ZROADZ Z745401 User manual

Page 1
START HERE
PLEASE READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE INSTALLATION.
Auto makers offer varied models to each vehicle and occasionally manufacture
more than one body style of the same model. To assure your part is correct; our tech
department can be contacted at [email protected] to verify fitment and assist with
technical questions. All other inquires can be directed to [email protected]. In the
event you do not have internet access please call 844-653-8040
* APPLICATION MODELS VARY. WE RECOMMEND TO VERIFY FITMENT BEFORE BEGINING INSTALLATION PROCESS.
* IMAGES FEATURED IN THE INSTRUCTION DOCUMENTS MAY NOT ALWAYS EXACTLY MATCH YOUR MODEL OR PART.
Parts included
HARDWARE
Installation Guide
Parts are PATENT PENDING. All Rights Reserved - Copyright ©2016 - ZROADZ LED, INC.
2021 FORD BRONCO (ALL)
Z745401, Z745421
ROCK SLIDER SIDE STEPS
STEP 2
Z745401 (4 Door)
(12) 10 Mm Flange Nut
(2) 10 Mm Bolt
(4) 8 Mm Bolt
Z745421 (2 Door)
(8) 10 Mm Flange Nut
(2) 10 Mm Bolt
(2) 8 Mm Bolt
Z745401 (4 DOOR)
(1) - Left Rock Slider Side Step
(1) - Right Rock Slider Side Step
Z745421 (2 DOOR)
(1) - Left Rock Slider Side Step
(1) - Right Rock Slider Side Step
2) Remove the factory Rock Rails.
STEP 1
1) Skip to Step 3 if your vehicle is not
equipped with the factory Rock Rails. If they
are equipped, remove them by carefully
untightening the single bolt and the (2) nuts
at each attachment point.
The 2 Door Bronco has a front and a rear
attachment point on each side whereas the
4 Door Bronco has a front, middle and rear
attachment point on each side. All horizontal
bolts are 6 Mm in size and in turn use 10
Mm Flange Nuts. The vertical bolts vary in
size depending on their position. Only the
front attachment points use the vertical 10
Mm bolts. The other vertical attachment
points use an 8 Mm bolt.
tools required
Drive Ratchet
10 Mm Socket
13 Mm Socket

Page 2
nstallation - Continued
LED Light Bracket Installation - Process complete
Parts are PATENT PENDING. All Rights Reserved - Copyright ©2016 - ZROADZ LED, INC.
STEP 3
3)Identify the correct Side Step for its corresponding side. The front-end
of a Side Step can be distinguished by the first attachment point. The first
attachment point will have a taller bracket welded to the Side Step tubing.
STEP 4
4)Using the same points of attachment from the factory Rock Rails
align the ZROADZ Side Steps similarly. If your vehicle did not have
factory Rock Rails, locate pairs of 6.5 Mm holes at about 5" apart
on the body pinch seam.
STEP 5
5)Ensure that each stud from the ZROADZ Side Steps extrudes across
the body pinch seam. Without tightening at this time, use the 10 Mm
Flange Nuts for each pair of horizontal bolts at each attachment point.
STEP 6
6)Using the provided 8 Mm and 10 Mm bolts, install them into the hole
found vertically as shown above. Remember that only the front attachment
uses the 10 Mm bolt while the others use an 8 Mm bolt. Once each
attachment point has been aligned, tighten each nut and bolt securely.
This completes the installation procedure for Z745401 / Z745421.

ZROADZ PRODUCT WARRANTY
ZROADZ warrants its grille products to be free from defects in material and workmanship for the lifetime of the grille. ZROADZ warrants the
finish of its grille products for a 3 year period beginning at the time of sale to the end user. These warranties are limited warranties and do
not cover abuse, modification or improper installation nor do they cover finish failure caused by caustic cleaning agents, road salts or other
chemicals. ZROADZ reserves the right to repair or replace a defective product at its sole discretion. Any ZROADZ product must be returned to
ZROADZ for warranty consideration and must be returned at the customer’s expense. In the event that the product is deemed to be defective,
the repaired or replaced item will be returned via a surface shipping method to the customer at ZROADZ expense. No provision is made for
any labor, rental car or other costs incurred by the failure of its products.
GENERAL GUIDELINES
LED Lights & LED Light Bars operate at relatively high currents and should only be installed by qualified personnel with experience in
switched / relayed high draw DC Circuits.
- Light Bars are designed for use only with standard 12v DC power systems
- Light Bars are for OFF-ROAD USE ONLY. Check your local laws & regulations regarding vehicle mounted lights.
- Some Light Bars are equipped with waterproof connectors while others are simply pig-tailed
- Red Wires = POSITIVE | Black Wires = NEGATIVE
- ALWAYS install your lights on a fused circuit. Basic fusing guidelines: maximum 5A for every 10” of LED Light Bar.
WARNING
PLEASE CONSULT YOUR LOCAL AUTOMOTIVE ELECTRICAL PROFESSIONAL FOR INSTALLATION SERVICES AND ADVICE. ZROADZ IS ONLY
EQUIPPED TO PROVIDE BASIC TECHNICAL ASSISTANCE DUE TO THE DIVERSITY OF VEHICLES, VEHICLE OPTIONS & MODIFICATIONS AND
LIGHTING CONFIGURATION OPTIONS AVAILABLE. ZROADZ cannot be held liable due to improper component installation and / or faulty wiring.
GENERAL USE, INSTALL AND ADJUSTMENT TIPS
NOTE 1: ZROADZ LED Light Bars themselves are for OFF-ROAD USE ONLY.
NOTE 2: Light Bars depending on the configuration of your vehicle and its options and/or modifications may need to be adjusted for appropriate
beam projection. To adjust the angle of your light bars simply loosen the mounting hardware on either side of each Light Bar, rotate the Light Bar
to adjust the angle, then tighten the hardware once the desired angle is achieved (please be careful not to over-tighten the mounting hardware or
scratch the protective powder-coat finish). It is best to adjust the angle with the vehicle on level ground with the lights facing a wall, garage door
or other solid barrier at a distance of approximately 25-30 feet.
NOTE 3: Please consult a qualified automotive electrical professional for light bar wiring installation.
NOTE 4: An optional universal wiring harness (part# Z390020S-A) is also available that includes high-heat & oil/fuel resistant wires, waterproof
connector, 12v relay, 12v rocker switch, inline fuse holder. Our universal wiring harness significantly expedites the installation process but is not a
vehicles specific “Plug & Play“ product and does not eliminate the need for a professional installation.
Please contact your local ZROADZ dealer for more information or visit www.zroadz.com.
PRODUCT CARE INFORMATION
Wash regularly as you would when caring for your vehicles. Never use dish soap. Never leave wet water spots as that may leave a blemish.
GLOSS BLACK FINISH
ZROADZwith Gloss Black Powder Coated Finish may be washed regularly as you would when caring for your vehicles finish using soap and
water. ZROADZshould be waxed at the same time that you wax the vehicle. As a general rule, anything you use to clean your vehicles painted
surfaces can be used to clean and maintain your ZROADZ grille. A Gloss powder Coated Finish can be cared for in the same fashion that you
would care for your vehicles factory paint job. Never leave wet water spots as that may leave a blemish.
MATTE BLACK FINISH
Paint warranty applies to defects in material and / or workmanship, it does not cover the matte finish surface appearance.
To enjoy the matte appearance for many years to come, please follow these owner care and maintenance tips.
Get a no-shine matte car wash soap that uses no fillers, no silicone, and won’t strip your matte paint of its layer of protection.
Do not use wax, detail spray, armorall®, or any products made for normal paint. Use only products specifically developed for matte
finish paint. Do not use products that are even mildly abrasive, such as polishes, glazes, or rubbing compounds. Do not use mechanical
cleaners or polishers. Do not use terrycloth, cloth, or paper towels. Do not rub the finish vigorously, this will burnish the paint finish,
causing a permanent shiny spot. Shiny spots cannot be removed.

Do not use commercial car wash facilities or their shine enhancement products. Most car wash brushes, large mechanized “towels,”
and shine enhancement products can damage matte paint.

Remove foreign substances such as insect remains, tar, and road debris using a soft applicator and a mild solvent; saturate and soak
area before cleaning—rub lightly.

Hand-wash with a soft wash mitt and mild cleaning product safe for matte paint. Use microfiber cleaning cloths with alcohol-based window
cleaner for basic surface clean-up.
