ZK Technology L7000 User manual

Fingerprint Lock User Manual
Version: 1.0
Date: Sept. 2010
About This Manual
This manual introduces the fingerprint lock interface and menu operations. For the
fingerprint lock installation, see the animated installation instructions.
Our products are subject to update from time to time, so our company
will neither make a commitment to guarantee the consistency between the
actual products and this document, nor assume any responsibility for any
dispute arising out of the discrepancy between the actual technical parameters
and this manual. This document is subject to change without prior notice.

Table of Contents
Table of Contents
1. Instruction for Use.....................................1
1.1 Functions Introduction........................................................................ 1
1.2 List of Installation Accessories........................................................... 3
1.3 Fingerprint Press Introduction ............................................................ 5
1.4 Installation Requirements ................................................................... 6
1.4.1 Precautions .................................................................................. 6
1.4.2 Use Backup Battery..................................................................... 8
1.4.3 Backup (Emergency) Mechanical Key........................................ 9
1.4.4 Convert of Unlock Direction ....................................................... 9
1.5 Front and Rear Views ....................................................................... 10
1.6 Precautions ....................................................................................... 13
1.7 User Privileges.................................................................................. 13
1.8 Time Setting...................................................................................... 14
1.9 Operation Overtime .......................................................................... 15
2. Enrollment and Verification....................16
2.1 Enroll an Administrator .................................................................... 16
2.1.1 Enroll a Fingerprint ................................................................... 17
2.1.2 Enroll a Password...................................................................... 18
2.2 Enroll an Ordinary User ................................................................... 19
2.3 Backup Enrollment........................................................................... 21
2.4 User Verification and Set NO Status................................................. 22
2.5 Delete User Information ................................................................... 23
I

Fingerprint Lock User Manual V1.0
II
3. Lock Function and Settings.....................27
3.1 Operation Settings ............................................................................ 27
3.1.1 Operate Alarm Setting ............................................................... 28
3.1.2 Illegal Times.............................................................................. 28
3.1.3 Lock Setting .............................................................................. 29
3.1.4 Verify Mode Setting .................................................................. 29
3.1.5 Normal Open Setting................................................................. 30
3.2 Language Settings ............................................................................ 31
3.3 Advanced Settings ............................................................................ 32
3.4 Browse System Information ............................................................. 34
3.5 Browse Logs..................................................................................... 36
3.6 USB Pen Drive Management (Optional).......................................... 37
4. Conventions on Other Functions............40
4.1 Routine Operation Indications.......................................................... 40
4.2 Administrator Loss Prevention ......................................................... 40
4.3 Battery Low Voltage Protection........................................................ 41
4.4 Program Automatically Exit and Power off...................................... 41
5. Appendix: Technical Specifications........42

1. Instruction for Use
1. Instruction for Use
Functions marked with “★” in this manual are only supported by specific product or
customized product and will be marked below.
1.1 Functions Introduction
1. By leveraging the perfect combination of biometrics and cryptography, our
fingerprint locks ensure double security through the fingerprint plus password
unlocking feature.
2. The state-of-the-art Organic LED (OLED) display affords crisp bright readouts
and makes our fingerprint locks intuitive and easy to use. You can simply use
our fingerprint locks with ease after following the operation instructions for
once.
3. Support setting of classified privileges for super administrators, administrators
and ordinary users.
4. Support deletion of all or the specified registered data.
5. Support firmware upgrade, uploading/downloading of user information and
unlocking records through a USB pen drive.
6. Support offline browse of unlocking records.
7. Support accurate display of time and date with annual deviation less than two
minutes.
8. Support temporary supply of backup batteries.
9. You can set the fingerprint locks to be in the Normally Open (NO) state in
special cases.
10. Support display of the battery charge level and generate low voltage alarms.
11. Feature an electric clutch handle design which helps effectively prevent the
fingerprint lock failure caused by damage to the internal structure as a result of
the forced destruction of the handle.
1

Fingerprint Lock User Manual V1.0
12. Single latch lock (support both 60mm and 70mm locks) of American standard
supports deadbolt lock either.
13. The max user capacity is 500 fingerprints. The max unlocking record is 30000
logs.
14. Unlock mode: fingerprint, password, mechanical key.
2

1. Instruction for Use
1.2 List of InstallationAccessories
2 Square shaft of handle 3 Lock body 4 Waterproof washer 5 Rear hold-down plate 6 Screw 7 Rear panel assembly 8 Battery 9 Battery cover
6
15 installation disk
1
6 Mountin
g
p
a
p
er
14 Key 1 Front panel 13 Backup battery
12 Wood grain screws 11 Strike plate 10 Box keep
3

Fingerprint Lock User Manual V1.0
List of Installation Accessories
SN Name Quantity Unit Remarks
01 Front panel assembly 1 Set
02 Square shaft of
handle 2 PCS One need to select base on the
door thickness
03 Lock body 1 Set Single latch lock
04 Waterproof washer 2 PCS Including the one on the front
panel assembly
05 Rear hold-down plate 1 PCS
06 Screw 6 PCS Two of screws need to select
base on the door thickness
07 Rear panel assembly 1 Set
08 Batteries 4 PCS Four pieces of alkaline AA
batteries
09 Battery cover 1 PCS
10 Box keep 1 PCS
11 Strike plate 1 Set
12 Wood grain screws 4 PCS
13 Backup battery 1 PCS 9V
14 Key 2 PCS
15 Installation disk 1 PCS
16 Mounting paper 1 PCS
4

1. Instruction for Use
1.3 Fingerprint Press Introduction
Enroll fingerprint by pressing index finger, middle finger or ring finger (thumb and
little finger are clumsy) .
1) Proper press:
Make finger center pressed on the
sensor window.
2) Improper press:
Upright Too lean
Too downward
Slant
Please adopt the correct way to place the finger to avoid improper
operation led to the identification performance degradation.
5

Fingerprint Lock User Manual V1.0
1.4 Installation Requirements
1.4.1 Precautions
1. The fingerprint lock is applicable to doors of 35–70 mm in thickness. Be sure to
list your special requirements or remarks for fingerprint locks to be installed on
doors in excess of 70 mm in thickness before placing an order.
2. Before ordering or installation of single latch lock, please confirm the
corresponding accessories.
Single latch lock:
3. Please confirm the door opening directions. Assume you are standing outside and
facing a door and then there are four door opening directions: Left inward, left
outward, right inward and right outward. Left inward/outward means the door
swings inward/outward with hinges on the left; right inward/outward means the door
swings inward/outward with hinges on the right, as shown in the following figure:
6

1. Instruction for Use
4. Ensure the central point of the handle is about 1 meter above the floor.
5. Ensure all the accessories installed on the right position.
6. Please follow the animated instructions to install fingerprint locks.
Recommended Tools:
You may need the following tools while following the instructions to install
fingerprint locks:
A ruler.
A marker pen.
A drilling tool.
A cross screwdriver.
7

Fingerprint Lock User Manual V1.0
1.4.2 Use Backup Battery
The fingerprint lock supports temporary use of external DC power for fingerprint or
password matching and unlocking, but when connected with an external battery, the
fingerprint lock cannot provide such special functions as enrollment, deletion and
setting, so as to prevent data loss as a result of power instability.
As shown in the figure below, connect a 9V battery to the two access points at the
bottom of a fingerprint lock, regardless of polarities.
If you power off a fingerprint lock without closing the lock during the use of
external power, the lock cylinder will not automatically return to its original position.
That is, the fingerprint lock remains in NO state. To solve this problem, you can
replace the battery and then verify to open the lock once to have the lock cylinder
back position.
8

1. Instruction for Use
1.4.3 Backup (Emergency) Mechanical Key
1. Remove the screw from the lock
handle, and take off the handle.
2. Insert the key, turn to right or
left 180º to unlock the door.
1.4.4 Convert of Unlock Direction
Waterproof washer
1. Remove the screw of handle, then
take off the handle and rotate 180º.
2. Reload the handle and fix it
with screws.
9

Fingerprint Lock User Manual V1.0
Note: In converting of unlock direction, you just need to rotate the lock body
180º entirely.
1.5 Front and Rear Views
Front view:
背视图
Number key 1
(“ESC” key)
Fingerprint sensor
Handle
Menu (Status indicator,
“OK” key, Start key)
Number key 4
Number key3
(“” key)
Number key 2
(“” key)
Emergency power
port
OLED display
10

1. Instruction for Use
Rear view:
USB Port
(optional)
Band switch
Handle
Battery
Battery cover
Number key 1: Press this key to exit current operation, press and hold this key to
power off the fingerprint lock. The number key “1” doubles as ESC key.
Number key 2: This key is used to manually increase (when held this key, the
display values will rapidly increase) the setup value or navigate among menu
options. The number key “2” doubles as key.
Number key 3: This key is used to manually decrease (when held this key, the
display values will rapidly decrease) the setup value or navigate among menu
options. The number key “3” doubles as key.
Menu key (Status indicator): This key can be used to start the fingerprint lock;
press and hold this key for three seconds on the initial interface to open the main
menu; this key also doubles as the confirmation OK key. The green LED indicator
blinks when the fingerprint lock operates properly and the red LED indicator is on
for three seconds if an error occurs. The green LED indicator is on for three seconds
11

Fingerprint Lock User Manual V1.0
when an operation succeeds.
Band switch: If you cannot access the menu options due to the loss of
administrators for some reason, proceed as follows: Press and hold the Menu key
for three seconds to display the administrator verification, and then turn the Band
switch at the rear of the lock to the left or right to open up the menu as a super
administrator.
OLED display: The black-and-white OLED display features white graphics or text
against a black background.
Fingerprint sensor: You can only collect or match fingerprints by pressing your
finger(s) at the fingerprint sensor when the light in the fingerprint sensor window
goes on; otherwise nothing happens when you press your finger(s) at the fingerprint
sensor.
Note: When you cannot power off the fingerprint lock due to the exception of
program, press and hold the ESC key to power off and then restart the fingerprint
lock. It is not recommended to power off the fingerprint lock by pressing and
holding the ESC key when the fingerprint lock operates normally.
Emergency interfaces:
Keyhole: You can use a mechanical key for emergency door opening.
Temporary external power interface: You can adopt an external backup battery to
open the lock in the event of unlocking failure due to insufficient power supply of
the fingerprint lock.
USB port (optional):
The USB port is used for firmware upgrade, uploading/downloading of user
12

1. Instruction for Use
information and unlocking records through a USB pen drive. Only some models
have USB port options.
1.6 Precautions
1. We strongly recommend you to enroll at least one administrator after installing the
fingerprint lock. You must at least enroll one administrator before enrolling ordinary
users.
2. Do not remove batteries when matching, enrolling or deleting fingerprints because
the sudden power-down may result in data loss of fingerprint locks. Prior to
removing batteries, make sure the fingerprint lock is not in working state.
3. It is recommended to replace the fingerprint lock batteries at least once every six
months to avoid damaging the circuit due to the battery leakage. Do not use batteries
with poor quality.
4.. When installing a fingerprint lock, connect the plug to the socket properly.
Improper connection may lead to fingerprint lock failure.
1.7 User Privileges
The user privileges are classified into three types: Super administrator,
administrators and ordinary users.
Super administrators: Refer to users who have access to all system functions and
modify all system settings.
Administrators: Refer to who have access to all operations except performing
advanced settings and enrolling super administrators.
Ordinary users: Refer to all users other than the super administrators and
administrators. Ordinary users only have access to the fingerprint matching and
unlocking functions.
13

Fingerprint Lock User Manual V1.0
1.8 Time Setting
You need to set the correct date and time on first use of a fingerprint lock in the
following steps:
1) Power on the fingerprint lock by pressing the
Menu key to open up the initial interface, as shown
in the figure on the left.
Note: The “ ” icon on the initial interface is the battery icon indicating
how much charge remains. On the top right corner of the initial interface, the display
alternates between date and time every 5 seconds.
02: 30: 30
FP LOCK
Admin Affirm
FP LOCK
Menu ↓
User Manage
►Options
PenDrive Mng
Options
Set Opt.
►System Opt.
2) Press and hold the Menu key for three seconds to
access the menu interface. The administrator verify
and enter the step 3). If no administrator exist,
please turn to step 3) directly.
3) Press 2 to select “Options.” and then press
Menu.
4) Press 3to select “System Opt.” and then press
Menu.
14

1. Instruction for Use
SystemOpt. ↓
►Date Time
Language English
Dev Num
YYYY-MM-DD 24H
2009-01-01
9: 34: 29
ESC OK
5) Press Menu to select "Date Time".
6) To modify date or time, press 2/3 to move the
cursor to the desired option, and then press 2/3
again to enter correct date or time. Press Menu. to
save your settings.
Note: You can set the date between January 1st 2003 and December 31st 2032.
To set the date beyond this range, you need to consult our commercial
representatives or pre-sales technical support engineers.
1.9 Operation Overtime
In any user operation state, the default overtime value is 5 seconds, after 5 seconds
the lock power off automatically.
15

Fingerprint Lock User Manual V1.0
2. Enrollment and Verification
2.1 Enroll anAdministrator
If the fingerprint lock has no administrator, you must at least enroll one
administrator before enrolling ordinary users. To enroll an administrator, proceed as
follows:
1) Power on the fingerprint lock by pressing the
Menu key to open up the initial interface. Press and
hold the Menu key to display the menu interface.
02:30:30
FP LOCK
Menu ↓
►User Manage
Options
PenDrive Mng
User Manage ↓
Enroll User
►Enroll Admin
Delete User
2) Press Menu to display the user management
interface.
3) Press 3 to select “Enroll Admin” and then press
Menu.
After that, the enrolled administrator can perform fingerprint and password
enrollment, the operation as follows.
16
