Zksoftware L7000-U User manual

User Manual
Version 1.1
Date: June 2012

1 Instructions 3
1.1 Introduction to L7000 . . . . . . . . . . . . .3
1.2 List of Installation Accessories. . . . . . . . . .3
1.3 Installation Requirements . . . . . . . . . . .4
1.4 Battery Backup. . . . . . . . . . . . . . . .5
1.5 Front and Rear View . . . . . . . . . . . . .6
1.6 Precautions . . . . . . . . . . . . . . . . .7
1.7 User Privileges . . . . . . . . . . . . . . . .7
1.8 Set Time. . . . . . . . . . . . . . . . . . .7
2 Enrolment and Verification 8
2.1 Enrol an Administrator . . . . . . . . . . . .8
2.1.1 Enrol a Fingerprint . . . . . . . . . . . . .9
2.1.2 Enrol a Password . . . . . . . . . . . . 10
2.2 Enrol a User . . . . . . . . . . . . . . . . 11
2.3 Backup Enrolment . . . . . . . . . . . . . 11
2.4 Set User Verification and NO Status . . . . . . 12
2.5 Delete User Data . . . . . . . . . . . . . . 12
3 Lock Function Information and Settings 13
3.1 Operation Settings . . . . . . . . . . . . . 13
3.1.1 Operate Alram Setting . . . . . . . . . . 14
3.1.2 Illegal Times . . . . . . . . . . . . . . 14
3.1.3 Lock Settings . . . . . . . . . . . . . . 15
3.1.4 Verify Mode Setting . . . . . . . . . . . 15
3.1.5 Normal Open Setting . . . . . . . . . . 15
3.2 Language Settings . . . . . . . . . . . . . 16
3.3 Advanced Settings . . . . . . . . . . . . . 16
3.4 Browse System Information. . . . . . . . . . 16
3.5 Browse Logs . . . . . . . . . . . . . . . . 17
3.6 Using USB . . . . . . . . . . . . . . . . . 17
4 Other Functions 18
4.1 Routine Operation Indications . . . . . . . . 18
4.2 Administartor Loss Prevention. . . . . . . . . 19
4.3 Battery Low Voltage . . . . . . . . . . . . 19
4.4 Auto Program Exit / Power Off . . . . . . . . 19
4.5 Unlock with Emergency Key . . . . . . . . . 20
5 Appendix 19
5.1 Technical Specifications . . . . . . . . . . . 19
Table of contents
2

Summary
* Ensure to be farmiliar
with all the componenets
before installation
* Do not install in direct
sunlight or bright light
* 0–50°C for optimal perfor-
mance
1. Instructions
1.1 Introduction to L7000
• By leveraging the perfect combination of biometrics and cryptography, our fin-
gerprint locks ensure double security through the fingerprint + password unlocking
feature.
• The state-of-the-art Organic LED (OLED) display affords crisp bright readouts and
makes our fingerprint locks intuitive and easy to use. You can simply use our finger-
print locks with ease after following the operation instructions for once.
• Support setting of classified privileges for super administrators, administrators and
ordinary users.
• Support deletion of all or the specified registration data.
• Support firmware upgrade and uploading/downloading of user information and
locking records through a USB pen drive.
• Support offline view of locking records.
• Support accurate display of time and date with annual deviation less than two-
minutes.
• Support a temporary connection with back-up batteries.
• You can set the fingerprint locks to be in the Normally Open (NO) state in special
cases.
• Support display of the battery charge level and generation of low-pressure alarms.
• Feature an electric clutch handle design which helps effectively prevent the fin-
gerprint lock failure caused by damage to the internal structure as a result of the
forced destruction of the handle.
• Single latch lock (support both 60mm and 70mm locks) of American standard sup-
ports deadbolt lock either.
• The max user capacity is 500 fingerprints. The max unlocking record is 30000 logs.
• Unlock mode: fingerprint, password, mechanical key.
1.2 List of Installation Accessories
3

Summary
1.3 Installation Requirements
• The fingerprint lock is applicable to doors of 35–50 mm in thickness. Be sure to list
your special requirements or remarks for fingerprint locks to be installed on doors in
excess of 70 mm in thickness before placing an order.
• Before ordering or installation of single latch lock, please confirm the corresponding
accessories.
• Single latch lock:
Unlock Directional Switch
* Follow these steps for
changing unlock direction
* Ensure environment be-
fore ordering units
4

Summary
* Ensure correct installation
* Take note of tools
* Battery override to be
able to do a biometric
reading
* NOT an administrator
override
• Please confirm the door opening directions. Assume you are standing outside and
facing a door and then there are four door opening directions: Left inward, left out-
ward, right inward and right outward. Left inward/outward means the door swings
inward/outward with hinges on the left; right inward/outward means the door
swings inward/outward with hinges on the right, as shown in the following figure:
• Ensure the central point of the handle is about 1m above the floor.
• Ensure all the accessories installed on the right position.
• Please follow the animated instructions to install fingerprint locks.
Recommended Tools
You may need the following tools while following the instructions to install fingerprint
locks:
• A ruler.
• A marker pen.
• A drilling tool.
• A cross screwdriver.
1.4 Battery Backup
The fingerprint lock supports temporary use of external DC power for fingerprint or
password matching and unlocking, but when connected with an external battery, the
fingerprint lock cannot provide such special functions as enrollment, deletion and set-
ting, so as to prevent data loss as a result of power instability.
As shown in the figure below, connect a 9V battery to the two access points at the bot-
tom of a fingerprint lock, regardless of polarities.
If you power off a fingerprint lock without closing the lock during the use of external
power, the lock cylinder will not automatically return to its original position. That is, the
fingerprint lock remains in NO state. To solve this problem, you can replace the battery
and then verify to open the lock once to have the lock cylinder back position. 5

Summary
* Be farmiliar with the unit
1.5 Front and Rear View
• Number key 1: Press this key to exit current operation, press and hold this key to
power off the fingerprint lock. The number key “1” doubles as ESC key.
• Number key 2: This key is used to manually increase (when held this key, the display
values will rapidly increase) the setup value or navigate among menu options. The
number key “2” doubles as UP key.
• Number key 3: This key is used to manually decrease (when held this key, the dis-
play values will rapidly decrease) the setup value or navigate among menu op-
tions. The number key “3” doubles as DOWN key.
• Menu key (Status indicator): This key can be used to start the fingerprint lock; press
and hold this key for three seconds on the initial interface to open the main menu;
this key also doubles as the confirmation OK key. The green LED indicator blinks
when the fingerprint lock operates properly and the red LED indicator is on for three
seconds if an error occurs. The green LED indicator is on for three seconds when an
operation succeeds.
• Band switch: If you cannot access the menu options due to the loss of administra-
tors for some reason, proceed as follows: Press and hold the Menu key for three
seconds to display the administrator verification, and then turn the Band switch at
the rear of the lock to the left or right to open up the menu as a super administrator.
• OLED display: The black-and-white OLED display features white graphics or text
against a black background.
• Fingerprint sensor: You can only collect or match fingerprints by pressing your
finger(s) at the fingerprint sensor when the light in the fingerprint sensor window goes
on; otherwise nothing happens when you press your finger(s) at the fingerprint sen-
sor.
* Keys on the unit
6

Summary
* Ensure to enrol adminis-
trator for security purposes
* Ensure to use 4x new bat-
teries together and do not
mix with old batteries
Note: When you cannot power off the fingerprint lock due to the exception of program,
press and hold the ESC key to power off and then restart the fingerprint lock. It is not rec-
ommended to power off the fingerprint lock by pressing and holding the ESC key when
the fingerprint lock operates normally.
• Emergency interfaces
Keyhole: You can use a mechanical key for emergency door opening. Temporary exter-
nal power interface: You can adopt an external back-up battery to open the lock in
the event of unlocking failure due to insufficient power supply of the fingerprint lock.
• USB interface
The USB interface is used for firmware upgrade and uploading/downloading of user
information and locking records through a USB pen drive.
1.6 Precautions
• We strongly recommend you to enroll at least one administrator after installing the
fingerprint lock. You must at least enroll one administrator before enrolling ordinary
users.
• Do not remove batteries when matching, enrolling or deleting fingerprints because
the sudden power-down may result in data loss of fingerprint locks. Prior to removing
batteries, make sure the fingerprint lock is not in working state.
• It is recommended to replace the fingerprint lock batteries at least once every six
months to avoid damaging the circuit due to the battery leakage. Do not use bat-
teries with poor quality.
• When installing a fingerprint lock, connect the plug to the socket properly. Improper
connection may lead to fingerprint lock failure.
1.7 User Privileges
The user privileges are classified into three types: Super administrators, administrators
and ordinary users.
• Super administrators: refer to users who have access to all system functions and
modify all system settings.
• Administrators: refer to users who have access to all operations except performing
advanced settings and enrolling super administrators.
• Ordinary users: refer to all users other than the super administrators and administra-
tors. Ordinary users only have access to the fingerprint matching and unlocking
functions.
1.8 Set Time
You need to set the correct date and time on first use of a fingerprint lock in the follow-
ing steps:
* Enrol correct people on
correct levels to ensure
security of the unit
* Correct Date and Time
are neccesary before
operating
7
1) Power on the fingerprint lock by pressing the
Start key to open up the initial interface, as shown
in the figure on the left.
Note: The “BATTERY ” icon on the initial interface
is the battery icon indicating how much charge
remains. On the top right corner of the initial inter-
face, the display alternates between date and
time every 5 seconds.

2. Enrolment and Verification
2.1 Enrol an Administrator
If the fingerprint lock has no administrator, you must at least enroll one administrator
before enrolling ordinary users. To enroll an administrator, proceed as follows:
Summary
* Ensure to enrol an admin-
istrator on the unit before
enrolling users
8
2) Press and hold the Menu key for three seconds
to access the menu interface. Press DOWN to
select “Options” and press MENU to display the
setting interface.
3) Press DOWN to select “System Opt.” and then
press MENU.
4) Press MENU to select “Date Time”.
5) To modify date or time, press UP/DOWN to move
the cursor to the desired option, and then press UP/
DOWN again to enter correct date or time. Press
MENU to save your settings.
1) Power on the fingerprint lock by pressing the
Start key to open up the initial interface. Press and
hold the Menu key to display the menu interface.
2) Press MENU to display the user management
interface.
3) Press DOWN to select “Enroll Admin” and then
press MENU.

Summary
2.1.1 Enrol a Fingerprint
Note: The last digit in “00001–0” refers to the fingerprint count. “0” refers to the first finger-
print, “1” refers to the second fingerprint and so on and so forth.
9
4) Press ▼to select “Enroll FP” and then press
MENU.
5) Press ▲/▼to select “Admin Accredit”, and then
select “Supervisor” (Super administrator) or “Ad-
min” (Administrator). Press MENU to confirm your
selection.
6) Press MENU to continue.
7) The system by default assigns unused user IDs
from 00001 and you may also manually enter an
unused user ID.
8) Press the same finger on the fingerprint sensor
three consecutive times by adopting the proper
finger placement mode. The system will prompt
you to save the enrollment information after you
enroll the fingerprint successfully. If enrollment fails,
the system will prompt you to re-enroll your finger-
print.
9) The system will prompt to save the enrollment
information after enrollment successful. If the
enrollment fails, the system will prompt if re-enroll
fingerprint. The system returns to the “New Enroll”
interface upon successful enrollment. You can
continue or exit the fingerprint enrollment.

2.1.2 Enrol a Password
Note: A password consists of 6 to 10 digits. You can enroll only one password
for each user ID and repeated passwords are allowed; otherwise, the system
will display the prompt “Password Error”.
Summary
* Password users can be
enrolled if FP is unavailable
* Take Note
10
4) Press ▼to select “Enroll Pwd” and then press
MENU.
5) Press ▲/▼to select “Admin Accredit”, and then
select “Supervisor” (Super administrator) or “Ad-
min” (Administrator). Press MENU to confirm your
selection.
6) Press MENU to continue.
7) The system by default assigns unused user IDs
from 00001 and you may also manually enter an
unused user ID.
8) Input a password by pressing the number keys
and press MENU to confirm your input.
9) Input the password again by pressing the num-
ber keys and press MENU to confirm your input.
Press MENU after successful password enrollment
to return to the “New Enroll” interface.
10) Press MENU to save the enrolled data and exit
the password enrollment.
