Zurik EMLV LED Driver 300W User manual

DCAC
INTRODUCTION
The Zurik® EMLV Dimmable Driver is the most versatile and ecient dimmable electronic driver for single color output LED strips. This driver has
a high power factor of 0.99, a universal input and perfect compatibility with a wide range of dimmers for icker free lighting. Its high power
eciency, wide voltage input, and quiet operation make the EMLV the professional’s choice when it comes to awless dimming.
SAFETY AND WARNINGS
Install in accordance with the National Electric Code (NEC) Article 450, and local regulations.
This product should be installed and serviced by a qualied electrician.
Install in a well ventilated area free from explosive gases and vapors.
Do not reverse the line voltage polarity upon installation. This will damage the driver.
Risk of electric shock: When used outdoors, install only on a circuit protected by a Class A GFCI.
Risk of re: Special rated wire required for installations inside walls and building structures.
Consult a qualied electrician. Do not install in wet locations. Install only in dry or damp locations.
Only use with compatible dimmable LED xtures.
Dimmer switches have minimum load requirements. Review the specications of the compatible dimmer.
Modifying or disassembling this product beyond these instructions will void the product warranty.
•
•
•
•
•
•
•
•
•
•
ZURIK®EMLV 12V & 24V 300W LED DRIVER
Low Voltage LED Driver
DRIVER
Output Power Wires
Addional Features
(L) Live Channel
(N) Neutral Channel
( ) Ground Channel Input Power Wire
Negative Channel (-)
Positive Channel (+)
*The 24V version comes with one Outlet Power Wire instead of two
•Constant voltage output
•Easy installation
•Cooling by free air convection
•Compatible with most forward phase, magnetic low voltage,
reverse phase, and electronic low voltage dimmers
•Flicker-free dimming
•Suitable for LED lighting and sign applications among other uses
•Comes with junction box: H: 17 13/16“ (453mm) W: 3 3/8“ (86mm)
D: 2 5/16” (59mm)
V.2021.10.13
support@FlexfireLEDs.com 925-273-9080 opt 1
ZRK-EMLV2-300W-XXDC-J
1page
ZURIK®EMLV LED Driver 300W
User Guide

Details
Notes
ZRK-EMLV2-300W-XXDC-J
IP66 (indoor and outdoor)
110 - 277 VAC
12VDC or 24VDC
12V: 25A 24V: 12.5A
300W
47 ~ 63Hz
0.99 (fully loaded)
12V: 86% 24V: 88%
3.4A @ 110VAC
<0.50mA
Shuts down output voltage, recovers
after faulty condition is removed
≤120%
212°F ± 18°F (100°C ± 10°C) Shuts
down output voltage, recovers after
faulty condition is removed
-40°F ~ 140°F (-40°C ~ 60°C)
SKU:
Ingress Protection:
Input Voltage:
Output Voltage:
Rated Current:
Rated Power:
Frequency Range:
Power Factor:
Efficiency (Typ.):
AC Current (Max.):
Leakage Current:
Short Circuit:
Overload Protection:
Overheat Protec-
tion:
20 ~ 90%RH. Non condensing
-40°F ~ 176°F (-40°C ~ 80°C),
10 ~ 95%RH
±0.03% /°C [32°F ~ 122°F (0 ~ 50°C)]
10 ~ 500Hz, 2G 10min./ 1 cycle, period
for 60min. Each along X,Y,Z axes
UL (E500166), conforms to UL8750,
certied to CSA STD.C22.2 No. 250.13
I/P-O/P:1880VAC
I/P-O/P:100MΩ/500VDC/25°C/70%RH
FCC Part 15B
3.74lb (1.7kg) without junction box
H: 10 7/8” (276mm) W: 3 1/8“ (78mm)
D: 1 7/8” (47mm)
400Hz
7 years
Working Humidity:
Storage Temp. and
Humidity:
Temp. Coefficient:
Vibration:
Certifications:
Withstand Voltage:
Isolation Resistance:
EMC Emission:
Weight:
Dimensions:
PWM Frequency:
Warranty:
•All parameters if not specially mentioned are measured at 120VAC input, rated load and ambient temperature of 25°C.
•To extend the life of the driver keep the load below 90%.
•Load on the driver should be within 10%-100%.
•Loading on the AC dimmer should not be below 40% in order to extend the life of the dimmer.
V.2021.10.13
support@FlexfireLEDs.com 925-273-9080 opt 1
ZRK-EMLV2-300W-XXDC-J
2page
User Guide •ZURIK®EMLV LED Driver 300W

-40
20
40
60
80
100
-20 0-10 -20 30
Ambient Temperature (°C)
Load (%)
40 50 60 70
Single Color LED strip
Small at-head screwdriver (4mm) Wire strippers or scissors
AC dimmer (optional)EMLV Driver Wire connectors
(terminal block, electrical
tape, crimp connector, etc)
2-wire stranded low
voltage wire
DC
AC
To extend the power supply’s life, refer to the Derating Curve above and derate according to the ambient temperature
DERATING CURVE
YOU’LL NEED
V.2021.10.13
support@FlexfireLEDs.com 925-273-9080 opt 1
ZRK-EMLV2-300W-XXDC-J
3page
User Guide •ZURIK®EMLV LED Driver 300W

AC
120V AC Magnetic Low
Voltage Dimmer Switch
120V AC
Power
Positive (+)
Negative (-)
Positive (+)
Negative (-)
or
Knockout Holes
12”
12”
12” 12”
Always pre-test your LED setup prior to permanent installation. This will ensure all components work correctly. Be sure to check the wattage pull
of the LED strip you’ve purchased so the driver isn’t overloaded (Max. 270W). Turn o the main AC breaker for the line you’ll be using before install-
ing your EMLV driver. If you experience any issues at all with your test set up, please be sure to contact us at After Sales Support.
Connect the AC line ground (G) to the green wire from the Power Input
Wire. Do the same with the AC neutral wire to the white wire on the
driver and the AC live wire to the black wire. you can secure these
connections with a terminal block.
When using a 3-pole dimmer as a single pole make sure to cap the
additional line and connect the rest of the wiring as recommended by
the dimmer instructions. Find our list of compatible dimmers below.
Look at your LED strips carefully and identify the positive (+) and
negative (-) channels.
Connect the driver’s Output Power negative (-) wire to the - channel on
the LED strip. Connect the positive (+) wire to the + channel.
INSTALLATION
It can be mounted in any orientation, the chosen location must be able
to support the weight of the power supply with 12” of clearance for
proper ventilation. Never mount it next to objects radiating heat.
Remove wiring knockouts as needed and install 3/8” romex connectors
or bushings to reduce strain on wires. One set of knockout holes is
reserved for input voltage while the second set is reserved for output
voltage.
3. 4.
5. 6.1.
Connect Power Wires Using A Dimmer
Idenfy The Channels On The Strip Connect Outbound LED Wires (12VDC)
1. 2.
Mounng The Juncon Box (oponal) Using The Knockout Holes (oponal)
V.2021.10.13
support@FlexfireLEDs.com 925-273-9080 opt 1
ZRK-EMLV2-300W-XXDC-J
4page
User Guide •ZURIK®EMLV LED Driver 300W

DC
DCAC
LUTRON COMPATIBLE DIMMERS
Forward
Phase
or Reverse
Phase
Dimming
Range
Input
Voltage
Model Number
(Dimmer)
Model Wattage
DVCL-153PR-WH 100-130V 0-100%Diva Forward Phase 150W
DVWCL-153PH-LA 100-130V 0-100%Diva Forward Phase
150W
MACL-153MH-LA 100-130V 20-100%Maestro Forward Phase
150W
DV-600PR-WH 100-130V 0-100%Diva Forward Phase
600W
MRF2-6ND-120-AL 100-130V 0-100%Maestro Forward Phase
600W
MRF2-6CL-GR 100-130V 15-100%Maestro Forward Phase
150W
MSCELV-600M 100-130V 0-100%Maestro Reverse Phase
600W
MRF2-6ELV-120 100-130V 0-100%Maestro Reverse Phase
600W
MIR-600M 100-130V 2-100%Maestro IR Remote Ctrl Forward Phase
600W
NTF-10-277 277V1000W 13-100%Nova T Forward Phase
TGCL-153PR-WH 100-130V 0-100%Ariadni / Toggler Forward Phase 150W
TGCL-153PH-WH 100-130V 0-100%Ariadni / Toggler Forward Phase
150W
TG-600PR-WH 100-130V 0-100%Ariadni / Toggler Forward Phase
600W
TG-10PR-WH 100-130V 0-100%Ariadni / Toggler Forward Phase
1000W
PD-6WCL 100-130V 20-100%Caseta Forward Phase
150W
PD-5NE-WH 100-130V 18-100%Caseta Forward Phase
250W
Caseta PD-10NXD-WH 100-130V800W 10-100% Forward Phase
Turn the main breaker for the AC line back on to power your EMLV
driver. The LED strip should turn on.
Look at your LED strips carefully and identify the positive (+) and
negative (-) channels.
7. Turn Power On 6.2 Connect Outbound LED Wires (24VDC)
V.2021.10.13
support@FlexfireLEDs.com 925-273-9080 opt 1
ZRK-EMLV2-300W-XXDC-J
5page
User Guide •ZURIK®EMLV LED Driver 300W

Forward
Phase
or Reverse
Phase
Dimming
Range
Input
Voltage
Model Number
(Dimmer)
Model Wattage
CTCL-153PDH-LA 100-130V 0-100%Skylark Contour Forward Phase 150W
CT-600PR-WH 100-130V 0-100%Skylark Contour Forward Phase
600W
CT-103PR-WH 100-130V 2-100%Skylark Contour Forward Phase
1000W
SCL-153PR-WH 100-130V 0-100%Skylark Forward Phase
150W
S-600PR-WH 100-130V 0-100%Skylark Forward Phase
600W
SELV-300P 100-130V 15-100%Skylark Reverse Phase
300W
NTLV-600-277-WH 277V 1-100%Nova T Forward Phase
450W
SF-12P-277 277V 13-100%Skylark Forward Phase
6Amp
OTHERS COMPATIBLE DIMMERS
Forward
Phase
or Reverse
Phase
Dimming
Range
Input
Voltage
Model Number
(Dimmer)
Brand Wattage
VPI06-1LZ 100-130V 15-100% Forward Phase 600W
Forward Phase
TTI06-1LZ 100-130V 1-100%600W
Forward Phase
IPL06 100-130V 15-100%150W
Forward Phase
DZ6HD 100-130V 17-100%600W
Forward Phase
6674 100-130V 16-100%Leviton 150W
Forward Phase
6672 100-130V 20-100%150W
Forward Phase
TBL03 100-130V 15-100%150W
Forward Phase
6602 100-130V 0-100%600W
Forward Phase
6683 100-130V 10-100%600W
Forward Phase
RHCL453PNICCV6 100-130V 6-100%-
Forward Phase
WSCL450TCCCV4 100-130V 11-100%Legrand 450W
Forward Phase
LSCL453PLACCV4 100-130V 11-100%450W
Reverse Phase
CNLW-DELVEX-P-W-S 100-130V 11-100%Crestron 500W
V.2021.10.13
support@FlexfireLEDs.com 925-273-9080 opt 1
ZRK-EMLV2-300W-XXDC-J
6page
User Guide •ZURIK®EMLV LED Driver 300W

L
N
AC
Input
Zurik EMLV Dimmable
Power Supply
Home Automation
System
Output
LED
AC Dimmer
(Lutron & Clipsal
C-Bus System)
L
N
AC
LN
Output
L
N
Input
Zurik EMLV Dimmable
Power Supply
LED
Output
L
N
Input
Zurik EMLV Dimmable
Power Supply
L
Output
L
N
Input
Zurik EMLV Dimmable
Power Supply
L
N
AC
Input
AC Dimmer
Zurik EMLV Dimmable
Power Supply
Output
LED
L
• Using a single driver
• Using multiple drivers
WIRING DIAGRAMS
V.2021.10.13
support@FlexfireLEDs.com 925-273-9080 opt 1
ZRK-EMLV2-300W-XXDC-J
7page
User Guide •ZURIK®EMLV LED Driver 300W

AC Dimmer
(Lutron & Clipsal
C-Bus System)
L
N
AC
LN
LED
L N
N
Output
L
N
Input
Black
Zurik EMLV Dimmable
Power Supply
Output
L
N Blue
Input
Zurik EMLV Dimmable
Power Supply
Output
L
N
Input
Zurik EMLV Dimmable
Power Supply
LUTRON
AC Dimmer
L
N
AC
LN
LED
DL/SL1
Output
L
N
Input
Zurik EMLV Dimmable
Power Supply
Output
L
N
Input
Zurik EMLV Dimmable
Power Supply
Output
L
N
Input
Zurik EMLV Dimmable
Power Supply
TROUBLESHOOTING
-If the driver is humming, lights are not turning on or are ickering:
•Check that this driver is not overloaded or overheated. The automatic breaker will trip and recover once the external cause has been corrected.
•Make sure the polarity of the AC line wires match the polarity of the channels on the Power Input Terminal.
•If the driver is powered, check the polarity on the Power Output Terminal. Make sure you have matched the markings on the LED strip to the
channels on the driver.
•Check that your dimmer is on the compatible dimmer list.
•Make sure all the connections (solderless connectors, solder joints, terminal blocks, and spliced wires) are secure and making correct contact.
•Make sure the power requirements are being met, 100-277VAC input and 12-24VDC output (depending on the driver), check these with a
multimeter.
•If the driver isn’t providing the adequate voltage ensure proper size gauge wire is installed by factoring voltage drop and amperage rating. If
the voltage at the end of the wire is 10.5V or less for a 12V unit and less than 21V for a 24V unit, we recommend installing a heavier gauge wire
between the driver and the LED load.
•Check that the wire connections are accurate by referring to the wiring diagrams provided.
•Check that your installation has not tripped the circuit breaker at the main service panel of the building. If this occurred reset the breaker. If it
trips again, it is possible that there is an electrical short/defective component or a connection issue on the AC side of the driver.
V.2021.10.13
support@FlexfireLEDs.com 925-273-9080 opt 1
ZRK-EMLV2-300W-XXDC-J
8page
User Guide •ZURIK®EMLV LED Driver 300W

Consumer’s Acknowledgment
Flexre LEDs, Inc. stands behind its products when they are used properly and according to our specications. When you purchase our
products, you are agreeing to the terms and conditions outlined in our warranty section. We try our best to make recommendations, but
the burden of proper installation, design, and maintenance relies on the purchaser.
This limited warranty does not include product failures that are the result of:
Not using a voltage regulated power supply to connect the LED product or controls; Connecting LED products to the wrong output
voltage; Improper connection of power supplies, LED products, or controls; Connecting LED products or controls directly to any AC
power source if they are stated for DC only input; Connecting power supplies backwards to an AC power source; Products used in an
inappropriate location or in environmental conditions (temperature, humidity, moisture, etc.) outside the normal specied range; Water
damage to products not specically sold as waterproof products; Electrical power surges and spikes; Damage from hail, ooding, torna-
do, re, wind, earthquake, lightning, electrical storm, or any other natural disasters or “force majeure” incidences; Damage caused by a
vehicle or other accident; Damage caused when transporting the item; Damage to any products that were modied by the user, used
for purposes other than as intended or directed, or connected to LED systems or components not purchased from Flexre LEDs; Products
that have been subjected to misuse, mishandling, misapplication or accident. Products used in connection with any components, devic-
es or systems other than those explicitly approved as compatible with Company’s products and listed on Company’s website. Excessive
wear and tear and/or physical or accidental abuse, loss, or theft. Improper repairs or warranty services performed by someone other than
Flexre LEDs will void this warranty.
WARRANTY INFORMATION
Limited Warranty:
This product has a 7 year limited warranty from the date of shipment. This warranty only includes the main product outlined in this speci-
cation sheet and does not include the additional accessories that are used as a reference. Complete warranty details for xtures and
additional accessories are available at https://www.exreleds.com/warranties/ within the Policies section. For warranty related ques-
tions please contact product support team at (support@exreleds.com).
V.2021.10.13
support@FlexfireLEDs.com 925-273-9080 opt 1
ZRK-EMLV2-300W-XXDC-J
9page
User Guide •ZURIK®EMLV LED Driver 300W
