2KC Solutions GCH500 User manual

Natural gas sampling standards (GPA 2166 and API 14.1) recommend
that before using the fi ll and empty method to collect a sample, the
cylinder must be preheated to a temperature above the hydrocarbon dew
point of the fl owing gas stream. The GCH500 provides a simple, effi -
cient solution to cylinder preheating. It consist of a heater enclosure and
a controller. The sample cylinder is preheated inside your vehicle on the
way to, or at, the sample location. Heating takes about 10 minutes. To
use the GCH500 just insert a clean empty cylinder into the heater enclo-
sure and connect the controller cable to the heater. Power for the heater
is taken from a vehicle 12 volt power point or cigarette lighter plug.
While heating, the sample cylinder’s temperature can be monitored us-
ing the controller’s display. When fully heated, the controller will keep
the cylinder at the set temperature (140°F) until you are ready to discon-
nect the controller from the heater and take the sample. The hot cylinder
stays in the heater enclosure until the sampling process is fi nished to
provide a safe method to handle the heated cylinder while taking the
sample without the need for gloves.
GCH500
500cc Gas Cylinder Heater
Operator’s Manual
• Designed to preheat a standard 2” OD 500cc gas sample cylinder
• Low power (100 wa s @ 12V DC) plugs directly into a cigare e
lighter
• Works with either stainless steel or aluminum cylinders
• Quickly preheats cylinder to 140°F, Cold to Hot in about 10 minutes
• Microprocessor based temperature controller with digital tempera-
ture display
• Rugged plas c case provides a safe compact environment for heat-
ing the cylinder plus a safe and durable method for handling the
heated cylinder
• Enclosure insulates heated cylinder to allow for addi onal hot sam-
pling  me
• Four heaters and four temperature sensors help insure uniform
hea ng of the sample cylinder
• Increased safety provided by thermal fuses and transient protec on
diodes
Overview
Features
130-0036 Rev 2, © copyright Microflex, LLC 2011-2017 - 2KC Solutions is a trademark of Microflex, LLC

Operation
Operating Procedure
► Open the heater enclosure and insert a clean dry
500cc sample cylinder into the cylinder clip.
► Close the heater enclosure and secure the latches.
► Locate the heater socket on the GCH heater and
unscrew the protection cap.
► Connect the heater plug on the control cable to the
heater socket on the GCH heater. Twist the locking
ring clockwise to lock it into place.
► Plug in the power cable into a standard auto
cigarette lighter or 12 volt power point.
► The controller display will show the approximate
cylinder temperature while heating the cylinder
to the set temperature (140°F for the GCH140
controller).
► After the cylinder has reached the desired
temperature and you are ready to take a sample,
disconnect the cable from the heater. Replace the
connector protection cap on the GCH500 connector.
► With the heater in the enclosure, begin the sample
collection process.
► After the sample is collected, remove the cylinder
from the enclosure. There is no longer any need
to heat the cylinder until the sample is ready to be
analyzed at a gas lab.
► Repeat this process to preheat the next cylinder.
The following operating procedures will guide you
through connecting the controller to the heater and pre-
heating a sample cylinder.
For best heating effi ciency, use clean sample cylinders
and avoid stickers, labels or any material on the sides of
the cylinder. It is important that the sample cylinder make
good thermal contact with the cylinder clip. Dirt or stick-
ers on the sample cylinder will interfere with heat fl ow
from the heaters to the sample cylinder and could aff ect
performance.
During the heating process the controller continuously
monitors the four temperature sensors. The average of
the sensor’s readings is used to control the heaters. A
large diff erence between any two sensor readings is an
indication of a possible heater failure. For example a
bad heater would be detected as a warm reading on one
sensor and a cooler reading on the sensor next to the bad
heater. When an error is detected, an error or “E2” code
will show on the controller display in place of the tem-
perature reading. If the heater plug is disconnected from
the heater while power is still on, the controller display
will change to a scrolling “.” character indication that the
controller can no longer read the temperature sensors.
When the plug is reconnected, the sensors will be detect-
ed and the display will return to displaying the cylinder
temperature.
Maintenance
• Only heat clean dry sample cylinders.
• Do not apply power to the controller in hazardous
locations.
• Do not connect the controller to the heater in haz-
ardous locations.
• Do not place the heater on surfaces that may be
damaged by heat.
WARNING
The sample cylinder and metal surfaces within the
heater enclosure may be hot.
Handle the cylinder by the end valves when removing
the heated cylinder from the enclosure.
CAUTION
Keep the cylinder clip inside the heater clean and dry for
maximum effi ciency. Use a damp cloth to wipe off debris
from the clip surface and both the inside and outside of
the heater enclosure. Avoid moisture on the connectors.
Excessive moisture may interfere with the controllers
ability to read the temperature sensors. To keep the con-
nector clean and dry, use an electronics contact cleaner
that leaves no residue and that does not harm plastics.
Note: If there is a temperature diff erence between
the cylinder and the heater assembly, it may take
several minutes before the controller reads the
correct cylinder temperature when a cylinder is fi rst
inserted into the heater.
130-0036 Rev 2, © copyright Microflex, LLC 2011 - 2KC Solutions is a trademark of Microflex

Specifications
Heaters .............................................................. 100 Watts @ 12V
Cylinder Size ................................................... 500cc x 2.00” O.D.
Over-temperature Protection ............................Thermal Fuses (4)
Temp Sensor Accuracy ....................................................... ±2.0°C
Weight ................................................................................... 1 Lb.

Limited Warranty
Service
Microfl ex, LLC warrants this unit against defects in materials and workmanship for a period of one year
from the date of shipment. Microfl ex, LLC will, at its option, repair or replace equipment that proves to be
defective during the warranty period. This warranty includes parts and labor.
A Return Materials Authorization (RMA) number must be obtained from the factory and clearly marked on
the outside of the package before equipment will be accepted for warranty work.
Microfl ex, LLC believes that the information in this manual is accurate. In the event that a typographical
or technical error exist, Microfl ex, LLC reserves the right to make changes without prior notice to holders
of this edition. The reader should consult Microfl ex, LLC if any errors are suspected. In no event should
Microfl ex, LLC be liable for any damages arising out of or related to this document or the information
contained in it.
EXCEPT AS SPECIFIED HEREIN, MICROFLEX, LLC MAKES NO WARRANTIES OR
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. CUSTOMER’S RIGHT
TO RECOVER DAMAGES CAUSED BY FAULT OR NEGLIGENCE ON THE PART OF 2KC
SOLUTIONS, LLC SHALL BE LIMITED TO THE AMOUNT THERETOFORE PAID BY THE
CUSTOMER. MICROFLEX, LLC WILL NOT BE LIABLE FOR DAMAGES RESULTING FROM
LOSS OF DATA, PROFITS, USE OF PRODUCTS, OR INCIDENTAL OR CONSEQUENTIAL
DAMAGES, EVEN IF ADVISED OF THE POSSIBILITIES THEREOF. This limitation of the liability
of Microfl ex, LLC will apply regardless of the form of action, whether in contract or tort, including
negligence. Any action against Microfl ex, LLC must be brought within one year after the cause of action
accrues. The warranty provided herein does not cover damages, defects, malfunctions, or service failures
caused by owners failure to follow 2KC Solutions installation, operation, or maintenance instructions;
owners modifi cation of the product; owner’s abuse, misuse, or negligent acts; and power failure or surges,
fi re, fl ood, accident, actions of third parties, or other events outside reasonable control.
The GCH500 has no fi eld serviceable components. For service please contact your distributor
listed below for a Return Materials Authorization number (RMA).
