1 BY ONE Easy Chime OUKQH-0761 User manual

Instruction Manual
SKU: OUKQH-0761
All product with the Easy Chime Logo work together
1byone Products Inc.
2313 E Philadelphia Street, Unit M, Ontario, CA 91761
www.1byone.com

VOLMODE
1. Package Contents:
2. Parts Names:
·1 x Push Button ·2 x Doorbell Receiver
·1 x Double-sided Adhesive
·1 x Instruction Manual
·1 x 3V Battery for Push Button (Type: CR2032)
Thank you for purchasing 1byone Wireless
Doorbell. Please read this instruction manual
before use to ensure safe operation.
If any package contents are visibly damaged or
missing, please immediately contact 1byone
Customer Service at ser[email protected] for
assistance.
LED indicator
Plug
Volume button
Ringtone selector button
Sound and flash button
Pairing button
Speaker
Receiver Push Button
Push button
Parameters:
Voltage of plug in receiver AC 110-120V (US)/AC 220-240V (EU)
Voltage of push button DC3V (Type CR2032)
Frequency 433.92MHz+100KHz
Operating range 150m/492ft (without obstacles)
Power consumption: Receiver: ＜0.3W
Push button: ＜10mA
Receiver’s ring volume ＞85dB within 0.5m/1.6ft
Working temperature -20℃~50℃
3 . Power Supply:
Receiver – Please plug into a power outlet.
Push button – Please insert the battery using the
following procedure:
· Insert a screwdriver into the small access port
at the bottom of the push button and
remove the push button’s back cover.
· Insert the 3V battery (type CR2032) into the
battery compartment, making sure the
battery surface marked with a “+”is facing
upwards.
· Reinsert the back cover, making sure it is
securely closed to ensure IP protection.
- 01 - - 02 -

For the receiver:
Safety Note:
4. Operation:
·Please plug it into a safe power outlet.
·Do not expose the receiver to water spray or
water drops and do not place liquid-filled
objects such as vases or opened drink
containers on or near the receiver and the
outlet.
·Unplug the receiver immediately if you sense
a burning smell or smoke. Have qualified
personnel check the receiver before using it
again.
·Unplug the receiver from the outlet if the
doorbell system is not to be used for an
extended period of time.
For the push button:
·The push button is powered by a CR2032
battery.When exhausted, replace it using the
same type and voltage battery.
·Always insert the battery using the correct
polarity to eliminate the danger of fire.
·Keep old and new batteries away from
children.
·Old batteries should be properly disposed
using safe environmental pracitices.
·Remove the batteries from the push button
if you do not intend to use the push button
for an extended period of time.
A. Selecting the notification mode:
The doorbell receiver can notify when the
push button has been pressed by playing a
ringing sound, flashing an LED, or ringing and
flashing an LED at the same time.These are
referred to as Sound, Flash, and Sound+Flash
mode.
Note: If the performance of the push button
deteriorates or compeletely stops, the
battery might be exhausted. Please replace
with another 3V type CR2032 battery.
Receiver – Please plug into a power outlet.
Push button – Please insert the battery using the
following procedure:
· Insert a screwdriver into the small access port
at the bottom of the push button and
remove the push button’s back cover.
· Insert the 3V battery (type CR2032) into the
battery compartment, making sure the
battery surface marked with a “+”is facing
upwards.
· Reinsert the back cover, making sure it is
securely closed to ensure IP protection.
- 03 - - 04 -

B. Selecting the ringtone:
There are 36 programmable ringtones to
choose from.
Press the Ringtone selector button to
change the ringtone.
Stop pressing this button when you reach the
desired ringtone.
C. Adjusting ringtone volume:
Press the Volume button until the desired
volume is set.There are 6 volume levels for
selection.
D. Re-pairing Function:
If a receiver starts ringing even when the push
button isn’t pressed, or a push button
interferes with other receivers, it may be
necessary to reset the current pairings and
pair again.
To reset the push button:
Press the Paring button on the receiver and
hold for 5 seconds.The LED light will come on
and beep five times then all pairing
information for the push button(s) will be
deleted.Next, unplug or remove the batteries
from the receiver and then reattach it to
power after 30 seconds.The LED light will
come on for 15 seconds and beep once.This
means the receiver is in pairing mode. Next
VOL
To change the notification mode (Sound only,
Flash only, and Sound+Flash), press the Mode
button on the side of the receiver.
When the Mode button is pressed, the
receiver will play a“beep”sound signifying
Sound Only mode; flash a LED signifying Flash
Only mode; play a “beep”sound and flash a
LED at the same time signifying Sound +
Flash mode.
Press the Mode button until you reach your
preferred notification mode.
MODE
- 05 - - 06 -

E. Installation:
Push button:
·Select a suitable location for the doorbell,
usually close to your outside door.
·Stick the push button to the wall using the
included double-sided adhesive.
Receiver:
Plug in the receiver into any safe power outlet.
Notes:
·The push button and receiver can connect
with a range up to 150 meters/492 ft without
any obstacles.
·The push button’s transmitting frequency is
433MHz and its range can be affected by
metal ,walls, concretes, and interfering signals
from other electronic appliances with the
same frequency including televisions, radios,
and cookers.
·Please plug the receiver into any power outlet
that is far away from the above electronic
appliances and make sure there are no metal
obstructions between the receiver and the
outlet.
·Please test the operating range of the receiver
and push button in your home before
installation.
·Do not install the push button and receiver
near any source of naked flames such as
lighted candles.
·Do not expose the push button and receiver
to direct sunlight or high temperatures,
otherwise overheating may cause them
irreparably damaged.
press the push button. If pairing is successful,
the receiver should ring.It normally takes
about 10-15 seconds for the push button and
receiver to pair. If there is no pairing within 15
seconds, the LED will turn off and beep twice
and automatically exit pairing mode. Please
try pairing again.
- 07 - - 08 -

5.Trouble Shooting:
a. The receiver rings without the push button
being pressed.
The receiver may be matching on the same
frequency with nearby push buttons.You
should reset the pairing and re-pair your push
button(s).
b.There is no ring/LED flash when the push
button is pressed.
·Check whether the battery (CR2032) is
inserted into the push button.
·Check whether the power outlet being used
for the receiver is working properly.
·Pair the receiver and push button again.
c. The ringtone volume is greatly reduced.
A weak battery can reduce the ringtone
volume. Change the battery every 10-12
months for the push button.
Metal constructions, walls, and other
appliances with the same frequency can also
affect the receiver’s ringing. Avoid mounting
the push button and receiver near any metal
objects.
Disposal of the appliance
Under no circumstances should you
dispose of the appliance in normal
domestic waste.This product is
subject to the provisions of European
Directive 2012/19/EU.
Dispose of the appliance via an approved
disposal company or your municipal waste
facility. Please observe the currently applicable
regulations. Please contact your waste disposal
centre if you need any further information.
Disposal
- 09 - - 10 -

The appliance’s packaging is made
from environmentally friendly
material and can be disposed of at
your local recycling plant.
Disposal of batteries
Used batteries may not be
disposed of in household waste.
All consumers are statutorily required to dispose
of batteries at a collection point provided by
their local municipality or retail store.
The purpose of this obligation is to ensure
batteries are disposed of in a non-polluting
manner. Only dispose of batteries when they are
fully discharged.
