3ALogic nDolphin User manual

Interior Body Exterior Body RF
Contactless Card Latch 4 AA Batteries Bolts & Screws
☞Included User Manual & Paper Pattern.
nDolphin Sticker
Item Spec.
Model Name nDolphin RF Digital Locker Lock
Dimension zFront: 17(D) x 50(W) x70(H)mm, Back: 31(D) x 63(W) x47(H)mm
Material zFront : Iron Die Casting/ABS Back : IronDie Casting/ABS
Power DC 6V(1.5V AA Size) 4 Alkaline Batteries
Temperature - 30℃~ + 80℃
Construction Dual Deadbolt (Deadbolt, Deadbolt for center)
Key ISO 15693/14443-A 13.56MHz Card,
Online network (option), USB PDA (option)
Emergency Power External 9V Alkaline Battery
Interior Body
Exterior Body
Latch
63
147
5
10
31 25
20
74
11
50
70
17
☞Not to Scale
- Automatic lock feature
- External emergency power source for battery exhaustion
- Signal alert for battery exchange (Approx. 40x use after first signal alert)
- Signal alert for irregular locked door
- Event management.
(With added network feature. Optional)
- Remote observation and control. (With added network feature. Optional)
- Signal alert for forced breakage
Product Introduction
Product Introduction
1. Contents
2. Key Features
3. Specification
4. Dimension (mm)
12

1. Remove battery case cover and press ‘administrator registration
button’in right bottom corner. (See Picture 1)
2. When you hear a ‘beep’, bring card key (to be set as
administrator card key) near the exterior body ( ).
(See Picture 2)
3. For successful registration, you will see ‘Green’light on LED.
If failed, ‘Red’light will appear.
4. For continued administrator card key registration, bring additional
card near the exterior body while LED is ‘Green’.
(Maximum 7 administrator card keys are allowed)
5. When registration process is completed, pressing ‘administrative
registration button’will finalize the administrator registration
process.
(For new and additional registrations of master key, previous
keys (guests, maids, etc) must be re-registered)
1. Press ‘initiation button’.
2. LED turns to ‘Green’.
3. Bring Registered card key to near exterior body.
4. After a ‘beep’door unlocks and using exterior body as a handle, open door.
1. Use one 9V Alkaline battery.
2. Apply battery to pop-out terminal. (See Picture 3)
3. When LED turns ‘Green’, bring card key to near exterior
body.
4. After a ‘beep’door unlocks.
(Caution: For emergency power source, please only
use 9V Alkaline battery.)
1. Press ‘initiation button’about 2~4 seconds until you hear a
‘beep’. (See Picture 1)
2. After a ‘beep’LED turns to ‘Orange’.
Bring an administrator card key near exterior body, then a ‘beep’
sounds and LED turns to ‘Green’, afterward, bring a guest card
to exterior body. When a ‘beep’sounds, guest card is registered.
Caution: 1) When locker door is opened with administrator card
key, guest card key is cancelled and no longer works as
door key.
2) When administrator key is not registered, any card key
can be registered. Therefore, register an administrator key
before use.
Picture 1
Picture 2
Picture 3
User Guide
User Guide
1. Administrator Registration
2. Guest Card Registration (When Administrator Card Key is registered)
3. Opening the door
4. Using emergency power source
34

☞ Not to Scale. Actual size pattern included. Please check the content.
Installation Guide
Installation Guide
1. Paper Pattern
56
1. Latch setting
. Loosely tighten top and bottom screws.
. Adjust to fit to proper location. Align popped
out portion to fit to end of door frame.
. Tighten screws.
. Tighten 2 additional screws in between.
2. Interior iron plate and exterior body setting
. Cables should be passed through cable hole before interior iron plate
is joined with
exterior body using bolts.
. Using 3 screws, tighten interior iron plate.
2. Installation Steps

3. Connecting cables and installing interior body
. Connect 3 cables to interior body.
(Please refer to cable setting section.)
. Organized cables before case is installed using 4 bolts.
4. Battery insertion and applying sticker
. Insert 4 AA batteries.
. Cover the batteries with case and fasten bolt.
. Apply sticker to cover bolts.
Installation Guide
Installation Guide
78
1. Connect 3 cables to proper slots.
. Please refer to below pictures.
2. Please make sure cables are connected properly and organized so will
not be too Squeezed when closing the case.
Interior Body
Interior Iron Plate
Exterior Body
①
②
③
A
B
C
3. Cable Setting

Shape Usage
zTo join exterior and interior body φ5Hole (2)
zTo join Interior body and interior iron plate (4)
zTo install Latch (4)
zTo tighten Interior iron plate (3)
zBattery cover (1)
Installation Guide
Installation Guide
4. Bolts and Screws
910
5. Colors Available
