ZyXEL Communications P-335WT User manual

P-335
Firewall Router with Print Server
P-335WT
802.11g Wireless Firewall Router with Print Server
Quick Start Guide
Version 3.60
9/2005
Table of Contents
ENGLISH 3
DEUTSCH 20
ESPAÑOL 40
FRANÇAIS 59
ITALIANO 78
中文 97

P-335, P-335WT Quick Start Guide
2
ENGLISH 3
DEUTSCH 20
ESPAÑOL 40
FRANÇAIS 59
ITALIANO 78
中文 97

ENGLISH
3
Overview
The Prestige is a broadband router with a built-in four-port 10/100 Mbps switch. The Prestige makes it easy to
set up a small home or office network and share Internet access via a broadband (cable/DSL) modem. Key
features of the Prestige include a firewall, print server, VPN, content filtering, NAT and UPnP.
You should have an Internet account already set up and have been given most of the following information.
Table 1 Internet Account Information
See your User’s Guide for background information on all features.
The follow lists what you need to do:
Your device’s WAN IP Address (if given): ______________
DNS Server IP Address (if given): Primary _____________, Secondary ______________
Connection Type:
Ethernet Service Type: _______________________
User Name: ____________
Login Server IP Address: ______________
Password: ____________
PPTP: User Name: ____________
Your WAN IP Address (if given) ____________
Connection ID (if required): ____________
Password: ____________
PPTP Server IP Address: ___________
or PPTP Domain Name: ___________
¦PPPoE (PPPoE) Service Name: ____________
User Name: ____________ Password: ____________
1Hardware Connections 2Accessing the Web Configurator
3Internet Access Setup 4Bandwidth Management Wizard
ENGLISH

ENGLISH
4
1 Hardware Connections
Do the following to make hardware connections for initial setup.
WAN Connection
Connect your modem to the “WAN” port using the cable that came with your modem.
LAN Connection
Connect your computer to a "LAN" port using the included Ethernet cable.
USB Printer Port Connection
Use a USB cable to connect a USB printer to this port. The Prestige has a built-in print server that allows a
network to share a printer. The Prestige automatically detects the make and model of the USB printer.
POWER Connection
Use the included power adaptor to connect the POWER socket to an appropriate power source (see the User’s
Guide for power adaptor specifications by region).
1
2
3
4

ENGLISH
5
2 Accessing the Web Configurator
1Launch your web browser. Enter “192.168.1.1” as the web site address.
Note: If you do not see the next screen, then please go to section 5.1.
The LEDs
Look at the front panel LEDs. When
you connect the power, the PWR and
WLAN (P-335WT) LEDs come on.
The LAN and WAN LEDs turn on if the
corresponding connections are
properly made. The USB LED turns on
if a USB device is connected.
2The Password window displays. Enter the
password (“1234” is the default) and click Login.
3Change the password in the screen that follows
and click Apply.
4Click Go Wizard setup and click Apply to set up
your Prestige for the first time.

ENGLISH
6
Note: The Next button is located on the bottom right of each screen.
3 Internet Access Setup
Note: Enter the Internet access information exactly as given to you by your ISP in each wizard screen
and then click Next to continue or click Back to return to the previous screen.
Current screen information will be lost if you click Back.
System Information
Wireless LAN (P-335WT)
Configure ONE of the following wireless security types on the Prestige:
•Auto security: Uses WPA-PSK security with an automatically generated Pre-Shared Key. View the generated
Pre-Shared Key in the Wireless LAN screen.
Note: Your wireless clients must support WPA-PSK and use the same key.
5Choose your language from the drop-down list
box. Click go.
6Click Next to proceed with the Connection Wizard.
1This screen is optional. You can just click Next.
•System Name is for identifying the Prestige. You
can enter your computer's "Computer Name".
• If you leave the Domain Name blank, the domain
name obtained by DHCP from the ISP is used.
STEP 1:
STEP 2:

ENGLISH
7
•None: Have no wireless LAN security configured. If you do not enable any wireless security on your Prestige,
your network is accessible to any wireless networking device that is within range.
•Basic security: WEP (Wired Equivalent Privacy) encrypts data frames before transmitting over the wireless net-
work. The higher the WEP Encryption, the higher the security but the slower the throughput.
•Extend (WPA-PSK or WPA2-PSK) security: Configure a Pre-Shared Key. Choose this option only if your wire-
less clients support WPA-PSK or WPA2-PSK respectively.
Note: The wireless clients and Prestige must use the same SSID, channel ID and WPA(2)-PSK (if
WPA(2)-PSK is enabled) or WEP encryption key (if WEP is enabled) for wireless communication.
OTIST
• OTIST (One-Touch Intelligent Security Technology) allows your Prestige to assign wireless clients the Pres-
tige’s SSID and static WEP or WPA-PSK encryption settings. The wireless client must also support OTIST and
have OTIST enabled.
A Enter a unique name to identify the Prestige in the wireless LAN.
BLeave the default setting. The Prestige and wireless client must use the same channel ID.
CSelect a level of wireless security. Choose Auto or None.
DYes is enabled by default. Select the No radio button and click Next to configure OTIST later.
EThe default OTIST Setup Key is “01234567”. This key can be changed in the web configurator. Be sure to use
the same OTIST Setup Key on the Prestige and wireless clients.
Auto or No Wireless Security

ENGLISH
8
A Enter a unique name to identify the Prestige in the wireless LAN.
BLeave the default setting. The Prestige and wireless client must use the same channel ID.
CSelect Basic(WEP) security.
DYou can generate or manually enter a WEP key by either:
Entering a Passphrase (up to 32 printable characters) and clicking Generate. The Prestige automatically
generates a WEP key.
Or entering manual keys in each Key (1~4) field and selecting ASCII or Hex WEP key input method.
ESelect 64-bit, 128-bit or 256-bit from the WEP Encryption drop-down list.
FSelect ASCII or Hex characters.
GSelect one of the Key radio buttons to use as the default WEP key.
HYes is enabled by default. Select the No radio button and click Next to configure OTIST later.
IThe default OTIST Setup Key is “01234567”. This key can be changed in the web configurator. Be sure to use
the same OTIST Setup Key on the Prestige and wireless clients.
D
E
A
B
C
Basic(WEP) Security

ENGLISH
9
A Enter a unique name to identify the Prestige in the wireless LAN.
BLeave the default setting. The Prestige and wireless client must use the same channel ID.
CSelect WPA-PSK or WPA2-PSK security.
DType a pre-shared key to have a more secure wireless connection than WEP encryption. Type from 8 to 63
case-sensitive ASCII characters.You can set up the most secure wireless connection by configuring WPA in
the advanced wireless screen. You need to configure a RADIUS server to do this.
EYes is enabled by default. Select the No radio button and click Next to configure OTIST later.
FThe default OTIST Setup Key is “01234567”. This key can be changed in the web configurator. Be sure to use
the same OTIST Setup Key on the Prestige and wireless clients.
F
D
E
G
A
B
C
D
E
Extend(WPA-PSK) or (WPA2-PSK) Security

ENGLISH
10
A
B
C
D
D
E

ENGLISH
11
WAN
The wizard attempts to detect which WAN connection type you are using.
If the wizard does not detect a connection type, you must select ONE from the drop-down list box. Check with your
ISP to make sure you use the correct type:
1Ethernet
2PPPoE
3PPTP.
Note: If you were given Internet access settings, enter them in the following fields. Otherwise leave the
default settings and just click Next
STEP 3:

ENGLISH
12
A Select Ethernet as your WAN connection type.
BSelect Get automatically from your ISP if your ISP did not assign you a fixed IP address. Skip to D.
Or
Select Use fixed IP address provided by your ISP to give the Prestige a fixed, unique IP address.
CEnter a WAN IP address and WAN IP Subnet Mask of the neighboring device, if you know it. If you do not,
leave the default settings.
If you were given IP address and/or DNS server settings, enter them in the fields. Otherwise leave the default
settings and just click Next.
D Select Factory Default to use the factory assigned default MAC address.
Ethernet Connection
A
B
C
D

ENGLISH
13
A Select PPPoE as your WAN connection type.
BType a Service Name (Optional), User Name and Password.
CSelect Get automatically from your ISP if your ISP did not assign you a fixed IP address. Skip to E.
Or select Use fixed IP address provided by your ISP to give the Prestige a fixed, unique IP address.
DEnter the WAN IP address of the neighboring device, if you know it. If you do not, leave the default settings.
If you were given IP address and/or DNS server settings, enter them in the fields. Otherwise leave the default
settings and just click Next.
E Select Factory Default to use the factory assigned default MAC address.
PPPoE Connection
A
B
E
C
D

ENGLISH
14
A Select PPTP as your WAN connection type.
BType a User Name and Password
C Select Get automatically from ISP if your ISP did not assign you a fixed PPTP IP address.
Or select Use fixed IP address to give the Prestige a fixed, unique PPTP IP address and subnet mask.
DType a PPTP Server IP Address
EType a Connection ID/Name (if provided)
FSelect Get automatically from your ISP if your ISP did not assign you a fixed IP address. Skip to H.
Or select Use fixed IP address provided by your ISP to give the Prestige a fixed, unique IP address.
GEnter a WAN IP address and WAN IP Subnet Mask of the neighboring device, if you know it. If you do not,
leave the default settings.
If you were given IP address and/or DNS server settings, enter them in the fields. Otherwise leave the default
settings and just click Next.
H Select Factory Default to use the factory assigned default MAC address.
PPTP Connection

ENGLISH
15
B
C
D
E
A
F
G
H

ENGLISH
16
Internet Access Setup Complete
4 Bandwidth Management Wizard
Click the Go to Bandwidth Management Wizard (optional) hyperlink or click the Bandwidth Management
wizard option in the Welcome to the ZyXEL Wizard Setup screen.
If you have any Internet access problems, follow the
on-screen instructions.
Click the Go to Bandwidth Management Wizard
(optional) hyperlink to start the bandwidth
management wizard; otherwise click Finish.
Bandwidth management allows you to control the
amount of bandwidth going out through the
Prestige’s WAN port and prioritize the distribution of
the bandwidth according to service bandwidth
requirements. This helps keep one service from
using all of the available bandwidth and shutting out
other users.
Click Next to proceed.

ENGLISH
17
General Information
Services Setup
Select the Active check box.
The Prestige does not control the bandwidth allocated
to traffic that comes into an interface.
Enter the amount of Managed Bandwidth in kbps (2
to 100,000) that you want to allocate for traffic. The
recommendation is to set this speed to be equal to or
less than the upstream speed of the cable/DSL
modem connected to the WAN port of the Prestige.
For example, set the speed to 1000 Kbps (or less) if the cable/DSL modem connected to the WAN port has an
upstream speed of 1 Mbps.
Select the services for which you want to manage
bandwidth.
Xbox Live: This is Microsoft’s online gaming service
that lets you play multiplayer Xbox games through
the Internet.
FTP: File Transfer Program enables fast transfer of
files, including large files that may not be possible
by e-mail.
VoIP (SIP): Sending voice signals over the Internet
is called Voice over IP or VoIP.
E-Mail: Electronic mail consists of messages sent through a computer network to specific groups or
individuals.
eMule/eDonkey: These programs use advanced file sharing applications relying on central servers to search
for files.
WWW: The World Wide Web is an Internet system to distribute graphical, hyper-linked information, based on
Hyper Text Transfer Protocol (HTTP) - a client/server protocol for the World Wide Web.
STEP 1:
STEP 2:

ENGLISH
18
Priority Setup
5 Troubleshooting
Note: If your computer cannot automatically communicate with the device, then see the multimedia
tutorial on how to set up your computer to receive an IP address dynamically or give it a fixed
one in the range specified in section 5.1.
Select High, Mid or Low priority to control the
distribution of bandwidth to selected services.
A service with High priority is given as much
bandwidth as it needs.
If you select services as having the same priority,
then bandwidth is divided equally amongst those
services.
Services not specified in bandwidth management are
allocated bandwidth after all specified services
receive their bandwidth requirements. If the rules set
up in this wizard are changed in the advanced setup,
then the service priority will be set to Others.
Click Finish to save and complete the wizard setup.
See the Bandwidth MGMT screens in the ADVANCED configuration to edit class configurations and
bandwidth rules.
PROBLEM CORRECTIVE ACTION
None of the LEDs turn on when
you connect the Prestige’s
power.
Make sure that you have the correct power adaptor connected to the Prestige, it
is plugged into an appropriate power source.
Check all cable connections. If the LEDs still do not turn on, you may have a
hardware problem. In this case, you should contact your local vendor.
Cannot access the Prestige
from my computer.
Check the cable connection from your computer to the Prestige.
If the Prestige’s IP address has changed, then enter the new one as the website
address.
Make sure your computer’s IP address is in the same subnet as the Prestige’s
IP address (see section 5.1).
Ping the Prestige from a computer on the LAN. Make sure your computer’s
Ethernet adapter is installed and functioning properly. In the computer, click
Start, (All) Programs, Accessories and then Command Prompt. In the
Command Prompt window, type "ping" followed by the Prestige’s LAN IP
address (192.168.1.1 is the default) and then press [ENTER]. The Prestige
should reply; otherwise see section 5.1.
STEP 3:

ENGLISH
19
5.1 Set Up Your Computer’s IP Address
This section shows you how to set your Windows NT/2000/XP computer to automatically get an IP address.
This ensures that your computer can communicate with your Prestige. Refer to your User’s Guide for detailed
IP address configuration for other Windows and Macintosh computer operating systems.
1In Windows XP, click start, Control Panel. In Windows 2000/NT, click Start, Settings, Control Panel.
2In Windows XP, click Network Connections. In Windows 2000/NT, click Network and Dial-up
Connections.
3Right-click Local Area Connection and then click Properties.
4Select Internet Protocol (TCP/IP) (under the General tab in Win
XP) and click Properties.
5The Internet Protocol TCP/IP Properties screen opens (the
General tab in Windows XP).
6Select the Obtain an IP address automatically and Obtain
DNS server address automatically options.
7Click OK to close the Internet Protocol (TCP/IP) Properties
window.
8Click Close (OK in Windows 2000/NT) to close the Local Area
Connection Properties window.
9Close the Network Connections screen.
Viewing Your Product’s Certifications
1Go to www.zyxel.com.
2Select your product from the drop-down list box on the ZyXEL
home page to go to that product's page.
3Select the certification you wish to view from this page.
Cannot access the Prestige
from my computer (continued).
Use Internet Explorer 6.0 and later or Netscape Navigator 7.0 and later with
JavaScript enabled.
Make sure you enter the password correctly (the field is case sensitive).
If you’ve forgotten the Prestige’s password, use the RESET button. Press the
button in for about 10 seconds (or until the SYS LED starts to blink), then
release it. It returns the Prestige to the factory defaults (password is 1234, LAN
IP address 192.168.1.1 etc.).
Cannot access the Internet. Verify the Internet connection settings in the wizard. Make sure you entered the
correct user name and password if you are using PPPoE or PPPoA.
PROBLEM CORRECTIVE ACTION

DEUTSCH
20
Übersicht
Der Prestige ist ein Breitband-Router mit einem integrierten 10/100 Mbps Schalter mit vier Anschlüssen. Mit
dem Prestige können Sie ganz einfach ein kleines Heim- oder Büronetzwerk aufbauen und einen
Internetzugang von mehreren Rechnern aus über ein Breitbandmodem (Kabel/DSL) nutzen. Die
Leistungsmerkmale des Prestige schließen eine Firewall, Druckserver, VPN, Webinhaltfilterung, NAT und UPnP
ein.
Voraussetzung sind ein bestehendes Internetkonto und die folgenden Informationen.
Tabelle 1 Daten zum Internetkonto
Ausführliche Informationen zu allen Funktionen finden Sie im Benutzerhandbuch.
Im Folgenden wird aufgeführt, welche Schritte notwendig sind:
Die WAN IP-Adresse Ihres Geräts (wenn vorhanden): ______________
DNS Server IP-Adresse (wenn vorhanden): Primär _____________, Sekundär ______________
Verbindungstyp:
Ethernet Diensttyp: _______________________
Benutzername: ____________
Login Server IP-Adresse: ______________
Passwort: ____________
PPTP: Benutzername: ____________
Ihre WAN IP-Adresse (wenn vorhanden)
____________
Verbindungs-ID (wenn erforderlich):
____________
Passwort: ____________
PPTP Server IP-Adresse: ___________
oder PPTP Domain-Name: ___________
PPPoE (PPPoE) Dienstname: ____________
Benutzername: ____________ Passwort: ____________
1Anschließen der Hardware 2Zugriff auf den Web-Konfigurator
3Einrichten des Internetzugangs 4Bandwidth Management Wizard (Bandbreitenmanagement-
Assistent)
DEUTSCH
