Ziton ZX832-3 Series Assembly instructions

© 2015 UTC Fire & Security. All rights reserved. 1 / 4 P/N 10-4211-501-ZX01-01 • ISS 26JAN15
ZX832-3 Addressable Optical/Heat
Multisensor Installation Sheet
1
2
3
4
EN: Installation Sheet
Description
The ZX832-3 Addressable Optical/Heat Multisensor integrates
both high sensitivity smoke and thermal sensors, resulting in
higher detection certainty. See Table 1 for a list of models. For
a complete list of sensing profiles refer to Table 2.
Table 1: Models
Number Description
ZX832-3P
ZX832-3B
ZX832-3S30
Addressable Optical/Heat Multisensor, Polar White
Addressable Optical/Heat Multisensor, Black
Addressable Optical/Heat Multisensor, Chubb
Figures
Figure 1: Inserting a detector
Figure 2: Position of the locking tab
Figure 3: Removing a locked detector
Figure 4: Setting the address
Installation
Note: For general guidelines on system planning, design,
installation, commissioning, use and maintenance, refer to the
EN 54-14 standard and local regulations.
To install a detector:
Insert the detector head into the mounting base and rotate it
clockwise until it clicks into place (Figure 1).
The detector may be locked into the mounting base if required.
To do this, remove the locking tab before installation shown in
Figure 2.

2 / 4 P/N 10-4211-501-ZX01-01 • ISS 26JAN15
After installation, ensure that the detector communicates with
the control panel. Always test detectors after installation.
To remove a locked detector:
1. Insert a small screwdriver into the locking tab slot
(Figure 3).
2. Press and rotate the detector anticlockwise.
Setting the address
The detector includes a seven-segment DIP switch (SW1) for
assigning detector addresses. Each switch segment has a
decimal value as shown in Figure 4. The address is the sum of
all the switch segments in the ON position. The full DIP switch
address range of 1 to 127 is shown on page 4.
For example, to select a detector address of 007, set SW1-1,
SW1-2, and SW1-3 to the ON position and the remaining
switch segments to the OFF position.
Locking base option
The detector is compatible with a range of bases (see
“Specifications”) and is easily installed by a simple twist and
lock action.
Note: To prevent unauthorised removal of a detector from its
base, an automatic locking tab is incorporated into all detector
mouldings. If the tab is removed, detectors can only be
released from their bases by use of a screwdriver, as shown in
Figure 3. This locking option is applied at the system
commissioning stage.
Maintenance and testing
Basic maintenance consists of a yearly inspection. Do not
modify internal wiring or circuitry.
Automatic self-test
Sensor sensitivity, calibration and self-testing are carried out
automatically by the fire panel. Removal or replacement of an
incorrect sensing detector will be identified by the system and
shown as a fault.
Specifications
Operating voltage 19.5 to 20.5 V pulsed,
max. 4 V line loss
Current
Standby
Alarm
600 µA
700 µA
Coverage
Smoke element
Thermal element
100 m2
50 m2
IP Rating IP32
Polarity sensitive Yes
Compatible bases Z-AUXD-2P
ZP7-IB-P
ZP7-RB1-P
ZP7-SB1-P
ZP7-SB1B, Black
ZP755B-2P
ZP755BV-4P
ZP755BV-5P
Compatible accessories Z-RL3 Remote LED unit
Z-RL4 Remote LED unit
Operating environment
Temperature
Storage temperature
Relative humidity
–10 to +85°C
–20 to +70°C
20 to 95% noncondensing
Dimensions (Ø x H) 106 × 58 mm
Weight 105 g
Regulatory information
This section includes both regulatory information and a
summary on the declared performance according to the
Construction Products Regulation 305/2011. For detailed
information refer to the product Declaration of Performance.
Certification
Certification body 0370
Declaration of
Performance number 360-4211-1099
Year of first CE
marking 14
Product identification ZX832-3
Intended use See DoP point 9
Essential
characteristics See DoP point 9
Manufacturer United Technologies Safety System Co., Ltd.
80, Changjiang East Road, QETDZ,
066004 Qinhuangdao, HEBEI, China
Authorized EU manufacturing representative:
UTC Fire & Security B.V. Kelvinstraat 7, 6003
DH Weert, Netherlands
2012/19 /EU (WEEE directive): Products
marked with this symbol cannot be disposed
of as unsorted municipal waste in the
European Union. For proper recycling, return
this product to your local supplier upon the
purchase of equivalent new equipment, or
dispose of it at designated collection points.
For more information see:
www.recyclethis.info.

P/N 10-4211-501-ZX01-01 • ISS 26JAN15 3 / 4
Contact information
For contact information, see www. utcfssecurityproducts.eu.
Table 2: Sensing profiles
Profile Sensitivity Notes
1 Smoke only - High Smoke only response, Sensitivity 1 Very high sensitivity
2 Smoke only - Normal Smoke only response, Sensitivity 2 (std) Normal sensitivity
3 [1] Smoke only - Medium Smoke only response, Sensitivity 3 Medium sensitivity [1]
4 Smoke only - Low Smoke only response, Sensitivity 4 Low sensitivity
5 [1] Heat only - High Heat only response, Sensitivity 1: 58ºC ROR Standard thermal sensitivity with rate of rise [1]
6 Heat only - Medium Heat only response, Sensitivity 2: 58ºC FT Standard thermal sensitivity
7 Heat only - Low Heat only response, Sensitivity 3: 75ºC ROR Low thermal sensitivity with rate of rise
8 Heat only- Low Option 2 Heat only response, Sensitivity 4: 75ºC FT Low thermal sensitivity
9 Smoke High/
Heat Medium Smoke Sensitivity 1, Heat 1: 58ºC ROR Early smoke response, Early thermal response
10 Smoke High/
Heat Medium Smoke Sensitivity 1, Heat 2: 58ºC FT Early smoke response, Medium thermal response
11 Smoke High/, Heat Low Smoke Sensitivity 1, Heat 3 - 75ºC ROR Early smoke response, Low thermal response
12 Smoke High/,
Heat Low Option 2 Smoke Sensitivity 1, Heat 4: 75ºC FT Early smoke response, Slow thermal response
13 Smoke Normal/
Heat High Smoke Sensitivity 2, Heat 1: 58ºC ROR Normal smoke response, Early thermal response
14 Smoke Normal/
Heat Medium Smoke Sensitivity 2, Heat 2: 58ºC FT Normal smoke response, Medium thermal response
15 Smoke Normal/
Heat Low Smoke Sensitivity 2, Heat 3: 75ºC ROR Normal smoke response, Low thermal response
16 Smoke Normal/
Heat Low Option 2 Smoke Sensitivity 2, Heat 4 : 75ºC FT Normal smoke response, Slow thermal response
17 Smoke Medium/
Heat High
Smoke Sensitivity 3, Heat 1: 58ºC ROR Medium smoke response, Early thermal response
18 Smoke Medium/
Heat Medium
Smoke Sensitivity 3, Heat 2: 58ºC FT Medium smoke response, Medium thermal response
19 Smoke Medium/
Heat Low
Smoke Sensitivity 3, Heat 3: 75ºC ROR Medium smoke response, Low thermal response
20 Smoke Medium/
Heat Low Option 2
Smoke Sensitivity 3, Heat 4: 75ºC FT Medium smoke response, Slow thermal response
21 Smoke Low/
Heat High
Smoke Sensitivity 4, Heat 1: 58ºC ROR Slow smoke response, Early thermal response
22 Smoke Low/
Heat Medium Smoke Sensitivity 4, Heat 2: 58ºC FT Slow smoke response, Medium thermal response
23 Smoke Low/Heat Low Smoke Sensitivity 4, Heat 3: 75ºC ROR Slow smoke response, Low thermal response
24 Smoke Low/
Heat Low Option 2
Smoke Sensitivity 4, Heat 4: 75ºC FT Slow smoke response, Slow thermal response
25 Enhanced Clean Room Dual detector, Smoke Sensitivity High
Heat 58ºC ROR
Verification 5 seconds
Fast smoke response, Fast thermal response
26 Enhanced Normal Dual detector, Smoke Sensitivity Normal
Heat 58ºC ROR
Verification 20 seconds
Medium smoke response, Medium thermal response
Medium time response
27 Enhanced Industrial Dual detector, Smoke Sensivity Low
Heat Low sensitivity
Verification 30 seconds
Slow smoke response, Slow thermal response
[1] The ZX832-3 has been certified to comply with 03 and 05 sensing profiles.
