Zip HydroTap G4 User manual

801621 - B, BA, BHA, BAHA, - HydroTap User Guide - July 2015 - V2.00 Page 1 of 24
ZIP HydroTap G4
User Guide
®
• Tap Operation...................(Pages 2-9)
• LCD Screen & Menu .......(Pages 10-21)
• Maintenance.................... (Page 21-22)
• Menu Icons.......................(Page 23)
Date of Installation............/........./.........
Affix Model Number Label
Here
801621
B & BA
Comm.
Models

Page 2 of 24 801621 - B, BA, BHA, BAHA, - HydroTap User Guide - July 2015 - V2.00
Tap safety - Boiling Ambient
The safety lock feature is provided to prevent boiling water flowing if the hot
lever is inadvertently operated.
This function can be activated and deactivated from either the Tap top levers
or from the touch screen display (Located on the unit in the cupboard). In or-
der to be able to change the safety lock settings, using the tap top levers, The
control panel settings must first be set to YES (allow safety settings change).
HydroTap Classic
B
C
A
To activate the safety
using the tap top levers
(Classic, Elite & AIO)
After selecting to allow the safety setting
from the menu screen. Place a finger on
the safety lock, then depress the Classic
Blue Ambient lever or touch the Elite Blue/
Ambient Button, while keeping both fingers
in position for more than ten seconds.The
Classic safety lock indicator light will now
be illuminated or the Elite lights will flash,
momentarily.
To deactivate the safety
using the tap top levers
(Classic, Elite & AIO)
First place a finger on the safety lock, then
depress the Classic Blue/Ambient lever or
touch the Elite Blue/Ambient Button, while
keeping both fingers in position for more
than ten seconds. The Classic safety lock
indicator light will now extinguish or the Elite
lights will flash, momentarily.
To control the safety
(From the touch screen):
(see page 20)
For Hot Isolation:
Not for HydroTap Arc/Cube, (see page 20)
Elite Tap
To allow the safety setting to be changed
using the tap top levers: (Classic, Elite & AIO)
1. Press [MENU] button for main
menu.
2. Press [Setting] button.
3. Press [Safety] button.
4. Press button - YES / NO
to allow or disallow the safety
setting to be changed on the
tap.
Note: The Factory setting is set at YES
Ambient lever
A

801621 - B, BA, BHA, BAHA, - HydroTap User Guide - July 2015- V2.00 Page 3 of 24
Tap Safety - Boiling Models
B
Boiling Models (Classic, Elite & AIO)
To set the safety using the touch screen:
1. Press the [MENU] button for
main menu.
2. Press the [Setting] button.
3. Press the [Safety] button.
4. Press button to Enable /
Disable, the safety lock feature
on the tap.
B
On Boiling Only models the safety lock feature is provided to prevent boiling
water flowing if any of the Classic hot levers or Elite buttons are inadvertently
operated.
The Safety Lock button on the tap can only be Disabled or Enabled from the
LCD touch screen (Located on the unit in the cupboard). When Disabled, no
water will be dispensed from the Boiling Hydrotap.
For HydroTap ARC/CUBE:
(Boiling Ambient and Boiling models)
The safety on the tap, can only be Disabled or Enabled from the LCD touch
screen (Located on the unit in the cupboard).
Light intensity varies from site to site, therefore it is recommended that a
re-calibration be performed at the time of the installation.
All direct natural sun light must be shaded from the HydroTap, during the
calibration. This can be achieved by closing any nearby curtains, blinds, etc.
or by shading the tap with a dark cloth.
Safety Sensor Calibration (lever models)
Pull both levers forward
Safety
sensor
1. With the unit in Normal operating mode
and with the safety enabled
2. Turn the power OFF
3. Pull both tap levers to the forward
position
4. Turn ON the power
5. The unit will calibrate the safety switch
6. Return the levers to the neutral
position.
7. To check the calibration, dispense Boiling water, in normal light
conditions with the safety enabled.

Page 4 of 24 801621 - B, BA, BHA, BAHA, - HydroTap User Guide - July 2015 - V2.00
Elite Tap:
The Elite tap uses touch
sensitive controls, to dispense
Boiling, and Ambient water.
When operating the tap,
ensure the touch surface is dry
as moisture may interfere with
the sensor touch control.
The safety lock can be con-
trolled from either the tap or
from the touch screen display
in the same way as the Classic
tap (See page 2)
Boiling Button Ambient Button
Safety Lock
3. Tap functions
All-In-One Tap:
The top of the All-In-One tap is operated the same as a Classic HydroTap.
The two levers are used for
dispensing Boiling and Ambient
water. The safety button operating
in the same way as on the
HydroTap.
The Mixer tap lever is operated
as a classic ‘Flick Mixer’. The hot
side is marked with a red mark
and the cold side with a blue
mark, for dispensing cold to warm
water.
Lifting the handle up will decrease
the flow rate and lowering the
handle will increase the flow rate.
Lift the handle all the way up to
turn the tap off.
When the handle is moved
towards the blue mark, the temperature is decreased and when moved
towards the red mark, the temperature is increased. The final temperature
will be dependant on the temperature of the incoming cold water.
For convenience, the spout may be swivelled, left or right through 120°.
NOTE:
The safety switch is always active
on Boiling Only models

801621 - B, BA, BHA, BAHA, - HydroTap User Guide - July 2015- V2.00 Page 5 of 24
3. Tap functions
MixerTap:
Lifting the handle up will
decrease the flow rate and
lowering the handle will
increase the flow rate. Raise
the handle all the way up to
turn the tap off.
When the handle is moved
towards the BLUE mark, the
temperature is decreased
and when moved towards the
RED mark, the temperature
is increased. The final
temperature will depend
on the temperature of the
incoming cold water.
On powerup, wait 30 secs.
for the unit to calibrate itself.
Tapping the select button will
allow the choice of Boiling
(RED) with safety or Ambient
(BLUE) water modes. The
Arc/Cube control may be
rotated in a forward or reverse
direction to dispense Boiling
or Ambient water.
The rotary control is spring
loaded in the anticlockwise
direction and when released,
will return to the OFF position.
When rotated clockwise the
tap operates in a “Pot fill”
mode. Water will flow from
between 5 and 15 seconds
(This is user adjustable). To
reset, return the handle to
the “Off” position and repeat
the step. The lever has to be
manually returned to the “Off” position.
After activating the Boiling mode, all the lights will flash for 2 seconds, during
which time you may dispense water. When the rotary control is returned to the
Off position the light will continue to flash for an additional 3 seconds, allowing
you to dispense more water.
When unattended, the control light will automatically default to the Ambient(-
BLUE) mode after 30 seconds.
Rotary control
Select Button
Safety Lock
HydroTap Arc/Cube:

Page 6 of 24 801621 - B, BA, BHA, BAHA, - HydroTap User Guide - July 2015 - V2.00
3. Tap operation
To dispense boiling water: (With the safety OFF)
HydroTap Classic:
Depressing the Red lever allows the
dispensing of boiling water.
Pulling forward the Red lever allows the
tap to operate in a “no-touch” mode.
Water will flow from between 5 and 15
seconds (This is user adjustable).
To reset, return the handle to the “Off”
position and repeat the step. The lever
has to be manually returned to the “Off”
position.
Elite Tap:
Touching the boiling button allows the
dispensing of boiling water.
HydroTap Arc/Cube:
If not showing RED, tap the select button until
the indicator light turns RED.
Rotating the control, when the indicator light is
RED, allows the dispensing of boiling water.
Press or pull lever
Elite Tap
To dispense Boiling
water: (With the safety ON)
HydroTap Classic:
Depress the Red lever, while
simultaneously covering the safety lock
button with a second finger. These two
actions need to occur within 2 seconds
for the successful dispensing of boiling
water.
Elite Tap:
Place a finger on the safety lock, then
touch the boiling button, while keeping
both fingers in position.
HydroTap Arc/Cube:
First tap the select button until the
indicator light turns RED. Then tap the
safety button twice until the RED light
flashes (This will flash for aprox 1-3
seconds if no water is being dispensed).
Boiling water may be dispensed by
rotating the control while the RED light
is flashing.
Safety Lock
Indicator
light
Arc/Cube Tap
Classic Tap

801621 - B, BA, BHA, BAHA, - HydroTap User Guide - July 2015- V2.00 Page 7 of 24
HydroTap Classic:
Depressing the Blue lever allows the
dispensing of Ambient water.
Pulling forward the Blue lever allows the
tap to operate in a “no-touch” mode.
Water will flow from between 5 and 15
seconds (This is user adjustable).
To reset, return the lever to the “Off”
position and repeat the step. The lever
has to be manually returned to the “Off”
position.
Elite Tap:
Touching the Ambient button allows the
dispensing of Ambient water.
HydroTap Arc/Cube:
If not showing Blue, tap the select button
until the indicator light turns Blue.
Rotating the control, when the indicator
light is Blue, allows the dispensing of
Ambient water.
Press or pull lever
Select
button
Indicator
light
Arc/Cube Tap
Classic Tap
Ambient button
3. Tap operation
To dispense Ambient water:

Page 8 of 24 801621 - B, BA, BHA, BAHA, - HydroTap User Guide - July 2015 - V2.00
Filter lights
Filter LightRed Light
Filter light
Filter light: Classic & Elite
Filter Change Light Off:
This indicates the filter is operating within its
normal specified lifespan.
Filter Change light flashing slowly:
The light will flash slowly when the filter is due
for replacement and the LCD will show “Filter
Change”. Refer to “Replacing the filter” in
section ‘C’ of this document.
HydroTap Arc/Cube
Flashing filter lights:
All three tap lights (Safety; Select and
Indicator light) will flash every
10 seconds, indicating a Filter change
is required.
Turn filter light OFF:
(All models)
Refer to “Filter Reset” in section ‘C’
of this document.
Safety Light
Indicator
light
Select light
Elite Tap
Classic Tap

801621 - B, BA, BHA, BAHA, - HydroTap User Guide - July 2015- V2.00 Page 9 of 24
3. Tap Lights
Blue Lights
Blue Ambient water
Lights:
(Not available on Elite)
On all the time:
This indicates that the Ambient water
is ready.
Red Lights
Red Boiling Water Light
(All)
On all the time:
This indicates that the boiling water is
ready.
Flashing slowly:
This indicates that the boiling water is
below the desired temperature.
Wait for the light to stop flashing
before dispensing water. The flashing
light will typically occur after switching
on, or coming out of sleep mode.
Filter LightRed Light
Warning: (All)
Flashing warning light:
When the indicator light flashes fast and
continuous, a system fault has occurred.
Check for details on the faults screen. If
unable to rectify, call a qualified service
agent.

Page 10 of 24 801621 - B, BA, BHA, BAHA, - HydroTap User Guide - July 2015 - V2.00
Note: When selecting Menu options, the screen will revert to the main menu,
if the screen remains inactive for a period, in excess of 10 seconds.
Zip HydroTap introduces a ‘TOUCH’ screen for easy setup and operation
adjustment. See page 23 for icon details.
Other possible messages in status window:
**Status Information Notes
Safety OFF Product is in normal operation
mode
-
Safety ON Safety lock is activated Refer to section
G - safety
System Fault Product has one or more system
faults
Refer to section B
Sleep Mode System is in sleep mode. Boiling
water or hot water is not available.
Refer to section
G - Energy mode
Change Filter External/Internal filter needs to be
replaced
Refer to section C
System Off System off in off mode. No boiling
water or chilled water available.
Refer to section
G - Energy mode
Hot Isolated Hot isolation has been activated.
Boiling water or hot water is not
available.
Refer to section
G - Safety
3LCD Screen

801621 - B, BA, BHA, BAHA, - HydroTap User Guide - July 2015- V2.00 Page 11 of 24
3LCD Screen Menu
Main Menu Sub Menu Sub Menu Options Section
Language
• English
• Deutsch
A
• Product Info
• System Faults
• Event Log
• Product serial No.
• Lists
B
Information
Installation
• Filter Flush
• Filter Reset
• Boiling Calibration
• Booster
• Lux sensor
calibration
• Reset options
• Calibration
options
C
Service Password protected
D
Security
• Enable Password
• Set Password
• Change Password
E
Communication
• Remote Monitor
• Remote Control
• Wifi Options
• Wifi Options
F
Settings
• Date/Time
• Temperature
• Filter
• Energy Modes
• Safety
• Dispense Times
• 12hr/24hr Mode
• Hot/Cold Setpoint
• Filter Life (Litres)
• Filter Life
(Months)
• Sleep Mode
Options
• Safety Lock
• Hot Isolation
• Hot/Cold
Dispensing
G

Page 12 of 24 801621 - B, BA, BHA, BAHA, - HydroTap User Guide - July 2015 - V2.00
A Set Language
B System Information
In this section, you can find your product serial number , check system fault
messages or view the event logs of your product.
LCD Screen operation - Section A
LCD Screen operation - Section B
1. Press [Product Info] to view the
current product information.
2. Press [<=] button for the previous
menu or press [Home] button to
return to the home screen.
1. Press [System Faults] to check the
faulty information;
2. Press [<=] button for the previous
menu or press
[Home] button to return to the
home screen.
1. Press [Filter Log] to view the
system’s filter logs
2. Press [<=] button for the previous
menu or press [Home] button to
return to the home screen.
1. Press the [MENU] button for main
menu.
2. Press the [Info] button to view the
product serial number and other
key information
1. Press [MENU] for main menu.
2. Press [Language] button.
3. Select the country to change the
language
4. Press [<=] button for the previous
menu

801621 - B, BA, BHA, BAHA, - HydroTap User Guide - July 2015- V2.00 Page 13 of 24
LCD Screen operation - Section C
C Install
Have a 10L bucket or similar container (not supplied) at the ready to hold
a quantity of water that will be ejected while the Filter Flush Mode is in
operation. Open the filter access door on the front of the HydroTap and the
filter cartridge will be exposed. Located to the rear RHS of the cartridge is a
flush line, approx 600mm long and the flush line stop cock. Place the valve
end of the flush line into the bucket or container.
Once your Zip HydroTap G4 unit has been installed, Go to Install menu to
configure the system settings for your product.
1 - Filter Flush
Note: Run at least 10 Litres
of water through to flush the
filter of any excess black carbon
particles (this is normal). Once
the filter flush has finished,
press the Stop button to display
the main menu
Sub menu:
1. - Filter Flush
2. - Filter Reset
3. - Boiling Calibration
4. - Booster
5. - Lux Sensor Calibration
OPEN
Position
CLOSED
Position
ON
OFF
1. Press [MENU] button for main
menu.
2. Press [Install] button. Turn the stop
cock ON.
3. Press [Filter Flush] button.
4. Press [Start] button to start filter
flush. Once the filter flush is
finished, Turn the stop cock OFF
first (to ensure the cock is properly
closed) then press [Stop] to end
filter flush mode.
5. Press [<=] button for the previous
menu or press [Home] button to
return to the home screen.
6. After initial installation, Turning
OFF the Filter Flush Mode puts the
HydroTap into calibration mode.
With subsequent filter changes, the
system reverts to the main menu.
The Zip HydroTap allows the user to adjust the filter life and to edit the filter
usage. (See filter details on Page 17 ).

Page 14 of 24 801621 - B, BA, BHA, BAHA, - HydroTap User Guide - July 2015 - V2.00
After replacing the filter, the counters should be reset
1. Press the [MENU] button for main
menu.
2. Press the [Install] button.
3. Press the [Hot Calibration] button.
4. In the next screen, press [Calibrate] if
you want to start calibration.
Boiling Calibration Screen
3. - Boiling Calibration
1. Press the [MENU] button for main
menu.
2. Press the [Install] button.
3. Press the [Booster] button.
4. If a Booster is installed, select YES to
enable the Booster.
5. Dispense boiling water for 30 secs
and check the outlet hose from the
Booster is warm.
6. Otherwise select NO, if no Booster is
installed
This function should only be considered when a Booster unit is installed.
G4 HydroTap Booster Screen
4. - Booster
Note: Failing to make the correct selection for ‘Booster’ will effect product
performance.
2. - Filter Reset
LCD Screen operation - Section C
1. Press the [MENU] button for main
menu.
2. Press the [Install] button.
3. Press the [Filter Reset] button.
4. To set the filter life or edit filter
usage, refer to section G- Filter.
On start up, the Zip HydroTap starts a self-calibration program. The controls
take the system through the calibration process. Once complete, the system
reverts back to normal operation. If you would like to calibrate the system
anytime after initial installation, please follow the steps below.
Caution: During calibration, boiling water units may vent steam from the
tap spout. Take care to avoid personal injury whenever this occurs.

801621 - B, BA, BHA, BAHA, - HydroTap User Guide - July 2015- V2.00 Page 15 of 24
LCD Screen operation - Section D
E Security
The Zip HydroTap G4 allows the appliance coordinator to set up a password
to protect against users changing the preferred system settings.
To set a password
1. Press the [MENU] button for main
menu.
2. Press the [Security] button.
3. Press [Change Password}
4. Enter a 4 digit password
To change a password
1. Press the [MENU] button for main
menu.
2. Press the [Security] button.
3. Press [Change Password}
4. Enter your old 4 digit password
5. Then enter your new 4 digit
password. You will need to
enter your password to access
the settings screen. If you have
forgotten the password, please
disconnect the power and restart
your HydroTap unit.
This section is reserved for service technicians only
Note: In Australia call a licensed electrician, plumber,or Zip office on
1800-638-633, for assistance, service, spare parts, or enquiries.
D Service
5 - Lux Sensor Calibration
NOTE: Conduct calibration under normal light conditions
1. Press [MENU] button for main menu.
2. Press [Install] button.
3. Press [Lux Sensor Calibration]
button.
4. The lights on the Tap head will flash
to confirm calibration.
5. Check for correct tap operation by
selecting ‘Lux Sensor-> OFF’. When the room is darkened (below the
calibrated light level), the tap lights will turn OFF after aprox 30 seconds.

Page 16 of 24 801621 - B, BA, BHA, BAHA, - HydroTap User Guide - July 2015 - V2.00
F Communication (when available)
The Zip HydroTap G4 allows the user to use wifi or Bluetooth to operate the
product remotely.
Not yet available
G Settings
3. LCD Screen operation - Section G g Instructions
LCD Screen operation - Section F
1. Press the [MENU] button for main
menu.
2. Press the [Settings] button.
3. Press [Enable Password].
4. Then enter your 4-digit password.
You will need to enter your
password to access the settings
screens. If you have forgotten the
password, please disconnect the
power and restart your HydroTap
unit.
1. Press [MENU] button for main
menu.
2. Press [Setting] button.
3. Press [Date/Time] button.
4. Select 12 hour mode or 24 hour
mode. The selected mode will be
displayed in dark grey colour with a
tick box on the right.
5. Press [NEXT] button to set time.
G4 HydroTap Set
Date/Time Screen
Set Date / Time
1. Select individually the hour, minutes
and day and adjust using the up
and down arrows.
2. Select individually the date, month
and year and adjust using the up
and down arrows.
3. Press [HOME] to return to the
Home screen.

801621 - B, BA, BHA, BAHA, - HydroTap User Guide - July 2015- V2.00 Page 17 of 24
3. LCD Screen operation - Section G tions
1. Press the [MENU] button for main
menu.
2. Press the [Temperature] button.
3. To adjust the temperature, press
the relevant temperature button and
then use the up and down arrows.
Zip HydroTaps are designed to operate within 1ºC to 2ºC of set point for
boiling water. All boiling water units are self calibrating to 98ºC, which is the
recommended setting. Adjustments to the 98ºC setting are not recommended
however, under certain circumstances adjustments may be made between
68º - 100ºC. It should be noted that a 6% energy saving in standby power
can be achieved when the 98ºC setting is selected over the 100ºC setting.
Furthermore, the 100ºC setting is not recommended as the delivery rate of
water may be affected.
Set Temperature
Filter
To edit the filter life:
1. Press [MENU] button for main
menu.
2. Press [Setting] button.
3. Press [Filter] button.
4. Press [Filter Life] button, for
Internal or External filter.
5. To change filter life, first select
filter life (Litres) or filter life (Months),
then adjust using the up or down arrows.
Note:
Filter Life increases in 500 litre
increments to a maximum of 10000
litres. Factory set at 6000 litres.
Zip HydroTap G4 allows the user to adjust filter life and edit filter usage.
Note: The filter life may be set as a
function of Litres used, or in months
from the filter change. When the first of
these functions is reached (i.e. Litres or
months expired), the filter warning light
will be illuminated on the tap.
Either of these functions may be
disabled (See below).

Page 18 of 24 801621 - B, BA, BHA, BAHA, - HydroTap User Guide - July 2015 - V2.00
To edit the filter usage:
This function is to reset the Filter
Change display after a filter has reached
the end of its life (refer to “Replace
Filter Instructions” section of this
document).
1. Press the [MENU] button for main
menu.
2. Press the [Setting] button.
3. Press the [Filter] button.
4. Press the [Edit Filter] button for
Internal or External filter.
5. To edit, select Edit Usage(Litres) or
Edit Usage (Months), then adjust
using the up or down arrows.
3. LCD Screen operation - Section G
This mode allows the HydroTap to Go into Energy Saving mode. There are
two options available: ‘Sleep’ mode and ‘ON/OFF’ mode.
To activate the sleep mode:
1. Press [MENU] button for main
menu.
2. Press [Setting] button.
3. Press [Energy Modes] button.
4. Press [Sleep Modes] button then in
the next screen, use the up and down
arrows to select one of the 7 options, as
shown in the table below.
Energy Modes
In Sleep Mode the unit will Go to “Sleep” after a 2hr period of inactivity.
The Boiling water will gradually drop to either 68°C or room temp, as shown
in the table below and the Chilled water will be ON or OFF.
When the period of inactivity passes, the home screen status window will
show “Sleep Mode”.
Sleep Mode Light
Level
Time
Delay State Boiler Chiller
2 Hours-> 68°C N/A 2 Hr Sleep 68°C ON
2 Hours-> OFF N/A 2 Hr OFF OFF OFF
Lux Sensor->68°C Dark N/A Sleep 68°C ON
Lux Sensor-> OFF Dark N/A OFF OFF OFF
Lux or 2 Hr-> 68°C Dark 2 Hr Sleep 68°C ON
Lux or 2 Hr-> OFF Dark 2 Hr OFF OFF OFF
Disable N/A N/A ON ON ON

801621 - B, BA, BHA, BAHA, - HydroTap User Guide - July 2015- V2.00 Page 19 of 24
LCD Screen operation - Section G
Lux (Light) Sensor Calibration: (Not for Elite tap)
It is recommended to recalibrate the Lux (Light) Sensor after selecting any of
the 4 Lux sensor options from the sleep mode menu. Before commencing,
ensure there are ‘Normal to Dim’ (Not Dark) operating light conditions.
1. Press Group 1 or Group 2 option
2. Press button to enable / disable
group set. When the enable box is
ticked, this allows each individual
day to have an “On/Off” time.
3. Press [ON/OFF Modes] button, to
set up ON/OFF time.
4. When in Group 2 Press [NEXT] to
select Sat-Sun options
This screen allows you to select the
individual days for programming.
Only one ON /OFF period is allowed
for each day.
Individual days set screen
Group set screen
A
A
Note: Any attempt, during OFF mode, to dispense water, will bring the unit
out of energy mode. The system will revert to the energy mode setting after
30 minutes of non use.
Note: Any attempt, during OFF mode, to dispense water, will bring the unit
out of sleep mode. The unit will return to sleep mode after 2 hours of non
use. Please allow sufficient time for the water to reach the set temperature
after disabling the sleep mode.
1. Press the [MENU] button for main
menu.
2. Press the [Setting] button.
3. If required, Enter your 4 digit
password
4. Press the [Energy Modes] button.
5. Select ‘Individual set’ if you wish
to allocate a specific time for each
day.
6. Select ‘group set 1’ if you wish to
allocate the same time to all 7 days
7. Select ‘Group set 2’ if you wish
to allocate the same time to the
5 working days (Mon-Fri) and
additional times for (Sat-Sun).
In ON / OFF Mode the user may turn the unit ON or OFF at specific times
for individual days or alternatively by weekly and/or weekend settings.
To activate ON/OFF mode:

Page 20 of 24 801621 - B, BA, BHA, BAHA, - HydroTap User Guide - July 2015 - V2.00
Hot Isolation: (Not available for HydroTap Arc/Cube) *
The HydroTap is equipped with a safety mode that allows for additional
safety protection, if needed.
When activated, the HOT Isolation mode will override the settings to ensure
Boiling water is not dispensed.
Safety
LCD Screen operation - Section G
Boiling Only Models
To set the safety using the touch screen:
1. Press the [MENU] button for
main menu.
2. Press the [Setting] button.
3. Press the [Safety] button.
4. Press button to Enable /
Disable, the safety lock feature
on the tap.
NOTE: When Disabled, boiling water may be dispensed from the Hydrotap
by pressing a Red lever.
B
B
Note: *Hot Isolation - Not available for the HydroTap Arc/Cube Tap.
Do not enable this function for the HydroTap Arc/Cube.
Boiling Ambient Models
To allow the safety setting to be changed using the tap top
levers: (Classic, Elite & AIO)
1. Press the [MENU] button for
main menu.
2. Press the [Setting] button.
3. Press the [Safety] button.
4. Press button to allow the
safety setting to be changed
on the tap.
To Enable or Disable the safety on the tap
5. Press button to select Enable / Disable
A
B
C
A
B
*
