3B Filters 8500 Series Operating instructions

4642 West 92nd Street | Oak Lawn, IL 60453 | Ph: 708-636-6240 | ISO 9001:2015
ver. 030321
8500 SERIES
SERVICE INSTRUCTIONS
** WARNING **
RELIEVE ALL PRESSURE IN THE LINE BEFORE SERVICING FILTER ASSEMBLY
RECLEANABLE STAINLESS ELEMENTS
1) Follow all company/OSHA safety rules, such as wearing protective goggles and gloves, etc.
2) Turn bowl off in counter-clockwise direction.
3) Pull element off post.
4) Remove seal from element.
5) Remove seal that is above threads in head.
6) Clean element as follows:
a. Remove external dirt in a separate container with cleaning fluid, and light brush.
b. Submerge the filter for thirty minutes in an approved cleaning fluid.
c. Following the soak, purge element from inside to outside with clean compressed air or similar
clean gas. DO NOT EXCEED 120 PSI.
d. Remove any remaining cleaning solution by dipping the element in isopropyl alcohol, or drying
appropriately.
7) Lubricate a new seal and install above threads.
8) Lubricate a new seal with a compatible lubricant and install into outlet port of element.
9) Slip element over mandrel. Teflon (T) o-rings are difficult to engage. For specific instructions on
Teflon installation contact the factory.
10) Inspect all threads for debris and clean thoroughly. Lubricate threads on head and bowl and assemble -
torque to 25 ft. - lbs.
11) Check for leaks while re-pressurizing.
DISPOSABLE ELEMENTS
1) Be sure to follow all company & OSHAsafety rules, such as wearing protective goggles and gloves.
2) Turn bowl off in counter-clockwise direction.
3) Pull element off post.
4) Remove seal that is above threads in head.
5) Lubricate a new seal and install above threads in head.
6) Lubricate the seal in the new element.
7) Slip element over mandrel. Teflon (T) o-rings are difficult to engage. For specific instructions on Teflon
installation contact the factory.
8) Lubricate threads on head and bowl, then torque to 25 ft. - lbs.
9) While system is re-pressurizing be sure to check for leaks.
NOTE:
The element life is based upon cleaning cycles and pressure drop. The estimated life of the element is 10 to 15
cleaning cycles. If the element has exceeded this level discard and replace.
The proper way to evaluate your element after cleaning is an ARP-901 Bubble point test. Contact factory for any
cleaning or testing requirements.
Recommended cleaning fluids are acetone, mineral spirits and a variety of others. Halo-carbon grease or Krytox
are recommended lubricants. Other acceptable lubricants include petroleum jelly or silicone. Caution should
be used when using dry lubricants, due to the fact that our threads are single point, precision threads and dry
lubricants can disrupt clearances.

4642 West 92nd Street | Oak Lawn, IL 60453 | Ph: 708-636-6240 | ISO 9001:2015
ver. 030321
8500SERIES
AccessoriesSERVICE INSTRUCTIONS
** WARNING **
RELIEVE ALL PRESSURE IN THE LINE BEFORE SERVICING FILTER ASSEMBLY
1) Follow all company/OSHA safety rules, such as wearing protective goggles and gloves, etc.
2) Remove indicator body from head being careful not to lose any of the indicator assembly parts when
pressure on spring is released.
3) Examine all of the indicator assembly components for damage or wear. If any components need
replacement, contact the factory for the appropriate replacement parts.
4) For proper indicator function, the differential pressure channels from the in & out ports must be free
of debris. If necessary use compressed air to blow any debris out of the channels.
5) Make sure that the piston can move freely.
6) When reinstalling the visual indicator assembly into the filter head be sure to install all components per
the appropriate assembly drawing. All o-ring seals need to be lubricated with appropriate lubrication prior
to assembly. Acceptable lubricant include petroleum jelly or silicone. (Check lubricant for aluminum
compatibility).
7) Torque indicator to 10 ft-lbs max.
A8500 Electrical Indicator
A8500 Visual Indicator
G8500 Visual Indicator
5) Also make sure that the piston can move freely.
6) When reinstalling the visual indicator assembly into the filter head be sure to install all components per
the appropriate assembly drawing. All o-ring seals need to be lubricated with appropriate lubrication prior
to assembly. Acceptable lubricants include petroleum jelly, silicone and Halocarbon among others.
7) Torque indicator to 25 ft-lbs.
5) When reinstalling the indicator assembly into the filter head be sure to install all components per the
appropriate assembly drawing. All o-ring seals need to be lubricated with appropriate lubrication prior to
assembly. Acceptable lubricants include petroleum jelly or silicone. (Check lubricant for aluminum
compatibility).
6) Torque Indicator carefully to 20-25 ft-lbs.
