C h a p t e r 1
Getting Started
T-Mobile’s 4G Mobile Hotspot is a 3G/4G Mobile Hotspot, which supports 802.11b/g, via Wi-Fi
interface; the 4G Mobile Hotspot supports data and text messaging services, enabling you to communicate
anytime and anywhere.
4G Mobile Hotspot Appearance
The following figure shows the appearance of the 4G Mobile Hotspot. It is only for your reference. The
actual device may be different.
1. Power Key
Press and hold the Power key for three seconds to turn on/off
the 4G Mobile Hotspot.
Press the Power Key to turn on the screen when it is in sleep
mode.
2. Memory card slot (microSD card)
The microSD card is inserted with the gold contacts facing up.
3. WPS
*WPS is an optional Wi-Fi security
method, however the receiving 4G
Mobile Hotspot must support WPS
Short press the button will turn on the Wi-Fi radio when the
4G Mobile Hotspot is not broadcasting.
Long press and hold of the button for three seconds to activate
Wi-Fi Protected Setup Authentication (WPS).
4. LCD Screen
Indicates the 4G Mobile Hotspot status and the icon status on the
LCD screen are duplicated in the web UI.
5. External Antenna Port
Can be used with an external cellular antenna (not included) to
enhance the signal strength.
6. Charger/USB Port
Dual purpose port is used for battery charging and USB
connection.
Notes:

6 Confidential and Proprietary Information of ZTE CORPORATION
Resetting the 4G Mobile Hotspot
•Press and hold the WPS and Power buttons simultaneously until the LCD turns off; then release the
buttons and the 4G Mobile Hotspot will restart automatically and restore to the factory default settings.
The 4G Mobile Hotspot will display ―Restarting…‖ which indicates a successful reset to factory
defaults. You can also reset the 4G Mobile Hotspot settings through the web admin page.
•is a trademark of SD Card Association.
LCD Screen Indicator
4G Mobile Hotspot Icon Indicators
Icon
Indication
Network signal strength. The antenna to the far left counts as one bar. More bars
means better coverage.
4G
4G network type, which means the device is being connected to a 4G network.
E
Edge network type, which means the device is being connected to an Edge network.
G
GPRS network type, which means the device is being connected to a GPRS network.
Network signal not detected.
5
New message received, and the number beside the icon indicates the number of the
unread messages.
Wi-Fi is not being broadcast. A short press of the ―WPS‖ button will turn on the
Wi-Fi radio.
Wi-Fi is being broadcast, and the number of the connected users is indicated to the
right of the Wi-Fi antenna (maximum of 5 total).
Battery power indication. The battery indicator will flash when the battery is
almost drained.
Hardware Installation
About SIM Card
Avoid handling the SIM card unnecessarily. Hold the card by the edges to prevent static damage. Keep
the SIM card away from electrical and magnetic appliances.
If you cannot get T-Mobile wireless service, please ensure:
1.Your T-Mobile service has been activated and you have a mobile phone number.
2.You are in an area with T-Mobile network coverage

Confidential and Proprietary Information of ZTE CORPORATION 7
3.Your T-Mobile SIM Card is properly inserted in the SIM card slot.
Inserting SIM Card and Battery
Warning:
Power off the 4G Mobile Hotspot and remove the external power adapter before removing or inserting
the SIM card. Otherwise, the 4G Mobile Hotspot or SIM card may be damaged.
1. Open the battery cover, located on the bottom of the 4G Mobile Hotspot.
2. Remove the battery.
3. Insert SIM Card into the designated slot.
3. Insert the battery as shown with the contacts located against the metal springs.
4. Line the battery cover up correctly and press gently to close the case.

8 Confidential and Proprietary Information of ZTE CORPORATION
Inserting microSD Card
1. Pull the microSD cover out of the card slot.
Notes:
Do not pull the MicroSD cover too hard, as it could break with excessive force.
2. Insert the microSD card into the microSD slot. The following picture shows the front of the 4G Mobile
Hotspot and how to correctly insert the microSD. You will hear and feel a click when the microSD card
locks in place.
3. Close the microSD cover.
Switching On/Off Your 4G Mobile Hotspot
Press and hold the Power button for 3 seconds to turn on/off the 4G Mobile Hotspot.
Notes:
•The 4G Mobile Hotspot is powered on when the LCD lights up and shows ―T-Mobile‖.
Charging Your 4G Mobile Hotspot
Notes:
•You can charge your 4G Mobile Hotspot by using the USB cable provided with your device.
1. Insert the charger cable carefully into your 4G Mobile Hotspot with the plug arrow facing the bottom of
the device.
2. The plug only fits one way. Do not use excessive force to insert the plug.

Confidential and Proprietary Information of ZTE CORPORATION 9

Confidential and Proprietary Information of ZTE CORPORATION 10
C h a p t e r 2
Working Mode
Your 4G Mobile Hotspot supports two working modes: USB mode and Wi-Fi mode. This document uses
PC or laptop connectivity for examples of connecting 4G Mobile Hotspot.
USB Mode
Connect the 4G Mobile Hotspot to your PC or laptop via the included USB cable, and then power on your
4G Mobile Hotspot.
Software Installation for Windows XP
When you connect your 4G Mobile Hotspot to Windows PC or laptop for the first time, the system will
automatically detect and recognize the new hardware and display the new icon in the desktop status
bar, indicating that the PC or laptop and the 4G Mobile Hotspot have been connected properly. After a
few seconds, the following installation interface will be shown if the laptop and desktop PC supports
automatic installation.
Notes:
