Benefits
Delivering Secure Converged
SMB Networks
ł
RIP, Static Routing Protocol Support
ł
Flexible 4 GbE Uplink Interfaces
(Copper/Fiber)
ł
Multilayer-aware (L2/L3/L4) ACL for
Security Protection
ł
Port Security and Enhanced 802.1x
Port Authentication
ł
MAC Freeze and Intrusion Lock
ł
Backup Power System Support
ł
Multilayer-Aware (L2/L3/L4) ACL for
Optimizing Traffic Prioritization
ł
IEEE 802.1p 8 Hardware Priority
Queue
ł
WFQ,WRR and SPQ Queuing
Algorithms
Delivering Secure Convergence within the SMB Network
The ZyXEL ES-2724 is designed for SMB networks to realize multifunctional and flexible connectivity.
In addition to L2 switching, the ES-2724 offers L3 routing for specialized applications to be handled that
makes the ES-2724 an one-device, cost-effective platform for a SMB to build a combined L2 switching and
L3 routing network. Moreover, the ES-2724 offers prioritization of applications such as VoIP and security
with QoS configured through the ES-2724 network management tools.
Secure Multi-Service Delivery Quality
To harness multiple services such as VoIP, video conferencing and video streaming in business
environments, the ES-2724 is equipped with valued-added features for optimized traffic prioritization.
The combination of eight priority queues and the WFQ scheduling algorithm guarantees the quality of
time-sensitive applications,while different services can be assigned to specific VLANs and configured with
different priorities for traffic management.The ES-2724 comes with Multi-layer ACLs that provides L2/L3/L4
indicators for enforcing policy management on traffics.
Enhanced Multi-layer Security Protection
The ES-2724 is capable of strict security protection. For example,intrusion lock deters intruders while MAC
freeze,static MAC forwarding and MAC filtering provides MAC address-based protection. 802.1Q VLAN
divides the network traffic into different virtual LANs to protect business-critical information. Multi-layer
ACL provides L2/L3/L4 indicators for policy management and security protection. In terms of access
authentication, 802.1x supported for centralized management, and 802.1x further facilitates VLAN and
bandwidth allocation.
cover
24-port Managed L3 Fast
Ethernet Switch
ES-2724

Specifications
Standard Compliance
• IEEE 802.3 10BASE-T Ethernet
• IEEE 802.3u 100BASE-Tx Ethernet
• IEEE 802.3ab 1000BASE-T Ethernet
• IEEE 802.3z
• IEEE 802.3x Flow control
• IEEE 802.1D Spanning tree protocol
• IEEE 802.1w Rapid Spanning tree protocol
• IEEE 802.1p Class of service, priority protocols
• IEEE 802.1Q VLAN tagging
• IEEE 802.1x Port Authentication
• IEEE 802.3ad LACP aggregation
Performance
• 12.8 Gbps non-blocking switching fabric
• Switching Forwarding Rate 9.6 Mpps (1488000
pps/1000BASE-T/1000BASE-X/1000BASE-BX,
148800 pps/100BASE-TX)
• Wire-speed performance
MAC and Packet Buffer
• 16 K MAC entries
• 32 MB Packet Buffer
Traffic Management and QoS
• Rate Limiting: Rule-based/Port-based
bandwidth control, 64 kbps granularity
• CIR/PIR for bandwidth control
• Port-based egress traffic shaping
• Broadcast Storm Control
• IEEE 802.1p with 8 priority queues per port for
different traffic types
• WFQ (Weighted Fair Queuing)/WRR (Weighted
Round Robin)/SPQ scheduling algorithm
• Supports DSCP
• Supports DSCP to 802.1p priority mapping
• Supports IGMP/IGMP snooping v1, v2
• Supports MVR
• Congestion control on all ports
IP Routing and Service Features
• 8 IP routing domains
• 4 K IP address table
• Wire-speed IP forwarding
• RIP v1, v2
• Static Routing
• IGMP v1, v2
• Support DHCP Server
Link Aggregation
• IEEE 802.3ad LACP link aggregation compliant
• Support static manually port trunking
• Up to 6 aggregation groups, 8 ports/per group
randomly selected
Resilient Network
• IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
• BPS (Backup Power System)
User Security and Authentication
• IEEE 802.1Q tag-based and port-based VLAN
• Support GVRP, automatic VLAN member
registration
• 256 static VLAN, up to 4K dynamic VLAN
• Full range 4 K PVID support
• Port-base VLAN & VLAN isolation
• IP Classification VLAN
• Intrusion Lock
• MAC Freeze
• MAC filtering per port secures access to each port
• Specific MAC forwarding per port: only specified
MAC addresses can access the network (Port
Security)
• Limited MAC number per port
• IP Filtering
• TCP/UDP Socket Filtering
• BPDU transparency
• 802.1x port-based authentication, compensated
assignment over VLAN and bandwidth for valid
access
Network Administration Security
• User name/password required for
Web/Telnet/local console administrators
• Two-level security by specific SNMP read/write
community
• Multiple login session
• Multiple access permission management
• SSH v1/v2
• SSL/TLS
Network Management
• ZyXEL iStacking™, up to 24 switches managed
by single IP address
• Web-based management
• Telnet CLI
• SNMP v1, v2
• RS-232c Local console
• IP management: static IP
• RMON four RMON groups 1, 2, 3, 9 (history,
statistics, alarms, and events) for enhanced
traffic management, monitoring, and analysis
• Port mirroring: supports Source/Destination/
Both port mirroring
• ZyXE EMS* support
Intelligent ACL
(L2/L3/L4 Access List Control)
• Based on MAC address
• Based on VLAN
• Based on IP address
• Based on Protocol type
• Based on TCP/UDP type
• Based on DSCP
inside

MIB Information
• RFC1213 MIB II
• RFC1493 Bridge MIB
• RFC1643 Ethernet MIB
• RFC1757 RMON group 1, 2, 3, 9
• RFC2011 IP MIB
• RFC2012 TCP MIB
• RFC2013 UDP MIB
• RFC2233 ifVHCPacketGroup
• RFC2674 VLAN MIB
• RFC2925 PING-MIB and TRACEROUTE-MIB
• ZyXEL Private MIB
Hardware Specifications
• Support of auto-negotiation
• Support of auto MDI/MDI-X
• Console: D-Sub 9 pin Female (DCE)
• Management: One out-of-band management
RJ-45 port
• Ports: 24 10/100Base-T,RJ-45 ports,
2 1000Base-T, RJ-45 ports and 2 dual-personality
GbE ports (RJ-45 or SFP open slots)
Physical Specifications
ES-2724 (28 ports)
• 24 10/100 ports + 2 1000Base-T ports + 2 Dual-
personality GbE ports
• Dimensions: 438 (W) x 270 (D) x 44.45 (H) mm
• Weight: 4.0 Kg
Power Requirements
• Input voltage of AC: 100-240VAC, 50/60Hz
• Max power rating of AC: 60 Watt
• Backup power supply into 12V DC
Environmental Specifications
• Operating temperature: 0°C ~ 45°C
• Storage temperature: -25°C ~ 70°C
• Operating humidity: 10% ~ 90%,
(non-condensing)
Safety
• UL 60950-1
• CSA 60950-1
• EN 60950-1
• IEC 60950-1
* EMS supports for future enhancement.
Operational Information
Gigabit Transceiver (Optional)Gigabit Transceiver (Optional)
SFP-SX
SFP-LX-10
SFP-BX1310-10
SFP-BX1490-10
SFP-LHX1310-40
SFP-ZX-80
L
C
L
C
L
C
LC
L
C
LC
M
u
l
t
i-m
od
e
Sin
g
le mod
e
Single mod
e
Sin
g
le mod
e
Single mod
e
Sin
g
le mod
e
850
n
m
1
3
1
0
n
m
1
310 nm
(
TX
)
1490 nm
(
RX
)
1
490 nm
(
TX
)
1310 nm
(
RX
)
1
3
1
0
n
m
1550 n
m
500
m
1
0
km
1
0
km
10 km
4
0
km
8
0 km
9
1-
0
1
0
-
06
4
00
1B
9
1-
0
1
0
-
06500
1B
9
1-
0
1
0
-1
5
2
00
1
B
9
1-010-153001
B
9
1-
0
1
0
-
06800
1
B
9
1-010-070001
B
4
71
893
74
20308
4
71
893
742
0
2
9
2
4
71
893
7
50
4
52
7
4
718
9
37504510
4
71
893
74
20
4
52
4
718
9
3742046
9
Distance EAN CodeP/NModeConnector Type WavelengthModel Name

back
For more product information, visit us on the web www.ZyXEL.com
65-100-272403B 09/07
