ZoneVu ZoneVu ZPD Series User manual

ZPD - n
PERIPHERAL DRIVERS
USERS MANUAL

ISSUE 02
MEYERTECH LIMITED
CONTENTS
1. WELCOME 3
2. FEATURES 3
3. PRODUCT SUPPORT 3
3.1 MULTIPLEXERS 3
3.2 VCR’S 4
3.3 DIGITAL TRANSMISSION EQUIPMENT 4
4. INSTALLATION 5
4.1 MUX DRIVERS 6
4.3 VCR DRIVERS 8
4.5 FAST SCAN DRIVERS 9
5. CONFIGURATION 10
6. TECHNICAL SUPPORT 11
7. TROUBLE SHOOTING GUIDE 11
8. SPECIFICATIONS 12
9. DECLARATION OF CONFORMITY 13
10. PRODUCT WARRANTY 14
11. DOCUMENT HISTORY 15
Whilst every effort has been made to confirm the information in this document is correct,
MEYERTECH LIMITED cannot accept any liability for any errors, omissions and or incorrect
information contained within this document.
No part of this document may be reproduced or distributed in any form or by any means
without prior written consent from MEYERTECH LIMITED.
MEYERTECH LIMITED are committed to continuous product development and therefore reserve
the right to change specifications without notice.
1998 ALL RIGHTS RESERVED.

ISSUE 02
MEYERTECH LIMITED
1. WELCOME
Thank you for purchasing your ZoneVu driver ZPD-n.
The ZVD-n range of products offers an integrated solution to CCTV control systems. Eliminating the
need for additional keyboards, Multiplexers, VCR’s and digital transmission equipment can all be
controlled from MEYERTECH’s range of operator keyboards.
This is achieved through intelligent RS422 to RS-232 interfaces.
MEYERTECH are dedicated to customer service and support. If you have any questions or problems,
our staff will be pleased to assist you on the technical help line listed on page 20.
Information regarding other MEYERTECH products and technical information can be found on the
MEYERTECH world wide web site by pointing your Internet browser to :
http://www.meyertech.co.uk
2. FEATURES
♦ RS422 Input
♦ RS422 Output
♦ 2 x RS232 Outputs
♦ Relay Contact (VCR triggering …etc)
♦ ZoneVu compatible software for VCR and Multiplexer control.
♦ 9 Pin DIN plug (RS422 input/output)
♦ 9 Pin Din plug (RS232 outputs & relay contact)
♦ Software Drivers for MUX, VCR’s & Fastscan’s.
3. PRODUCT SUPPORT
3.1 MULTIPLEXERS
MEYERTECH currently offer support for the following Multiplexer products.
• Dedicated Micros Series 2
• Tecton Drax
• Robot MV200, MV90 and MV90e
Additional drivers may be available.
MAN-ZPD

ISSUE 02
MEYERTECH LIMITED
3.2 VCR’S
MEYERTECH offer support for the following VCR products.
• Mitsubishi HS-S5600E(RS)A & HS-S5600E(BRS)A
• Sony SVP1000P
Additional drivers may be available.
3.3 DIGITAL TRANSMISSION EQUIPMENT
MEYERTECH offer support for the following digital transmission products.
• Adpro Fastscan VST10
Additional drivers may be available.

ISSUE 02
MEYERTECH LIMITED
4. INSTALLATION
Unpack the ZPD and check against the list below.
♦ ZPD Protocol converter box.
♦ 12Vdc Power Cube.
♦ Connectors.
To obtain the optimum performance from your ZPD please take time to read this manual before
commencing installation. If you have any questions or problems our staff will be pleased to assist you
on the technical help lines listed on page 20.
Connect up the ZPD in accordance with the accompanying wiring diagrams, paying particular attention to the
maximum ratings and the notes below.
• The ZPD must always be powered from a 12Vdc supply.
• Always use screened cables for low voltage and signal cables ensuring the screen is
connected to Earth (0v) at both ends of the cable run.
• The maximum cable run for twisted pair RS422 is 2Km.
WARNING THIS EQUIPMENT MUST BE EARTHED TO PREVENT FIRE OR
SHOCK HAZARD. DO NOT EXPOSE THIS EQUIPMENT TO RAIN
OR MOISTURE.
ZoneVu RS-422
Keyboard Network
ZPD-n
Equipment
RS-232
Interface
Tx+ Rx+Tx- Rx-
Tx+Rx+ Tx-Rx-
TxRx
RxTx
N.C. N.C.
Pin 2 Pin 1
Pin 2
RS-422
Interface
Pin 3Pin 5
Gnd
Gnd
Gnd
Gnd
Pin 5
MAN-ZPD

ISSUE 02
MEYERTECH LIMITED
4.1 MUX DRIVERS
4.11 DEDICATED MICROS
Type : Series 2
Features
• Full Screen (with camera selection)
• Multi-screen
• Picture in Picture
• Activity
• Live
• Hold
• Encode
• Decode
• Time/Date synchronization at 12:00hrs (ver. 4 onwards)
Interface : RS232, 1200 baud.
123
6
45
789
Tx Rx 0V
ZPD RS232
3
2
5
4.12 TECTON
Type : Drax
Features
• Full Screen (with camera selection)
• Quad screen format
• Multi screen modes
• VCR Mode
• Freeze On/Off
• Play
• Record
• Time/Date synchronization at 12:00hrs (ver. 1 onwards)
Interface : RS232, 9600 baud.

ISSUE 02
MEYERTECH LIMITED
123 64 5 7 8 910111213
22 23 24 2514 15 16 17 18 19 20 21
Tx Rx 0V
ZPD RS232
3
2
5
4.13 ROBOT
Type : MV200
MV90
MV90e
Features
• Full Screen (with camera selection)
• 3x3 display
• Picture in Picture
• Activity
• Live
• Sequence
• Encode
• Decode
• Time/Date synchronization at 12:00hrs (ver. 1 onwards)
Interface : RS232, 1200 baud.
123 64 5 7 8 910111213
22 23 24 2514 15 16 17 18 19 20 21
Tx Rx 0V
ZPD RS232
3
2
5
MAN-ZPD

ISSUE 02
MEYERTECH LIMITED
4.3 VCR DRIVERS
4.31 MITSUBISHI
Type : HS-S5600E(RS)A
HS-S5600E(BRS)A
Features
• Rewind Tape
• Fast Forward Tape
• Pause
• Stop
• Play
• Record
• Time/Date synchronization at 12:00hrs (ver. 2 onwards)
Interface : RS232, 1200 baud.
123 64 5 7 8 910111213
22 23 24 2514 15 16 17 18 19 20 21
Tx Rx 0V
ZPD RS232
3
2
5

ISSUE 02
MEYERTECH LIMITED
4.32 SONY
Type : SVP1000P
Features
• Rewind Tape
• Fast Forward Tape
• Pause
• Stop
• Play
• Record
Interface : RS232, 1200 baud.
123
6
45
789
Tx Rx 0V
ZPD RS232
3
2
5
Note : Optional SVT-RS1A board is required.
MAN-ZPD

ISSUE 02
MEYERTECH LIMITED
4.5 FAST SCAN DRIVERS
4.51 ADPRO
Type : VST10
Features
• Normal Mode
• PTZ Mode
• Focus Mode
ZPD-3
RJ11
Socket
Keyboard Lead
Adpro VST10
232 Data Port
RS232 Port
Channel 1 Channel 2
Printer / Computer
Interface
N.B. The Address selection switches for this interface, select the Monitor number. To control
the Adpro, the keyboard must have the same Monitor selected.
Interfaces : Data channel : RS232, 9600 baud (ZPD-3 Channel 1)
123
6
45
789
Tx Rx 0V
ZPD RS232
32 5

ISSUE 02
MEYERTECH LIMITED
Printer / Computer Interface – RS232, 9600 baud (ZPD-3 Channel 2)
9
123
6
45
789
Tx Rx 0V
ZPD RS232
5
5. CONFIGURATION
The unit has two rotary switches located on the underside of the unit.
5.1 SETTING THE ADDRESS
This switch setting assigns a unit number address allowing a ZoneVu keyboard to talk to an individual unit and
hence the MUX or VCR device. Note setting 1 = Address 1 and setting 0 = Address 16.
5.2 SETTING THE PROTOCOL
This setting determines the protocol transmitted to the connected device i.e. Setting 1 = Mitsubishi VCR protocols.
For a full list of Device drivers available see label attached to the underside of the unit.
MAN-ZPD

ISSUE 02
MEYERTECH LIMITED
6. TECHNICAL SUPPORT
MEYERTECH are dedicated to customer service and support. If you have any questions or problems,
our staff will be pleased to assist you on the technical help lines listed on page 20.
A list of equipment manufactures contact numbers and technical help lines is listed below.
Dedicated Micros
[phone]
[phone]
Mitsubishi
[phone]
[phone]
Robot
[phone]
[phone]
[phone] (Technical Direct)
Sony (Broadcast & Professional Europe)
[phone]
[phone]
Tecton
[phone]
[phone]

ISSUE 02
MEYERTECH LIMITED
7. TROUBLE SHOOTING GUIDE
This Trouble Shooting Guide should be used in the first instance of encountering any problems with
your ZPD-1. If problems persist, contact MEYERTECH on the Technical Help line numbers given on
page 20.
Symptom Solution
Control ok but no Make sure unit is connected to Transmit pair on
time and date sync the keyboard network.
MAN-ZPD

ISSUE 02
MEYERTECH LIMITED
8. SPECIFICATIONS
8.1 ELECTRICAL
POWER INPUT - 12Vdc
CURRENT CONSUMPTION - 35 mA
RELAYS - 5A max
8.2 PHYSICAL
DIMENSIONS - 155 x 125 x 40 (W x D x H in mm)
WEIGHT - 260 gramms max
TEMPERATURE - Operational 0 degrees to 40 degrees C
- Storage minus 20 Degrees to plus 60 Degrees C.
- Humidity 10% to 95% (Non-condensing)

ISSUE 02
MEYERTECH LIMITED
9. DECLARATION OF CONFORMITY
EC DECLARATION OF CONFORMITY ACCORDING
TO ARTICLE 10 OF COUNCIL DIRECTIVE 89/336/EEC
Manufacture’s Name: MEYERTECH LIMITED
Manufacture’s Address: MEYERTECH Limited
OfficeBlockOne
Southlink Business Park
Oldham
OL41DE
declares, that the product(s):
Product Name(s): ZPD-1
Model(s) : All
Product Options : All
conforms to the following Product Specifications :
EN55022 CLASS B
EN50093
EN60950 Amendments 1, 2, & 3 1992
Supplementary Information :
MEYERTECH declare under our sole responsibility that the product to which this declaration
relates, is in conformity with the protection requirements of council directive 89/336/eec on
the approximation of the laws of the member states relating to electromagnetic compatibility,
when installed in accordance with the instructions given in this manual.
SIGNED -
S K MEYERS
DirectorMEYERTECH LIMITED
ISSUED THIS DAY : 1st May 1998
European Contact : Meyertech Limited (Head Office), Office Block One,
Southlink Business Park, Oldham, England, OL4 1DE.
MAN-ZPD

ISSUE 02
MEYERTECH LIMITED
10. PRODUCT WARRANTY
MEYERTECH LIMITED warrants that at the time of shipment the products manufactured by
Meyertech will be free from defects in material and workmanship.
Should any defects appear within twelve months from date of shipment, Meyertech Limited shall at it’s
sole discretion repair or replace the defective material. Such material shall not be accepted for return
or repair without prior notification of Meyertech Limited.
Return shipments to Meyertech Limited shall be at the customer’s expense. Meyertech Division will
return said equipment prepaid via best way.
This warranty is in lieu of and excludes any and all other expressed or implied warranties of
merchantability or fitness, or otherwise. Items manufactured by any supplier other than Meyertech
Limited shall bear only the warranty made by the manufacturer of that product, and Meyertech
Division assumes no responsibility for the performance or reliability of that product.
Meyertech Limited will not be liable for any special or consequential damages, or for loss, damages,
or expense directly or indirectly arising from the use of the products, or any inability to use them either
separately or in combination with any other equipment or material or from any other cause.
This warranty does not extend to any product manufactured by Meyertech Limited which has been
subject to misuse, neglect, accident, war, civil disturbance, terrorist acts, improper installation, act of
God, or in violation of the instructions supplied by Meyertech Limited.

ISSUE 02
MEYERTECH LIMITED
11. DOCUMENT HISTORY
ZoneVu Peripheral Drivers Users Manual : MAN-ZPD.
ISSUE DATE CHANGE RECORD
01 1 July 1998 First Issue
02 30 October 1998 Updated for new hardware, added Adpro interface
MAN-ZPD

ISSUE 02
MEYERTECH LIMITED
NOTES

ISSUE 02
MEYERTECH LIMITED
MAN-ZPD
ISSUE 02
MEYERTECH LIMITED
MAN-ZPD
NOTES

ISSUE 02
MEYERTECH LIMITED
