Znewtech Digital Column Bathroom Scale User manual

Digital Column Bathroom Scale
User Manual
Z
Z N E W T E C H

LCD Display
Stand Pole
Stand Pole
Stand Base
Screws
Pole Connector
Wire Connectors
1
2
7
3
4
5
6
8 Scale Platform
Getting to know your Znewtech Scale
1

Step-by-Step Assembly Instructions
Required Tool:
Philips screwdriver (not included)
Parts Listing:
A Scale Base (1 Unit) Stand poles (2 Units)
B C Display (1 Unit)
D Pole Connector (1 Unit) E Screws (6 Units)
Assembly will take 10-20 minutes
2

Lay down all the parts on the floor as shown below
Single screw hole ends
Both single screw holes need to face down
1
Two screw holes ends
3

Connect a stand pole with the stand base
2
Align the two screw holes on the stand pole
with the two slots on the stand base, and push
the stand pole into the stand base firmly.
Run the wire from stand base through a stand pole
4

Connect a stand pole with the scale display
The single screw hole faces down
3
Run the wire from scale display through a stand pole
Align the two screw holes on the stand pole
with the two slots on the display, and push
the stand pole into the display firmly.
5

Insert the pole connector and connect two wires
4
Align the slot on the pole connector
with the screw hole on the stand
pole , and push the pole connector
into the stand pole firmly
Connect the two wires
together
6

Connect two stand poles together
5
Push the stand pole into
the pole connector firmly
7

Install batteries
6
Install 4 AAA batteries into the
battery compartment on the
bottom of scale platform
8

Finish assembly
7
Hold up the scale to
stand-up position and
fasten all 6 screws
Use the scale on a hard, level and even surface (no carpeting).
Inconsistent and soft surfaces will cause inaccurate measurements.
Troubleshooting
How to reset the scale?
1) Uninstall batteries
2) Wait for one hour
3) Reinstall batteries
Screw
Screw
Screw
Screw
Screw
Screw
Need Help?
[e-mail]
9

1. Press the Unit Set Switch located on the back of the scale LCD Display to select the unit
(kg/lb/st) that you want to set. The stone (st) is a unit of measure equal to 14 pounds (lb)
avoirdupois, or 6.3503 kilograms (kg).
2. The unit changes each time the set switch is pressed.
Setting Units
Unit Set Switch
10

Measuring Your Weight
1. Place the scale on the hard and flat surface.
2. Step on the scale platform, the scale stand pole can be tilted forward up to 15°. Remain
still and the scale will count up to your weight. The display will flash twice when the
weight is locked.
3. Your weight will be displayed for about 10 seconds, and then the scale turns off
automatically.
11

The “LO” indicates the battery power is
low. Please change new batteries.
The “Err” indicates overload.
Maintenance
Warranty
One-Year Limited Warranty
Contact us for questions or returns:
[e-mail]
Capacity: 440 lbs (200 kg)
Weight Increments: 0.2 lbs (100 g)
Switch-on Over: 3kg / 6lbs
Power Source: 4 AAA batteries
Unit Modes: kg/lb/st
Platform Size: 12" x 12" (31 cm x 31 cm)
Scale Height: 40 " (100 cm)
Low Battery and Overload Indication
Specifications
Support
Please visit our website www.znewtech.com
for more information about the product.
Contact us at [email protected].
