New England Arbors Savannah Composite Trellis User manual

Check Box for These Contents
In the event of missing or defective parts please call our customer service
dept. at 1 800 282 9346 (Mon. to Fri. 8:00 AM to 4:00 PM EST).
1. Post Caps (3)
2. Arches (2)
3. Top Long Spindles (2)
4. Top Short Spindles (2)
5. Top Rail (1)
6. Posts (2)
7. Vertical Spindles (5)
8. Horizontal Spindles (5)
9. Bottom Rail (1)
10. Ground Anchoring Stakes (2)
11. 3/4”Self-Auguring Stainless Steel Screw (24)
Tools You Will Need
• Cordless Drill
• Hammer
• Tape Measure
• Level
• Shovel
General Information
• Read Instructions through carefully before beginning assembly.
• When assembling components, place on a non-abrasive surface
(i.e.shipping box) to avoid scratching.
• We recommend an area approx 5’x 8’ for unobstructed assembling.
• You should not need to use excessive force when assembling component.
Savannah Composite Trellis
Please read through before starting assembly.
ASSEMBLY INSTRUCTIONS
1
1
2
11
Not to Scale
6
4
3
5
IMPORTANT: CHECK THE INSIDE OF YOUR POSTS FOR ALL MATERIALS.
V1.0/101315
10
36 in
39 in
54.7 in
22.5 in
7 in
47.7 in
77.2 in
7
8
9
www.newenglandarbors.com

2
1
Lay one of the posts on the ground and insert the bottom
rail and the five horizontal spindles as shown aside.
Note that the bottom and top rails are different - the bottom
rail only has one side with routed holes.
Insert the five vertical spindles as shown aside. Make sure
to weave the spindles as they are being inserted.
Please note that there isone spindle with a ‘spear head’
and should be placed inthe middle.
Continue assembly by inserting the top railend into the
post and progressively into eachof the vertical spindles.
proceed to attach the second post to the trellis assembly
as shown below. Ensure tabs are inserted all the way into
the post.
Insert the top arches into the post caps as shown.
Note that there is a sticker on each of the arches indicating
the top of the arch.
Fasten the post caps to the arches using the eight screws
provided.
1
2
3
4
STEP ONE
2
3
NOTE: There are locking tabs located at the ends of the
horizontal rails. Once inserted and pushed into the routed
holes, they will lock into place.
4
5
5
Bottom rail
Spear Head
Insert 1st
Sticker
Savannah Composite Trellis

3
STEP T WO
Install the Top Arch
Insert the arch spindles to the openings on the top rail.
Note that there are two different sizes of spindles and should
be inserted as shown aside.
Align the four spindles into the bottom of the arch while
simultaneously inserting the arch assembly to the posts.
Excessive force shouldnot be neccesary.
Fasten the arch assembly to the posts using the screws
provided in the hardware kit.
Finish the trellis assembly by fastening the posts to the
top and bottom rails as shown.
1
2
3
4
1
2
3
Short Spindle
Short Spindle
Long Spindle
Long Spindle
4
Savannah Composite Trellis
www.newenglandarbors.com

4
STEP THREE
Insert the ground anchoring stakes into the bottom of the trellis
posts. Secure withscrews as shown aside.
Mounting Into the Ground
Install the Ground Anchor Stakes
Toll Free Phone: [phone] Toll Free Fax: [phone]
www.newenglandarbors.com
3
Trellises must be well secured inthe event of highwinds, etc. We
have provided two ground anchoring stakes for securing the trellis
eitherinto the groundor into a concrete footing. If you are
installing your trellis directly to the wall of your home,or on a wood deck
or concrete surface,please see your hardware store for the appropriate
galvanized bracket hardware.
STEP FOU R
Move the trellis to its final location. When you are satisfied with
the location,mark the positions of the posts,then move the trellis
aside and lay it carefully on it’s side. Excavate the 2 post holes
approximately 12" deep x 6" diameter. Carefully move the trellis
back into position.
Level it both vertically and horizontally into the excavated holes.
Backfill the holeswith the excavated soil.
A
B
C
Install Trellis into Ground
C
A
4
12”
Level
6“
B
