Zip HydroTap BCS Series User manual

802265US v1.27 06.21 BCS, BCS100-75 Install Instructions Page 1 of 36
BCS100/75 and BCS Series
Zip HydroTap
Installation and Operating Instructions
®
Scan QR Code to download the latest version of this document.
English French

Page 2 of 36 802265US v1.27 06.21 BCS, BCS100-75 Install Instructions
Faucet options
The HydroTap appliance series offers a range of interchangeable faucets to suit the customer’s needs. For
ease of installation, it is recommended to fit the faucet before installing the Command Center.
The installation procedure for each of the faucets is detailed in the Faucet Installation instruction book
supplied with the faucet.
For all operational features of the HydroTap, please refer to the User Guide.
Classic Arc Cube Wave
Faucet options
The Celsius All-In-One Arc faucet may be used to provide
instant boiling water together with mixed hot and cold
water from the mains supply.
Celsius All-In-One Arc

802265US v1.27 06.21 BCS, BCS100-75 Install Instructions Page 3 of 36
HydroTap Specifications
Installation Checklist .................................................................................................................... 4
General Product Features............................................................................................................ 5
Important Safety Instructions ....................................................................................................... 6
Warnings and Regulatory Information.......................................................................................... 7
Major Components and Accessories ........................................................................................... 8
Technical Specification ................................................................................................................ 9
Before Installation and Site Requirements................................................................................... 10
Installation Procedure
STEP 1 - Fit the faucet to the benchtop or sink, before installing the Command Center.
(Refer to the Faucet Installation instruction book)
STEP 2 - Check for adequate ventilation
Section 2 - Ventilation
2.1 - Ventilation for All Models .......................................................................................... 11
2.2 - Cabinet Air Circulation .............................................................................................. 12
STEP 3 - Fit the CO2Gas cylinder
Section 3 - CO2Cylinder
3.1 - Secure the cylinder cradle ........................................................................................ 14
3.2 - Connect the regulator ............................................................................................... 14
3.3 - Connect the gas hose............................................................................................... 14
3.4 - Test for gas leaks...................................................................................................... 14
STEP 4 - Install the Command Center
Section 4 - Command Center installation
4.1 - Electrical power supply ............................................................................................. 16
4.2 - External filter bypass valve ....................................................................................... 16
4.3 - Hose and tube fitting................................................................................................. 17
4.4 - Installing carbonation valve....................................................................................... 17
4.5 - Model BCS installation and connection .................................................................... 18
4.6 - Model BCS Celsius All-In-One (Mains) installation and connection ......................... 19
STEP 5 - Commission the HydroTap
Section 5 - Commissioning
5.1 - CO2Purge................................................................................................................. 20
5.2 - Filter Flush ................................................................................................................ 20
5.3 - Boiling Calibration..................................................................................................... 21
5.4 - Booster...................................................................................................................... 21
5.5 - Sensor calibration ..................................................................................................... 22
5.6 - Conditioning Adjustment........................................................................................... 22
5.7 - Carbonation Valve Flow Adjustment......................................................................... 22
5.8 - Backflow Prevention ................................................................................................. 23
Troubleshooting Table ................................................................................................................. 24
End of Life Disposal ..................................................................................................................... 24
Performance Data Sheets............................................................................................................ 25
Warranty....................................................................................................................................... 34
Index

Page 4 of 36 802265US v1.27 06.21 BCS, BCS100-75 Install Instructions
Before Installation:
A. Read the instructions and check if there is adequate space to mount all of the components.
B. Note: Not all fittings are supplied with the appliance kit. Isolation valves are not supplied.
C. Check the mains water pressure is between 250 - 700 kPa (37 - 100 psi).
D. Products are rated for either 110-120V, 60Hz OR 230V, 50Hz AC installations. Check that the
electrical power supply is suitable for your HydroTap.
E. Check the water quality to determine if extra filtration will be required. NOTE: This product
must be fitted to a potable water supply.
F. Check the appliance rating plate and ensure correct power is available for the appliance.
G. Check the under counter cabinet supporting the appliance is adequate for the total weight of
the appliance, when full of water.
Before Commissioning:
1. Check the Command Center has been installed correctly.
2. Check all plumbing fittings have been tightened.
3. Ensure the outlet and vent pipes are positioned to drain correctly.
4. Ensure there is adequate ventilation.
5. Check all tubes from the Command Center to the faucet have a constant rise and there are no
sags or kinks in the hoses.
6. Check all electrical connections are correct and there are no loose wires.
Commission: (See Section 5)
7. Flush the supply line before connecting.
8. Turn on the water and check for leaks.
9. Flush the filters (this commences auto calibration for boiling models)
10. Activate / enable the Booster (if fitted)
11. Purge the CO2
12. Calibrate the safety sensor (for Boiling models)
13. Where applicable, programme the Command Center to suit the customer’s requirements.
Installation checklist

802265US v1.27 06.21 BCS, BCS100-75 Install Instructions Page 5 of 36
Thank you for purchasing a Zip HydroTap. Please read and follow these instructions carefully to ensure safe
and trouble free service.
What is the Zip HydroTap ?
The Zip HydroTaps are electronically controlled, filtered, Boiling, Chilled and Sparkling water, drinking
systems for kitchens and tea rooms. The HydroTap Command Centers are under bench drinking water
appliances with a dispensing faucet mounted on a sink or bench, which may be used for residential or
commercial applications. These units utilise a conventional refrigerant compressor to chill the water and
an immersion heating element to boil the water, and all utilise a CO2gas cylinder to carbonate the chilled
water. Depending on the model, these units will dispense boiling water, factory set to 98°C (208°F) chilled
water, factory set to 6 - 10°C (43-50°F). These Command Centers are NOT designed to be used for sanitary
fixtures.
The boiling water units are fitted with a faucet-mounted child safety lock. In addition, there are various energy
saving options accessible via the main menu. Each boiling unit is equipped with a self-calibrating program
which caters for altitude adjustment. The CO2bottle and water filter require periodic replacement and are
covered by a limited OEM warranty.
General Product Features
ON-OFF Switch
Din plug
(for accessories)
IEC Socket
110-120V, 60Hz
OR
230V, 50Hz
HydroTap BCS
Command Center

Page 6 of 36 802265US v1.27 06.21 BCS, BCS100-75 Install Instructions
Important Safety Instructions
This manual contains important safety and installation instructions for the Zip HydroTap.
Safety
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety. Children should be supervised to ensure that they do not play with the appliance.
For products sold in Europe, this appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.
Refrigerant
The Zip HydroTap Command Center contains R134A refrigerant under pressure. Maintenance of the
refrigeration unit must be carried out by an accredited service provider or qualified refrigeration technician.
Qualifications
If the power cable is damaged it must be repaired only by a qualified technician. To avoid hazards, all
Installation procedures must be carried out by a suitably qualified tradesperson. The power cable and power
outlet must be in a safe visible position for connection.
Venting
Sometimes steam and / or condensed droplets may discharge through a vent outlet at the faucet. If the
faucet is not installed using the Font pedestal, ensure the faucet body is located so the faucet outlet safely
dispenses into the sink bowl area.
Lifting
Take care when lifting the Zip HydroTap Command Center. Some units may exceed safe lifting limits. If you
feel this is beyond your personal capabilities, please seek assistance with the lift. The weights of the units are
marked on the packaging. Do not lift the Command Center by the front cover or any connections at the top
rear of the unit. Refer to section 1.2 technical specification for the weight of your product.
Airflow
The ambient operating temperatures, when installed in a cabinet, must be between 5 - 35°C (41 - 95ºF). The
system will operate satisfactorily only with proper air ventilation. The recommended air gaps of 50mm (2”) on
each side, and 200mm (8”) above must be provided. See section 2 for correct ventilation details.
Altitude
Water boils at varying temperatures at different altitudes. Your HydroTap adjusts for this during startup
calibration and will recalibrate itself on a regular basis.
Frost Protection
If this appliance is located where the ambient air temperature could fall below 5°C (41°F) when the heater is
not in use, do not turn off the appliance electrically. This safeguard does not offer the same protection to the
connecting pipework and fittings.ed
Positioning
It is important to ensure the Command Center is positioned in an accessible area close to the floor level. The
Command Center must have its base mounted in a horizontal position with all inlets and outlets facing up.
The Faucet must be located above the Command Center.
!

802265US v1.27 06.21 BCS, BCS100-75 Install Instructions Page 7 of 36
Important Safety Instructions
WARNINGS
1. The Zip HydroTap Command Center must be earthed. The resistance of the
earth connection from each exposed metal part must be less than 1 ohm.
2. All Installation and service work must be completed by trained and suitably
qualified Tradespeople. Faulty operation due to unqualified persons working
on this product, or any other Zip product may void warranty coverage.
3. All Plumbing and Electrical connections must comply with local, state and
federal codes.
4. All Plumbing and Electrical connections must be made in accordance with
local regulations.
5. Ensure the electrical power supply at the installation site is suitable for your
HydroTap. HydroTap models are rated for either 110-120V, 60Hz OR 230V,
50Hz AC installations.
6. Command Centers must never be located near, or cleaned with water jets.
7. Zip HydroTaps are not to be exposed to the elements of nature
8. Due to the process of continuous improvement, Zip reserves the right to
change details mentioned in this manual, without notice.
9. If this device is not maintained and operated as specified in this document,
there is a risk of exposure to contaminants.
10. When dispensing hot water, the device can create a scald hazard.
!
CO2 Cylinder Warnings:
• Pressurised container.
• Protect from sunlight.
• Contains gas under pressure, may explode if heated.
• Do not expose to temperatures exceeding 50°C (122°F).
• Do not pierce or burn, even after use.
• Do not refill - non-rechargeable
• Do not expose to naked flame or any incandescent material.
• Keep out of reach of children.
• High concentration of gas may cause asphyxiation.
• Use only in ventilated areas.
• Store in a location with a volume no less than 50 cubic meters for each 6 lb
bottle.
• Use only in an upright position.
• This bottle must be used with the approved pressure regulator.
• Avoid shock.
• Use according to MSDS (Material Safety Data Sheet).

Page 8 of 36 802265US v1.27 06.21 BCS, BCS100-75 Install Instructions
Parts supplied Description
1x faucet with hoses
(Classic Faucet
shown)
1x HydroTap
Command Center
with air and water
filters
1x Mains water
connection hose
Vent Kit
1x Inlet vent
1x Outlet vent
9x Screws
1x Installation
Instructions
(this book) and
1x User Guide
1x
CO2gas cylinder &
regulator assy.
Major components and accessories
Accessories Description
Softener
and head assembly
Font (Drip Tray)
Kit for Arc & Cube
models
93580US (Chrome)
Font (Drip Tray) Kit
for Classic Models
93303US (Chrome)
Replacement Filter
1Z-LS
(Culligan P/N:
01034276)
Accessibility Lever
Kit
1x Connector +
Strainer Sub-assy
Install
Instruct
User
Guide

802265US v1.27 06.21 BCS, BCS100-75 Install Instructions Page 9 of 36
Technical Specifications
NOTES:
Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection
before or after the system. Systems certified for cyst reduction may be used on disinfected waters that contain
filterable cysts.
* Available in a range of premium metallic finishes. XX refers to the specific finish of the faucet.
** BCS – Classic XX, BCS – CUBE XX, BCS – ARC XX, BCS – Celsius AIO XX, BCS100/75 – Classic XX,
BCS100/75 – CUBE XX, BCS100/75 – ARC XX and BCS100/75 – Celsius AIO XX have been tested and
certified by WQA against NSF/ANSI Standard 372 for low lead requirement, and against NSF/ANSI Standard
42 and NSF/ANSI Standard 53. This will deliver the required bacteriostatic effect and the reduction of aesthetic
chlorine, taste, odor, nominal particulate Class I (≥ 0.5 µm to < 1 µm), cyst and lead as verified and substanti-
ated by test data. See Performance Data Sheets for specific performance claims. Certified performance claims
are only valid when filter cartridge 1Z-LS (Culligan Part Number 01034276) is used.
*** BCS - Classic XX, BCS - ARC XX, BCS - CUBE XX, BCS - Wave XX, BCS100/75 - Classic XX,
BCS100/75 - CUBE XX and BCS100/75 - ARC XX have been certified by IAPMO R&T against NSF/ANSI
Standard 372 for low lead requirement, NSF/ANSI Standard 42, NSF/ANSI Standard 53, CSA B483.1, ASSE
1023, and ASSE 1087. This will deliver the required bacteriostatic effect and the reduction of aesthetic chlo-
rine, taste, odor, nominal particulate Class I (≥ 0.5 μm to < 1 μm), cyst and lead as verified and substantiated
by test data. See Performance Data Sheets for specific performance claims. Certified performance claims are
only valid when filter cartridge 1Z-LS (Culligan Part Number 01034276) is used.
**** Add an extra 5 kg (11 lb) when full of water.
Models*: BCS100/75 (230V) - Classic XX
BCS100/75 (230V) - CUBE XX
BCS100/75 (230V) - ARC XX
BCS100/75 (230V) - Celsius AIO XX
BCS (230V) - Classic XX
BCS (230V) - CUBE XX
BCS (230V) - ARC XX
BCS (230V) - Wave XX
BCS (230V) - Celsius AIO XX
BCS (110-120V) - Classic XX
BCS (110-120V) - CUBE XX
BCS (110-120V) - ARC XX
BCS (110-120V) - Wave XX
BCS (110-120V) - Celsius AIO XX
Model BCS100/75 (230V) BCS (230V) BCS (110-120V)
Command Center dimensions,
WxDxH, mm (in)
340 x 460 x 333
(13.5” x 18.5” x 13.0”)
340 x 460 x 333
(13.5” x 18.5” x 13.0”)
340 x 460 x 333
(13.5” x 18.5” x 13.0”)
Dry weight, kg (lb)**** 24 kg (53 lb) 24 kg (53 lb) 24 kg (53 lb)
Water inlet connection 1/2” BSP 1/2” BSP 1/2” BSP
Power outlets required 1x NEMA6-15:
230V, 50/60Hz, 15A
1x NEMA6-15:
230V, 50/60Hz, 15A
1x NEMA5-15: 120V,
50/60Hz, 15A
Power rating 9.5A (2.03kW)
at 230V, 60Hz
6.9A (1.45kW)
at 230V, 60Hz
9.9A (1.33kW) at
110-120V, 50/60Hz
Refrigerant R134a R134a R134a
*****

Page 10 of 36 802265US v1.27 06.21 BCS, BCS100-75 Install Instructions
Before Installation
Before installing ensure that the following have been provided at the Installation site:
• Review all the technical specifications.
• Ensure the undersink can support the product weight when full of water (allow an extra 5 kg (11 lb)
when full).
• Sufficient space in the cabinet to install all of the Command Centers in accordance with these
Installation Instructions. Refer to technical specification for dimensions. Make allowance for a water
softener if required. Refer to section 3 & 4, for Installation Instructions.
• If an external water treatment or water softening device is required, then it is important to allow extra
space for these items.
• Depending on your HydroTap model, either a 110-120V, 60Hz OR a 230V, 50Hz, 15A AC electrical
power outlet will be required.
• A potable water supply connection with isolating valve inside the cabinet within reach of the braided
hoses and positioned so that the connection point and the stop cock will not be obstructed when the
Command Centers are installed.
• For the Celsius All-In-One, an external hot and cold water supply will be required. For other faucets,
the system shall only be supplied with cold water.
• A cold water supply with a working pressure range of 250 - 700 kPa (37 - 100 psi) connected via an
isolation valve. Water inlet connection size is 1/2” BSP. The system shall only be supplied with cold
water.
• Potable water should have a minimum TDS (Total Dissolved Solids) of 50 ppm. In areas where
the TDS exceeds 150 ppm and where mineral scale could be a problem, consideration should be
given to the maintenance required. Adding a water softener or reverse osmosis system should be
considered.
• Ensure sufficient space for ventilation, including minimum clearances and installation of vents. See
Section 2.
• The appliance must be placed with its base in a horizontal position.
Note: Check all cable and hose lengths against inlet/outlet positions before proceeding (see Section
4 for general layout).
IMPORTANT! Do not proceed with installation if these requirements are not met.
!
Section 1
Faucet Installation
Refer to the Faucet installation instruction book.

802265US v1.27 06.21 BCS, BCS100-75 Install Instructions Page 11 of 36
Section 2
Ventilation
Clearance
405
Air Space
Min 200mm (8”)
3mm (0.15”) buffer to
ensure ventilation gap
2.2 Recommended Installation Diagram
When installing air ow ducts, the following tools will be required:
• Jigsaw and a 12mm (½”) Drill
• Keyhole or Wall Board saw.
2.1 Ventilation for All Models
Proper air circulation must be provided for all models. The system will operate correctly only if the
recommended air gaps are achieved during installation.
IMPORTANT: Allow a minimum clearance envelope of 50mm (2”) either side, and 200mm (8”)
above the Command Center.
Fit the 3mm (0.15”) door buffer to the inside edge of the cabinet door to allow sufficient air circulation inside the
cabinet (see diagram below).
!

Page 12 of 36 802265US v1.27 06.21 BCS, BCS100-75 Install Instructions
Ventilation
Airflow through the cabinet
If the air flow, using the silicone door buffers, is insufficient, it will be necessary to fit a standard HydroTap
vent kit, which ensures heat dissipation through natural convection via installed vents.
For high use applications, where the cabinet space temperature is near 35°C (95°F) or higher, the inlet vent
(See Item B below) and silicone buffers, need to be fitted. If the airflow is still insufficient to maintain normal
operating temperatures then the inlet vent and door outlet vent (See item D below) will need to be fitted.
Alternatively a fan kit may be installed, using the AUX din plug of the right hand side of the appliance
(Contact your local service centre for availability).
Note: The vent kit has to be installed in a way that allows air to be drawn in from the bottom of the cabinet
and expelled through the top of the cabinet. Therefore placement of the outlet vent should be towards the top
of the door or on the side of the cabinet.
2.3 Alternative Ventilation
Cool air IN
Warm air
OUT
Air inlet vent position B
D
Door outlet vent
1. Drill four pilot holes
12mm (½") dia.
2. Finish the cut-out using
a jig saw and keyhole
or Wall Board saw
Cut-out details
(½")
(11¼")
(2⅜")

802265US v1.27 06.21 BCS, BCS100-75 Install Instructions Page 13 of 36
Typical Cut-out procedure for
Ventilation
1. Mark out and cut the air inlet and door outlet holes as shown
2. Ensure the air inlet vent and air outlet vent are positioned at opposite ends
of the same cabinet space.
3. Fit the inlet vent, as shown and secure with 5 screws
4. Fit the outlet vent, as shown in the hottest part (top) of the cabinet and
secure with 4 screws
BD
B
Air inlet vent
(1/5")
Cut-out details
(12⅜")
(½")
(½")
(½")
(11/16")

Page 14 of 36 802265US v1.27 06.21 BCS, BCS100-75 Install Instructions
Section 3 - CO2Cylinder
STORAGE WARNING:
CO2gas cylinders must be installed in an open plan area or in an enclosed room, with a volume no less than
50 cubic metres (65 cubic yards) for each 2.6kg (6lb) of stored gas. If more than 1 gas cylinder containing
CO2is present within the same location, the recommended ventilated area should be in proportion to the
number of gas cylinders stored in that location. A ventilated area is a non-enclosed area which could include
the kitchen, living room etc. See gas bottle and MSDS sheet for a complete list of warnings.
3.1 Secure the cylinder cradle:
After marking out the cradle location, secure it to a suitable wall, within 3 feet of the Command Center. Make
sure the gas bottle, regulator and cradle assembly can comfortably fit, with sufficient clearances, before
securing the cradle inside the cabinet. Due to regulatory requirements the gas bottle must be stored securely
and in an upright position. Secure the bottle with the hook-and-loop straps provided.
3.2 Connect the regulator:
After removing all packing material, fit the regulator to the gas bottle as shown in the diagrams. Ensure the
plastic seal is fitted securely inside the large chrome nut, before attaching to the gas bottle. If the plastic seal
is not an easy fit over the spigot, soak it in hot water, before re-applying. Do not force the seal to fit.
Turn the regulator OFF by rotating the regulator knob, all the way out, in an anti-clockwise direction.
NOTE: Two plastic seals are supplied with a new regulator. Only one is required, the other is supplied as
a spare part.
3.3 Connect the gas hose:
Connect the braided gas hose to the top of the Command Center via the John Guest fitting marked ‘Gas IN’
Then connect the threaded end to the regulator (Do not lose the small sealing olive). When commissioning,
first, turn the regulator, grey knob, all the way out (anticlockwise). Then turn the gas ON by rotating the black
knob on top of the cylinder, anti-clockwise. Finally, adjust the outlet pressure by rotating the grey regulator
knob in a clockwise direction, to 3.0±0.1 bar (39±1 psi) (green zone)
NOTE: The arrow should sit in the green zone of the regulator gauge; it should not fall in the red or yellow
sections.
3.4 Test for gas leaks:
When commissioning, use soapy water to perform a leak test. Apply the soapy water to the gas connections
using a sponge or brush. If any bubbles appear and grow, there is a gas leak at the connection. Clean away
the soapy residue and tighten or refit the leaking connection. Make sure the gas is turned off when tightening
or refitting the leaking connection.
Fit the gas bottle into the cradle and secure with the Hook-and-loop strap. Ensure the bottle is in an upright
position.
NOTE: Care must be taken when working with high pressure carbon dioxide, and in no cases should the
normal operating pressure of 3.0±0.1 bar (39±1 psi) be exceeded.
!

802265US v1.27 06.21 BCS, BCS100-75 Install Instructions Page 15 of 36
After replacing a bottle or after making a gas connection, perform a Leak Test:
Stage 1:
1. Turn the gas OFF
2. Using soapy water applied with a sponge, or with a brush, cover all of the gas joints with a liberal
amount of suds.
Stage 2:
1. Turn ON the gas.
2. Adjust the pressure to 3 bar (39 - 43 psi)
3. Inspect the joint for leaks.
4. If any bubbles appear, the joint will need to be resealed.
CO2Regulator
Leak Test
Pressure regulating knob
ON - OFF knob
Green zone
Relief
valve
NOTE:
Be careful not to lose the
small sealing olive in the
end of the braided hose.
This olive is necessary
to ensure a gas tight
seal between the braided
hose and the regulator.
This gauge shows the pressure in the bottle and
indicates when the bottle is empty. Initial bottle
pressure will be 35-40 bar (507-580 psi) .
This gauge shows the adjustable limit (3.0±0.1 bar,
or 39±1 psi) required for the HydroTap to function
correctly

Page 16 of 36 802265US v1.27 06.21 BCS, BCS100-75 Install Instructions
B
Rotate 90°
only
1
2
3
4
If no external water treat-
ment device is installed,
select position A.
If an external water treat-
ment device is installed,
select position B
4.2 External filter bypass valve
The diverter bypass valve allows the user to choose to have the boiling water treated either by the internal or by
an optional external water treatment device. This diverter valve is located at the rear panel of the Zip HydroTap
Command Center (see the image below). Check to determine which bypass position you need for your product.
Section 4
Command Center Installation
A
Rotate 90°
only
1
2
3
4
NOTE: Before installation, determine whether a water softener or an external filter is required.
4.1 Electrical power supply
Warning: HydroTap models are available for either 110-120V, 60Hz OR 230V, 50Hz AC
installations. Ensure the electrical power supply at the installation site is suitable for your HydroTap.
Use only the power lead supplied with the product. Connect the power lead to the HydroTap and
connect the plug into the electrical power outlet, ensuring both ends are securely engaged to
reduce the risk of overheating.
Power lead for 110-120V, 60Hz ONLY
(NEMA 5-15 / IEC C19)
Power lead for 230V, 50Hz ONLY
(NEMA 6-15 / IEC C13)

802265US v1.27 06.21 BCS, BCS100-75 Install Instructions Page 17 of 36
4.3 Hose and tube fitting
• Remove all caps from the top of the Command Center
(except the mixer caps)
• Only remove the mixer caps if a mixer faucet is to be
fitted.
• Fit the foam insulation to the Blue and to the White tubes
after trimming them to length
• Install the mains water braided hoses to the Command
Center before locating the unit in place.
NOTE: Do not overtighten
Connector + Strainer
90° Bend end
of Braided Hose
To HydroTap
Command Centre
Braided hose for
Mains Water Supply
From Mains
Water Supply
Installation Instructions
John Guest fittings (Insertion and removal)
Be careful when cutting the poly tube so that there are no rough
edges and that the tube is not distorted.
1. Use a sharp knife to ensure the tube has a clean, straight
edge. Do not cut at an angle.
2. Remove any swarf or unwanted material.
3. Push the tube into the John Guest fitting making sure all
connections to the John Guest fittings are pushed in past
the “O” ring to full depth, at least 15mm (⅝”).
4. Check for a good joint by pulling back on the tube. If the
tube comes out, of the fitting, repeat the above step.
5. To remove the tube, press the collet into the fitting and at
the same time pull back on the tube.
4.4 Installing carbonation valve
1. Connect the white tube for sparkling water from the faucet
to the outlet of the carbonation valve.
2. Connect the white tube from the inlet of the carbonation
valve to the Sparkling Outlet connection on top of the Com-
mand Center, as shown in the following Sections.
3. The carbonation valve has an adjustable ow rate. The op-
timum setting for the valve is 1.6L (0.4 gallons) per minute.
Using a 6mm (¼”) Allen key or a large at blade screw driv-
er, you can adjust the ow on the valve. See section 5.7 for
carbonation valve ow rate adjustment.
To faucet
From Sparkling Outlet
of Command Centre

Page 18 of 36 802265US v1.27 06.21 BCS, BCS100-75 Install Instructions
4.5 Model BCS 100/75
Installation Instructions
: Not required for standard BCS HydroTap models.
339mm (13.5”)
RED
CLEAR
BLUE
BRAIDED
BRAIDED
USB
CHILLED
OUTLET
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
SPARKLING
OUTLET
CO2
IN
WHITE
Note:Note: thethe
hoses need tohoses need to
have a constanthave a constant
downwarddownward
gradient to thegradient to the
HydroTap toHydroTap to
allow all waterallow all water
to drain backto drain back
into the tanks.into the tanks.
Note: The tube lengths are matched to the pump performance and therefore CANNOT be lengthened
Min. 50mm (2”)
side clearance
Note:
Mains hose length is
750mm (30”)
Plug and Cord length is
1800mm (70”)
Position the Command
Center close to the
outlet faucet, within
reach of the hose and
cord lengths supplied

802265US v1.27 06.21 BCS, BCS100-75 Install Instructions Page 19 of 36
Installation Instructions
: Not required for standard BCS HydroTap models
H
4.6 Model BCS 100/75 Celsius All-In-One (Mains)
Note: The tube lengths are matched to the pump performance and therefore CANNOT be lengthened
RED
CLEAR
BLUE
BRAIDED
BRAIDED
USB
CHILLED
OUTLET
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
SPARKLING
OUTLET
CO2
IN
WHITE
External HOT and
COLD isolation
valves
(Not Supplied)
Note:Note: thethe
hoses need tohoses need to
have a constanthave a constant
downwarddownward
gradient to thegradient to the
HydroTap toHydroTap to
allow all waterallow all water
to drain backto drain back
into the tanks.into the tanks.
Note:
Mains hose length is
750mm (30”)
Plug and Cord length is
1800mm (70”)
Position the Command
Center close to the
outlet faucet, within
reach of the hose and
cord lengths supplied

Page 20 of 36 802265US v1.27 06.21 BCS, BCS100-75 Install Instructions
5.2 - Filter Flush
Section 5
Commissioning
5.1 - CO2Purge
1. Press the [START] button to commence the purging
process.
2. Purge for 10 seconds and ensure all water has stopped
flowing through the faucet. (You will hear the CO2gas
escaping from the faucet).
3. Press the [Stop] button.
4. Press [Next] for the filter flush screen
The HydroTap is now ready to be commissioned.
• Turn ON the water and gas and check for any leaks.
• Turn the power ON at the power outlet and at the side of the Command Center
• Familiarise yourself with the operation of the Faucet, in preparation for use (See User Guide)
• Follow the Installation instructions below (and review Section C of the User Guide).
• Initially you will be prompted to select a language
• After commissioning, the system may be customised by selecting further options in
Section G - Settings, within the User Guide.
BC Sparkling 10:30 Wed 04,Jul 2018
BC Sparkling 10:30 Wed 04,Jul 2018
A new filter cartridge is provided (but NOT fitted), inside the
filter door. Unpack the new filter cartridge and write today’s
date on the label. To install the cartridge, align the key tabs
and insert upwards into the filter head. Turn the cartridge to the
right until it locks in place.
Have a 10 liter (2.6 gallon) bucket or similar container (not
supplied) at the ready to hold a quantity of water that will be
ejected while the Filter Flush Mode is in operation. Open the
filter access door on the front of the HydroTap and the filter
cartridge will be exposed. Located to the rear RHS of the
cartridge is a flush line and the flush line stop cock. Place the
valve end of the flush line into the bucket or container.
Note: You will need to Press the [Start] [Stop] buttons to start
and stop the filter flush.
1
1
2
