1 BY ONE OUS00-0816 User manual

GARDEN LASER LIGHT
1byone Products Inc.
2313E,Philadelphia Street,Unit M,Ontario,CA 91761
www.1byone.com
User Manual

01 02
THANKS FOR PURCHASING 1byone GARDEN
LASER LIGHT:
CONTENTS:
Please read this manual carefully before operating the product.This
manual provides general information for optimal performance and
safety. The GARDEN LASER LIGHT is for both indoor and outdoor use
and is IP65 weather-resistant rated.
1. Insert the sharp end of the spike into the ground. Users can gently
hammer the spike down if the ground is hard. (Picture 1)
2. Screw the bracket onto the spike. (Picture 2)
3. Fix the laser light on the bracket with the screw, and adjust to the
desired angle. (Picture 3)
4. Connect the power cord into a 120V power outlet and the laser
light will automatically turn on.
5. Unplug when not in use.
6. Use the remote control to switch between different light modes
and timers.
PART NAMES:
① Laser light (IP65)
② Screw
③ Bracket
④ Spike
⑤ Adapter (IP44)
LASER COLOR SELECTION:
Single red laser light
Single green laser light
Red and Green laser lights
●1x Laser Light Unit with Screw and Bracket
●1x Spike ●1x Adapter ●1x User Manual
●1x IR Remote Controller (include a CR2025 battery)
INSTALLATION:
5
1
2
3
4

03 04
Timer Operation：
The garden laser light has a built-in
default timer; If the user does not set a timer and does not unplug
or turn off the light, it will automatically enter sleep mode after 6
hours of operation and wake again after 18 hours.
Remote Control:
Power on/off Red & green continuously cycle
Red & green continuously cycle and flash
Red flash Green flash Red & green flash
Red solid Green solid Red & green solid
Red brighter Green brighter Flash speed increase
Red dimmer Green dimmer Flash speed decrease
1 hour timer 2 hour timer 3 hour timer
4 hour timer 5 hour timer 6 hour timer
Built- in timer function:
Built-in 6 hour timer:
6 hours
18 hours
For example, if the user presses '1H', the light will enter sleep
mode after 1 hour and then wake again after 23 hours:
When you power off using the Power
on/off button, the garden laser light will remember all of your settings
(light patterns, brightnesses, flashing speeds, timers) for next time.
Last Memory function:
The user can also set the timer as 1H, 2H, 3H, 4H,
5H, or 6H using the remote control.
1-6H setting:
ON OFF
If you set any timer mode and later turn off the light using
the "Power on/off" button, this timer will become active the next time
the light is turned on.
Notice 1:
The light will switch off for 3 seconds when pressing a
timer button to show the timer has been successfully set.
Notice 2:
Once the unit is unplugged, settings memory will be cleared.
Notice :
Once the unit is unplugged, the timer will be reset to
the default 6H setting.
Notice 3:
1 hour
23 hours
ON OFF
1
1
2
2
4
4
5
5
7
7
8
8
10
10
11
11
13
13
14
14
16
16
17
17
19
19
20
20
3
3
6
6
9
9
15
15
18
18
21
21
12
12

05 06
ATTENTION:
Point the infrared remote control directly towards the head of the
laser light and make sure there is a clear line of sight between the
remote control and laser light as infrared signal cannot travel
through walls or other obstacles.
CAUTION & WARNINGS:
Please read through the instruction manual before use.
Do not use seasonal products outdoors unless marked suitable for
indoor and outdoor use.When products are used in outdoor
applications, connect the product to a Ground Fault Circuit Inter-
rupting (GFCI) outlet. If one is not installed, please contact a quali-
fied electrician for proper installation.
This seasonal-use product is not intended for permanent installa-
tion or use.
Do not secure the product's electric cord with staples or nails, or
place it on nails or sharp hooks.
Do not place large objects such as floor lamps, tables, or chairs on
the product's electric cord.
Do not hang ornaments or any other objects from the product's
electric cord.
Do not close doors or windows on the product's electric cord as
this may damage the wire insulation.
Do not keep the product plugged in when left unattended (such as
when leaving home or when asleep).
Do not cover the product with cloth, paper or any material not part
of the product when in use.
DO NOT use the product if damaged.The laser light head, electric
cord,adapter and plugs must not be damaged in any way prior to use.
This product is not a toy. Please keep it out of the reach of children
and pets.
Close supervision is necessary when product is in use near children
or dependents.
Garden Laser Light is a class IIIa laser product. Do not stare into the
laser beams or view directly with optical instruments.
Avoid direct eye exposure.
Keep at least 1 meter (approximately 3 feet) distance between the
product and flammable materials.
Ingress protection: IP65. Can protect against rainy days but DO NOT
submerge directly in water.
Turn off the power before installation or maintenance.
Use this product only for the intended use as described in these
instructions. Disconnect this product from power immediately in
case of malfunction.
DO NOT open the housing.
Check local laws and contact the FAA to ensure safe operation in
flight paths.
Do not project the laser towards the sky as it may interfere with air
traffic.
To reduce the risk of fire and electric shock:
a) Do not install on trees containing coverings that are or appear to
be made of metal.
b) Do not intertwine the product's electric cable with other cables
or wires in a manner that may cut or damage the cable's insulation.

07 08
MAINTENANCE & CLEANING：
Maintenance and cleaning shall only be done to the product
surface.
Unplug this product from the power socket before cleaning.
Do not wet any electrical parts of this product. Please use a dry,
soft cloth for cleaning. Do not use sharp tools.
Clean the lens regularly. It is recommended to clean the lens
every 30 days.
When not in use, store neatly in a cool, dry location protected
from sunlight.
Please keep away from heaters and other heating sources.
When the product is placed on a live tree, the tree should be
well maintained and fresh. Do not place on live trees in which
the needles are brown or break off easily. Keep the tree stand
filled with water.
If the product is placed on a tree, the tree should be well secured
and stable.
When storing the product, carefully remove the product from
wherever it has been place, such as the ground, trees, branches,
or bushes, to avoid any undue strain or stress on the product's
conductors, connections, and wires.
SPECIFICATIONS:
Power input: 120V~60Hz
Power output: DC 5V 2A
Laser class: IIIa
Laser Power: Red: Maximum radiant power: 1.3mW;
Green: Maximum radiant power: 0.7mW
IP protection: IP65 for the device body and IP44 for the adapter
Working temperature: -35°C (-31°F) to 35°C (95°F)
Remote control distance: 30ft (9m)
Distance and coverage: 3.5ft: 57-85sqft
10ft: 265-325.6sqft
15ft: 776.8-971.44sqft
20ft: 1240-1550.00sqft
25ft: 1687.2- 2109.72sqft
WEEE Directive & Product Disposal
At the end of its serviceable life, this product should not be treated as
household or general waste.
It should be handed over to the applicable collection point for the
recycling of electrical and electronic equipment.
