3branch magstak User manual

NOTE: Towers with standard size modules
are 6 modules high. Towers with tall
modules are 5 modules high (pictured).
Towers with magazine modules are 4
modules high. Signage is optional.
See care instructions for proper care and
handling of product.
Safety Warning: Tower bases
are heavy! Use two people
when installing levelers into
bottom of base.
Remove items from packaging and check packing slip for
proper content and quantity.
Tightly screw adjustable levelers into bottom of quad tower base
before assembling.
Optional: connect bottom module to spinner base
using connector bolts (see detail 1). Stack second
module in same fashion and connect the two modules
using the binding post, neoprene washer and binding
screw (see detail 2) to ensure a secure and stable fit.
Do not over tighten!
Stack one magstak™ module on top of the spinner base
using the alignment disks that set into alignment ports
as shown below.
2
1
4
3
5
magstak™ quad tower display
assembly instructions
quad tower base
magstak™ module
(quantities vary)
black spinner
base
detail 1
connector bolt
connector bolt
module
module
neoprene washer
binding post screw
completed tower
optional
2-sided sign
(2 pieces)
optional
4-sided sign (2 pieces)
adjustable
levelers (4)
©3branch All Rights Reserved.
3branch.com
Sept 2023 877.899.9902
See optional magstak™ signage assembly instruction
on reverse/page 2.
detail 2
binding post
binding post
module

Insert your printed signage into appropriate holder as
shown below.
You can use one standard 8.5 x 11 inch piece of paper to
satisfy all of your signage needs. See options below. Combine signage components.
Place signage on top-most magstak™ module, making
sure to connect alignment discs with alignment ports.
2
1
4
3
8.5 x 11 inch
Letter Paper
8.5 x 5.5 in
8.5 x 2.75 in
optional magstak™ signage
assembly instructions
©3branch All Rights Reserved.
3branch.com
Sept 2023 877.899.9902
for 2-sided signage for 4-sided signage 2-sided signage 4-sided signage
11 x 2.125 in
2-sided signage 4-sided signage 2-sided signage 4-sided signage
