3D Perception COMPACTVIEW HMR-15 User manual

2005 3D perception AS All rights reserved.
The copyright of this document is the property of 3D perception AS. The document is supplied on the
express terms that it is to be treated as confidential. No part of this document may be reproduced or
transmitted in any form or by any means, electronic or mechanical for any purpose, without the
express written permission of 3D perception AS. The information in this document is subject to
change without notice and is provided ‘AS IS’.
C OMPACTVIEW HMR-15
U
SER
M
ANUAL

3D perception C OMPACT V IEW HMR-15
Revision 1 User Manual
ii
D
OCUMENT
S
TATUS
Revision Month Year Paragraph(s) Prepared by Description of
Change
0 Jul 2005 All A F Rotheram Initial release
1 August 2005 5.3 A F Rotheram Set security key

3D perception C OMPACT V IEW HMR-15
Revision 1 User Manual
iii
T ABLE OF C ONTENTS
1. BEFORE YOU START.................................................................................................................1
1.1 Projector pack...............................................................................................................1
1.2 Accessories...................................................................................................................1
2. INTRODUCTION........................................................................................................................2
2.1 Optional Modules .........................................................................................................2
2.2 Lens ..............................................................................................................................3
3. SAFETY....................................................................................................................................4
3.1 Safety............................................................................................................................4
3.2 Safety Instructions........................................................................................................4
4. BEFORE SET-UP AND USE ........................................................................................................5
4.1 Overview ......................................................................................................................5
4.2 Rear Connector Panel...................................................................................................6
5. SET-UP.....................................................................................................................................7
5.1 Load CompactDesigner/CompactControl to PC ..........................................................7
5.2 Connect control interface..............................................................................................7
5.2.1 Connecting multiple projectors ....................................................................................8
5.3 Set functionality codes for projectors...........................................................................9
5.4 Set computer source for projectors.............................................................................13
6. FOCUS AND ZOOM .................................................................................................................14
6.1 Focus...........................................................................................................................14
6.2 Zoom...........................................................................................................................14
7. MOUNTING THE PROJECTOR ..................................................................................................15
7.1 To a Ceiling Mount.....................................................................................................15
7.2 To a Tabletop..............................................................................................................16
8. USING THE PROJECTOR..........................................................................................................17

3D perception C OMPACT V IEW HMR-15
Revision 1 User Manual
iv
8.1 Projector On/Off.........................................................................................................17
8.2 Signal Source..............................................................................................................17
9. MAINTENANCE ......................................................................................................................18
10. LAMP REPLACEMENT ............................................................................................................19
10.1 Remove old lamp........................................................................................................19
10.2 Insert New Lamp ........................................................................................................20
11. SERVICE INFORMATION .........................................................................................................21
12. TECHNICAL DATA..................................................................................................................22
12.1 Warping and edge blending specifications.................................................................22
12.2 Projector specifications...............................................................................................23
13. LIMITED WARRANTY, ‘FCC STATEMENT’ AND ‘TRADEMARKS COPYRIGHT’.......................24
14. CONTACT US..........................................................................................................................26

3D perception C OMPACT V IEW HMR-15
Revision 1 User Manual
1
1. B EFORE YOU START
Thank you for choosing a 3D perception C OMPACT V IEW HMR-15 projector
1.1 Projector pack
Please take a few minutes to ensure that your C
OMPACT
V
IEW
HMR-15 projector pack contains
the following items.
C OMPACT V IEW HMR-15 Projector
Cables
VGA male Blue - VGA male Blue, 2m
DVI-I male White - DVI–I male White, 2m
Communication Cable 6’ spiral with RJ12 connectors
Power cord, 3m (European)
Power cord, 3m (US)
1.2 Accessories
Please refer to our website at www.3d-perception.com

3D perception C OMPACT V IEW HMR-15
Revision 1 User Manual
2
2. I NTRODUCTION
The C OMPACT V IEW HMR-15 projector is the ultimate in high-resolution projectors when
projection on to flat, curved or double curved screens with multiple projectors is the requirement.
The C
OMPACT V IEW HMR-15 is unique in that it is purchased as an empty unit and users select
from a list of Optional Modules (see details below) and purchase only those functionalities that
they require. An activation code is then supplied for each projector and must be loaded prior to
use (see chapter Set up).
The C
OMPACT
V
IEW
HMR-15 projector is compatible with most data and video sources, both
analogue and digital and provides the user with outstanding features such as:
• High resolution
• High brightness
• High contrast
• Colour control
• Gamma correction
• CompactControl interface
• Compact, low weight
• Low noise
• Single Chip DLP technology
• Desktop and ceiling-mountable
This user guide contains important information about safety precautions and the set-up and use
of the projector.
Please read the manual carefully before you operate the projector.
2.1 Optional Modules
Optional modules within CompactView HMR-15 offer the following unique functions:
Module ID
Functionality
KK100 Basic activation module
KK200 Colour matcher
KK300 Seamless edge-blending for fl at screens
KK350 Seamless edge-blending for curved screen
KK400 Image warping for fl at screens
KK450 Image warping for curved screens
KK500 Active to passive decoder
KK600 Megawall for 2 projectors
KK650 Megawall for 4 projectors (UXGA compatible)
KK700 Wireless LAN

3D perception C OMPACT V IEW HMR-15
Revision 1 User Manual
3
2.2 Lens
3 lens options are available
Lens ID Specifications
PL115 1.15 – 1.34: 1 wide zoom lens
PL140 1.38 – 1.61:1 intermediate zoom lens
PL180 1.8 – 2.1:1 long throw zoom lens
NOTE: The specifications and functionality of the product, as detailed in this manual, may
change without prior notice.

3D perception C OMPACT V IEW HMR-15
Revision 1 User Manual
4
3. S AFETY
3.1 Safety
This device complies with relevant safety regulations for data processing equipment for use in
an office environment.
Before using the projector for the first time, please read the safety instructions thoroughly.
3.2 Safety Instructions
Use only the cables and cords supplied with the projector or original replacement cables. Using
other cables or cords may lead to malfunction and permanent damage of the projector
Only open the projector to change the lamp. The projector contains no other user serviceable
parts. Refer all repairs to qualified personnel only.
When changing the lamp always replace it with a lamp of the same type and rating.
Make sure that no objects enter into the vents and openings of the projector. Do not spill any
liquids on the projector or into the vents or openings of the projector.
Do not look into the projection lens when the projector is switched on. The strong light may
permanently damage sight.
Place the projector on a stable surface, or mount it securely using an approved ceiling-mount.
Do not drop the projector.
Always operate the projector horizontally. Operating the projector in other positions may reduce
the lamp life significantly, and may lead to overheating, resulting in malfunctioning.
Always allow ample airflow through the projector. Never block any of the air vents. Never cover
the projector in any way while it is running. Allow for sufficient distance to walls and ceilings to
avoid overheating.
The projector is designed for indoor use only. Never operate it outdoors.
Do not operate the projector outside its temperature and humidity specifications, as this may
result in overheating and malfunctioning.
Only connect the projector to signal sources and voltages as described in the technical
specification. Connecting to unspecified signal sources or voltages may lead to malfunction and
permanent damage of the projector.

3D perception C OMPACT V IEW HMR-15
Revision 1 User Manual
5
4. B EFORE S ET - UP AND U SE
Be sure you have read the Safety Instructions in chapter 3 before proceeding with the set-up
and use of the C
OMPACT V IEW HMR-15 projector.
Unpack the supplied parts and familiarize yourself with the various components.
Remove the lens cap from the projection lens. If you switch the projector on with the lens cap in
place, the lens cap may melt, damaging not only the lens cap itself, but also the projection lens
and surrounding parts.
Familiarize yourself with the C
OMPACT V IEW HMR-15 projector before switching on.
4.1 Overview
A
B
C
D
EF
G
H
A.
Ceiling Mount housing E. Focus ring
B.
On/Off Button F. Zoom ring (optional lens)
C.
Wireless LAN (Optional) G. Lamp housing
D. Ventilation H. Fixing screw for lamp housing

3D perception C OMPACT V IEW HMR-15
Revision 1 User Manual
6
4.2 Rear Connector Panel
C
DEF
HI J
KL
G
B
A
M
A. Analogue RGB In - Red
H. VGA – Analogue RGB In. The standard analogue
computer graphics interface
B. Analogue RGB In - Green
C. Analogue RGB In - Blue I. DVI - Digital RGB. For low noise computer and
video image..
J. RS232 Control chain InD. Analogue RGB In – Horizontal
and Composite Sync
K. RS232 Control chain Out
E. Analogue RGB In - Vertical
Sync
L. LAN. Provides access to control and monitoring over
a Local Area Network
F. Stereo control input
M. Main power connector
G. Ventilation

3D perception C OMPACT V IEW HMR-15
Revision 1 User Manual
7
5. S ET - UP
The first time the C OMPACT V IEW
HMR-15 is switched on, a
message will appear on the
screen requesting a valid license
key (activation code) for the
projector. The message box will
also indicate the following details
for the projector:
Address
Software version
IP address
The following procedures now require completion before the C OMPACT V IEW HMR-15 projector is
ready for use.
1. Load CompactDesigner/CompactControl to PC
2. Connect control interface
3. Set functionality codes for projectors
4. Set computer source for projectors
5.1 Load CompactDesigner/CompactControl to PC
If CompactDesigner or CompactControl software has not yet been loaded to the PC designated
as the control PC for the projection theatre, then load it now.
NOTE: CompactDesigner or CompactControl software will only be required to be loaded once
for a projection theatre, regardless of the number of projectors in the theatre.
5.2 Connect control interface
Connect the Control PC
(running CompactDesigner or
CompactControl) to the
projectors RS232 In port (A).
The supplied 6 lead cable
plugs into the Control PC’s
serial port using a RJ12 6 pin
to serial DB-9 female adapter.
Alternatively connect to either
LAN (B)
A
B

3D perception C OMPACT V IEW HMR-15
Revision 1 User Manual
8
or Wireless LAN (C)
C
5.2.1 Connecting multiple projectors
Multiple projectors may be connected together in a ‘daisy chain’ by one of the following
methods:-
1. By cable
2. By LAN
3. By WLAN (Optional)
5.2.1.1 By cable
Connecting multiple projectors
together by cable is achieved by
using the input and output RS232
ports on each projector. The first
projector is connected to the control
PC via the RS232 In port (A) as
described above. Then another 6
lead cable connects between the
RS232 Out port (B) and the RS232 In
port (A) of the next projector. This
‘chain’ can be extended up to the
theoretical limit of 255 projectors.
AB

3D perception C OMPACT V IEW HMR-15
Revision 1 User Manual
9
5.2.1.2 By LAN
Connect all projectors via the LAN
port (C) to the same LAN as the
control PC (running
CompactDesigner or
CompactControl) is connected.
C
5.2.1.3 By WLAN (Optional)
Only applicable if Optional module
KK700 has been purchased
To be developed
D
5.3 Set functionality codes for projectors
Complete the following steps within CompactControl for each C
OMPACT
V
IEW
HMR-15
introduced into the theatre.

3D perception C OMPACT V IEW HMR-15
Revision 1 User Manual
10
Step 1
Select Projectors on the drop-down menu
under Maintenance under the main File
menu
Step 2
On the Projector maintenance dialogue box click
right on the desired projector and select
Properties from the drop-down menu.
NOTE: The address of all CompactView HMR-15
projectors will commence with the characters CH.

3D perception C OMPACT V IEW HMR-15
Revision 1 User Manual
11
Step 3
If the IP address and Subnet mask are set
automatically (default option), the DHCP
standard protocol will be used to assign the
address.
If the IP address and Subnet mask are to be
set manually, it is recommended that users
consult with their own network administrator.
Step 4
Only applicable if Optional module KK700 has
been purchased
WLAN
(To be developed)

3D perception C OMPACT V IEW HMR-15
Revision 1 User Manual
12
Step 5
Check the Lamp time is indicated showing the
projector is switched on.
NOTE: This dialogue page can also used to
reset the lamp time to zero in the event that
the lamp unit has to be replaced.
Step 6
Enter the unique Security key for the projector.
(The security key for each projector can be
obtained by e-mail from 3D perception. Send
the projector address [CH….] of each projector
to any of the sales staff, support staff or to
[e-mail] or
[e-mail])
Press "Update" once and then press “OK”.
This will register and activate the optional
modules purchased.
Note: You will not see any notification or
warnings when you press the "update"
button
Wait for 30 seconds and the projector will then
start to scan for source.

3D perception C OMPACT V IEW HMR-15
Revision 1 User Manual
13
Step 7
CW (Colour Wheel)
This dialogue page will indicate the colour
wheel index delay.
NOTE:
1. Changing the colour wheel index
delay will not improve or adjust the
colour on the projector.
2. Changing the colour wheel index
delay should only be performed by a
qualified technician.
5.4 Set computer source for projectors
The projector may be connected to up to 3 computer sources simultaneously, using the
Analogue RGB inputs at (A) and (B) and the Digital RGB input at (C).
Connect the power cord (D) .
B C
D
A

3D perception C OMPACT V IEW HMR-15
Revision 1 User Manual
14
6. F OCUS AND Z OOM
A
B
6.1 Focus
Turn the Focus ring (A) on the projection lens to get a correctly focused image.
6.2 Zoom
Turn the Zoom ring (B) on the projection lens to zoom In and Out. (This is only available on the
optional intermittent and long throw lens.)
If the desired image size cannot be achieved by adjusting the zoom ring, relocate the projector
nearer or farther away from the projection screen and re-try.
NOTE: The focus and zoom adjustment rings are deliberately stiff and difficult to move. If
adjustment is required then a certain amount of pressure must be used.

3D perception C OMPACT V IEW HMR-15
Revision 1 User Manual
15
7. M OUNTING THE P ROJECTOR
7.1 To a Ceiling Mount
The projector can be ceiling mounted using any approved UL tested/listed ceiling mount fixture
with a minimum weight capacity of 12 kg (26 lbs).
The ceiling mount obtainable through 3D perception (as illustrated below) is only approved for
C OMPACT V IEW HMR-15 projectors.
For proper ventilation, the minimum distance from the ceiling/rear wall should be 30 - 50 cm, (12
- 20 inches).
The specifications and functionality of the product may change without prior notice.
A
C
B
A Locking screw for vertical adjustment
B Slide
C Housing for slide (1 on top and 1 on under side)

3D perception C OMPACT V IEW HMR-15
Revision 1 User Manual
16
7.2 To a Tabletop
Although the projector is not equipped with adjustable legs it may be sited directly onto a
tabletop, however, this is only recommended for temporary use or for demonstration purposes.
It is not recommended for permanent installation such as in a simulator.
