LG CF3DA User manual

OWNER'S MANUAL
LCOS PROJECTOR
CF3DA
Please read this manual carefully before operating
your set and retain it for future reference.
www.lg.com

LCOS PROJECTOR
LCOS PROJECTOR
This device meets the EMC requirements for home appliances (Class B)
and is intended for home usage. This device can be used in all regions.
HDMI, HDMI logos and High-Definition Multimedia Interface are the trade-
marks or registered trademarks of
HDMI Licensing LLC.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the
user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence
of important operating and maintenance (servicing) instructions in the literature accompanying
the appliance.
WARNING/CAUTION
- TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
On Disposal (Hg lamp)
- The fluorescent lamp used in this product contains a small amount of mercury.
- Do not dispose of this product with general household waste.
- Disposal of this product must be carried out in accordance to the regulations of your local authority.

Contents
3
Contents
Safety Precautions........................................................ 4
Parts and Components
Main Unit ...................................................................................7
Control Panel.............................................................................7
Back ........................................................................................... 8
Name of remote control buttons ............................................9
How to insert a battery ............................................................9
Projector Status Indicators....................................................10
Accessories ...............................................................................11
Optional Extras ........................................................................11
Installation and Configuration
Caution on Installation...........................................................12
Projection Distance per Screen Size.................................... 13
Turning on the Projector........................................................14
Turning off the Projector.......................................................14
Focus and Position of the Screen Image.............................15
Selecting Input Signal............................................................15
Connecting Device
Connecting to a PC ................................................................16
Connecting to a Video Player................................................ 16
Connecting to a DVD Player ................................................. 17
Connecting to a DTV Set-Top Box........................................ 17
3D Function
Caution When Watching 3D Video.......................................18
Requirements for Watching 3D Images...............................18
Watching 3D Images ..............................................................19
Setting 3D Mode....................................................................20
Exiting 3D Mode .................................................................... 20
Function
Video Function
Picture Mode ........................................................................... 21
Adjusting Color Temperature................................................. 21
Adjusting Picture Settings ................................................... 22
Advanced Options.................................................................. 22
Picture Initialization Function .............................................. 24
TruMotion Demo Function .................................................... 24
Screen Function
Using the Pause Function..................................................... 24
Using the Screen Size Function........................................... 25
Test Pattern Function............................................................ 25
Using Keystone ...................................................................... 25
Changing Projection Mode ................................................... 25
Using the AUTO Function..................................................... 26
Adjusting PC Input ................................................................ 26
Time Function
Using SLEEP Function .......................................................... 27
Auto Off.................................................................................. 27
Option Functions
Selecting a Language............................................................ 28
Using the Blank Image Function.......................................... 29
Selecting the Blank Image Color......................................... 29
Camera Calibration................................................................ 29
To adjust the brightness of the screen, ..............................30
High Altitude ..........................................................................30
Network Settings ...................................................................30
Setting SET ID ....................................................................... 32
Setting the Name of a Connected Device.......................... 32
Setting Power Sound............................................................. 32
Information Function
Checking Projector Information........................................... 32
Serial Communication Function
Establishing Serial Communication..................................... 33
Communication Protocol ...................................................... 33
Communication using Hyper Terminal ................................ 39
Miscellaneous
Supported Monitor Display.................................................... 41
Maintenance ...........................................................................42
Do not turn off the projector ..............................................44
Troubleshooting...................................................................... 46
Product Specifications .......................................................... 47
Open Source software Information .....................................48

Safety Precautions
4
Safety Precautions
Please take note of the safety instructions to prevent any potential accident or misuse of the projector.
ꔈSafety Instructions are given in two forms, i.e. 'Warning' and 'Notes' as detailed below.
Warning: The violation of this instruction may cause serious injury and even death.
Note: The violation of this instruction may cause injury or damage to the projector.
ꔈRead the owner's manual carefully and keep it at hand.
Indoor Installation Warning
Do not place the projector in direct
sunlight or near heat sources such
as radiators, fires, stoves etc.
There is risk of fire.
Do not place flammable materials
such as aerosols near the projector.
There is risk of fire.
Do not allow children to hang from
or climb on the projector.
This may cause the projector to fall,
causing injury or death.
Power Warning
Indoor Installation Caution
The earth cable should be connected.
Ensure that you connect the earth
cable to prevent possible electric shock.
If it is not possible to ground the unit,
have a qualified electrician install a
separate circuit breaker.
Do not try to ground the projector by
connecting it to telephone wires, light-
ning rods or gas pipes.
The power plug should be inserted
fully into the power outlet.
An unstable connection may cause a
fire.
Do not place heavy objects on
the power cord.
This may create a fire hazard or
cause electric shock.
Do not place the projector close to
sources of steam or oil such as a
humidifier or kitchen counter.
This may create a fire hazard or
cause electric shock.
Do not place the projector
where it might be exposed to
dust.
There is risk of fire.
Do not install the product in a place with
no ventilation (e.g., on a bookshelf or in a
closet) or on a carpet or cushion.
Failure to do so may result in a fire due to
the increase in the internal temperature.
Ensure good ventilation around the
projector. The distance between
the projector and the wall should
be more than 30 cm.
Failure to do so may result in a fire due to
the increase in the internal temperature.
Do not use the projector in a damp
place such as a bathroom where it
is likely to get wet.
This may create a fire hazard or result in
electric shock.
Make sure the air vent is not
blocked by a tablecloth or curtain.
Failure to do so may result in a fire due
to the increase in the internal tempera-
ture.
When placing the projector on a
table or shelf, be careful not to put
it near the edge.
The projector could fall, causing injury,
and damage to the projector. Only use
a suitable stand.
Do not place the projector on an
unstable or vibrating surface such as
a wobbly shelf or a slope.
It may fall and cause injury.
Disconnect the projector from the
power supply and all connected appara-
tus before moving or cleaning.
The power cord may be damaged and
may create a fire hazard or result in elec-
tric shock.

Safety Precautions
5
When in Use Warning
In the event that liquid or a foreign
object falls into the projector, please
switch it off and unplug it from the
power outlet and contact an LG
Electronics Service Center.
This may create a fire hazard or cause
electric shock.
Make sure that a child does not swallow the batteries when you
replace the old remote control batteries with new ones. Keep bat-
teries out of reach of children.
If a child swallows a battery, consult a doctor immediately.
Do not remove any covers except
the lens or dust covers. There is a
high risk of electric shock.
Do not look directly into the lens
when the projector is in use. The
strong light may damage your eyes.
When the lamp is on or has just
been turned off, avoid touching the
air vent or lamp cover because they
will be very hot.
Power Warning
Power Caution
Do not plug too many devices
into one multi-power outlet.
This may result in the power outlet
overheating and creating a fire hazard.
Never touch the power plug with
wet hands.
The fluid can cause blindness.
Prevent dust from collecting on the
power plug pins or outlet.
The fluid can cause blindness.
Hold the plug firmly when
unplugging.
A damaged wire may create a fire
hazard.
Ensure the power cord and plug are
not damaged, modified, severely bent,
twisted, pulled, sandwiched or hot. Do
not use the product if the power out-
let is loose.
This may create a fire hazard or cause
electric shock.
Keep the power cord away
from heating devices.
The wire coating may melt, which
may cause a fire or result in electric
shock.
Place the projector where people
will not trip over or tread on the
power cord to protect the power
cord and plug from any damage.
This may create a fire hazard or cause
electric shock.
Do not turn the projector on/off by plugging in the power plug or
unplugging it from the power outlet. (Do not use the power plug as a
switch.)
This may create a fire hazard or result in electric shock.
Do not place anything containing liq-
uid on top of the projector such as a
flower vase, flower pot, cup, cosmet-
ics, or medicine; or ornaments, can-
dles, etc.
This may create a fire hazard, result in elec-
tric shock, or cause injury due to falling.
In the event that there is a big
impact shock or the cabinet is
damaged, switch it off, unplug it
from the power outlet and contact
an authorized service center.
This may create a fire hazard or cause
electric shock.
Do not insert pieces of metal such
as coins, hairpins or metal debris,
nor flammable materials such as
paper or matches into the projector.
This may create a fire hazard or cause
electric shock.

Safety Precautions
6
When in Use Caution
Do not place heavy objects on the
projector.
It may fall and cause injury.
Be careful not to allow impact to
the lens during transport.
Do not touch the lens. The lens
may be damaged.
Miscellaneous Caution
Cleaning Caution
You need to clean the projec-
tor periodically.
If you do not clean the projector,
dust will accumulate inside and
may create a fire hazard or mal-
function.
When cleaning plastic parts such as the projector case, unplug the power
first and wipe with a soft cloth. Do not spray with water or wipe with a wet
cloth. Never use glass cleaner, automobile or industrial shiner, abrasives
or wax, benzene, alcohol etc., which can damage the projector.
This may create a fire hazard, result in electric shock or product damage (deforma-
tion, corrosion or breakage).
Cleaning Warning
Do not spray the projector with
water when cleaning. Make sure
water does not flow into the pro-
jector.
This may create a fire hazard or cause
electric shock.
In the unlikely event of smoke or a
strange smell coming out from the
projector, switch it off, unplug it
from the power outlet and contact
the LG Electronics Service Center.
Otherwise, it may create a fire hazard or
result in electric shock.
Use an air spray or soft cloth or
cotton swab moistened with a lens
cleaning chemical or alcohol to
remove dust or stains on the front
projection lens.
Miscellaneous Warning
Only a qualified technician can disassemble or modify the projector. For diagnosis, adjustment, or repair, con-
tact your seller or service center.
This may create a fire hazard or cause electric shock.
Be sure to unplug if the projector is
not to be used for a long period.
Accumulated dust is a fire hazard and may
result in electric shock due to overheating,
ignition, or poor insulation.
Do not mix new batteries with
old ones.
Burst or leaking batteries are a fire
hazard or may result in electric shock.
Only use the specified type of
battery.
Burst or leaking batteries are a fire
hazard or may result in electric
shock.
When in Use Warning
If there is a gas leak, do not touch the power outlet, and open the win-
dows for ventilation.
Sparks may cause fire or burns.
Always open the lens door and
remove the lens cap when the
projector lamp is on.
Do not use any sharp tools on the
projector such as a knife or ham-
mer, because this may damage the
casing.
In the event that no image appears
on the screen, please switch off the
projector, unplug it from the power
outlet and contact the LG
Electronics Service Center.
This may create a fire hazard or cause
electric shock.
Do not drop anything onto the
projector or allow anything to
impact the projector.
This may cause mechanical failure or
personal injury.

Parts and Components
7
Parts and Components
Main Unit
Control Panel
MENU Button
Selects or closes menus.
AUTO button
Adjusts the picture position and minimizes image
shaking.
INPUT button
Selects the input mode.
LENS SHIFT dial
Move the screen image up or down.
∧/∨/＜/＞ button
Adjusts functions of menus.
◉ OK button
Checks present mode and
saves function changes.
Top Filter Cover
* Be careful not to block the filter cover while
the projector is in use.
A sensor receiving the remote control signal.
Camera Sensor
* This is used to operate the Camera Calibration
function.
Air vents
* Do not close the air vents while the projector is
in use. The projector may be shut down.
Lens, Lens Cap
* Be sure to open the lens cap before using the projector.
* Do not touch the lens while the projector is in use.
Slide Door
Focus ring
Zoom ring

Parts and Components
8
Back
HDMI IN 1 HDMI IN 2 RGB IN RS-232C LAN
USB(SVC ONLY) COMPONENT IN VIDEO
Y
PBPR
USB (SVC ONLY) port
COMPONENT IN port
AC IN port
VIDEO IN port
HDMI IN 1,2 port
RGB port
RS232C port
LAN port
A sensor receiving the remote control signal.
* Be careful not to block the sensor receiving the remote control signal.

Parts and Components
9
Name of remote control buttons
How to insert a battery
ꔈOpen the lid at the back of the remote control and insert batteries as described
by the ＋－ instructions.
ꔈUse new batteries of the same kind (1.5V AAA).
O#2U
ᯝ
3$77(51
VOHHS
5$7,2
/,*+7,1*
.(<6
6G#RSWLRQ
SLFWXUH
9,'(2 &203 5*%
+'0, +'0, 
EDFN
ᯜ
3D
POWER
Turns the projector on or off.
INPUT
Changes the input source.
3D
Accesses the 3D mode.
L/R
Exchanges Left / Right picture in 3D mode.
PATTERN
Adjust screen pattern.
KEY.S
Adjusts Keystone.
BLANK
Turns the projector screen
LIGHTING
Illuminates the remote control buttons.
RATIO
Resizes an image.
SLEEP
Sets the length of time until the projector to turns off.
MENU
Accesses the menu.
AUTO
Automatically adjusts the input from a computer.
Q.MENU
Accesses the quick menu.
3D OPTION
Adjusts 3D option.
Navigation buttons(up/down/left/right)
Scrolls through menus or options.
OK
Selects menus or options and confirms your input.
Adjusts Keystone. Change the image mode.
STILL
Freeze the moving image.
(Functions as the STILL button in any mode other than DivX.)
BACK
Returns to the previous level.
Control buttons
These access special functions in some menus.

10
Parts and Components
Projector Status Indicators
* |Lamp indicator, operation indicator and temperature indicator at the top of the projector show the user the operating status of the
projector.
Display
Blue Standby.
Green (Blinking) On
Green The projector is in use.
Cyan (Blinking) Power off (It takes about 90 seconds for the lamp to switch off completely.).
Temperature
Red (Blinking) An error has occurred in the internal cooling fan.
Yellow High temperature warning.
Yellow (Blinking) The projector is automatically turned off due to excessive heat.
Lamp
Magenta The lamp is reaching the end of its life and needs to be replaced with a new
lamp.
Magenta (Blinking) An error has occurred in the lamp.
Red The lamp cover is open.
Air vent Cyan An error has occurred in the air vent.
Filter Blue (Blinking) The filter cover is open.
Operation indicator
Temperature indicator
Lamp indicator
Top filter cover lock
Power Button
Turns the projector On/Off.
