Zonet ZVC7640W Operation manual

PRODUCT DATA
H.264/1.3Mega Pixels
Wireless IP Camera
ZVC7640W
Features:
Micron 1/3”1.3mega pixels CMOS
Sensor
Up to 15fps at 1280 x 1024 resolution
(both MJPEG and H.264)
Triple-stream, H.264, MJPEG & 3GPP
simultaneously
Support E-PTZ
Support 3GPP mobile surveillance via
3G Mobile phone or PDA
Night Function---effective range
up to 20M
Advanced encryption mode WPA2-PSK
The Zonet ZVC7640W Wireless IP Camera
W
is a latest triple-stream
(H.264,MJpeg,3GPP) internet camera. ZVC7640 can connect directly to an Fast Ethernet
network with simple installation. You can easily and quickly set up a comprehensive surveillance
solution within your network.
54
Mbps
Detection
Motion
1.3Mega
Pixel
Osram IR module
(20M)
1.3M Pixels
Carbon FiberPlate
H.264
MJPEG
3GPP

Specification
*Maximum wireless signalrate derived fromIEEE 802.11b/g specifications.Actual data throughput will
vary from volume ofnetwork traffic, buildingmaterials and construction,and network overhead,
lower actual datathroughput rate.
Zonet is a registered trademark.Other Brands and product namesare trademarks of their respectiveholders. Information provided in thisdocument pertains to
Zonet products and issubject to change atany time, without notice.For the most recentproduct information please visit
http://www.zonetusa.com
Copyright© Zonet. All Rights Reserved.
Contact Us:
1.888.883.8880
[email protected]
www.zonetusa.com
Related Products:
ZVC7640
ZVC7631W
ZVC7631
ZVC7611
ZVC7611W
ZVC7100
ZVC7500
One ZVC7640W
One Quick InstallationGuide
One Installation CDw/Manual
One PowerAdapter
One Camera Stand
One Ethernet Cable
Package content:
Zonet USA Corporation
18513 East Gale Ave. City of Industry, CA 91748
Tel: [phone] Fax: [phone]
Image Sensor
Lens
Image Processing
Image Sensor
Resolution
Minimum Illumination
Lens Type
Aperture (F/No.)
Focus Length
View Angle (Diagonal)
Compression
Auto Exposure Control
Auto White Balance
Auto Gain control
Upside down and Mirror
Image Resolution and Frame rate
Frame rate setting
Image setting
Network Processor
System ROM
System RAM
Browser
Supported OS
H.264/1.3M Pixels IP Camera
Wireless Pan&Tilt IP Camera
Pan&Tilt IP Camera
IP Camera
Wireless IP Camera
480k USB Web Camera
1.3M USB Web Camera
Micron 1.3Mega pixels 1/3" Color CMOS Sensor
1280x1024
0 Lux (IR On) effective range up to 20M
Board Lens
2.0
6mm
53
H.264/1.3Mega Pixels
Wireless IP Camera
ZVC7640W
H.264 / MJPEG / 3GPP Triple Streaming
Yes
Yes
Yes
Yes
15fps@1280 x 1024
Auto, Manual(10,15,20,25,30fps)
Brightness, Sharpness, Saturation
ARM9 base
8MByte NOR Flash
64MByte SDRAM
Internet Explore 6.0 and above
Apple Safari 2 and above
Mozilla Firefox 2.00 and above
Windows 2000/XP/Vista/7, Macintosh 10.0 and above, Linux2.6.14

Specification
*Maximum wireless signalrate derived fromIEEE 802.11b/g specifications.Actual data throughput will
vary from volume ofnetwork traffic, buildingmaterials and construction,and network overhead,
lower actual datathroughput rate.
Zonet is a registered trademark.Other Brands and product namesare trademarks of their respectiveholders. Information provided in thisdocument pertains to
Zonet products and issubject to change atany time, without notice.For the most recentproduct information please visit
http://www.zonetusa.com
Copyright© Zonet. All Rights Reserved.
Contact Us:
1.888.883.8880
[email protected]
www.zonetusa.com
Related Products:
ZVC7640
ZVC7631W
ZVC7631
ZVC7611
ZVC7611W
ZVC7100
ZVC7500
One ZVC7640W
One Quick InstallationGuide
One Installation CDw/Manual
One PowerAdapter
One Camera Stand
One Ethernet Cable
Package content:
Zonet USA Corporation
18513 East Gale Ave. City of Industry, CA 91748
Tel: [phone] Fax: [phone]
H.264/1.3M Pixels IP Camera
Wireless Pan&Tilt IP Camera
Pan&Tilt IP Camera
IP Camera
Wireless IP Camera
480k USB Web Camera
1.3M USB Web Camera
H.264/1.3Mega Pixels
Wireless IP Camera
ZVC7640W
Application Software
Communication
Software
Other
Ethernet
Wireless
Supported Protocols
Frequency
output transmit power
Night vision
LED control
Digital Zoom
Antenna
Antenna Gain
Compression Ratio Setting
IP Setting
Email
Time Management
Event Management
FTP Upload
Device Configuration
User Administration
System log
Dimension (L x W x H)
One RJ45 port; IEEE 802.3u compliant 10/100 Mbps Fast Ethernet with Auto-MDIX
IEEE802.11b/802.11g Wireless LAN
HTTP, TCP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, UPnP, Bonjour, DDNS, IEEE802.1X,
WPA2-PSK
2.412GHz~2.472GHz
IEEE802.11b 17dBm@MAX ; IEEE802.11g 15dBm@MAX
View channel:16 Chs ; Manual/Schedule Record
Video Playback/Stop/Forward/Pause ; Motion detect
Military standard Osram IR LED x 2
Normal / Always On / Off
4X
External Dipole Antenna
2dBm@MAX
3 levels setting :Standard / Good / Hi
Static / PPPoE / DHCP
SMTP
NTP / RTC / Sync with PC / Manual
FTP, Email, Recording
Yes
Backup/Restore to/from Configuration file
Password protected and 3 levels of Authorization:
Admin: Full-function control
User: Full-function control except Maintenance(firmware upgrade)
Viewer: Only Viewing
1000 items (max.) store in SDRAM
93mm x 55mm x 32mm (Device only)
119mm x 63mm x 32mm (IR Module attached)
