3B Medical Lumin LM3000 User manual
USER MANUAL
LM3000 Household Item UV Sanitizer
www.3BLumin.com
®
2 3
Explanation of Symbols ....................4
Understanding Your Device .................4
Specications ............................4
Using Your Lumin .........................5
Caring for Your Lumin Device ...............5
Lumin UV Multi-Purpose Sanitizer............6
Indications for Use ........................6
Features .................................6
Sanitizing Other Personal Care Items .........7
Electromagnetic Compatibility...............8
Warnings ................................9
Warranty ................................11
EXPLANATION OF SYMBOLS USED
Equipment protected throughout by double
insulation or reinforced insulation.
Refer to instruction manual.
Important information concerning your safety or
the operation of your device.
SAFETY REQUIREMENTS
1. The Lumin needs to be installed and used according
to EMC information provided in the document.
2. Some wireless equipment may be affected when
lumin is working, such as wireless home network
devices, mobile phones, cordless telephones and
their base stations, walkie-talkies. It should be kept
at least a distance away from Lumin.
3. Refer to all necessary instructions for maintaining
basic safety and essential performance with regard
to electromagnetic disturbances for the expected
service life.
4
Understanding Your Device
The Lumin operates using UV-C light. The drawer is made
of polished aluminum which reects the UV light to improve
coverage. The Lumin operates using a form of high energy light
that is focused narrowly on the wavelength that is most effective
in reducing bacteria* and viruses.*
5
Using Your Lumin
1. Plug the Lumin power cord in a wall outlet.
2. Place the article face up on the acrylic rack.
3. If the article is visibly soiled please rst wipe thoroughly with a
wipe.
4. Close the Lumin chamber drawer.
5. Press round power button, the Cycle-On orange light will turn
on indicating that the 5 minute cleaning cycle has started.
6. After 5 minutes the Lumin will emit a beep and the UV light will
no longer be visible. A green light will indicate completion of
the cleaning cycle.
No waiting period is necessary
and your article is now ready to use.
Caring for Your Lumin Device
The Lumin bulb is designed to exceed the life of your device
so changing the bulb should not be necessary. If, however,
it does become necessary, the bulb is removed by simply
grabbing the base and pulling rmly. The bulb is easily replaced
by inserting the new bulb and pushing it into the socket. If you
are in need of a replacement bulb please contact 3B Medical
at 863-226-6285 for a replacement bulb. Alternatively you may
also log on to www.3BLumin.com and order a bulb or email
The Lumin drawer is lined with polished aluminum. Do not
use baking soda or other alkali-based cleaners on aluminum
as it can cause discoloration. Aluminum scratches fairly easily,
so avoid abrasive cleaners and scrubbers when cleaning and
polishing. If using a metal or glass cleaner, test the cleaner on
a small portion of the drawer. Polish with a soft lint free cloth.
Should the casing of your 3B Lumin become soiled you may
wipe down with any moist cloth. Do not immerse your Lumin
into water or any cleaning solvents. Place your Lumin on a level
counter or tabletop. Do not drop your Lumin or the bulb and or
glass drawer may shatter.
SKU: LM3000
Weight: 5.5 lbs
Dimensions: 12.25 x 8.5 x 7.75”
Voltage: AC 110 V 0.2A 60Hz
AC 220 V 0.15A 50Hz
Fuse: 250 V, 2A, Interrupting
Capability: 50A
TUV Lamp Useful Life: 9000 hr
Lamp Wattage: 9 W
UV-C Radiation: 2.3 W
Environmental Conditions:
Storage Temperature: 0˚ to 120˚ F / -18˚ to 49˚ C
Operating Temperature: 20˚ to 100˚ F / 7˚ to 38˚ C
Humidity: Up to 93%, non-condensing
Atmospheric Pressure: 800-1060hPa
Altitude: 2000m
SPECIFICATIONS
Lab Tested on Hard Non-Porous Surfaces:
* Bacteria: E. coli 99.99%, S. enterica 99.99%, S. aureus 99.99%. K. pneumoniae 99.99%
Lab Tested on Porous Soft Surfaces:
** Viruses: Inuenza A (H1N1) >99.9% and Human Coronavirus 229E >99.9%,
Human Adenovirus 2 (ATCC VR-846) >99.9%
6
Indications for Use
The Lumin is a UV device intended to sanitize a variety of
household and personal care items (e.g. cell phones, electric
toothbrush, keys, video game controllers, etc).
Thank you for your recent purchase of the Lumin Multi-
Purpose UV Sanitizer.
Please read and follow all directions in this user manual.
Lumin
Multi-Purpose UV Sanitizer
FEATURES
Simple one-touch operation.
Quick 5 Minute
Cleaning
Uses UV Light
Easy
to Use
No Chemicals
Required
Affordable
7
Sanitizing Other Personal Care Items
Lumin is a multipurpose sanitizer that is lab tested to reduce
bacteria* & viruses* on multiple surfaces. Lumin may be used on
cell phones, keys, video game controllers, face masks for home
use, etc. To use Lumin on your personal care items, simply
place them in the Lumin drawer, close and hit the start button.
Lumin’s cycle lasts only 5 minutes!
Lab Tested on Hard Non-Porous Surfaces:
* Bacteria: E. coli 99.99%, S. enterica 99.99%, S. aureus 99.99%. K. pneumoniae 99.99%
Lab Tested on Porous Soft Surfaces:
** Viruses: Inuenza A (H1N1) >99.9% and Human Coronavirus 229E >99.9%,
Human Adenovirus 2 (ATCC VR-846) >99.9%
98
Item Compliance Electromagnetic
Environment
Radiated Emission
(CISPR 11) P
Its RF emissions are very
low and are not likely to
cause any interference
in nearby electronic
equipment
Harmonics of Current
(IEC 61000-3-2.) P 40 order harmonics
Voltage Flicker
(IEC 61000-3-3) –
Without testing according
to clause 6.1 of IEC
61000-3-3.
Electrostatic
Discharge Immunity
(IEC 61000-4-2)
P
±8 kV contact
±2 kV, ±4 kV, ±8 kV, ±15
kV air
Conducted
Disturbance Immunity
(IEC 61000-4-6)
PHome Healthcare
Environment
Electrical Fast
Transient/BurstIEC
(61000-4-4)
P±2 kV 100 kHz repetition
frequency
Surge Immunity
(IEC 61000-4-5) P
Line to line±0.5kV, ±1Kv
Line to earth ±0.5kV,
±1kV,±2kV
Voltage Dips and
Interruptions
(EN 61000-4-11)
P
0%UT 0.5(at 0°, 45°, 90°,
135°, 180°, 225°, 270°,
315°)
0%UT 1(at 0°)
70%UT 25(at 0°)
0%UT 250(at any angle)
Radiated
Electromagnetic Field
Immunity
(IEC 61000-4-3)
P
Home Healthcare
environment
80 to 2700 MHz (Front,
Rear, left, right)
Field Strength: 10V/M
Power Frequency
Magnetic Field
Immunity
(IEC 61000-4-8)
P
Orientations of Induction
Coil (X, Y, Z)
Magnetic Field Strength:
30A/m
ELECTROMAGNETIC COMPATIBILITY Warning - the Lumin is not a toy and is not intended to be
used by children.
Warning - the Lumin has a powerful UV light bulb
included, use with care in case of broken glass.
Warning - do not use in or around sinks, tubs, pools or any
bodies of water.
Warning - the UV that is emitted in the closed chamber is
not compatible with life, never place living creatures in the
Lumin.
Warning - Ultraviolet (UV-C) Radiation Hazard. Any
exposure to the UV-C will cause signicant eye damage
and may cause skin damage. If you see any crack or
damage in the tinted oval window on the top of the unit,
unplug the power and stop using immediately, and contact
3B Medical for assistance.
Warning - do not stack objects on top of your Lumin.
Warning - use this device only for its intended use as
described in this manual. If the equipment is not used
in the manner specied, the cleaning provided by the
equipment may be less eective.
Warning - Do not attempt to operate this device with
the drawer open. The device was designed to shut o
automatically when the drawer is open. It is important not
to defeat or tamper with this safety feature as UV light can
cause damage to eyesight.
Warning - The Lumin plugs into an outlet. Disconnect the
device by unplugging. Do not plug the device into an outlet
that is dicult to access.
Warning - Lumin relies on the optics of UVC light. Results
may vary depending on positioning and shadowing.
10 11
WARRANTY
Your Lumin is warranted for a period of 2 years from time of
purchase to be free from manufacturer defect or workmanship.
Should you encounter a warranty issue please contact 3B Medical
at www.3BLumin.com to submit a return authorization or email
It is at the discretion of 3B Medical to repair, replace or exchange
your Lumin unit should it be necessary. 3B Medical is not liable for
misuse, mishandling or breach of this written guarantee. Attempts to
alter the Lumin in any way will void warranty.
203 Avenue A NW, Suite 300 | Winter Haven, FL 33881
www.3BLumin.com and www.3Bproducts.com
Technical Support contact 3BLumin.com/support
Please register your Lumin at www.3BLumin.com
5010494
This equipment has been tested and found
to comply with the limits for a Consumer ISM
equipment, pursuant to Part 18 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses and can radiate radio frequency energy and,
if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installation.”
Please note that changes or modications of this
product is not expressly approved by the party
responsible for compliance could void the user’s
authority to operate the equipment.
If this equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and on, the
user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
•Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV
technician for help.
This product may cause interference to radio
equipment and should not be installed near maritime
safety communications equipment, ships at sea
or other critical navigation or communications
equipment operating between 0.45-30 MHz.
Lumin
LM3000 Multi-Purpose UV Sanitizer
This device complies with Part 18 of the FCC Rules.
3B 0121 4326 LUMINdual MID-140/v2.0
