ZXMWNR8120A/8120D
DigitalMicrowaveTransmissionSystem
MaintenanceGuide
Version:V2.04.02
ZTECORPORATION
No.55,Hi-techRoadSouth,ShenZhen,P .R.China
Postcode:518057
Tel:[phone]
Fax:[phone]
URL:http://support.zte.com.cn
E-mail:[email protected]

LEGALINFORMATION
Copyright©2016ZTECORPORATION.
Thecontentsofthisdocumentareprotectedbycopyrightlawsandinternationaltreaties.Anyreproductionor
distributionofthisdocumentoranyportionofthisdocument,inanyformbyanymeans,withoutthepriorwritten
consentofZTECORPORATIONisprohibited.Additionally,thecontentsofthisdocumentareprotectedby
contractualcondentialityobligations.
Allcompany,brandandproductnamesaretradeorservicemarks,orregisteredtradeorservicemarks,ofZTE
CORPORATIONoroftheirrespectiveowners.
Thisdocumentisprovided“asis”,andallexpress,implied,orstatutorywarranties,representationsorconditions
aredisclaimed,includingwithoutlimitationanyimpliedwarrantyofmerchantability,tnessforaparticularpurpose,
titleornon-infringement.ZTECORPORATIONanditslicensorsshallnotbeliablefordamagesresultingfromthe
useoforrelianceontheinformationcontainedherein.
ZTECORPORATIONoritslicensorsmayhavecurrentorpendingintellectualpropertyrightsorapplications
coveringthesubjectmatterofthisdocument.ExceptasexpresslyprovidedinanywrittenlicensebetweenZTE
CORPORATIONanditslicensee,theuserofthisdocumentshallnotacquireanylicensetothesubjectmatter
herein.
ZTECORPORATIONreservestherighttoupgradeormaketechnicalchangetothisproductwithoutfurthernotice.
UsersmayvisittheZTEtechnicalsupportwebsitehttp://support.zte.com.cntoinquireforrelatedinformation.
TheultimaterighttointerpretthisproductresidesinZTECORPORATION.
RevisionHistory
RevisionNo.RevisionDateRevisionReason
R1.02015-09-17Firstedition
SerialNumber:SJ-20150804150350-006
PublishingDate:2015-09-17(R1.0)
SJ-20150804150350-006|2015-09-17(R1.0)ZTEProprietaryandCondential

Contents
AboutThisManual.........................................................................................I
Chapter1RoutineMaintenance................................................................1-1
1.1DailyMaintenance..............................................................................................1-1
1.1.1CheckingtheStatusofBoards..................................................................1-1
1.1.2CheckingtheCurrent24-HourPerformanceData.......................................1-2
1.1.3CheckingPerformanceDataofthePast10Days.......................................1-2
1.1.4CheckingAlarms......................................................................................1-3
1.1.5CheckingDeviceEvents...........................................................................1-4
1.1.6CheckingtheStatusofIndicators..............................................................1-5
1.2MonthlyMaintenance.........................................................................................1-5
1.2.1CheckingPowerSupply............................................................................1-5
1.2.2CleaningtheEquipment............................................................................1-5
1.2.3MaintainingtheEquipmentRoomEnvironment..........................................1-6
1.3QuarterlyMaintenance.......................................................................................1-7
1.3.1CheckingtheReceiveLevel......................................................................1-7
1.3.2CheckingtheODUInstallation..................................................................1-8
1.3.3CheckingtheCombinerInstallation...........................................................1-9
1.3.4CheckingtheAntennaInstallation.............................................................1-9
1.3.5CheckingtheIFCable............................................................................1-10
Chapter2Troubleshooting........................................................................2-1
2.1ApplicationFaults...............................................................................................2-2
2.1.1APCConnectedtotheLMTInterfaceCannotPingEquipment...................2-2
2.1.2APCConnectedtotheNMSInterfaceCannotPingtheEquipment.............2-2
2.2RadioLinkFaults...............................................................................................2-3
2.2.1TheReceiveLevelDoesNotReachtheTheoreticalValue..........................2-3
2.2.2ErrorCodesAreGeneratedontheRadioLink...........................................2-4
2.2.3RadioLinkIsDisconnected.......................................................................2-4
2.2.4InstantaneousLinkBreak..........................................................................2-5
2.2.5TheMULosesLock.................................................................................2-5
2.2.6AirInterfacePerformanceIsZero..............................................................2-5
2.3TDMServiceFaults............................................................................................2-6
2.4EthernetServiceFaults......................................................................................2-6
2.5NetworkManagement.........................................................................................2-7
I
SJ-20150804150350-006|2015-09-17(R1.0)ZTEProprietaryandCondential

2.5.1NetworkManagementServicesAreDisconnected......................................2-7
2.5.2NEsAreOutofControl.............................................................................2-7
Chapter3FaultLocatingMethods............................................................3-1
3.1PerformingtheLoopbackT est.............................................................................3-1
3.2CheckingtheEthernetOAMFunction..................................................................3-3
3.2.1CheckingCFM.........................................................................................3-5
3.2.2CheckingEFM.......................................................................................3-13
3.3PerformingtheMSTPSingle-StepOperation.....................................................3-16
Chapter4Indicators...................................................................................4-1
Glossary..........................................................................................................I
II
SJ-20150804150350-006|2015-09-17(R1.0)ZTEProprietaryandCondential

AboutThisManual
Purpose
ThismanualprovidesinformationabouttheroutinemaintenancemethodsfortheZXMW
NR8120A/8120DDigitalMicrowaveTransmissionSystem.Theroutinemaintenanceitems
andmethodsaredescribedinaccordancewiththemaintenanceperiod,includingday,
month,andquarter.Thetroubleshootingow,commonfaultanalysis,andfaultlocating
methodarealsoprovidedforreferenceinthismanual.
IntendedAudience
ThismanualisintendedformaintenanceengineerswhoworkwiththeZXMW
NR8120A/8120D.
WhatIsinThisManual
Thismanualcontainsthefollowingchaptersandappendix.
Chapter1,RoutineMaintenanceDescribesthedailymaintenance,monthlymaintenance,and
quarterlymaintenancefortheZXMWNR8120A/8120D.
Chapter2,TroubleshootingDescribesthecommonfaultanalysis,includingapplicationfault,
radiolinkfault,TDMservicefault,Ethernetservicefault,and
networkmanagementfault.
Chapter3,FaultLocating
Methods
Describesthecommonfaultlocatingmethodincludingloopback
test,EthernetOAMtest,andMSTPsingle-stepoperation.
Chapter4,IndicatorsDescribestheindicatorsoftheZXMWNR8120A/8120Dsystem.
Conventions
Thismanualusesthefollowingtypographicalconventions:
ItalicsVariablesincommands.Itmayalsorefertootherrelatedmanualsand
documents.
BoldMenus,menuoptions,functionnames,inputelds,optionbuttonnames,
checkboxes,drop-downlists,dialogboxnames,windownames,parameters,
andcommands.
ConstantwidthTextthatyoutype,programcodes,lenames,directorynames,andfunction
names.
[]Optionalparameters.
{}Mandatoryparameters.
|Separatesindividualparametersinaseriesofparameters.
I
SJ-20150804150350-006|2015-09-17(R1.0)ZTEProprietaryandCondential

Danger:indicatesanimminentlyhazardoussituation.Failuretocomplycan
resultindeathorseriousinjury,equipmentdamage,orsitebreakdown.
Warning:indicatesapotentiallyhazardoussituation.Failuretocomplycan
resultinseriousinjury,equipmentdamage,orinterruptionofmajorservices.
Caution:indicatesapotentiallyhazardoussituation.Failuretocomplycan
resultinmoderateinjury,equipmentdamage,orinterruptionofminorservices.
Note:providesadditionalinformationaboutacertaintopic.
II
SJ-20150804150350-006|2015-09-17(R1.0)ZTEProprietaryandCondential

Chapter1
RoutineMaintenance
Routinemaintenanceincludesdailymaintenance,monthlymaintenance,andquarterly
maintenance.
TableofContents
DailyMaintenance......................................................................................................1-1
MonthlyMaintenance.................................................................................................1-5
QuarterlyMaintenance...............................................................................................1-7
1.1DailyMaintenance
1.1.1CheckingtheStatusofBoards
Thisproceduredescribeshowtocheckthestatusofboards.
Bycheckingthestatusofboards,maintenancepersonnelcandetectandresolveboard
faultsinatimelymanner.
Steps
1.LogintotheWEBLMTsystem,Intheleftnavigationtree,selectHome>Home.The
boardstatusinformationisdisplayedintherightpane,seeFigure1-1.
Figure1-1BoardStatusInformation
2.(Optional)Iftherunningindicatorofaboardislitred,troubleshoottheboardfault
immediately.
Fordetailedinformation,refertothe"ZXMWNR8120ADDigitalMicrowave
TransmissionSystemAlarmandNoticationHandlingReference".
–EndofSteps–
1-1
SJ-20150804150350-006|2015-09-17(R1.0)ZTEProprietaryandCondential

ZXMWNR8120A/8120DMaintenanceGuide
1.1.2CheckingtheCurrent24-HourPerformanceData
Thisproceduredescribeshowtocheckthecurrent24-hourperformancedata,usingthe
procedureofcheckingthecurrent24-hourEthernetperformancedataasanexample.
Steps
1.LogintotheWEBLMTsystem,Intheleftnavigationtree,selectPerformance>ETH
>RMON&QoS15Min,setSlotNo.andPortNo.thattheservicecorrespondsto,
andclicktheQuerybutton.The15-minuteEthernetperformancedataisdisplayedin
therightpane,seeFigure1-2.
Figure1-215-MinuteEthernetPerformanceStatisticsData
2.Checktheperformanceindexesofthecurrent15minutes,andverifythatthe
performanceindexesarenormal.
Fordetailedinformationofeachperformanceindex,refertothe"ZXMWNR8120AD
DigitalMicrowaveTransmissionSystemKPIReference".
–EndofSteps–
1.1.3CheckingPerformanceDataofthePast10Days
Thisproceduredescribeshowtochecktheradiolinkperformancedataofthepast10days.
Steps
1.LogintotheWEBLMTsystem,Intheleftnavigationtree,selectPerformance>
RadioLink>24Hour,setSlotNo.thattheservicecorrespondsto,andclickthe
Querybutton.The24-hourradiolinkperformancedataisdisplayedintherightpane,
seeFigure1-3.
1-2
SJ-20150804150350-006|2015-09-17(R1.0)ZTEProprietaryandCondential

Chapter1RoutineMaintenance
Figure1-3RadioLink24-HourPerformanceStatisticsData
2.Checktheperformanceindexesofthepast24hoursoftheradiolink,andverifythat
theperformanceindexesarenormal.
Fordetailedinformationofeachperformanceindex,refertothe"ZXMWNR8120AD
DigitalMicrowaveTransmissionSystemKPIReference".
–EndofSteps–
1.1.4CheckingAlarms
Thisproceduredescribeshowtocheckalarms.
Context
Inthealarmmanagementwindow,maintenancepersonnelcanobserveandanalyzethe
alarminformationreportedfromeachNetworkElement(NE),includingthecurrentalarms,
historicalalarms,andnotications.Ithelpsdetectandresolvethefaultsorpotentialfaults
duringnetworkoperationinatimelymanner.
Note:
Here,theprocessofcheckingthecurrentalarmsisusedasanexampletodescribehow
tocheckalarms.
Steps
1.LogintotheWEBLMTsystem,Intheleftnavigationtree,selectAlarm>Current.
Theshelfdiagramisdisplayedintherightpane.
2.SetPositionandAlarmLevel,andclicktheQuerybutton.Thecurrentalarm
informationisdisplayed,seeFigure1-4.
1-3
SJ-20150804150350-006|2015-09-17(R1.0)ZTEProprietaryandCondential

ZXMWNR8120A/8120DMaintenanceGuide
Figure1-4CurrentAlarmInformation
Note:
UserscanexportthealarmqueryresulttoanExcelleoraWordleforfurtheranalysis
andprocessing.
3.Ifthereisanycriticalalarm,locate,isolate,andresolvethefaultassoonaspossible.
Fordetailedinformation,refertothe"ZXMWNR8120ADDigitalMicrowave
TransmissionSystemAlarmandNoticationHandlingReference".
–EndofSteps–
1.1.5CheckingDeviceEvents
Thisproceduredescribeshowtocheckdeviceevents.
Bycheckingdeviceeventsinthealarmmanagementwindow,maintenancepersonnelcan
detectandresolvethefaultsorpotentialfaultsduringnetworkoperationinatimelymanner.
Steps
1.LogintotheWEBLMTsystem,Intheleftnavigationtree,selectAlarm>Event.The
deviceeventinformationisdisplayedintherightpane,seeFigure1-5.
Figure1-5DeviceEventInformation
1-4
SJ-20150804150350-006|2015-09-17(R1.0)ZTEProprietaryandCondential

Chapter1RoutineMaintenance
2.Verifythattherearenoabnormaldeviceevents.Ifthereisany,locatethesystem
faultsandresolvetheminatimelymanner.
–EndofSteps–
1.1.6CheckingtheStatusofIndicators
Analyzingthestatusofindicatorsisacommonmethodusedwhenafaultisdetected.
Maintenancepersonnelcanlocateandresolvethefaultsbyobservingthestatusof
indicatorsoneachboardpanel.
Fordetailedinformationofthestatusofindicators,referto"Chapter4Indicators".
1.2MonthlyMaintenance
1.2.1CheckingPowerSupply
Thisproceduredescribeshowtochecktheequipment'spowersupplytoensurethatthe
equipmentcanoperateproperly.
Steps
1.Verifythatthestatusofthepowercabinet(UninterruptiblePowerSupply(UPS))is
normal.
2.Verifythattheairbreakswitchpowersupplyoftheportalframeisnormal.
3.Verifythattherack,antennafeeder,IDU,ODU,andlightningprotectorarewell
grounded.
4.VerifythatthepowerindicatorsofthefollowingboardsoftheIDUareinnormalstatus:
TheOPWERindicatorsoftheRadioCoreCrossModemUnitA(RCMUA)andRadio
ModemExpansionA(RMEA)board.
–EndofSteps–
1.2.2CleaningtheEquipment
Thisproceduredescribeshowtocleantheequipment.
Communicationequipmentislikelytobecontaminatedafteroperatingforalongtime.
CleaningtheequipmentregularlycanreduceBitErrorRate(BER),faultrate,andboard
failureratebyimprovingtheheatdissipationcapabilityoftheequipment.
Steps
1.Ifpossible,powerofftheequipment,detachthecircuitboardsandcomponentsfrom
theequipmentinaccordancewiththespeciedprocedure,andthenfullycleaneach
partoftheequipment.
1-5
SJ-20150804150350-006|2015-09-17(R1.0)ZTEProprietaryandCondential

ZXMWNR8120A/8120DMaintenanceGuide
2.Ifitisnotallowedtopowerofftheequipment,cleanthepower-onequipmentwithone
ofthefollowingmethodswheneverapplicable:
lSpray-washtheequipmentrst,andthenwashitwithawatergun.
Thismethodisapplicablewhenalotofdustcoverstheequipment.
Operationprocedure:Spraythecleanerontheequipment,waituntilthecleaner
inltratesthedirttoinsulatethedirtparticlesandtheoatingdustdeposits,and
then,washtheequipmentwithawatergun.
lCleantheequipmentfromtoptobottom.
Thismethodisapplicablewhentheequipmentcontaminationisnotserious.
lCleantheequipmentfrombottomtotop.
Thismethodisapplicablewhentheequipmentcontaminationisserious.It
preventsdirtaccumulationontheequipment.
lCollectthedirtbetweenlayersandatthebottom.
Thismethodisapplicableduringtheentireprocedureofcleaningthepower-on
equipment.
Operationprocedure:Insertantistaticpapersbetweeneachshelfandabovethe
cabinetbottom,cleantheequipmentlayerbylayer,andextractallthepapers.
lCleannarrowgaps.
Thismethodisusedtocleanaboardthathasa3-5mmgapfromotherboards
ortheequipment.
Operationprocedure:Inserttheextensionpipeofaspecialspraygunora
hand-heldpressuresprayerintothegap,andspray-washtheboardsides.
lCleanboardswithoutgaps.
Thismethodisusedtocleanboardsthatdonothavegapsfromotherboardsor
theequipment.
Operationprocedure:Inserttheextensionpipeofaspecialspraygunintothegap
betweenshelves,andspray-washtheboardsides.
lCleanthefan.
Operationprocedure:T akeouttheRadioFanAsset(RFA)boardoftheIndoor
Unit(IDU)rack,andcleanthedirt,toensurethefantooperateproperly.
–EndofSteps–
1.2.3MaintainingtheEquipmentRoomEnvironment
Thisproceduredescribeshowtomaintaintheequipmentroomenvironment.
Theequipmentroomenvironmentincludesalltheconditionsthatinuencetheequipment
operationintheequipmentroom,suchastemperature,humidity,anddust.Equipment
roomenvironmentmaintenanceprotectstheequipmentfromadverseenvironmental
factors.
1-6
SJ-20150804150350-006|2015-09-17(R1.0)ZTEProprietaryandCondential

Chapter1RoutineMaintenance
Steps
1.Keepavacuumcleanerintheequipmentandcleandustintheequipmentperiodically.
Operationprocedure:Useablowertoblowawaythedustontheequipmentsurface,
anduseabsolutealcoholtowashtheequipmentsurface.Itisrecommendedtoputa
thinlayerofheat-conductivesiliconoilonthecomponentsexposedintheair.
2.Takeantistaticmeasurestoprotecttheequipment.
Operationprocedure:Keepacertainhumidityinsidetheequipmentroom,preventthe
accumulationofstaticelectricity,andkeepgoodcontactbetweenthegroundingcable
andtheequipment.
3.Verifythattheairconditionerintheequipmentroomisoperatingproperly,andkeep
thetemperatureinsidetheequipmentroomwithintherangefrom15°Cto35°C.
4.Keepthehumidityinsidetheequipmentroomwithintherangefrom20%to80%,and
takewaterproofanddampproofmeasuresfortheequipmentintherainyseason.
–EndofSteps–
1.3QuarterlyMaintenance
1.3.1CheckingtheReceiveLevel
Thisproceduredescribeshowtocheckthereceivelevelandthehandlingmethodsincase
thatthereceivelevelisoutoftheplannedrange.
Steps
1.VerifythattheODUreceiveleveliswithintheplannedrange.
a.LogintotheNetNumenU31client.
b.SelectPerformance>HistoryPerformanceDataQuery.TheAddHistory
PerformanceDataQuerywindowisdisplayed.
c.ClicktheCounterSelectiontab,setNETypetoZXMWNR8120A/8120D,setMO
TypetoNR8120A/8120DODU,andclickOK.TheODUperformancestatistics
dataisdisplayed.
2.Performrelevantoperationsinaccordancewiththecheckresult.
CheckResultHandlingSuggestion
Thereceivelevelislowerthan
thedesignedvalue.
Referto"2.2.1TheReceiveLevelDoesNotReachthe
TheoreticalValue".
1-7
SJ-20150804150350-006|2015-09-17(R1.0)ZTEProprietaryandCondential

ZXMWNR8120A/8120DMaintenanceGuide
CheckResultHandlingSuggestion
Thereceiveleveluctuates.lIffrequencyinterferenceexists,performthefrequency
sweeptesttogettheinterferencefrequencyandadjust
thefrequencypointsofthemicrowavelink.
lIfthelevelattenuationiscausedbybadweatherlikerain,
àModifythepolarizationmodetobealowerone,or
enabletheAdaptiveCodingandModulation(ACM)
function.
àFrequencyresourcespermitting,usealow-band
ODU(<11GHz).
àIncreasethetransmitpower,usealarge-aperturean-
tenna,andenabletheAutomaticTransmitterPower
Control(ATPC)function.
lIfthereceivefaultiscausedbymultipathattenuation,
àModifytheequipmentprotectionmodetospacedi-
versitymodetoeliminatethemultipatheffect.
àAdjusttheantennaheight.
àIncreasetheantennaaperture.
–EndofSteps–
1.3.2CheckingtheODUInstallation
TheproceduredescribeshowtochecktheOutdoorUnit(ODU)installation,toensurethat
theODUcanoperateproperlyandwellcooperatewithotherdevices.
Steps
1.VerifythattheinstallationpositionanddirectionoftheODU'sadaptermeetthe
engineeringdesignrequirement.
2.VerifythattheODU'sadapterisrmlyxedonthepole,meetingthewindresistance
requirement.
3.IftheODUisinstalledinseparatemode,verifythattheinterfaceoftheexible
waveguideangeisrmlyandreliablyconnectedtotheODU'sadapter,andensure
thatthebendingradiusoftheexiblewaveguidedoesnotexceed90°.
4.VerifythattheODUiswithintheprotectionrangeofthelightningrod.
1-8
SJ-20150804150350-006|2015-09-17(R1.0)ZTEProprietaryandCondential

Chapter1RoutineMaintenance
Note:
Theprotectionangleoftheantenna'slightningrodmustbelessthan45°.Inareas
withhighmountainsorfrequentthunderstorm,theprotectionangleoftheantenna's
lightningrodmustbelessthan30°.
5.VerifythattheODU'sgroundingcableisproperlyconnected.
6.VerifythatthewaterproofclayandtapebetweentheIntermediateFrequency(IF)cable
andtheODUarereliablysealed.
–EndofSteps–
1.3.3CheckingtheCombinerInstallation
Thisproceduredescribeshowtocheckthecombinerinstallation,toensurethatthe
combinercanoperateproperlyandwellcooperatewithotherdevices.
Steps
1.Verifythatthecombinerisfastenedtotheantennarmlyandthefourscrewsare
secured.
2.Verifythatthecombineriswithintheprotectionrangeofthelightningrod.
Note:
Theprotectionangleoftheantenna'slightningrodmustbelessthan45°.Inareas
withhighmountainsorfrequentthunderstorm,theprotectionangleoftheantenna's
lightningrodmustbelessthan30°.
3.Verifythatthecombinerdoesnothavewaterleakage.
–EndofSteps–
1.3.4CheckingtheAntennaInstallation
Thisproceduredescribeshowtochecktheantennainstallation,toensurethattheantenna
canoperateproperlyandwellcooperatewithotherdevices.
Steps
1.Verifythattheinstallationpositionanddirectionoftheantennameettheengineering
designrequirement.
1-9
SJ-20150804150350-006|2015-09-17(R1.0)ZTEProprietaryandCondential

ZXMWNR8120A/8120DMaintenanceGuide
2.Verifythattheantennabracketisrmlyandreliablyxedonthepole,meetingthewind
resistancerequirement.
3.Verifythattheantennaiswithintheprotectionrangeofthelightningrod.
Note:
Theprotectionangleoftheantenna'slightningrodmustbelessthan45°.Inareas
withhighmountainsorfrequentthunderstorm,theprotectionangleoftheantenna's
lightningrodmustbelessthan30°.
–EndofSteps–
1.3.5CheckingtheIFCable
ThisproceduredescribeshowtochecktheIFcable,toensurethattheIFcableisproperly
connected.
Steps
1.VerifythattheoutdoorconnectorandgroundingclipoftheIFcablearewellsealed.
2.VerifythattheconnectorsoftheIFcablearefastened.
3.VerifythattheIFcableisnotbrokenortwistedanditsshieldinglayerisnotexposed.
4.VerifythatthebendingradiusoftheIFcableisgreaterthan30cm.
5.VerifythatthegroundingpointsoftheIFcablecomplywiththespecication.
TheIFcableshouldbemorethan60minlengthandisgroundedinthethree-point
groundingmode.IftheIFcableisshorterthan60m,itisrecommendedtogroundthe
cableinthetwo-pointgroundingmode.Waterproongmeasuresshouldbemadeat
thegroundingpoints.
6.Tosatisfytheantennaheightadjustmentrequirementinfuture,reserve5-10mofthe
IFcabletomakearingandxitonthemetaltower,seeFigure1-6.
Figure1-6ReservingCertainLengthoftheIFCable
1-10
SJ-20150804150350-006|2015-09-17(R1.0)ZTEProprietaryandCondential

Chapter1RoutineMaintenance
7.BindtheindoorIFcableandthepowercableseparately,andxtheIFcablewithcable
ties.
8.FixtheoutdoorIFcablewithcabletieseveryonemeter.
Note:
AtthepositionwheretheIFcableisledfromoutdoorstoindoors,iftheoutdoorIFcable
ishigherthanthefeederwindowbottom,makeawaterproofbendnearthefeeder
window;otherwise,thereisnoneedtomakeawaterproofbend.
Foroperationdetails,refertothe"ZXMWNR8120ADDigitalMicrowaveTransmission
SystemHardwareInstallationGuide".
–EndofSteps–
1-11
SJ-20150804150350-006|2015-09-17(R1.0)ZTEProprietaryandCondential

ZXMWNR8120A/8120DMaintenanceGuide
Thispageintentionallyleftblank.
1-12
SJ-20150804150350-006|2015-09-17(R1.0)ZTEProprietaryandCondential

Chapter2
Troubleshooting
Thisprocedureshowsanexamplewhentheairinterfaceuses1+1conguration.The
followingprinciplesshouldbeobservedfortroubleshooting:
lTroubleshootindoorproblemsbeforetroubleshootingoutdoorproblems.
lTroubleshootpowerproblemsbeforetroubleshootingequipmentproblems.
lTroubleshootlocalproblemsbeforetroubleshootingremoteproblems.
lTroubleshootproblemsbelowtowersbeforetroubleshootingproblemsabovetowers.
Figure2-1displaysthetroubleshootingow.
Figure2-1TroubleshootingFlow
TableofContents
ApplicationFaults.......................................................................................................2-2
RadioLinkFaults.......................................................................................................2-3
TDMServiceFaults....................................................................................................2-6
EthernetServiceFaults..............................................................................................2-6
NetworkManagement................................................................................................2-7
2-1
SJ-20150804150350-006|2015-09-17(R1.0)ZTEProprietaryandCondential

ZXMWNR8120A/8120DMaintenanceGuide
2.1ApplicationFaults
2.1.1APCConnectedtotheLMTInterfaceCannotPingEquipment
Performthefollowingtroubleshootingsteps:
1.ChecktheIPcongurationofthePersonalComputer(PC).
ToaccesstheequipmentthroughtheLMTinterface,theIPaddressofthePCmustbe
conguredwithinthesamenetworksegmentofthedefaultLMTdebugIPaddress.
2.VerifythattheFTPprocesscanbeaccessed.
3.VerifythatthePCisconguredwithonlyonenetworkadapter.
IfthePCisconguredwithtwonetworkadapters,itcannotaccesstheequipment
sometimes.Inthiscase,disableonenetworkadapter.Afterthat,thePCcanaccess
theequipmentsuccessfully.
4.VerifythattherewallfunctionisnotenabledonthePC.
Normally,therewallfunctionwillprohibitsomeprogramstoaccessthenetwork.Itis
recommendedtodisabletherewallfunctionoraddtheportstobeaccessedinthe
rewallconguration.
5.ChecktheRUNindicatoroftheRadioCoreCrossModemUnitA(RCMUC)orRCMUD
boardtoverifythattheRCMUCorRCMUDboardisoperatingproperly.
lIftheRUNindicatorislitredforveseconds,theRCMUCorRCMUDboardis
beingstarted.
lIftheRUNindicatorislitgreen,theRCMUCorRCMUDboardisoperating
properly.
lIftheRUNindicatorisnotlitgreenaftertheRCMUCorRCMUDboardisstarted,
theRCMUCorRCMUDboardmaybefaulty.
6.Iftheproblemstillexistsafterthepreviousoperations,replacethePC.
2.1.2APCConnectedtotheNMSInterfaceCannotPingthe
Equipment
Performthefollowingtroubleshootingsteps:
1.ChecktheIPcongurationofthePC.
ToaccesstheequipmentthroughtheNMSinterface,theIPaddressofthePCand
thatoftheNMSinterfacemustbeconguredinthesamenetworksegment.Ifthetwo
IPaddressesarenotconguredinthesamenetworksegment,recongurethem,and
accesstheequipmentagain.
2.ChecktheportmodeandVLANcongurationoftheNMSinterface.
ToenablethePCtoaccessequipment,enabletheNMSinterface,settheportmode
oftheNMSinterfacetoAccess,andsetPVIDtotheNMSVLANID.
3.VerifythatthePCisconguredwithonlyonenetworkadapter.
2-2
SJ-20150804150350-006|2015-09-17(R1.0)ZTEProprietaryandCondential
