3branch KURVE COLLECTION User manual

* * **.**.**
DATEREV # REVISION DESCRIPTION
DRAWING #DATE:
product design solutions
3branch
P 847.291.3900
F 847.291.3901
www.3branch.com
DESCRIPTION:
SHEET 1 OF 50 REV #
KURVE COLLECTION ROUND COMPUTER TABLE
W/CYLINDER BASE & TOP DIVIDERS
ASSEMBLY INSTRUCTIONS
KU-CT-60-26-CYB-ATD-ASSEMBLY-0107.08.21
3D MODEL- ASSEMBLED TABLE
PLAN VIEW- ASSEMBLED TABLE
SIDE VIEW- ASSEMBLED TABLE END VIEW- ASSEMBLED TABLE
ASSEMBLY INSTRUCTIONS

PARTS LIST:
TABLE TOP QTY= 1
SUB-TOP QTY= 1
BASE CYLINDER QTY= 1
ACRYLIC TOP DIVIDER PANEL- LONG QTY= 1
ACRYLIC TOP DIVIDER PANEL- SHORT QTY= 2
HARDWARE:
LEVELER 5/16"-18 X 1 1/2"L STEM QTY= 5
SUB-TOP/CYLINDER MOUNTING PLATES QTY= 4
TOP DIVIDER MOUNTING BRACKETS- QTY= 8
FOR 3/8"TH PANEL, 13/16" DIA X 1 3/4"H,
STAINLESS STEEL, SATIN FINISH
#10 X 3/4"L FLAT HEAD PHILLIPS SHEET METAL QTY= 16
SCREW (SUB-TOP TO CYLINDER BASE
MOUNTING)
#10 X 1 1/2" FLAT HEAD PHILLIPS SHEET METAL QTY= 8
SCREW (TOP PANEL TO SUB-TOP MOUNTING)
5/16"-18 X 1 1/4"L FLAT HEAD PHILLIPS QTY= 8
MACHINE SCREW (BRACKET MOUNTING)
TOP PANEL SUB-TOP
LEVELERS PANEL BRACKETS
BASE CYLINDER TOP DIVIDER PANEL- SHORTTOP DIVIDER PANEL- LONG
SUB-TOP MOUNTING PLATES
WIRE MANAGMENT:
GROMMET & LINER, 2"O.D., 1 9/16" I.D., QTY= 4
1 3/4" BORE, 5/8" X 15/16" SLOT, 5/8" TH,
ABS, FINISH TO BE SPECIFIED,
DOUG MOCKETT #SG3-XX
TOOLS REQ'D:
POWER DRILL/SCREW GUN
PHILLIPS DRIVERS
NOTE:
ACRYLIC TOP DIVIDERS MUST BE MOUNTED
TO TOP PANEL PRIOR TO MOUNTING TOP
PANEL TO SUB-TOP!!!
DRAWING #DATE:
product design solutions
3branch
P 847.291.3900
F 847.291.3901
www.3branch.com
DESCRIPTION:
SHEET 2 OF 50 REV #
KURVE COLLECTION ROUND COMPUTER TABLE
W/CYLINDER BASE & TOP DIVIDERS
ASSEMBLY INSTRUCTIONS
KU-CT-60-26-CYB-ATD-ASSEMBLY-0107.08.21

STEP 3
LAY BASE CYLINDER ON COVER WITH LARGE OPENING TURNED DOWN.
*THREADED INSERTS RECESSED INTO BOTTOM PANEL OF BASE CYLINDER
FOR LEVELERS WILL BE VISIBLE.
THREAD LEVELERS INTO THREADED INSERTS LOCATED IN BOTTOM OF
CYLINDER.
STEP 1
LAY CLEAN COVER ON FLOOR TO PROTECT FLOOR & TABLE PARTS.
STEP 2
REMOVE ALL PACKING MATERIAL FROM TABLE PARTS.
*CAUTION: TWO PEOPLE REQ'D FOR TABLE ASSEMBLY TO AVOID
DAMAGE TO TABLE PARTS & PERSONAL INJURY!
DRAWING #DATE:
product design solutions
3branch
P 847.291.3900
F 847.291.3901
www.3branch.com
DESCRIPTION:
SHEET 3 OF 50 REV #
KURVE COLLECTION ROUND COMPUTER TABLE
W/CYLINDER BASE & TOP DIVIDERS
ASSEMBLY INSTRUCTIONS
KU-CT-60-26-CYB-ATD-ASSEMBLY-0107.08.21
STEP 4
FLIP BASE CYLINDER UPRIGHT ON COVER WITH LEVELERS
TURNED DOWN.
MOUNT SUB-TOP MOUNTING PLATES TO TOP OF CYLINDER
WITH #12 X 3/4" FLAT HEAD PHILLIPS SCREWS.
*NOTE: PILOT HOLES FOR MOUNTING PLATE SCREWS ARE
PRE-DRILLED INTO THE TOP PANEL OF THE BASE CYLINDER.
STEP 5
VERIFY THAT SUB-TOP MOUNTING PLATES ARE SECURED TO TOP OF
BASE CYLINDER.
REMOVE BASE CYLINDER FROM FLOOR COVER.
LEVELERS
SMALL HOLE
MOUNTING PLATES
#10 X 3/4" FHP
SCREWS
FLOOR
COVER
BASE CYLINDER

DRAWING #DATE:
product design solutions
3branch
P 847.291.3900
F 847.291.3901
www.3branch.com
DESCRIPTION:
SHEET 4 OF 50 REV #
KURVE COLLECTION ROUND COMPUTER TABLE
W/CYLINDER BASE & TOP DIVIDERS
ASSEMBLY INSTRUCTIONS
KU-CT-60-26-CYB-ATD-ASSEMBLY-0107.08.21
STEP 8
FLIP BASE CYLINDER/SUB-TOP ASSEMBLY UPRIGHT.
STEP 9
LAY TOP OVER SUB-TOP
*NOTE: RECESSED COUNTERSUNK MOUNTING HOLES FOR TOP
DIVIDER BRACKETS NEED TO BE FACING DOWN.
*DO NOT ATTACH TOP DURING THIS STEP!!!
STEP 6
LAY SUB-TOP ON FLOOR COVER.
NOTE: COUNTERSUNK TOP MOUNTING HOLES ARE FACING UP.
FLIP BASE CYLINDER OVER WITH LEVELERS TURNED UP.
CENTER BASE CYLINDER ON SUB-TOP.
MARK & DRILL 1/8"DIA PILOT HOLES IN SUB-TOP FOR MOUNTING
SCREWS.
STEP 7
MOUNT BASE CYLINDER TO SUB-TOP WITH #12 X 3/4" FLAT HEAD PHILLIPS
SCREWS INSERTED THRU MOUNTING PLATES & THREADING INTO PILOT
HOLES PREVIOUSLY DRILLED IN BOTTOM FACE OF SUB-TOP.
SUB-TOP
#10 X 3/4" FHP
SCREWS
TOP PANEL
COUNTERSINK
FACING UP

DRAWING #DATE:
product design solutions
3branch
P 847.291.3900
F 847.291.3901
www.3branch.com
DESCRIPTION:
SHEET 5 OF 50 REV #
KURVE COLLECTION ROUND COMPUTER TABLE
W/CYLINDER BASE & TOP DIVIDERS
ASSEMBLY INSTRUCTIONS
KU-CT-60-26-CYB-ATD-ASSEMBLY-0107.08.21
STEP 10
MOUNT TOP DIVIDER BRACKETS TO TOP PANEL WITH 5/16" X 1 1/4"
MACHINE SCREWS INSERTED UP THRU COUNTERSUNK HOLES IN
TOP PANEL.
*NOTE LEAVE DIVIDER BRACKETS SLIGHTLY LOOSE UNTIL DIVIDER
PANEL ARE INSERTED IN THE SLOTS IN THE BRACKETS.
*NOTE: TOP PANEL WILL NEED TO BE MOVED AROUND TO ACCESS
HOLES LOCATED @ CENTER OF TOP PANEL. TWO PEOPLE REQ'D
TO PREVENT TOP FALLING.
STEP 11
CENTER & INSERT LONG TOP DIVIDER PANEL INTO SLOTS IN BRACKETS.
INSERT SHORT TOP DIVIDER PANELS INTO SLOTS IN BRACKETS.
*NOTE: OFFSET SHORT DIVIDER PANELS 1/8" FROM FACE OF LONG DIVIDER
PANEL.
TIGHTEN SET SCREWS IN TOP DIVIDER BRACKETS TO SECURE DIVIDER
PANELS.
AFTER ALL DIVIDER PANELS HAVE BEEN SECURED, TIGHTEN ALL DIVIDER
MOUNTING BRACKET MACHINE SCREWS.
STEP 12
CENTER TOP PANEL ON BASE CYLINDER.
MOUNT TOP PANEL TO SUB-TOP WITH #10 X 1 1/2" FLAT HEAD PHILLIPS
SHEET METAL SCREWS.
STEP 13
INSTALL GROMMETS IN HOLES LOCATED @ CENTER OF TOP.
LOCATE & LEVEL ASSEMBLED TABLE.
ADD SAND BAG TO BASE THRU ACCESS DOOR.
DIVIDER PANEL
MOUNTING
BRACKETS
5/16-18 X 1 1/4" FHP
MACHINE SCREWS
TOP DIVIDER
PANELS
#10 X 1 1/2" FHP
SCREWS
GROMMETS
