1 BY ONE O00QL-0043 User manual

1byone Products Inc.
USER MANUAL
400 Watt Fog Machine
Model No.: O00QL-0043
It is very important to operate this product according to the following instructions. Failure to do so may
render your guarantee void.
●Power Sources : Input AC110~120V 60Hz
●Power Consumption: 400W
●Warm Up Time: 3-5 Minutes
●Tank Capacity: 0.15 gal(550ml)
●Fog Output: 2,000CFM
●Output Distance: 8.2 ft（2.5M）
●Outline Size: 9.31 x 5.78 x 4.84 in.(236.5 x 147 x 123 mm)
●Fuse: 5A, 125V
●Wired on/off controller (included): 6.56ft(2M) length cord
• 1 x Product Body with Power Cable • 1 x Wired Control Cable and Box
• 1 x User Manual • 1 x Warranty Card
INTRODUCTION
Product Overview
Specifications
What is Included
User ManualProduct Body with Power Cable Wired Control
Cable and Box

(A) Spray Nozzle
(B) Handle
(C) Tank Lid
(D) Product Cover
(E) Wired Control Cable Interface
(F) Fuse Knob
(G) On/Off Switch
(H) Wired Control Indication Light
(I) Wired Control Box
(J) Wired Control Cable
Before using the fog machine, you have to prepare Fog Liquid (not included).Then operate according to following
sequence.
1. Remove all the packages.
2. Carefully put this product onto a clean, flat and solid surface, close to the power socket.
3. Unscrew the lid on the tank by turning counterclockwise and pour the Fog Liquid inside. Do not spill Fog Liquid onto
the product body. Do not overfill. If liquid gets into the Fog Machine, leave it to be dry completely before plugging in.
Do not cut, pinch, or break the tube connected through the tank lid. Screw the lid clockwise to the tank tightly.
Always make sure there is enough Fog Liquid in the tank before using the Fog Machine.
4. Connect the wired control cable to the Interface at the back of the Fog Machine.
5. Connect the product with proper power socket.
6.Warm up time is approximately 4 – 5 minutes.When fully heated, the Wired Control Indication Light will turn on and
the Fog Machine will be ready to produce and spray fog.
7. Set the On/Off Switch to on position, nozzle will start spraying fog. Set to off position, spraying will stop.
8.Turn off the unit before refilling the fog machine.
9. Unplug the unit when not in use.
10.To refill the tank; turn off the unit, unplug and follow the directions in Step 3.
How to Use?
Names for Parts
A
B
E
C
D
F
J
H
G
I

A: Fog Machine
B:Wired Control Box and Cable
C: Fog Liquid (not included)
D: Power Cable
(a) It is normal if there is condensation on the nozzle of the Fog Machine.
(b) A small amount of fog may spray during or after operation.
(c) The Fog Machine will have to reheat after long spray. It will stop operation for a short period in order to heat up
to operating temperature again.While this is happening,fog cannot be produced.
The Wired Control Indication Light will turn on again when the unit is ready to generate more fog.
(d) All fog machines are apt to clogging due to the consistency of Fog Liquid and the high
temperatures at which it vaporizes.
●Maintenance and cleaning shall only be done to the product surface. Unplug this product from the power socket
before cleaning.
●Do not wet any electric parts of this product. Please use a dry, soft cloth instead of sharp tools for cleaning.
●If you find there is low fog output after many hours of continuous operation or after the machine has been idle or
in storage for a long time, it is advised to empty all Fog Liquid from the machine and clean the tank.Please unplug
the machine from power socket before cleaning.
It is important to clean up fluid in the Fog Machine when storing for an extended period of time.
1. Remove the tank lid.Pour out the fog liquid in the fog machine to a container.
2. Keep the fog machine working for a few seconds to run out the fog liquid in the fog machine.
3. Fill a little fog machine cleaner liquid in the tank, keep the fog machine working till running out.
4. Switch off, unplug the fog machine,and put it on a flat, dry place.
Additional Information
Storage
Maintenance and Cleaning

If the Fog Machine does not work at all when it is connected to the power socket, then it is probably that the fuse
has been broken.
WARNING: Risk of electric shock and fire. Disconnect from power socket before replacing the fuse.
1.Turn the fuse knob counterclockwise to reveal the fuse.
2. Replace the fuse with the same size and type fuse: 5A, 125V
3. Place fuse in cover and reinstall by turning clockwise. Be sure not to over tighten.
At the end of its serviceable life, this product should not be treated as household or general waste.
It should be handed over to the applicable collection point for the recycling of electrical and electronic equipment.
●Please read through this instructions manual before use.
●Before use, check the fog machine to see if there is any crack in the product cover, wired control cable and box,
power cable and plug. Make sure there is not any exposed wire.Do not use if any of the above conditions is found.
●The fog machine will become hot during use. After use, please wait for some minutes before trying to touch it by
hand.
●Keep away from the spray nozzle at least 0.5 meters when the nozzle spraying fog.
●Attention! Do not place the product onto wet or uneven surfaces. Accidental falls may cause fire.
●The product shall be changed if it has become damaged or thermally deformed.Disconnect this product from
power immediately in case of malfunction. Do not resume use until it’s repaired.
●Do not use outdoors. It is not waterproof.
●This product is not a toy. Please keep this unit out of reach of children and pets.
●Close supervision is necessary when this product is used by invalids, or disabled persons, or near children.
●Use this product only for its intended use as described in these instructions. Do not use attachments not recom-
mended by the manufacturer.
●Keep the power cable away from heated surfaces.
●Never drop or insert any object into any opening.
●Please unplug the power cable if you want to stop use of this unit for long time.
●The external flexible cable of this product cannot be replaced; if the power cable is damaged, the product shall be
destroyed. Never operate this product if it has a damaged cable or plug, if it is not working properly, if it has been
dropped or damaged, or dropped into water.
Fuse Replacement
Safety and Notes
WEEE Directive & Product Disposal

1byone Product Inc.
Address: 2313 E PHILADELPHIA ST UNIT M, ONTARIO,CA 91761-8048 United States
Phone: [phone]
Email: [email protected]
Web: www.1byone.com
General Troubleshooting
Contact Information
Symptom Possible Cause Possible Action
Circuit breaker or fuse keeps
blowing
• Excessive load on the circuit • Make sure that the total load
does not exceed 80% of the
breaker or fuse nominal current
• Short circuit along the power
lines
• Check the power lines and
power cords
Product does not power up • Blown fuse • Replace blown fuse with a good
one of the same type and rating
• Internal problem •Please contact our service and
will replacement or repair
Noise sound when you used • Fog juice pipeline jam •Try to maintain correct fog juice
pipeline smoothly
•It will more longer life if you periodic cleaning every two months
If you still experience problems after trying the above solutions, contact 1byone® Service
Support and will resolve your problem ASAP.
