Zte ZXV10 W300 Technical specifications

Operator Logo
ZXV10 W300
Product Description

ZXV10 W300 Product Description
ZXV10 W300 Product Description
Version Date Author Approved By Remarks
V1.00 2009-04-10 Not open to t e T ird Party
ZTE Confidential Proprietary © 2008 ZTE Corporation. All rig ts reserved. I
© 2009 ZTE Corporation. All rig ts reserved.
ZT CONFID NTIAL: T is document contains proprietary information of ZTE and is not to be
disclosed or used wit out t e prior written permission of ZTE.
Due to update and improvement of ZTE products and tec nologies, information in t is document is
subjected to c ange wit out notice.

ZXV10 W300 Product Description
TABLE OF CONTENTS
1 ZXV10 W300 Brief Introduction.................................................................................................1
2 Hardware Support......................................................................................................................1
2.1 Interface1
2.2 C ipset 2
2.3 WLAN Module Antenna.............................................................................................................2
2.4 P ysical Dimensions.................................................................................................................2
2.5 Power Supply............................................................................................................................2
2.6 Operating Environment.............................................................................................................2
2.7 Reliability...................................................................................................................................2
2.8 Packaged Accessories..............................................................................................................3
2.9 LED indicators...........................................................................................................................3
3 Technical Features:...................................................................................................................4
3.1 ADSL Standards.......................................................................................................................4
3.2 ATM Feature.............................................................................................................................4
3.3 PPP Function............................................................................................................................5
3.4 IP/Networking............................................................................................................................5
3.4.1 IP Protocol Support ............................................................................................................. 5
3.4.2 Networking Applications ...................................................................................................... 5
3.5 WiFi Feature..............................................................................................................................6
3.6 Security 7
3.7 IP QoS 7
3.8 Management and Configuration................................................................................................8
II © 2008 ZTE Corporation. All rig ts reserved. ZTE Confidential Proprietary

ZXV10 W300 Product Description
FIGURES
ZXV10 W300...................................................................................................................................1
Led Indicators................................................................................................................................3
ZTE Confidential Proprietary © 2008 ZTE Corporation. All rig ts reserved. III

ZXV10 W300 Product Description
IV © 2008 ZTE Corporation. All rig ts reserved. ZTE Confidential Proprietary

ZXV10 W300 Product Description
1 ZXV10 W300 Brief Introduction
Figure 1 ZXV10 W300
Specifically designed for residential and SOHO markets, ZXV10 W300 allows users to
s are ADSL access from t eir PCs or STBs t roug Et ernet or 802.11g/b wireless
interface. For ig -speed Internet and IPTV service, it provides ATM QoS and IP QoS to
meet different requirements.
It also provides secure wireless encryption modes and powerful SPI firewall to protect
network security. It supports remote network management t roug TR-069, SNMP, CLI
and Web GUI.
2 Hardware Support
T e device offers t e following ardware features support.
2.1 Interface
T e device provides t e following interfaces:
•4 x 10/100Mbps Et ernet Ports(RJ45)
ZTE Confidential Proprietary © 2009 ZTE Corporation. All rig ts reserved. 1

ZXV10 W300 Product Description
•1 x ADSL/ADSL2/ADSL2+ Port(RJ11)
•1 x 802.11g/b WIFI Interface
2.2 C ipset
T e device utilizes t e TrendC ip TC3162P2H c ipset.
2.3 WLAN Module Antenna
T e device uses built-in antenna wit 2 dBi gain for Wireless LAN module
2.4 P ysical Dimensions
•Size: 164*127*32mm
•Weig t: 260g
2.5 Power Supply
•Power supply: uses an external adapter
•Input voltage: 100V~240V, 50Hz~60Hz
•Rated voltage: 12V DC
•Rated current: 700mA
2.6 Operating Environment
•Working temperature: 0°C to +40°C
•Storage temperature: -20°C to +60°C
•Working umidity: 30% to 90%
•Storage umidity: 10% to 93%
2.7 Reliability
•Mean time between failure (MTBF)>60000 ours
2 © 2008 ZTE Corporation. All rig ts reserved. ZTE Confidential Proprietary

ZXV10 W300 Product Description
• Mean time to repair (MTTR)<30 minutes
2.8 Packaged Accessories
Included in t e standard point of sale package will be t e following items:
•1 x W300 Host
•1 x AC Adapter
•1 x Splitter
•1 x Et ernet Cable
•1 x User Manual
•2 x Telep one Line
•1 x Warranty Certificate
2.9 LED indicators
Figure 2 Led Indicators
ZTE Confidential Proprietary © 2009 ZTE Corporation. All rig ts reserved. 3

ZXV10 W300 Product Description
3 Tec nical Features:
3.1 ADSL Standards
•Multi-mode
•ANSI T1.413 Issue 2
•ITU G.992.1 (G.dmt)
•ITU G.992.2 (G.lite)
•ITU G.992.3
•ITU G.992.4
•ITU G.992.5 Annex A/L/M
•ITU G.994.1 (G. s)
•ITU G.997.1
•Fast pat and Interleave pat
3.2 ATM Feature
•Maximum 8 PVCs supported
•MultiProtocol over AAL5 (RFC 1483/2684)
•RFC 2684 Brdiging
•RFC 2684 Routing
•Support multiple sessions based on Single or Multiple PVC
•Support PPPoE (RFC2516), PPPoA (RFC2364), Static, DHCP, Bridge connection
•VPI range :0-255 / VCI range:1-65535
•Support PVC Auto-configuration
•Support PVC isolation
•Support PVC-based and MAC-based packet filtering;
4 © 2008 ZTE Corporation. All rig ts reserved. ZTE Confidential Proprietary

ZXV10 W300 Product Description
3.3 PPP Function
•PAP (RFC 1334) / CHAP (RFC 1994)
•Multiple PPPoE sessions
•Always on/ connect on demand/ manual connect
3.4 IP/Networking
3.4.1 IP Protocol Support
•RFC 791-IP
•RFC 793-TCP
•RFC 768-UDP
•RFC 792-ICMP
•RFC 826-ARP
•RFC 1661-Point-To-Point Protocol(PPP)
•RFC 1332-PPP IP Control Protocol (IPCP)
•RFC2131 Dynamic Host Configuration Protocol
•RFC2132 DHCP Options and BOOTP Vendor Extensions
•PPP Aut entication Protocols
−RFC 1334-PAP
−RFC 1994-CHAP
3.4.2 Networking Applications
•DHCP server/client
•DNS client /proxy
•DDNS client (RFC 2136)
•SNTP client
ZTE Confidential Proprietary © 2009 ZTE Corporation. All rig ts reserved. 5

ZXV10 W300 Product Description
•IGMP v1/v2, IGMP proxy/IGMP snooping
•Bridging
−Supporting IEEE 802.1D Transparent Bridging
−256 MAC address entries
•Routing
−Static routing
−Policy routing
−Default routing
−RIP V1/V2
•UPNP
−Internet Gateway Device (IGD) implementation
•802.1Q VLAN tagging
•L2TP/PPTP/IPSec VPN passt roug
•NAT/PAT/ALG(SIP, TFTP, FTP,H.323, PPTP, RTSP)
•NAT/ALG Enable/Disable
3.5 WiFi Feature
•Operation Frequency :2.4GHz
•Support IEEE802.11g and IEEE802.11b standards
•Support WEP64/128 and WPA-PSK / WPA2-PSK
•Support Hide ESSID
•Support multiple ESSIDs
•Configure RTS/CTS; Fragmentation T res old; Beacon Interval
•Support WMM
•Operating C annels:11 (US), 13 (Europe)
•IEEE 802.11i (Security)
6 © 2008 ZTE Corporation. All rig ts reserved. ZTE Confidential Proprietary

ZXV10 W300 Product Description
•WDS
3.6 Security
•Denial of Service (DoS) protection : Ping of Deat ,SYN Flooding, ARP flooding,
Spoofing, LAND,Smurf
•Prevent port scanning
•IP address filtering
•Mac address filtering
•Port and protocol filtering
•Support URL filtering based on keywords;
•Stateful packets inspection(SPI)
•DMZ, WAN access control
•Port forwarding(Virtual Sever)
•Http basic and digest aut enticaton, certificate based aut entication
•User Privilege: Administrator and User
•Support NAT and firewall enabling/disabling;
3.7 IP QoS
•Support packet classification based on:
−IP source address/IP source subnet mask
−IP destination address/IP destination subnet mask
−Destination TCP/UDP port number or range of port numbers
−MAC source address
−DSCP field
−TOS filed
−Protocol type
ZTE Confidential Proprietary © 2009 ZTE Corporation. All rig ts reserved. 7

ZXV10 W300 Product Description
−SSID
•802.1P and DSCP remarking based on packet classification
•Strict Priority
•4 Priority Queue
3.8 Management and Configuration
•Support TR-069;
•Support TR-064 (optional)
•Support SNMP V1/V2;
•Support Web-based GUI;
•Support User Access Levels;
•Support Traceroute;
•Support CLI;
•Support Telnet management;
•Support TFTP and HTTP firmware upgrade;
•Support TFTP and HTTP configuration file upload and download;
•Factory setting reset;
•Support system log;
•Support F4/F5 SEG, ETE OAM
•Diagnostic Tool for ADSL and IP Ping
•Support manual upgrade of software and configuration t roug local web-based
management interface.
•Support remote firmware and configuration upgrade accessible t roug web-based
management interface and TR069 ACS.
