1
1. B EFORE YOU START
Thank you for choosing a 3D perception C OMPACT V IEW SX+40 projector.
1.1 Accessories
Please take a few minutes to ensure that your C OMPACT V IEW SX+40 projector pack contains all
the necessary parts as listed on the Accessories Page.
1.2 Cables
Please take a few minutes to make sure that your C OMPACT V IEW SX+40 projector pack contains
all the necessary cables, as listed on the Accessories Page.
1.3 Other accessories
Please refer to our website at www.3d-perception.com

3D perception C OMPACT V IEW SX+40
User Manual
2
2. A CCESSORIES
C OMPACT V IEW SX+40 P ROJECTOR R EMOTE C ONTROL AND BATTERIES
M ODELS : SX+40I
SX+40E
C ABLE COVER
A IRFLOW COVER
User Manual
Cables
VGA male Blue - VGA male Blue, 2m
DVI-I male White - DVI–I male White, 2m
A/V Cable 3 x Phono – Phono + 3,3mm stereo jack, 2m
S-Video Mini DIN 4 pin male - Mini DIN 4 pin male, 2m
Sound Cable 3,5mm stereo jack - 3,5mm stereo jack, 2m
USB A – USB B, 2m
Communication Cable 6’ spiral with RJ12 connectors
Power cord, 3m

3D perception C OMPACT V IEW SX+40
User Manual
3
3. I NTRODUCTION
The C OMPACT V IEW SX+40 projector is the ultimate in high-resolution projectors when projection
on to flat, curved or double curved screens with multiple projectors is the requirement.
The C OMPACT V IEW SX+40 projector is compatible with most data and video sources, both
analogue and digital, and provides the user with outstanding features such as:
•1400x1050 pixel SXGA+ DLP™ technology. Single chip DMD™ with DarkChip2™
technology by Texas Instruments®
•BrilliantColour™ technologly for saturated and accurate colours•
•High resolution
•High brightness
•High contrast
•Geometry correction functionality
•Edge blending functionality
•Faroudja DCDi™
•Lamp ECO mode
•Variable lamp power
•Multiple lens options
•Six video and graphics inputs
•Compact, low weight
•Low noise
•Desktop and ceiling-mountable with rear protection.
This user guide contains important information about safety precautions and the set-up and use
of the projector.
Please read the manual carefully before you operate the projector.
The specifications and functionality of the product may change without prior notice.

3D perception C OMPACT V IEW SX+40
User Manual
4
4. S AFETY & W ARNINGS
This user manual contains important information regarding safety precautions and the set-up
and use of the projector. Please read the manual carefully before you operate the projector.
4.1 Safety
This device complies with relevant safety regulations for data processing equipment for use in
an office environment. Before using the projector for the first time, please read the safety and
warning instructions thoroughly.
4.2 Warnings
Always use 3-prong power cord to ensure proper grounding of the unit. Never use 2-prong
power cords, this is dangerous and could lead to electrical shock.
Never open the unit. The projector contains no user serviceable parts. Refer all repairs to
qualified personnel only.
Make sure that no objects enter into the vents and openings of the unit.
Do not spill any liquids on the projector or into the vents or openings of the unit.
Always remove the lens cap before switching on the projector. If the lens cap is not removed, it
may melt due to the high energy light emitted through the lens. Melting the lens cap may
permanently damage the surface of the projection lens.
Do not look into the projection lens when the projector is switched on. The strong light may
permanently damage your eyesight.
Do not look into the laser beam when activated on the remote control. Laser light may
permanently damage your eyesight.
Do not point the laser beam at people.
Only place the projector on a stable surface, or mount it securely using an approved ceiling-
mount.
Do not drop the projector.
Always allow sufficient airflow through the projector. Never block any of the air vents. Never
cover the unit in any way while it is operation. Allow sufficient distance to walls and ceilings in
order to avoid overheating. Minimum safety distance to any side of the unit is 50 cm (20") in any
direction.
CAUTION! Hot air is exhausted from the side vent. Do not place objects that are sensitive to
heat nearer than 50cm (20") to the exhaust vent.

3D perception C OMPACT V IEW SX+40
User Manual
5
The projector is designed for indoor use only. Never operate the unit outdoors.
Do not operate the projector outside its temperature and humidity specifications, as this may
result in overheating and malfunctioning.
Operating the projector in a dusty environment may reduce performance or damage projector.
Only connect the projector to signal sources and voltages as described in the technical
specification chapter. Connecting to unspecified signal sources or voltages may lead to
malfunction and permanent damage of the unit.
Allow the unit to cool down for 60 minutes before lamp change.
4.3 Mercury Vapour
The following information and warnings about potential health issues relate to mercury vapour.
This projector is using an extremely bright UHP™ lamp for illumination to attain the desired high
brightness image.
This technology is similar to other high-pressure discharge lamps that are extensively used in
cars, street lights and other lighting appliances today. These lamps, like fluorescent lighting,
contain small amounts of mercury. The amount of mercury present in a lamp is far below the
limits of danger set by the authorities.
It is very important that lamps containing mercury are treated properly to minimize potential
health hazards.
The UHP™ lamp, like any other high brightness projector lamp, is under high-pressure when
operating. While the lamp and the projector are carefully designed to minimize the probability of
lamp rupture, the lamp may break while operating and small amounts of mercury vapor may be
emitted from the projector. The probability of rupture increases when the lamp reaches its
nominal life. It is therefore highly recommended that the lamp is replaced when the rated lifetime
is reached.
As a general precaution, secure good ventilation in the room when operating the projector. If
lamp rupture occurs, evacuate the room and secure good ventilation. Children and pregnant
women in particular should leave the room.
When replacing a worn lamp, dispose of the used lamp carefully by proper recycling.
Mercury is a naturally occurring, stable metallic element that may pose a safety risk to people
under certain conditions. According to the Public Health Statement for Mercury published by the
Agency for Toxic Substances and Disease Registry (“ATSDR”, part of the United States
Public Health Service), the brain, central nervous system and kidneys are sensitive to the
effects of mercury, and permanent damage can occur at sufficiently high levels of exposure.

3D perception C OMPACT V IEW SX+40
User Manual
6
Acute exposure to high concentrations of mercury vapor can cause conditions such as lung and
airway irritation, tightness in the chest, a burning sensation in the lungs, coughing, nausea,
vomiting and diarrhea. Children and fetuses are particularly sensitive to the harmful effects of
metallic mercury to the nervous system.
Seek medical attention if any of the above symptoms are experienced or if other unusual
conditions are experienced following lamp rupture.
4.4 Remote Control Warning
Laser radiation class II product; wavelength 670nm; maximum output 1mW.
Remote control complies with applicable requirements of 21 CFR 1040.10 and 1040.11.
Remote control complies with applicable requirements of EN 60 825-1: 1994 + A11

3D perception C OMPACT V IEW SX+40
User Manual
7
5. B EFORE S ET - UP AND U SE
Be sure you have read the Safety and Warnings chapter in this manual before proceeding with
the set-up and use of the C OMPACT V IEW SX+40 projector.
Unpack the supplied parts and familiarize yourself with the various components.
Remove the lens cap from the projection lens. If you switch the projector on with the lens cap in
place, the lens cap may melt, damaging not only the lens cap itself, but also the projection lens
and surrounding parts.

3D perception C OMPACT V IEW SX+40
User Manual
8
6. O VERVIEW
A. Focus ring H. Lamp house
B. Zoom ring (optional lens) I. Adjustable foot
C. IR sensor J. Foot release
D. Ventilation K. Security lock
E. Keypad L. Ceiling Mount
F. Connector panel M. Control Chain In (only on I models)
G.
Power connector
N.
Control Chain Out (only on I models)

3D perception C OMPACT V IEW SX+40
User Manual
9
7. K EYPAD
POWER
Switch the projector on and off.
AUTO
Automatically detect and synchronize to the signal source selected.
MENU
Activate the menu system. Use the four arrow keys to navigate and to activate.
SELECT/KEYSTONE
Select menu option when the menu system is activated. When the menu system is not in use
the menu button will activate the keystone correction. Use the four arrow keys to adjust
horizontally and vertically.
VOLUME +/-
Use these two arrow keys to adjust the volume when the keystone correction and the menu
system are not activated.
SOURCE
Use these two arrow keys to select the source when the keystone correction and the menu
system are not activated.
STATUS
This is not a key. The LED indicates the current projector status. See chapter Status for details.

3D perception C OMPACT V IEW SX+40
User Manual
10
8. S TATUS
GREEN LIGHT
A permanent GREEN light indicates the
projector is turned on
YELLOW LIGHT
A permanent YELLOW light indicates the
projector is either switched off or is in stand-by
mode.
YELLOW LIGHT FLASHING
A flashing yellow light indicates wait. The
yellow light will flash for a period of 10 -15
seconds after the power cord is connected and
for a period of 45 seconds after the projector
has been turned off.
RED LIGHT
A permanent RED light indicates it is time to
change the projection lamp. It may also
indicate faulty lamp power. Failure to change
the lamp may lead to the lamp exploding.
RED LIGHT FLASHING
A flashing RED light indicates the projector is
overheated. Turn the projector off immediately.
Check if any air inlets are covered or if the
ambient temperature is outside specifications.
It may also indicate that one of the fans is not
turning due to physical damage or blockage.
Do not remove the power cord.

3D perception C OMPACT V IEW SX+40
User Manual
11
9. R EMOTE C ONTROL
The remote control allows flexible access to the projector settings, either through direct keys, or
through the menu system. The remote control can be used to emulate the computer mouse
through the USB interface.
POWER
Switches the projector between on and standby modes.
AUTO
Adjusting the projector to display a correct image,
including position, width, height, contrast, brightness
and overall stability.
OSD
Toggle On Screen Display (OSD) feedback on and off.
When on, all user commands are echoed on screen.
When off, user commands will not be echoed on
screen.
INFO
Displays source and projector status on screen.
VIDEO
Selects the composite video input as signal source
S-VIDEO
Selects the super video input as signal source
YPbPr
Selects component video input
DVI
Selects the DVI input
VGA 1
Selects the VGA 1 input
VGA 2
Selects the VGA 2 input
STILL
Toggles between live and still (frozen) image
AV MUTE
Toggles between live and no (muted) sound

3D perception C OMPACT V IEW SX+40
User Manual
12
BRIGHT
Adjusts image brightness from dark to bright
CONTRAST
Adjusts the image contrast from soft to hard
COLOR
Adjusts the color of the image from pale to saturated
VOLUME
Adjusts the sound volume
ASPECT
Cycles through the aspect ratios available with the
current source
MENU
Toggles the menu system on and off
TRACKBALL
When USB cable is connected between PC and
projector, the trackball is used to move the mouse
pointer when not in the menu. Use the trackball to
navigate between options when in the menu.
LEFT/SELECT
Use as mouse LEFT key when not in the menu. Use as
SELECT key when in the menu
RIGHT
Use as mouse RIGHT key
LASER
Activates the built-in laser pointer.
CAUTION! Do not point laser beam at people. Do not
stare into laser beam.
ARROW KEYS
Use the four arrow keys as alternatives to the trackball
for menu navigation
SELECT
Select option in menu. Same function as
LEFT/SELECT above.

3D perception C OMPACT V IEW SX+40
User Manual
13
10. C ONNECTOR P ANEL
A. Component video In (YPbPr). Used for
high quality video reproduction.
B. Super video In. Used for improved
quality video.
C. Composite video In. Used for standard
video quality.
D. DVI - Digital RGB. For a low noise
computer and video image.
E. Monitor VGA out: Allows for connection
to local VGA monitor or daisy-chaining of
several projectors using VGA. Works with
VGA inputs only.
F. VGA - Analogue RGB In (x 2). The
standard analogue computer graphics
interface.
G. RS 232 control in. Allows for wired
remote control and monitoring of many
projector functions used in installation
environments.
H. RS 232 control Out. The secondary output
connector allows for daisy-chaining, enabling
both individual and global control and
monitoring of multiple projectors.
J. Audio Out. Connection to external audio
system.
K. RC In. Allows connection of external IR
receiver or wired remote control.
L. Audio In (x 2). Allows for the connection of
up to two audio sources simultaneously.
M. USB interface. Allows for computer
mouse control.
N. LAN. Provides access to control and
monitoring over a Local Area Network
O. Mains power connector

3D perception C OMPACT V IEW SX+40
User Manual
14
11. S ET - UP
Before any set-up, switch off all equipment.
11.1 Set-up computer
The projector may be connected to up to three computer sources simultaneously, using the
VGA and DVI inputs.
The VGA interface is analog and may cause some noise in the projected image, depending on
the signal quality from the VGA graphics card in the computer and cabling.
The DVI (Digital Visual Interface) interface is all digital and will yield a projected image with very
low noise.
Connect the USB cable to allow for remote mouse control.
Connect the power cord.
Connect the RS232 interface to allow for individual or global control of multiple units in a daisy
chain configuration.
Connect the LAN connector for individual control and monitoring of multiple projectors over
LAN.

3D perception C OMPACT V IEW SX+40
User Manual
15
11.2 Set-up Video
Three video sources may be connected, using the YPbPr (component), S-VIDEO (super video)
and VIDEO (composite video) inputs.
Component video will display more detailed images. Composite video yields images with less
detail.
In addition, the DVI-D input can be used with video sources (DVD player fitted with an HDCPTM
compliant DVI or HDMI connector) for a pure digital connection.
Connect the power cord.
