3idee smsng-s24d User manual

www.3idee.eu
smsng-s24d VESA adapter
Assembly instructions
The VESA adapter is compatible with the following Samsung products
(samsung.com):
S24D590PL
The VESA adapter allows you to conveniently mount your SAMSUNG brand monitor
to a monitor arm with a VESA hole pattern (75 x 75mm). Use the included screws
and nuts.
If you want to mount your VESA adapter directly to the wall, use suitable screws
and dowels (not included).

2
Assembly instructions
Important Safeguards
Please read these instructions carefully and keep them for future reference.
If you pass the product on to third parties, these instructions should also
always be given. Failure to follow these instructions may result in injury or
damage to people and the product, for which we cannot accept any liability.
IMPORTANT - KEEP FOR FUTURE REFERENCE.
- Use of this product should always be in accordance with the specified safety instructions.
- Do not exceed the maximum weight of the compatible monitor models or serious injury or property
damage may result.
- Observe the maximum ambient temperature of 35°C when using the product.
- Do not mount the VESA adapter near a heat source or under direct sunlight as this may heat up the
adapter.
- Check whether your mounting point (e.g. monitor arm) can withstand the weight of the monitor with
VESA adapter.
- The product is designed exclusively for mounting with a hole pattern of 75x75 mm.
- After installing the VESA adapter, the position of the monitor must be readjusted to ensure proper
ergonomics.
⚠ CAUTION
Make sure that the device is switched off and disconnected from the power supply before
installation to avoid possible injury or damage.
1. Before First Use
Check the product carefully for possible transport damage and for the absence of accessories, such as
screws, which should be included in the scope of delivery.
⚠ CAUTION
Make sure that packaging materials and small screws and parts contained therein are
inaccessible to children to minimize the risk of choking and other risks.
2. Maintenance and Cleaning
2.1 Maintenance
- It is recommended to check every three months that all screws are still tight. Also, regularly check the
condition of all components of the product.
- Store the product in a cool and safe place, ideally at a maximum storage temperature of 40°C. For
additional safety, keep the product away from children and preferably in its original packaging.
- Avoid any vibrations and shocks so as not to affect the life and functionality of the product.
2.2 Cleaning

3Assembly instructions
- No corrosive or hot cleaning agents should be used to clean the product. Likewise, wire brushes, metal
or other sharp materials are unsuitable for cleaning and should not be used.
- For gentle and effective cleaning, the use of a soft, damp cloth is recommended.
3. Waste Disposal
For the disposal of this product we recommend to contact the responsible local authorities or disposal
services. They can provide you with detailed information on available disposal options and recycling
centers in your area.
4. Manufacturer Information
3idee Technologies S.à r.l.
5 Um Lenster Bierg
L-6125 Junglinster
Luxembourg
5. Help and Feedback
If you need help with your article, we are here for you. We also appreciate any feedback.
https://help.3idee.eu/en/contact

4
Assembly instructions
Scope of Delivery Accessories
4x M4x14 screw with cross recess
(SP2)

5Assembly instructions
Horizontal / Vertical Alignment
Please note: Not all VESA adapters and monitors are designed for vertical (upright) orientation. This
limitation is often due to the specific geometry of the adapter or monitor. Do not ignore this information,
as the load limit of the adapter can quickly be exceeded if not installed properly.
We are continuously working on developing monitors and adapters that are also suitable for vertical
orientation.
However, monitors are designed for horizontal alignment by default.
Horizontal
Mounting: YES
Vertical
Mounting: NO

6
Assembly instructions
Assembly Instruction
Step 1
Figure 1
Place your SAMSUNG monitor securely on a soft surface.
Now remove the base of your SAMSUNG monitor if it is
attached.
To do this, pull firmly on the base of your monitor and press
it left and right at the same time.
(Figure 1)
Step 2
Figure 2
Mount the VESA adapter to your monitor arm using the
supplied screw.
(Figure 2)
Step 3
Figure 3
This is how the 3idee VESA adapter should look after it is
attached to your monitor arm. (Figure 3)
Step 4
Figure 4
Now insert your monitor into the VESA adapter from above
while holding your monitor arm from below. (Figure 4)

7Assembly instructions
Step 5
Figure 5
This is how the correctly mounted VESA adapter looks on
your monitor now. (Figure 5)
Step 6
Figure 6
Done!
Make sure that the VESA adapter comes off when you
pull the monitor up. This is because the monitor is
designed to remove the original Samsung monitor
base (Figure 6).
