the lower left hand button once to
activate the “Fill” light. Once the light is visable, push the button again and it
will flash, each flash represents approximately one second of “fill time”. When
the required amount of water has been dispensed, push the lower left hand
button again to shut the valve. Fill time is now set.
If the installer does not press the Fill Switch again, the counting will stop after
15 minutes and the Fill Time set to 15 Minutes.
Setting Delay Time
To set Delay TIme, push and hold the upper Delay button for approximately 2
seconds until the green Delay LED comes on (as shown).
Push the button again and the light will change from Green to Red as shown,
repeat this as many times as required for Delay TIme. Each push of the button
ads 45 seconds Delay, up to a maximum of 30 minutes and changes the LED’s
from Green to Red to Green.
Valve Override
Once the unit has been set up, it is possible to open the valve using a
straightened paper clip. Simply push the paper clip through the smallest
hole on the face of the unit, and the micro switch will be triggered. This will
automatically open the valve for the preset time.
On completion, fit the sensor lid to the mounting box by pushing it on tight.
Fit sensor to the ceiling and wipe clean the outer surfaces. In the case of a
surface mount sensor, ensure the body is securely fixed to the ceiling surface,
then fit the cover by tightening the 4 fixing screws.
NOTE:
The FlushMaster goes through a “re-charge” for approximately 1 minute after
completing a cycle, during this time the sensor remains dormant and will only
target a user once recharge is complete.
Completing Installation
Fill button
Delay button
Fill -LED pulses when fill
button is held down
Delay - LED
Green
LED’s Change from Green to
Red to Green
Delay - LED
Red
Each press of
the Delay button
will change the
LED colour.
Each change
adds a 45 sec.
delay

Page 10 of 12 Zip FlushMaster Pearl Installation & Maintenance Instructions - 82902 - January 2012 v1.00
Maintenance Instructions
Cleaning
Keep the slot openings in the face of the sensor clear of dirt.
Never clean the case with strong or abrasive cleaners.
Wipe with a soft cloth, warm water and dish washing liquid.
Never hose or spray any part of the flushing system.
Where the Zip FlushMaster is powered by a long life lithium battery a life of up
to three years can be anticipated depending on frequency of activation.
However to avoid the inconvenience associated with any malfunction of the
flushing system, it is recommended that both the battery and the latching valve
diaphragm be replaced annually.
Where the optional power pack is fitted, the power must be turned off at the
power point before any form of maintenance is attempted.
Battery Replacement
Remove protective cover from sensor housing, locate battery holder.
Remove cover from battery holder and remove existing battery.
Replace existing battery with lithium cell type CRP2 / 223A only (Zip product
code 90098). Reset the Fill and Delay times (see notes on page 8 and 9).
Replace cover on battery holder and replace cover on sensor housing.
Battery low
When the battery voltage becomes low, the detection LED on front of unit
will flash both Green and Red (as shown). This will continue until there is not
enough power to open and close the valve. At this point the valve will close
and the detection LED will only flash Red (as shown). At this stage the battery
must be changed.
Valve Diaphragm Replacement
Isolate the water supply.
Remove fixing clip on top of latching valve coil by levering up clip with screw
driver and clicking back until clip releases from shaft.
Lift coil, spring clip and spacer from latching valve shaft.
Carefully undo the 4 screws retaining the valve housing. When the last screw
is about to be released, grip the valve body and top section as it is spring
loaded.
Carefully separate the top section containing the spring and plungers from the
lower body. The diaphragm should now be visible. Lift it out of position.
Remove the centre plastic piece from the rubber diaphram. Fit the new
diaphram to the plastic centre. Replace it in the same orientation.
Re-assemble in the reverse of above. Note the position of all parts in the
diaphragm for correct assembly. To order quote Zip part number 90279
Diaphram Kit.
Replacement
rubber for
diaphragm
LED

Zip FlushMaster Pearl Installation & Maintenance Instructions - 82902 - January 2012 v1.00 Page 11 of 12
Problem Solving
Symptoms Possible Causes Suggested Action
Cistern Does not fill or direct inject
does not flush.
Water supply turned off.
Latching valve flow regulator full on.
Latching valve installed backwards.
Latching valve cable damaged or
latching cable unplugged.
Latching valve faulty.
Sensor not activating.
Check water supply, turn on tap.
Back off regulator screw.
Reinstall latching valve correctly.
Check cable and replug into sensor
circuit board.
Replace latching valve.
Check sensor as below.
Cistern under fills, or direct inject
flushes too long.
Sensor duration time set incorrectly.
Latching valve flow regulator on.
Reset sensor timer switches.
Cistern over fills, or direct inject
flushes for only 5 seconds at a time.
Sensor duration time set incorrectly.
Latching valve flow regulator off.
Reset sensor timer switches.
Cistern fills or direct inject flushes for
only 5 seconds at a time.
Sensor timers set to test mode. Reset sensor timer switches.
Cistern fills or direct inject flushes for
only 35 seconds at a time.
Sensor timers set to test mode and
latching valve cable wires crossed.
Reset sensor timer switches
and uncross latching valve wire
connection.
Cistern fills or direct inject flushes
continually except for time set as
duration ‘on’ period.
Sensor cable wires crossed. Uncross latching wire connection.
Cistern continues to fill during and
after having just flushed.
Sensor duration time set incorrectly.
Sensor timing out of sync with fill.
Reset sensor timer switches.
Empty cistern, then restart timing.
Flushing will not stop. False activation.
Sensor not activating.
Check for sensor vibration.
Check sensor as below.
Sensor not activating. Battery flat.
Power turned off.
Sensor fuse blown.
Lens slot blocked.
Not detecting users.
Faulty sensor.
Replace battery.
Check Powerpack, turn on power.
Replace fuse on circuit board.
Clean lens slots.
Reposition sensor appropriately.
Replace sensor.

Zip FlushMaster Pearl Installation & Maintenance Instructions - 82902 - January 2012 v1.00 Page 12 of 12
Contact Details
Head Office
Zip Heaters (Aust) Pty. Ltd.
ABN 46 000 578 727
67 Allingham Street
Condell Park NSW 2200
Postal: Locked Bag 80
Bankstown 1885 Australia
Website: www.zipheaters.com
Facsimile: [phone]
Telephone: [phone]
Free Call:1 800 638 633
IPG Z 103
As Zip policy is one of continuous product improvement, changes to
specifications may be made without prior notice. Images in this booklet have
been modified and may not be true representations of the finished goods.
