2N SIP SPEAKER Instruction sheet

2N® SIP Speaker
Public Address Paging
Configuration Manual
Version 1.15.1
Firmware 1.15.x www.2n.cz

The 2N TELEKOMUNIKACE a.s. joint-stock company is a Czech manufacturer and supplier
of telecommunications equipment.
The product family developed by 2N TELEKOMUNIKACE a.s. includes GSM gateways,
private branch exchanges (PBX), and door and lift communicators.
2N TELEKOMUNIKACE a.s. has been ranked among the Czech top companies for years
and represented a symbol of stability and prosperity on the telecommunications market
for almost two decades. At present, we export our products into over 120 countries
worldwide and have exclusive distributors on all continents.
2N®is a registered trademark of 2N TELEKOMUNIKACE a.s.. Any product and/or other
names mentioned herein are registered trademarks and/or trademarks or brands
protected by law.
2N TELEKOMUNIKACE administers the FAQ database to help you quickly find information
and to answer your questions about 2N products and services. On faq.2n.cz you can find
information regarding products adjustment and instructions for optimum use and
procedures „What to do if...“.
Declaration of Conformity
2N TELEKOMUNIKACE a.s. hereby declares that the 2N®SIP Speaker product complies
with all basic requirements and other relevant provisions of the 1999/5/EC directive. For
the full wording of the Declaration of Conformity see the CD-ROM enclosed and at www.2n.cz.
The 2N TELEKOMUNIKACE Company is a holder of the ISO 9001:2008 certificate. All
development, production and distribution processes of the company are managed by this
standard and guarantee a high quality and advanced technical level of and a professional
approach to all of our products.

Contents
1. Product Overview...............................................................5
1.1 Product Description....................................................................................................... 6
Basic Properties ............................................................................................................... 6
Advantages of Use........................................................................................................... 6
Basic Features.................................................................................................................. 7
Optional Accessories........................................................................................................ 7
1.2 2N®SIP Speaker Components and Associated Products.......................................... 8
Basic Unit ......................................................................................................................... 8
Accessories...................................................................................................................... 8
Associated Products......................................................................................................... 9
1.3 Upgrade......................................................................................................................... 10
1.4 Terms and Symbols Used ........................................................................................... 11
Symbols Used in Manual................................................................................................ 11
Future Functions and Features...................................................................................... 11
2. Description and Installation............................................12
2.1 Product Description..................................................................................................... 13
2N® SIP Speaker Front and Back Panels ..................................................................... 14
2.2 Before You Start........................................................................................................... 15
Product Completeness Check........................................................................................ 15
Installation Conditions .................................................................................................... 15
2.3 Mounting ....................................................................................................................... 16
Surface Mounting ........................................................................................................... 16
2.4 Electric Installation ...................................................................................................... 17
Electric Installation Step by Step.................................................................................... 17
Loudspeaker Connection ............................................................................................... 17
Headset/External Amplifier Connection ......................................................................... 18
Microphone/Line Connection.......................................................................................... 18
Digital Output Connection .............................................................................................. 18
Digital Input Connection ................................................................................................. 19
LAN Connection ............................................................................................................. 19
Power Supply Connection.............................................................................................. 20
3. 2N®SIP Speaker Configuration ......................................21
3.1 Default Reset................................................................................................................. 22
Factory Default............................................................................................................... 22
Factory Default Reset..................................................................................................... 22

3.2 Configuration................................................................................................................ 24
Description of 2N®Helios IP Network Scanner.............................................................. 24
Login............................................................................................................................... 25
Language Selection........................................................................................................ 25
Information...................................................................................................................... 26
Telephone Directory....................................................................................................... 28
Scheduler ....................................................................................................................... 29
Switch............................................................................................................................. 32
Network .......................................................................................................................... 34
Date and Time................................................................................................................ 35
SIP Settings.................................................................................................................... 37
Administration Web Server............................................................................................. 39
Audio .............................................................................................................................. 40
Audio Codecs................................................................................................................. 42
Streaming....................................................................................................................... 43
Auto Update.................................................................................................................... 46
System Log..................................................................................................................... 47
Miscellaneous................................................................................................................. 48
Tools............................................................................................................................... 51
Configuration.................................................................................................................. 52
Firmware......................................................................................................................... 53
User Sounds................................................................................................................... 54
Network Trace................................................................................................................ 56
Licence........................................................................................................................... 56
4. Function and Use.............................................................58
4.1 Basic Functions............................................................................................................ 59
2N®SIP Speaker Button Control.................................................................................... 59
2N®SIP Speaker Remote Control.................................................................................. 59
2N® SIP Speaker Status Signalling ................................................................................ 60
Operational Status Signalling......................................................................................... 60
5. Technical Parameters......................................................63
5.1 Technical Parameters .................................................................................................. 64
Mechanical and Electrical Parameters........................................................................... 64
6. Supplementary Information ............................................67
6.1 List of Abbreviations.................................................................................................... 68
6.2 List of Figures............................................................................................................... 69
6.3 List of Tables ................................................................................................................ 71

5
1
1. Product
Overview
In this section, we introduce the 2N®SIP Speaker product, outline its application
options and highlight the advantages following from its use. The section also includes
safety precautions.
Here is what you can find in this section:
Product Description
Associated Products
Upgrade
Terms and Symbols Used

Product Description
1.1
6
1.1 Product Description
Basic Properties
2N®SIP Speaker is a versatile sound transmission system for IP networks. It is
designed as a universal VoIP telephone with an audio output/input, button and
switched circuit connection option. It finds a variety of applications - in schools,
hospitals, office buildings, hotels, production halls, shopping centres, bus terminals,
airports and so on. You can monitor the events in the 2N®SIP Speaker area using an
integrated streaming server.
2N®SIP Speaker is a stand-alone SIP-based sound decoder and converter with an
amplifier. 2N®SIP Speaker communicates with the other audio system components
via the SIP Proxy or directly via a specified address.
Press the attached button to set up a call to up to three predefined numbers or
addresses, with calls being transferred automatically at no answer. Configure the
button function using an integrated calendar to make sure that the called subscriber is
always accessed.
You can make use of a lot of convenient VoIP services thanks to the integrated SIP
such as call forwarding at no answer (to another worksite, recording machine or
mobile phone) and call transfer (from the secretary to the required person, e.g.).
2N®SIP Speaker is equipped with a switch for you to control the electric door lock
from any telephone (by tone-entering the password).
You can manage your 2N®SIP Speaker unit via a configuration web interface, by
pushing the unit buttons or with a remote controller.
Advantages of Use
Operable in the Ethernet network
Ethernet-based power supply –PoE
SIP
Integrated administration web server
1 programmable button
Streamed audio support
Integrated calendar with programmable DAY/NIGHT/WEEKEND modes
Applicable as standard VoIP telephone/communicator
DTMF detection according to RFC2833, in-band and SIP-INFO

Product Description
1.1
7
Basic Features
10/100Base-TX LAN interface
12V DC / 1.8A or PoE 802.3af supply
Integrated 30W STEREO/MONO amplifier
Line/headset output
Colour LED operational status signalling
Universal galvanically isolated output
Universal galvanically isolated digital input
Two volume control buttons
Infrared remote control
Optional Accessories
12V DC/2A Supply Adapter
Universal power supply adapter for 2N®SIP Speaker. With it, you can make
the best of the integrated amplifier power.
802.3af PoE Injector
Universal PoE injector for the 2N®SIP Speaker power supply. Useful for
places where 12V power supply is unavailable or a 12V adapter cannot be
used.
Remote Control
Infrared remote control for comfortable volume or channel adjustment.

2N® SIP Speaker Components and Associated Products
1.2
8
1.2 2N®SIP Speaker Components and
Associated Products
Basic Unit
914401E
2N®SIP Speaker
Accessories
91378100
PoE Injector
914102E
12VDC/2A Adapter
914103E
Remote Controller

2N® SIP Speaker Components and Associated Products
1.2
9
Associated Products
2N®SIP Speaker with
Loudspeaker for Soffit
Mounting
Flush Mounting Box
Wall Mounting
Box

Upgrade
1.3
10
1.3 Upgrade
The manufacturer reserves the right to modify 2N®SIP Speaker in order to improve
its qualities.
Manual
Version
Changes in Documentation
1.0.0
The User Manual corresponds to 2N®SIP Speaker FW version
1.15.0
Caution
The manufacturer keeps improving the firmware according to the clients’
requirements. Refer to the 2N web sites www.2n.cz for the current 2N®SIP
Speaker firmware and User Manual versions.

Terms and Symbols Used
1.4
11
1.4 Terms and Symbols Used
Symbols Used in Manual
Safety Warning
Always abide by this information to prevent injury of persons.
Warning
Always abide by this information to prevent damage to the device.
Caution
Important information for system functionality.
Tip
Useful advice for quick and efficient functionality.
Note
Routines or advice for efficient use of the device.
Future Functions and Features
The grey-marked text in this document designates the functions and features that are
under preparation or development at present.

2
2. Description and
Installation
In this section, we describe the 2N®SIP Speaker product and its installation.
Here is what you can find in this section:
Product Description
Before You Start
Mounting

Product Description
2.1
13
2.1 Product Description
2N®SIP Speaker is an Ethernet audio converter designed for public sound distribution.
It is connected to and communicates with the SIP Proxy server via telephone calls.
This guarantees compatibility with all SIP-based systems.
The main principle of the 2N®SIP Speaker operation is to convert an audio signal
between the Ethernet and audio interfaces. Therefore, 2N®SIP Speaker is equipped
with an integrated 2x10W amplifier for direct loudspeaker connection.
You can control 2N®SIP Speaker with two buttons on the front panel or using an
infrared remote controller.
2N®SIP Speaker is equipped with a digital input and output, which extend the
converter options and may be helpful in special applications.
Use an integrated web interface for 2N®SIP Speaker configuration. Apply the 2N®
Helios IP Network Scanner to search all the 2N®SIP Speaker units connected.

Product Description
2.1
14
2N® SIP Speaker Front and Back Panels
Figure 2.1 2N®SIP Speaker Front and Back Panel
Connectors and Controls
1. 12V DC/2A power supply adapter connector
2. Alternative power supply connection terminals -
3. Alternative power supply connection terminals +
4. Relay output with galvanic isolation for external 24V/1A AC/DC load switching
5. Digital input with galvanic isolation for external sensor/button, etc. connection
6. 10/100BASE-TX LAN RJ-45 connector
7. Integrated amplifier output terminals for 1 or 2 loudspeakers
8. Headset/line output for standard earphones/external amplifier
9. –and + volume control buttons
10.Microphone input
11.Power up LED indicator
12.Operational status LED indicators
13.RESET button
14.Infrared signal receiver for remote control and signal reception LED

Before You Start
2.2
15
2.2 Before You Start
Product Completeness Check
Before installing this product, check whether the product delivery includes:
1 2N®SIP Speaker
2 wall-mounting L-profiles
4 6mm dowels
4 3.5x35mm screws
4 self-adhesive device feet
1 5-pin terminal block
1 4-pin terminal block
Quick User Manual
User Manual and Software CD-ROM
Certificate of Warranty
Installation Conditions
2N®SIP Speaker is to be connected to the LAN.
2N®SIP Speaker is designed for indoor use.
2N®SIP Speaker may not be operated in damp environments.

Mounting
2.3
16
2.3 Mounting
If you intend to use your 2N®SIP Speaker unit in various interiors, please stick the
four feet included in the delivery onto the bottom side of the device to avoid
scratching of the underlying surface.
Surface Mounting
Use the included L-profiles to mount your 2N®SIP Speaker unit on a wall or another
solid surface. Insert the L-profiles in the sides of the assembly and fit them with four
screws to keep the device in place. You can use the dowels and screws included in the
delivery for wall mounting. Follow the instructions below while drilling the mounting
holes.
Figure 2.2 Mounting Holes

Electric Installation
2.4
17
2.4 Electric Installation
Electric Installation Step by Step
It is very easy to connect 2N®SIP Speaker electrically. Follow the steps below to avoid
equipment damage or electrical injury:
Connect the microphone, loudspeaker, headset or external amplifier.
Connect the digital input and output.
Connect the UTP cable.
Connect a 12V power supply (unless PoE is used).
Caution
Be sure to connect the 2N®SIP Speaker power supply as the last step.
The same applies to PoE supply from the LAN.
Loudspeaker Connection
2N®SIP Speaker is equipped with a power amplifier for 1 (MONO) or 2 (STEREO)
loudspeakers. The loudspeakers to be used must have the nominal impedance of 4-8Ω
each. Refer to the table below for possible configurations and related maximum power
outputs (sinus, THD < 1%):
Loudspeaker(s)
12V/2A
PoE
Two 4Ω STEREO
2 x 10W
2 x 5W
Two 8Ω STEREO
2 x 9W
2 x 5W
One 4Ω MONO
1 x 18W
1 x 10W
One 8Ω MONO
1 x 12W
1 x 10W
Use the 2N®SIP Speaker back panel terminals marked L + and L –for the left
channel and R + and R –for the right channel. Use the R + and L -or L + and R –
terminals for the MONO mode.
Figure 2.3 Loudspeaker Connection

Electric Installation
2.4
18
Headset/External Amplifier Connection
2N®SIP Speaker is equipped with a headset/external amplifier output. The 3.5mm
jack is available on the front panel.
Figure 2.4 Audio Output Connection
Microphone/Line Connection
2N®SIP Speaker is equipped with a microphone/external supply output. The 3.5mm
jack is available on the front panel.
Figure 2.5 Audio Input Connection
Digital Output Connection
2N®SIP Speaker is equipped with a relay switch for light signalling/external
amplifier/alarm activation. The output is available on terminals marked LOGIC OUT
and allows for switching of up to 24V/1A AC/DC loads. By default, the output is in the
NO (normally open) state.
Figure 2.6 Digital Output Connection
Warning
Do not exceed the upper voltage and current limits to avoid irreversible
damage of the equipment.

Electric Installation
2.4
19
Digital Input Connection
2N®SIP Speaker is equipped with a digital input for an optional button, movement
sensor or other applications. This input is available on the LOGIC IN terminal. Up to 5
to 24V DC voltage can be applied to the input against the ground terminal marked
DC IN -.
Figure 2.7 Digital Input Connection
Warning
Do not exceed the maximum voltage values (24V) applied to the LOGIC
IN input to avoid irreversible damage of the equipment.
LAN Connection
2N®SIP Speaker can be connected to a standard local area network using a LAN
interface via the RJ-45 connector on the back panel. Always use CAT-5d or higher
class cables for reliability reasons.
Figure 2.8 LAN Connection
The LAN interface is equipped with the Auto MDIX function for automatic straight/
cross-over cable detection.
The LAN interface can also be used for the 2N®SIP Speaker power supply through
active network elements or injectors meeting the IEEE 802.3af standard.
Note
With PoE, the integrated amplifier power output is limited to 5W stereo /
10W mono. To utilise the maximum power output of the amplifier, feed
2N®SIP Speaker from a 12V DC/1.8A external power supply.

Electric Installation
2.4
20
Power Supply Connection
2N®SIP Speaker can be fed using active network elements or PoE injectors via the
LAN interface. In case this option is unavailable, use a 12V DC/2A (Part No. 914102E)
power supply or another power supply on condition that you keep the nominal values
included in the Mechanical and Electrical Parameters subsection.
Connect the 12V DC power supply either to the back panel supply connector marked
DC IN, or terminals marked DC IN + and DC IN –.
Figure 2.9 Power Supply Connection
Warning
If you use an adapter other than the recommended one, do not exceed
the nominal supply voltage value of 12V. Also make sure that the supply
voltage polarity is correct. Exceeding nominal values and/or incorrect
connection may lead to irreversible damage of the equipment.
