Aeotec Door / Window Sensor 7 User manual

Door / Window Sensor 7

Quick start
This is a secure Alarm Sensor. To run this device please insert fresh 1 * 1/2 AA batteries. Please make
sure the internal battery is fully charged. The DSK for the S2 inclusion can be found inside the sensors
packaging.
If your Z Wave gateway supports SmartStart: scan the QR code on Door / Window Sensor 7 using the
gateway’s app. Your sensor will join your Z Wave network automatically.
Important safety information
Please read this manual carefully. Failure to follow the recommendations in this manual may be
dangerous or may violate the law. The manufacturer, importer, distributor and seller shall not be liable for
any loss or damage resulting from failure to comply with the instructions in this manual or any other
material. Use this equipment only for its intended purpose. Follow the disposal instructions. Do not
dispose of electronic equipment or batteries in a fire or near open heat sources.
What is -Wave?
Z Wave is the international wireless protocol for communication in the Smart Home. This device is suited
for use in the region mentioned in the Quickstart section.
Z Wave ensures a reliable communication by reconfirming
every message (two-way communication) and every mains
powered node can act as a repeater for other nodes
(meshed network) in case the receiver is not in direct
wireless range of the transmitter.
This device and every other certified Z Wave device can
be used together with any other certified -Wave device
regardless of brand and origin as long as both are suited
for the same frequency range.
If a device supports secure communication it will communicate with other devices secure as long as
this device provides the same or a higher level of security. Otherwise it will automatically turn into a lower
level of security to maintain backward compatibility.
SmartStart. Available in selected Z Wave Plus devices built upon 500 series technology and all devices
built upon 700 series technology, SmartStart lets you setup Z Wave devices in seconds. Using SmartStart
enabled apps, simply scan the QR code on any compatible app to connect it to your Z Wave gateway.
For more information about Z Wave technology, devices, white papers etc. please refer to www.z
wave.info.
Product Description
The AEOTEC Door/Window Sensor 7 Pro is a sensor, which detects if your window is opened or closed.
The sensor is easily retrofittable.
Thanks to its slim design the AEOTEC Door/Window Sensor 7 Pro can be installed unflashy on every

window. The sensor just has to be installed on the window casement. Additionally, there has to be a slim
magnet installed closely to the sensor at the window frame. By using a patented method the sensor can
reliably detect the exact position of the window.
Tripple clicking the tamper button includes (adds) and excludes (removes) the device.
A single click on the button will wake up the device. The device supports the Z Wave Security S2
framework with authenticated and unauthenticated network keys. Please follow the instructions on the
central controller when including. The device also supports Smart Start.
Prepare for Installation / Reset
Please read the user manual before installing the product.
In order to include (add) a Z Wave device to a network it must be in factory default state. Please make
sure to reset the device into factory default. You can do this by performing an Exclusion operation as
described below in the manual. Every Z Wave controller is able to perform this operation however it is
recommended to use the primary controller of the previous network to make sure the very device is
excluded properly from this network.
Reset to factory default
This device also allows to be reset without any involvement of a Z Wave controller. This procedure should
only be used when the primary controller is inoperable.
Once Cover is removed and the tamper switch is tripped, push the tamper for 5 seconds until the RED
LED blinks once. Then release tamper and push it again for 5 seconds while the RED LED is blinking until
the GREEN LED blinks once.
Safety Warning for Batteries
The product contains batteries. Please remove the batteries when the device is not used. Do not mix
batteries of different charging level or different brands.
Installation
The sensor can be mounted either on the moving part or on the fixed part of a door or a window.
Mounting can be accomplished either using the tape by peeling off the protection foil or using two
screws with the holes inside the battery compartment. If the tilt detection on a window (only normal
windows, no roof windows) shall be used the sensor device must be placed on the moving part of the
window and the magnet on the window frame.
The sensor comes with two types of magnets:
 The standard magnet covered by plastic part, mountable beside the sensor. Make
sure the two indicating lines on sensor enclosure and magnet are opposite to each
other. The image on the right hand side shows the position of magnet and sensor
body.
 A slim naked magnet to be mounted behind the sensor in case the sensor body is
placed on the side of a window.

Inclusion/Exclusion
On factory default the device does not belong to any Z Wave network. The device needs to be added to
an existing wireless network to communicate with the devices of this network. This process is
called Inclusion.
Devices can also be removed from a network. This process is called Exclusion. Both processes are
initiated by the primary controller of the Z Wave network. This controller is turned into exclusion
respective inclusion mode. Inclusion and Exclusion is then performed doing a special manual action right
on the device.
Inclusion
1. Open the housing.
2. Remove the battery protection.
3. Press the tamper on the side of the appliance three times quickly.
Exclusion
1. Open the housing.
2. Press the tamper on the side of the appliance three times quickly.
Product Usage
Once installed the sensor will report "open" and "close" status changes to a central Z Wave controller
using notification commands. Additionally, the sensor can directly control other devices using association
group 2. The device is protected by a tamper switch.
Link testing
When activated by configuration parameter #5 the device can perform a link test. Double clicking the
tamper will start the process. As a result, the GREEN LED will blink two times in case of success and the
RED LED will blink two times in case of failure.
Notifications
The device sends the following notifications to the central controller:
 Window Opened(0x06 0x16)
 Window Closed(0x06 0x17)
 Tamper Removed(0x07 0x03)
Node Information Frame
The Node Information Frame (NIF) is the business card of a Z Wave device. It contains information about
the device type and the technical capabilities. The inclusion and exclusion of the device is confirmed by
sending out a Node Information Frame. Beside this it may be needed for certain network operations to
send out a Node Information Frame. To issue a NIF execute the following action: Press the tamper once
Quick trouble shooting
Here are a few hints for network installation if things don’t work as expected.
1. Make sure a device is in factory reset state before including. In doubt exclude before include.

2. If inclusion still fails, check if both devices use the same frequency.
3. Remove all dead devices from associations. Otherwise you will see severe delays.
4. Never use sleeping battery devices without a central controller.
5. Dont poll FLIRS devices.
6. Make sure to have enough mains powered device to benefit from the meshing
Firmware-Update over the Air
This device is capable of receiving a new firmware 'over the air'. The update function needs to be
supported by the central controller. Once the controller starts the update process, perform the following
action to confirm the firmware update: Wake Up the device by removing the cover. Then hit the tamper
switch once.
Association - one device controls another device
Z Wave devices control other Z Wave devices. The relationship between one device controlling another
device is called association. In order to control a different device, the controlling device needs to maintain
a list of devices that will receive controlling commands. These lists are called association groups and
they are always related to certain events (e.g. button pressed, sensor triggers, ...). In case the event
happens all devices stored in the respective association group will receive the same wireless command
wireless command, typically a 'Basic Set' Command.
Association Groups:
Group Number
Maximum
Nodes Description
1
5
Lifeline
2
5 Control devices when a magnet is tripped.
3
5 Sends out alarm message when a magnet is tripped
4
5 Sends alarm messages when tamper is tripped
Configuration Parameters
Z Wave products are supposed to work out of the box after inclusion, however certain configuration can
adapt the function better to user needs or unlock further enhanced features.
IMPORTANT: Controllers may only allow configuring signed values. In order to set values in the range
128 ... 255 the value sent in the application shall be the desired value minus 256. For example: To set a
parameter to 200 it may be needed to set a value of 200 minus 256 = minus 56. In case of a two byte
value the same logic applies: Values greater than 32768 may needed to be given as negative values too.
Parameter 3: Door/window state
This parameter allows to set in what state is door/window when the magnet is close to the sensor.
Size: 1 Byte, Default Value: 0

Setting
Description
0
Closed when Magnet near
1
Opened when Magnet near
Parameter 4: Visual LED Indications
This parameter defines when the red LED will indicate events. Disabling all indications may extend
battery life. Value 0 means no indications.
Size: 1 Byte, Default Value: 7 (values 1 + 2 + 4 summarized)
Setting
Description
0
No indications.
1
Open/Close Status Change
2
Wake Up
4
Device Tampering
Parameter 5: Range Test after double click
Allows to enable the activation of a Z Wave range test. Double clicking the tamper will start the process.
As a result, the GREEN LED will blink two times in case of success and the RED LED will blink two times in
case of failure.
Size: 1 Byte, Default Value: 0
Setting
Description
0
Disabled
1
Enabled
Parameter 6: 2nd Association Group Trigger
This parameter defines the status of the magnet switch that causes sending a BASIC command to all
devices of Association Group 2.
Size: 1 Byte, Default Value: 0
Setting
Description
0
Switch after Opening and Closing
1
Switch after Open
ing
2
Switch after Clos
ing
Parameter 7: Command Sent to Devices of Association Group 2
This parameter defines which commands is sent to 2nd Association Group
Size: 1 Byte, Default Value: 2
Setting
Description
0
On

1
Off
2
On and Off
Parameter 8: BASIC command value sent to 2nd Association Group on On event
This is the BASIC command value sent in case of On event.
Size: 1 Byte, Default Value: 255
Setting Description
0
-
99
Value
255
Value
Parameter 9: BASIC command value sent to 2nd Association Group on Off event
This is the BASIC command value sent in case of Off event.
Size: 1 Byte, Default Value: 0
Setting
Description
0
-
99
Value
255
Value
Parameter 10: Time Delay of On command frame from 2nd Association Group
On command is sent after a delay defined in this parameter.
Size: 2 Byte, Default Value: 0
Setting
Description
0
-
32400
seconds
Parameter 11: Time Delay of Off command frame from 2nd Association Group
Off command is sent after a delay defined in this parameter.
Size: 2 Byte, Default Value: 0
Setting
Description
0
-
32400
seconds
Parameter 12: Delay of Tamper Alarm Cancellation
Time a tamper alarm is delayed.
Size: 2 Byte, Default Value: 0
Setting
Description
0
-
32400
seconds
Parameter 13: Reporting Tamper Alarm Cancellation
This parameter defines if the alarm cancellation event is reported.
Size: 1 Byte, Default Value: 1

Setting
Description
0
Do not se
nd alarm cancellation r e
port
1
Send
alarm cancellation
r
eport
Parameter 22: Enalbe/ disbale Binary Sensor report
Backwards compatibility, Binary Sensor.
Size: 1 Byte, Default Value: 0
Setting
Description
0
Disable
1
E
nable
Parameter 23: Report low battery report when level goes under threshold setting
Size: 1 Byte, Default Value: 20
Setting
Description
1
0
-
50
10
50%
Parameter 24: Report battery report at an interval set in hour
Size: 1 Byte, Default Value: 24
Setting
Description
0
Disable
1
-
255
1
2
55 hours
Parameter 255: Reset Parameter
This parameter helps reset configuration parameters and the device to factory defaults
Size: 4 Byte, Default Value: 0
Setting
Description
1
-
1431655764
Reset all Parameter settings to their default settings.
1431655765
Completely factory reset sensor and send device reset locally
notification.
Technical Data

Dimensions
28x95x35 mm
Hardware Platform
ZGM130S
IP Class
IP 20
Battery Type
1 * 1/2 AA
Device Type
Notification Sensor
Generic Device Class
Sensor Notification
Specific Device Class
Routing Sensor Notification
Network
Operation
Reporting Sleeping Slave
Firmware Version
02.00
-
Wave Version
07.1
5
-
Wave Product Id
0371.0002.000C
Frequency
Europe
868,4 Mhz
Maximum transmission
power
5 mW
Supported Command Classes
 Configuration Command Class, Version 4 (highest granted security level)
 Multilevel Sensor Command Class, Version 11 (highest granted security level)
 Multi Channel Association Command Class, Version 3 (highest granted security level)
 Association Group Information Command Class, Version 3 (highest granted security level)
 Device Reset Locally Command Class, Version 1 (highest granted security level)
 Z Wave Plus Info Command Class, Version 2 (non Secure)
 Notification Command Class, Version 8 (highest granted security level)
 Manufacturer Specific Command Class, Version 2 (highest granted security level)
 Powerlevel Command Class, Version 1 (highest granted security level)
 Firmware Update Meta Data Command Class, Version 5 (highest granted security level)
 Battery Command Class, Version 1 (highest granted security level)
 Wake Up Command Class, Version 2 (highest granted security level)
 Indicator Command Class, Version 3 (highest granted security level)
 Association Command Class, Version 2 (highest granted security level)
 Version Command Class, Version 3 (highest granted security level)
 Security 2 Command Class, Version 1 (highest granted security level)
 Supervision Command Class, Version 1 (non Secure)
 Transport Service Command Class, Version 2 (non Secure)
 Central Scene Command Class, Version 3 (highest granted security level)
Explanation of -Wave specific terms

 Controller — is a Z Wave device with capabilities to manage the network. Controllers are typically
Gateways, Remote Controls or battery operated wall controllers.
 Slave — is a Z Wave device without capabilities to manage the network. Slaves can be sensors,
actuators and even remote controls.
 Primary Controller — is the central organizer of the network. It must be a controller. There can be
only one primary controller in a Z Wave network.
 Inclusion — is the process of adding new Z Wave devices into a network.
 Exclusion — is the process of removing Z Wave devices from the network.
 Association — is a control relationship between a controlling device and a controlled device.
 Wakeup Notification — is a special wireless message issued by a Z Wave device to announces
that is able to communicate.
 Node Information Frame — is a special wireless message issued by a Z Wave device to
announce its capabilities and functions.
