ZoneVu ZoneVu ZVD-GW1-STR User guide

ZVD-GW1-STR
STAR DOME INTERFACE
INSTALLERS MANUAL

MEYERTECH DIVISION
ISSUE 01
CONTENTS
1. PRODUCT WELCOME 3
2. PRODUCT SUPPORT 3
3. FEATURES 3
4. INSTALLATION 4
4.1 CONNECTING THE TELEMETRY DISTRIBUTION 4
5. CONFIGURATION 5
6. OPERATION 6
6.1 PRESETS 6
6.2 TOURS 6
6.3 SPECIAL FUNCTIONS 6
6.3.1 FLIP 6
6.3.2 STORE TO EEPROM 6
6.4 GLOBAL COMMANDS 7
6.5 OPERATIONAL NOTES 7
7. SPECIFICATIONS 8
8. TROUBLE SHOOTING GUIDE 9
9. DECLARATION OF CONFORMITY 10
10. PRODUCT WARRANTY 11
11. DOCUMENT HISTORY 12
Whilst every effort has been made to confirm the information in this document is correct,
MEYERTECH DIVISION cannot accept any liability for any errors, omissions and or incorrect
information contained within this document.
No part of this document may be reproduced or distributed in any form or by any means
without prior written consent from MEYERTECH DIVISION.
MEYERTECH DIVISION are committed to continuous product development and therefore
reserve the right to change specifications without notice.
1997 ALL RIGHTS RESERVED.
Page 2 MAN-GW1-STRhttp://www.meyertech.demon.co.uk

ISSUE 01
MEYERTECH DIVISION
1. PRODUCT WELCOME
Thank you for purchasing a ZoneVu 3rd Party dome interface.
In conjunction with the ZoneVu DVK-001 keyboard and an extensive range of 3rd Party Domes, the
ZVM-328 provides a complete and powerful retail solution.
This Manual should be used in conjunction with the standard ZoneVu Matrix and Keyboard manuals.
MEYERTECH are dedicated to customer service and support. If you have any questions or problems,
our staff will be pleased to assist you on the technical help line listed on page 16.
Information regarding other MEYERTECH products and technical information can be found on the
MEYERTECH World Wide Web site by pointing your Internet browser to:
http://www.meyertech.demon.co.uk
2. PRODUCT SUPPORT
The ZVD-GW1-STR supports the following domes, manufactured by Star Micronics
• MD-2000
• MD-1200S
• MD-1200H
• MD-800
3. FEATURES
The following features are supported on the Star Micronics range of domes.
• 2-wire RS-485 telemetry distribution for up to 31 domes, per interface.
• Simultaneous Pan, Tilt, Zoom and Autofocus.
• 8-Speeds on each axis.
• 64 Presets including Home position.
• 9 Fast Presets (volatile memory storage)
• Write to EEPROM command, for permanent memory storage.
• 4 Preset Tours, with selectable approach speed and dwell time.
• Selectable Auto/Manual Focus operation.
• Flip operation, for fast 180°turn.
Page 3http://www.meyertech.demon.co.ukMAN-GW1-STR

MEYERTECH DIVISION
ISSUE 01
4. INSTALLATION
To obtain the optimum performance from your ZoneVu system, please take time to read this manual
before commencing installation. If you have any questions or problems our staff will be pleased to
assist you on the technical help line listed on page 16.
WARNING EQUIPMENT POWER SUPPLY UNITS CONTAIN HAZARDOUS
VOLTAGES. THE EQUIPMENT MUST BE EARTHED TO
PREVENT FIRE OR SHOCK HAZARD. DO NOT EXPOSE THIS
EQUIPMENT TO RAIN OR MOISTURE.
This ZoneVu interface should only be used in conjunction with the following equipment:
• ZVM-328 3u 19” Low Profile Case (1 required per bank of 32 Domes).
• ZVM-PSU Matrix Power Supply 12V (1 required for each ZVM-328 module).
• DVK-001 Keyboard (1 required per system).
• DVK-PSU 12V DC Keyboard Power Cube.
• Star Micronics MD-200 Series Dome Cameras
4.1 CONNECTING THE TELEMETRY DISTRIBUTION
Connect up the telemetry distribution in accordance with diagram below and the specifications in
Section 7, paying special attention to the maximum ratings and the notes below.
1. ALWAYS use Screened cables for low voltage and signal cables, ensuring the screen is
connected to 0V or Earth.
2. AVOID looming cables of differing characteristics together E.G. Telemetry cables with cables
carrying mains power.
3. The maximum cable run for Twisted Pair is typically 1Km.
4. The maximum number of Dome cameras that can be connected to a driver interface is 31.
5. The domes should be ‘Daisy Chained’ with the last dome in the chain having it’s termination
switch set to ON, and all other domes unterminated.
Page 4 MAN-GW1-STRhttp://www.meyertech.demon.co.uk

ISSUE 01
MEYERTECH DIVISION
ZVM-328
Matrix (master)
2 Wire
RS-422
Telemetry
2 Wire
RS-485
Telemetry
Comms I/O
ZVM-328
Matrix (slave)
Termination = OFF Termination = ON
Termination = OFF Termination = ON
ZVD-GW1 -
Star Interface
Channel 1
Channel 2
ZVD-GW1 -
Star Interface
Channel 1
Channel 2
Comms I/O
5. CONFIGURATION
Please refer to the ZVM-328 matrix manual for details on how to configure the system.
When configuring the matrix, the telemetry type should be set up as follow:
• Within the Main Menu of the On Screen Display, select Setup Matrix
• Within the Setup Matrix menu, select Cameras.
• Within the Cameras menu, select each camera controlled through the ZVD-GW1
interface, and in turn set each ‘Head Type’ to ‘DomeVu’ as shown below.
CAMERA OPTIONS MENU
Camera [ [ 01 ]
Video [ PRESENT ]
Camera Text
Text [ TOP ]
Text Colour [WHITE]
Time/Date [ BOTH ]
Head Type [ DomeVu ]
Digital Zoom [ENABLE]
Return To Sub Menu
N.B. The Digital Zoom option is not applicable through this interface.
Page 5http://www.meyertech.demon.co.ukMAN-GW1-STR

MEYERTECH DIVISION
ISSUE 01
6. OPERATION
All Functions operate as described in the DVK-001 Manual with the following exceptions and
additions:
6.1 PRESETS
The system is limited to 64 presets on each Dome. Presets 1 – 63 are accesed through the Preset
key, and preset 0 through the Home key. Additionally, presets 1 to 8 are quick access presets which
are accessed using the P1 to P8 keys. These presets are not stored in permanent memory, and are
thus stored faster, and accesed by a single keystroke. To transfer these presets into permanent
memory, please see Storing to EEPROM.
6.2 TOURS
Each dome can be configured with up to 4 tours. A tour is a list of preset positions, dwell times and
maximum approach speeds which the dome systematically cycles through.
The limits of the Tour Data are as follows:
• Up to 9 positions per tour.
• Dwell times are in the range 1 – 99 seconds
• Speeds are in the range 1 – 8.
A tour is stopped by sending any PTZF function to the camera.
Tours are stored in permanent memory and should thus be remebered if the dome is switched off.
6.3 SPECIAL FUNCTIONS
6.3.1 FLIP
The Dome supports a one key flip operation ( 180 degree turn) , as described in the DVK-001 manual,
but does not support a 90 degree turn.
6.3.2 STORE TO EEPROM
All Preset and Tour information can be stored in permanent memory using the Store Function.
This is accessed by the following key combination:
Page 6 MAN-GW1-STRhttp://www.meyertech.demon.co.uk

ISSUE 01
MEYERTECH DIVISION
F2 + 1 + Enter
6.4 GLOBAL COMMANDS
The Domes do not support global commands.
6.5 OPERATIONAL NOTES
The RS-485 interface to the domes relies on a 2-way communication protocol. If for any reason the
dome fails to respond to repeated commands, it will be logged off the system. This will mean that any
commands for that camera will be ignored, to prevent slowing down the rest of the system.
A period of 30 seconds will elapse before communications with the dome will be re-tried.
N.B. When powering up the dome, it will not respond to communications until it has completed it’s
power-up test. No attempt should be made to control the dome in this period.
Page 7http://www.meyertech.demon.co.ukMAN-GW1-STR

MEYERTECH DIVISION
ISSUE 01
7. SPECIFICATIONS
POWER INPUT - 12VDC Power Supply (included) from 230VAC
TELEMETRY INPUT - 9 pin D type connector (Female)
RS-422 (2-wire)terminated
Pin 1 Rx-
Pin 2 Rx+
Pin 5 Ground
TELEMETRY OUTPUT - 9 pin D type connector (Female)
RS-485 (2-wire)terminated
Pin 3 Rx-/Tx-
Pin 4 Rx+/Tx+
Pin 5 Ground
CURRENT CONSUMPTION - 100mA Max.
DIMENSIONS - 155mm x 108mm x 40mm
WEIGHT - 0.5 kg
TEMPERATURE - Operational 0 Degrees to 40 Degrees C
- Storage minus 20 Degrees to plus 60 Degrees C
- Humidity 10% to 95% (Non-condensing)
Page 8 MAN-GW1-STRhttp://www.meyertech.demon.co.uk

ISSUE 01
MEYERTECH DIVISION
8. TROUBLE SHOOTING GUIDE
This Trouble Shooting Guide should be used in the first instance of encountering any problems with
your Dome control system. If problems persist, contact MEYERTECH on the Technical Help line
numbers given on page 16.
Symptom Solution
Dome moves without
joystick control.
Calibrate keyboard joystick. See Relevant section of
keyboard manual.
Dome control
intermittent
Check cable insulation and termination. See Section 4.1
Page 9http://www.meyertech.demon.co.ukMAN-GW1-STR

MEYERTECH DIVISION
ISSUE 01
9. DECLARATION OF CONFORMITY
EC DECLARATION OF CONFORMITY ACCORDING
TO ARTICLE 10 OF COUNCIL DIRECTIVE 89/336/EEC
Manufacture’s Name: MEYERTECH
Manufacture’s Address: MEYERTECH Division
OfficeBlockOne
Southlink Business Park
Oldham
OL41DE
declares, that the product(s):
Product Name : ZVD-GW1-STR
Dome control interface
Model(s) : All
Product Options : All
conforms to the following Product Specifications :
EN55022 CLASS B
EN50093
EN60950 Amendments 1, 2, & 3 1992
Supplementary Information :
MEYERTECH declare under our sole responsibility that the product to which this declaration
relates, is in conformity with the protection requirements of council directive 89/336/eec on
the approximation of the laws of the member states relating to electromagnetic compatibility,
when installed in accordance with the instructions given in this manual.
SIGNED -
S K MEYERS
DirectorMEYERTECH DIVISION
ISSUED THIS DAY : 1st October 1997
European Contact : Meyertech Division (Head Office), Office Block One,
Southlink Business Park, Oldham, England, OL4 1DE.
Page 10 MAN-GW1-STRhttp://www.meyertech.demon.co.uk

ISSUE 01
MEYERTECH DIVISION
10. PRODUCT WARRANTY
MEYERTECH DIVISION warrants that at the time of shipment the products manufactured by
Meyertech will be free from defects in material and workmanship.
Should any defects appear within twelve months from date of shipment, Meyertech Division shall at
it’s sole discretion repair or replace the defective material. Such material shall not be accepted for
return or repair without prior notification of Meyertech Division.
Return shipments to Meyertech Division shall be at the customer’s expense. Meyertech Division will
return said equipment prepaid via best way.
This warranty is in lieu of and excludes any and all other expressed or implied warranties of
merchantability or fitness, or otherwise. Items manufactured by any supplier other than Meyertech
Division shall bear only the warranty made by the manufacturer of that product, and Meyertech
Division assumes no responsibility for the performance or reliability of that product.
Meyertech Division will not be liable for any special or consequential damages, or for loss, damages,
or expense directly or indirectly arising from the use of the products, or any inability to use them either
separately or in combination with any other equipment or material or from any other cause.
This warranty does not extend to any product manufactured by Meyertech Division which has been
subject to misuse, neglect, accident, war, civil disturbance, terrorist acts, improper installation, act of
God, or in violation of the instructions supplied by Meyertech Division.
Page 11http://www.meyertech.demon.co.ukMAN-GW1-STR

MEYERTECH DIVISION
ISSUE 01
11. DOCUMENT HISTORY
ZoneVu Interface Installation Manual: MAN-GW1-STR
ISSUE DATE CHANGE RECORD
01 24 November 98 First Issue
Page 12 MAN-GW1-STRhttp://www.meyertech.demon.co.uk

ISSUE 01
MEYERTECH DIVISION
NOTES
Page 13http://www.meyertech.demon.co.ukMAN-GW1-STR

MEYERTECH DIVISION
ISSUE 01
Page 14 MAN-GW1-STRhttp://www.meyertech.demon.co.uk
MEYERTECH DIVISION
Page 14 MAN-GW1-STRhttp://www.meyertech.demon.co.uk
ISSUE 01
NOTES

ISSUE 01
MEYERTECH DIVISION
Page 15http://www.meyertech.demon.co.ukMAN-GW1-STR Page 15http://www.meyertech.demon.co.ukMAN-GW1-STR
ISSUE 01
MEYERTECH DIVISION
NOTES

MEYERTECH DIVISION
Page 16 MAN-GW1-STRhttp://www.meyertech.demon.co.uk
ISSUE 01
Office Block One
Southlink Business Park
Oldham
England
OL4 1DE
Sales Support
[phone]
[phone]
Email: [email protected]
Technical Support
Oldham [phone]
Email: [email protected]
http://www.meyertech.demon.co.uk
