Zline RCIND-24 User manual

INDUCTION COOKTOP
www.zlinekitchen.com
Installation Manual

ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your
dreams is never out of reach. Through our unique designs and unparalleled quality, we’re
dedicated to providing you an elevated experience in the heart of your home. With an
endless selection of features and finishes, our inspiration is your reality.
ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end
luxury designs and professional features into everyone’s homes. Because we continually strive
to improve our products, we may change specifications and designs without prior notice.
WARNING: This product can expose you to chemicals including nickel, which is known to the
State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.

COVERAGE
ZLINE Kitchen and Bath range products will be warrantied for one year from the
original purchase date for the original purchaser of the product. This warranty covers
all parts and labor for necessary repairs if any part of the product proves to be
defective in materials or workmanship. The product must be deemed serviceable via
troubleshooting with the ZLINE Kitchen and Bath service team. All service on ZLINE
Kitchen and Bath range products under the above warranty must be performed by
ZLINE approved and certified service, unless otherwise specified by ZLINE Kitchen
and Bath. Service will be provided during normal business hours.
TERMS
This warranty applies only to the original purchaser of a range product installed for
normal residential use. This is defined as a single-family, residential dwelling in a
non-commercial setting. Commercial settings include but are not limited to: schools,
churches, hotels, restaurants, vacation rentals such as Airbnb, day care centers,
private clubs, fire stations, common areas in multi-family dwellings, nursing homes,
food service locations, and institutional food service locations such as hospitals or
correction facilities. This warranty is non-transferable and will not be extended based
on the date of installation. The warranty applies only to products installed in the
continental United States and the District of Columbia.
Failure to secure certified warranty service per these terms will result in a forfeiture
of the remaining warranty. Out of pocket payments will not be reimbursed unless
prior approval is received from ZLINE Kitchen and Bath and/or our service contract
partner. Unapproved out of pocket payments for service will not be reimbursed. All
warranty procedures must be followed to maintain warranty coverage.
Warranty shall not apply and ZLINE Kitchen and Bath is not responsible for damage
resulting from negligence, improper maintenance, misuse, abuse, alteration of or
tampering with the appliance, accident, natural disaster, improper electric supply,
flare-up fires, unauthorized service or repair, improper installation, or installation not
in accordance with the instructions contained in the manual, or the local codes.
WARRANTY

WHAT IS NOT COVERED
1. Installation or start-up, damages or problems caused by improper
installation or use.
2. Service by an unauthorized service providers or damage related to
unauthorized service or unauthorized parts.
3. Installation in any commercial or non-residential application.
4. Removal or re-installation cost.
5. Aesthetic damage, scratches, or natural wear caused by normal use.
6. Second-hand, open box products or products purchased from an
unauthorized retailer.
NOTE: In the event that service is dispatched, and it is discovered that the reported
issue is not covered under warranty based on the disclaimers above, the customer
will be responsible for all service fees. Failure to pay these fees will result in the
forfeiture of remaining warranty coverage.
WARRANTY

TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS 1
BEFORE INSTALLATION 6
INSTALLATION INSTRUCTIONS 8
TECHNICAL SPECIFICATIONS 13
OPERATION 14
COOKING TIPS AND CARE 26
CARE AND CLEANING 28
TROUBLESHOOTING 29

1
General Safety
WARNING
PLEASE READ THE FOLLOWING INSTRUCTIONS
CAREFULLY BEFORE USING THE APPLIANCE.
• Please make this information available to the person responsible for installing the
appliance as it could reduce your installation costs.
• In order to avoid a hazard, this appliance must be installed according to these
instructions for installation.
• This appliance is to be properly installed and earthed only by a suitably
qualified person.
• Proper installation – Be sure your appliance is properly installed and grounded
by a qualified technician.
• No combustible material or products should be placed on this appliance
at any time.
• Never use your appliance for warming or heating the room.
• Wear proper apparel – Loose-fitting or hanging garments should never be worn
while using the appliance.
• User servicing – Do not repair or replace any part of the appliance unless
specifically recommended in the manual. All other servicing should be referred
to a qualified technician.
• Storage in or on appliance – Flammable materials should not be stored in an
oven or near surface units.
• Do not use water on grease fires – Smother fire or flame or use dry chemical or
foam-type extinguisher.
• Use only dry potholders – Moist or damp potholders on hot surfaces may result
in burns from steam. Do not let potholder touch hot heating elements. Do not use
a towel or other bulky cloth.
• Use proper pan size – This appliance is equipped with one or more surface units
of different size. Select utensils having flat bottoms large enough to cover the
surface unit heating element. The use of undersized utensils will expose a portion
of the heating element to direct contact and may result in ignition of clothing.
Proper relationship of utensil to burner will also improve efficiency.
• Never leave surface units unattended at high heat settings – Boil-over causes
smoking and greasy spillovers that may ignite.
• Make sure reflector pans or drip bowls are in place – Absence of these pans or
bowls during cooking may subject wiring or components underneath to damage.
SAFETY INSTRUCTIONS

2
General Safety
SAFETY INSTRUCTIONS
• Protective liners – Do not use aluminum foil to line surface unit drip bowls or
oven bottoms, except as suggested in the manual. Improper installation of these
liners may result in a risk of electric shock, or fire.
• To reduce the risk of burns, ignition of flammable materials, and spillage due to
unintentional contact with the utensil, the handle of a utensil should be positioned
so that it is turned inward, and does not extend over adjacent surface units.
• Do not cook on broken cooktop – If cooktop should break, cleaning solutions
and spillovers may penetrate the broken cook-top and create a risk of electric
shock. Contact a qualified technician immediately.
• Clean cooktop with caution – If a wet sponge or cloth is used to wipe spills on a
hot cooking area, be careful to avoid steam burn. Some cleaners can produce
noxious fumes if applied to a hot surface.
• Do not place metallic objects such as knives, forks, spoons and lids on the
cooktop surface since they can get hot.
• DO NOT TOUCH SURFACE UNITS OR AREAS NEAR UNITS – Surface units
may be hot even though they are dark in color. Areas near surface units may
become hot enough to cause burns. During and after use, do not touch, or let
clothing or other flammable materials contact surface units or areas near units
until they have had sufficient time to cool. Among these areas are (identification
of areas – for example, the cook-top and surfaces facing the cook-top).
• CAUTION - Light (Error Code) signals a component failure. Disconnect
power supply and call serviceman. Have appliance repaired by a qualified
serviceman before using.
• This appliance should be connected to a circuit which incorporates an isolating
switch providing full disconnection from the power supply.
• WARNING: Use only cooktop guards designed by the manufacturer of
the cooking appliance or indicated by the manufacturer of the appliance in the
instructions for use as suitable or cooktop guards incorporated in the appliance.
The use of inappropriate guards can cause accidents.
• Failure to install the appliance correctly could invalidate any warranty or
liability claims.
• Regarding the details of installation, refer to the section Installation.
• Connect only to a 3-wire, 240-volt power supply; the neutral conductor is not
required for the operation of the appliance. The potential at the power supply
electrical connections shall be 150-volts-to-ground or less.

3
General Safety
SAFETY INSTRUCTIONS
ELECTRICAL SHOCK HAZARD
• Do not cook on a broken or cracked cooktop. If the cooktop surface is break
or crack, switch the appliance off immediately at the mains power supply (wall
switch) and contact a qualified technician.
• Switch the cooktop off at the wall before cleaning or maintenance.
• Failure to follow this advice may result in electrical shock or death.
HEALTH HAZARD
• This appliance complies with electromagnetic safety standards.
HOT SURFACE HAZARD
• During use, accessible parts of this appliance will become hot enough to
cause burns.
• Do not let your body, clothing or any item other than suitable cookware contact
the ceramic glass until the surface is cool.
• Metallic objects such as knives, forks, spoons and lids should not be placed on
the cooktop surface since they can get hot.
• Handles of saucepans may be hot to touch. Check saucepan handles
do not overhang other cooking zones that are on. Keep handles out of
reach of children.
• Failure to follow this advice could result in burns and scalds.
CUT HAZARD
• The razor-sharp blade of a cooktop scraper is exposed when the safety cover is
retracted. Use with extreme care and always store safely and out of
reach of children.
• Failure to use caution could result in injury or cuts.
SAFETY INSTRUCTIONS
• Never leave the appliance unattended when in use. Boil over causes smoking
and greasy spillovers that may ignite.
• Never use your appliance as a work or storage surface.
• Never leave any objects or utensils on the appliance.
• Never use your appliance for warming or heating the room.
• After use, always turn off the cooking zones and the cooktop as described in this
manual (i.e. by using the touch controls).

4
General Safety
SAFETY INSTRUCTIONS
• Do not leave children alone – Children should not be left alone or unattended in
area where appliance is in use. They should never be allowed to sit or stand on
any part of the appliance.
• Do not allow children to play with the appliance or sit, stand, or climb on it.
• Do not store items of interest to children in cabinets above the appliance. Children
climbing on the cooktop could be seriously injured.
• Do not leave children alone or unattended in the area where the appliance is in use.
• Children less than 8 years of age shall be kept away unless continuously
supervised.
• Do not repair or replace any part of the appliance unless specifically
recommended in the manual. All other servicing should be done by a qualified
technician.
• Do not use a steam cleaner to clean your cooktop.
• Do not place or drop heavy objects on your cooktop.
• Do not stand on your cooktop.
• Do not use pans with jagged edges or drag pans across the glass surface as this
can scratch the glass.
• Do not use scourers or any other harsh abrasive cleaning agents to clean your
cooktop, as these can scratch the ceramic glass.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
• This appliance is intended to be used in a domestic household environment only!
Commercial use of any kind is not covered under the manufacturer’s warranty!
• WARNING: The appliance and its accessible parts become hot during use.
• Care should be taken to avoid touching heating elements.
• Children shall not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
• WARNING: Unattended cooking on a cooktop with fat or oil can be
dangerous and may result in fire. NEVER try to extinguish a fire with water, but
switch off the appliance and then cover flame e.g. with a lid or a fire blanket.
• WARNING: Danger of fire: do not store items on the cooking surfaces.
• WARNING: If the surface is cracked, switch off the appliance to avoid
the possibility of electric shock, for cooktop surfaces of glass-ceramic or similar
material which protect live parts.
• The appliance is not intended to be operated by means of an external timer or
separate remote-control system.

5
Disposal
SAFETY INSTRUCTIONS
This appliance is labeled in compliance with European directive
2012/19/EU for Waste Electrical and Electronic Equipment
(WEEE). By ensuring that this appliance is disposed of correctly,
you will help prevent any possible damage to the environment
and to human health, which might otherwise be caused if it were
disposed of in the wrong way.
The symbol on the product indicates that it may not be treated as
normal household waste. It should be taken to a collection point
for the recycling of electrical and electronic goods.
This appliance requires specialist waste disposal. For further
information regarding the treatment, recover and recycling of this
product please contact your local council, your household waste
disposal service, or the shop where you purchased it.
For more detailed information about treatment, recovery and
recycling of this product, please contact your local city office,
your household waste disposal service or the shop where you
purchased the product
DISPOSAL:
Do not dispose
this product
as unsorted
municipal waste.
Collection of
such waste
separately for
special treatment
is necessary
All range products carry a one-year parts warranty and if appropriate, service. If
you experience any issues with your product, contact us directly at 1-614-777-5004.
The ZLINE customer service team is ready to work on resolving your issues and
assessing if service is required. All service repairs should only be conducted by an
industry professional with PRIOR approval from the ZLINE customer service team.

6
Product Dimensions
BEFORE INSTALLATION
RCIND-24
RCIND-30
RCIND-36

7
Electrical Connection
ELECTRIC POWER RATING
Voltage: 240 volts
Frequency: 60 Hz
RCIND-24 RCIND-30 RCIND-36
Amperage 30A 30A 40A
Reccommended circuit 40A 40A 50A
Wattage 7200W 7200W 9300W
BEFORE INSTALLATION
1500W
1500W
1500W
1500W
1200W
1200W
1200W
1200W
2300W
2300W
2300W
3000W
2100W
2100W
2100W
2100W
1800W
1800W
1800W
1800W
3700W
3700W
1500W
1500W
1200W
1200W
B
RCIND-24
RCIND-36
RCIND-30
BOOST
BOOST
BOOST
BOOST
BOOST
BOOST
BOOST
BOOST
BOOST

8
INSTALLATION
Wiring
POWER SHARING
Power sharing happens when the total amount of watts is above the rated wattage,
which is 7200W for RCIND-24 and RCIND-30 and 9300W for RCIND-36. Max
watts is the first number in the diagram to the left and Boost watts is second number.
Power levels 3 through 9 will use the max watts on the burner being used. When
using three burners at once above power level 3 and then adding a fourth on Boost,
this will combine the total wattage being used above the rated 7200W. Power
sharing will activate and will make the total watt usage 7200W, thus it will drop that
Boost level to 9 instead and show the change on the display panel.
CONNECTING THE COOKTOP TO THE MAIN POWER SUPPLY
The power supply should be connected in compliance with the relevant standard, or
a single-pole circuit breaker. The method of connection is shown as below.
If the cable is damaged or needs replacing, this should be done by an after sales
technician using the proper tools, so as to avoid any accidents.
• If the appliance is being connected directly to the mains supply, an omnipolar
circuit breaker must be installed with a minimum gap of 0.12" between
the contacts.
• The installer must ensure that the correct electrical connection has been made
and that it complies with safety regulations.
• The cable must not be bent or compressed.
• The cable must be checked regularly and only replaced by a proper
qualified person
NOTE: If your house has a 4 wire system, under no circumstances should the neutral
line be connected to ground, as it may result in injury and fire.
Cable from home
power supply
Yellow/Green ground wires
Green ground wires
Red wires White wires
3-wire cable
from cooktop
Black
wires
Black
wires
Cable from home
power supply
3-wire cable
from cooktop
Yellow/Green ground wires
Green ground wires
Red wires
Black
wires
Black
wires

9
INSTALLATION
Ventilation
WARNING: To eliminate the risk of burns or fire by reaching over
heated surface units, cabinet storage space located above the surface units
should be avoided. If cabinet storage is to be provided, the risk can be reduced
by installing a range hood that projects horizontally a minimum of 5" beyond the
bottom of the cabinets.
Minimum spacings drawings (General requirement):
1
6
3
5
A
7
4
21. Building back wall
2. Top building cabinet
3. Control panel
4. Cooking surface
5. Building side wall
6. Base
7. Building side wall
A = 30" minimum clearance between the top of the cooking surface and the bottom
of an unprotected wood or metal cabinet; or A = 24"minimum when bottom of wood
or metal cabinet is protected by not less than 1/4" thick flame retardant millboard
covered with not less than No. 28 MSG sheet steel, 1/64" thick stainless steel,
1/32" thick aluminum, or 1/32" thick copper
ROOM VENTILATION
The use of this appliance generates heat and humidity in the room where it is installed.
Proper ventilation in the room is needed. Make sure the kitchen is equipped with a
range hood of appropriate power (400 CFM minimum). Activate the exhaust fan/
range hood when possible. Intensive and continuous use of the appliance may
require additional ventilation, for example by opening a window.

10
Cutout Dimensions
INSTALLATION
SELECTION OF INSTALLATION EQUIPMENT
• Cut out the work surface according to the sizes shown in the drawing.
• For the purpose of installation and use, a minimum of 1 31/32" space shall be
preserved around the hole.
• Be sure the thickness of the work surface is at least 1 3/16". Please select heat-
resistant work surface material to avoid larger deformation caused by the heat
radiation from the hotplate. As shown below: The work surface material must use
the impregnated wood or other insulation material.
• Ensure the table supporting the surface unit on the metal frame edge,
see drawing below
W
L
H
X
B
XX
A
X
D
SEAL
Under any circumstances, make sure the cooktop is well ventilated and the air inlet and
outlet are not blocked. Ensure the cooktop is in good work state. As shown below.
D
C
B
A
E
A B C D E
30" 2 31/
32” Mini 13/ 16” Mini Air Intake Air exit

11
Installation Notes
INSTALLATION
BEFORE YOU INSTALL THE COOKTOP, MAKE SURE THAT
• The work surface is square and level and no structural members interfere with
space requirements.
• The work surface is made of a heat-resistant material.
• If the cooktop is installed above an oven, the oven has a built-in cooling fan.
• The installation will comply with all clearance requirements and applicable
standards and regulations.
• A suitable isolating switch providing full disconnection from the mains power
supply is incorporated in the permanent wiring, mounted and positioned to
comply with the local wiring rules and regulations.
• The isolating switch must be of an approved type and provide a 0.12" air gap
contact separation in all poles (or in all active [phase] conductors if the local
wiring rules allow for this variation of the requirements).
• Consult local building authorities and by-laws if in doubt regarding installation.
• Use heat-resistant and easy-to-clean finishes (such as ceramic tiles) for the wall
surfaces surrounding the cooktop.
WHEN YOU HAVE INSTALLED THE COOKTOP, MAKE SURE THAT
• The power supply cable is not accessible through cupboard doors or drawers.
• There is adequate flow of air from outside the cabinetry to the base of the
cooktop.
• If the cooktop is installed above a drawer or cupboard space, a thermal
protection barrier is installed below the base of the cooktop.
• The isolating switch is easily accessible by the customer.
BEFORE LOCATING THE FIXING BRACKETS
The unit should be placed on a stable, smooth surface (use the packaging). Do not
apply force onto the controls protruding from the cooktop.

12
Installation Checklist
INSTALLATION
LOCATING THE FIXING BRACKETS
• Fix the cooktop on the work surface by screw four brackets on the bottom of
cooktop (see picture) after installation.
• Adjust the bracket position to suit for different work surface’s thickness.
Table
Hob
Bracket
Table
Hob
Bracket
CAUTIONS
• Cooktop must be installed by qualified personnel or technicians. Please never
conduct the operation by yourself.
• Cooktop shall not be mounted to cooling equipment, dishwashers, or rotary dryers.
• Cooktop shall be installed such that better heat radiation can be ensured to
enhance its reliability.
• The wall and induced heating zone above the work surface shall withstand heat.
To avoid any damage, the layers and adhesive must be resistant to heat.
• A steam cleaner is not to be used.
• This ceramic can be connected only to a supply with system impedance no more
than 0.427 ohm. In case necessary, please consult your supply authority for
system impedance information.
AFTER INSTALLING THE COOKTOP
1. Remove all the stickers and items from the top of the cooktop surface.
2. Clean cooktop before use. Dry with a soft cloth. See Maintenance and Cleaning
for reference.
3. Read Operation.
4. Turn on the power to the cooktop.
5. Verify all function operation properly.
NOTE: If the cooktop does not work or you meet any problem in your operation,
please check that the circuit breaker has not tripped or the fuse has not blown. For
more information, please See Troubleshooting. If the problem cannot be resolved,
call ZLINE at 1-614-777-5004.

13
Product Specifications
Induction Cooktop RCIND-24
Cooking Zones 4 Zones
Supply Voltage 240V~ 60Hz
Installed Electric Power 7200W
Product Size WxDxH (in) 24 x 20 1
/
2x 2 5
/
16
Building-in Dimensions 22 1 /
16 x 19 5
/
16
Induction Cooktop RCIND-30
Cooking Zones 4 Zones
Supply Voltage 240V~ 60Hz
Installed Electric Power 7200W
Product Size WxDxH (in) 30 x 21 x 2 5
/
16
Building-in Dimensions 28 3/
4x 19 5
/
16
Induction Cooktop RCIND-36
Cooking Zones 5 Zones
Supply Voltage 240V~ 60Hz
Installed Electric Power 9300W
Product Size WxDxH (in) 36 x 21 x 2 5
/
16
Building-in Dimensions 33 7/
8x 19 5
/
16
OPERATION

14
24" Surface Burner Layout
RCIND-24
1
2
3
4
5
B
1. Left front cooking element
2. Left back cooking element
3. Right rear cooking element
4. Right front cooking element
5. Touch control panel
OPERATION
B
15 4223
6 6
1. ON/OFF switch
2. Select power level
3. Setting the timer
4. Child lock
5. Boost control
6. Heating zone
