ZKTeco ZK-D1010S User manual

Contents I
Quick Start Guide
Walk Through Metal Detector:
ZK-D1010S
Version: 1.0

Contents
1 ZK-D1010S..............................................................................................1
1.1 Parts............................................................................................. 1
1.2 Installation....................................................................................2
1.3 Technical Parameters................................................................... 3
Contents I

1 ZK-D1010S
1.1 Parts
1.Control Unit Case 2..Power Line Interface
3.Built-in Probe 4. InfraredSensors
5.Waterproof Foot Cover
2
1
3
4
5

1.2 Installation
1. Remove the packageof control unit and door panel.
2. Put the control unit caseand door panels as above picture
shown, and then connect the left and right door panel with the
control unit case by bolts and nuts.Tightening screws.
3. Probe line of the left and right door panel tight inserted into the
motherboard corresponding socket respectively.
4. Install the screws on the control unit case cover.
5. Lift the walk through metal detector to the vertical position and
move to the assigned position.
6. Plug power cable.
2
Left door panel
Right door panel

1.3 Technical Paramenters
Input voltage:100-240V,50/60Hz Power:<30W
Gross weight:55KG
Working temperature: -25℃~ 55℃
Sensitivity: 100 steps adjustable
Alarm:Sound alarm
Inner Dimensions: 1990mm (High) x 700mm (Wide) x 400mm (Deep)
External Dimensions:2215mm (High)x 820mm (Wide) x 475mm (Deep)
