Zoomax Acesight S User manual

Quick Guide
V 1.0

Power Indicator
Full Color/Menu
Left Arrow Button
Outline Button
+ Zoom in
Floating Reading
Button
Power Button
Color Mode Button
Right Arrow Button
- Zoom out
Power Input
USB Port for Firmware
Upgrade

Basic Function
Instruction
Turn On/ Off
Press Power Button
for 2 seconds.
Zoom In
Press Zoom In Button .
Zoom Out
Press Zoom Out Button .
Color Mode
Press Color Mode Button to
circle through color modes.
Outline
Press Outline Button .
Adjust Thickness of
Outlines/Adjust Contrast of
High Contrast Colors
Press Arrow Buttons .
Switch to Full Color Mode
Press Full Color/Menu Button .
Lock/unlock the Controller
Press the Zoom In and Zoom Out Button
simultaneously.

Advanced Function
Instruction
Floating
Reading
Mode1
Step 1: Enter
Preview
Short press the Floating Reading
Button . A yellow square with a
+ symbol will appear .
Step 2: Enter
Floating
Reading Mode
Press the Floating Reading Button
again to freeze the image you
want to see.
Step 3: See with
Floating
Reading Mode
& Exit
Move your head around to view
the frozen image. If image
disappears, press Full Color/Menu
button . To exit, press the
Floating Reading Button .
1
Floating Reading Mode makes your eyes less tiring when reading longer
documents. For more information, please contact your dealer/doctor.

Advanced Function
Instruction
Lock/Release Focus2
Press Arrow Buttons
simultaneously.
Adjust the Interpupillary
Distance (IPD)3
Close the left eye and adjust
the IPD dial on headset for
right eye. Repeat for the
other side.
2
Please lock the focus when reading texts, and unlock it when looking
around.
3
Please contact your dealer/doctor for assistance if there is any problem
adjusting the IPD.
Headset
Adjustment
Dial
Brightness +
Camera
IPD Dial
Brightness -

Advanced Function
Instruction
Access
the
Menu
Enter/Exit
Menu
Press Full Color/Menu Button
for 3 seconds to enter
Menu. Short press it again to exit.
Enter/Exit
Options
Press Mode Button to enter
select options. Press Outline
Button to exit.
Switch Options
Press Arrow Buttons to
switch between Floating Reading
Mode Calibration4 and
Factory Reset .
4
It’s not suggested to use Floating Reading Mode Calibration Function
without professional advice.

Specifications
Display
Full HD display, 1920*1080 resolution
Camera
8 megapixels
Field of view
45° (per eye)
Refresh rate
60 Hz
Magnification
1.1x-15x
Display modes
Full color and 4 high contrast color modes
Usage time
4+ hours
Weight
Headset: 410g (0.8lb)
Controller: 183g (0.4lb)
