Thank you for using our product.
1. This is user's manual for H.264 HD DVR (Digital Video Recorder).
2. This manual contains product specification and introduction, installation guide,
operating guide and other necessary matters for easy understanding. Users should
read this user's manual carefully for proper use.
3. Contents in this manual may be changed according to the specification change and
f t i t ith t tifi ti
f
ea
t
ure
i
mprovemen
t
w
ith
ou
t
any no
tifi
ca
ti
on.
4. This user's manual shall never be copied without prior agreement and violating this
may be a reason for legal punishment on piracy.
5. If there is any incorrect or insufficient content in this user's manual, notify it to
Customer Support Center.
2

Contents
CONTENTS
CH 1. Product Introduction
1-1. Product Contents 5
1-2. Specifications 7
1-3. Product Characteristics 8
1-4. Name of Each Part 11
CH 2. Installation Guide and Cautions
2-1. Cautions 17
2-2. Product Installation 20
2-2-1. Power Connection 20
2
2
2 Connecting External Device
20
2
-
2
-
2
.
Connecting
External
Device
20
CH 3. How to Use
3-1. General Usage Information 23
3-2. Live Mode 24
3
2
1
Li d t l
24
3
-
2
-
1
.
Li
ve mo
d
e con
t
ro
l
24
3-2-2. Live mode feature 26
3-3. Search Mode 31
3-3-1. Search selection type 31
3-3-2. Play mode 35
3
-
4
Se
tup Mode
36
3
-
4
.
Se
tup
Mode
36
3-4-1. Display 36
3-4-2. Record 38
3-4-3. Device 43
3-4-4. Network 50
3-4-5. System 53
3
-
5. Firmware Upgrade
56
3
3
5.
Firmware
Upgrade
56

Contents
CONTENTS
Warranty 59
Trouble Shooting 60
A
pp
endix
A
Connectin
g
usin
g
Web browser 61
pp
gg
Appendix B Catcheye for Android mobile 64
Appendix C Catcheye for iPhone 70
Appendix D How to Connect POS 76
Appendix E How to Connect xbox1 78
4

CH1. Product Introduction
CH 1 Product Introduction
1-1. Product Contents(EYEON 04/04+/08)
After removing packing materials of this product, check whether all following
contents are included.
Main Body (DVR):
This converts the analog video and audio signal
to the digital signal and saves on HDD.
Adapter:
This 12V ada
p
ter su
pp
lies
p
ower to the
p
roduct.
pppp p
Power Cable:
This connect the adapter and the power source.
Pro
g
ram CD:
g
This contains the User’s manual and Client
Program for DVR.
Remote Controller:
This is an IR remote controller for convenience.
Battery:
These are 2(two) battery for the remote controller.
5

1-1. Product Contents(EYEON 08R/16R/16R+)
CH 1 Product Introduction
After removing packing materials of this product, check whether all following
contents are included.
Main Body (DVR):
This converts the analog video and audio signal
to the digital signal and saves on HDD.
Adapter:
Thi 12V d t li t th d t
Thi
s
12V
a
d
ap
t
er supp
li
es power
t
o
th
e pro
d
uc
t
.
Power Cable:
This connect the adapter and the power source.
PCD
P
rogram
CD
:
This contains the User’s manual and Client
Program for DVR.
Remote Controller:
This is an IR remote controller for convenience.
Battery:
These are 2(two) battery for the remote controller.
6

1-2. Specifications
CH 1 Product Introduction
EYEON S i
Model
EYEON
S
er
i
es
EYEON 4 EYEON 4+ EYEON 8 EYEON 8R EYEON 16R EYEON 16R+
Compact case 19” rack type
Video
Camera input 4 BNC 4 BNC 8 BNC 8 BNC 16 BNC 16 BNC
Individual HD/Analog selecta
ble SDI only All Hybrid(Patent Pending)
Available source 720p25,30,50,60/1080p25,30,50,60/1080i50,60/Composite/960H/Mixed
Output 1 HDMI+1 VGA (simultaneously) / 1 Programmable SPOT with OSD
Audio Audio input 4 RCA 8 RCA 16 RCA
Output 1 RCA
Sensor In 4 (NC, NO selectable) 8(NC, NO sele
ctable) 16(NC, NO selectable)
Alarm out 1 relay 6 TTL, 2 relay 14 TTL, 2 relay
Operating System Embedded Linux OS
Speed
Real Time
Display
Speed
Real
Time
Resolution (Pixel) 1280X1024, 1280X720, 1920X1080
Split screen 1,4 1,4 1,4,8 1,4,8 1,4,6,8,9,13,16
Recording
CODEC H.264 / JPEG for 3G, Dual CODEC
Resolution (Pixel) 720p, 1080p,1080i, 960H, 720H, Mixed
Picture quality 4 steps (Super, High, Medium, Low)
Speed NTSC area
PAL area
120fps@1080p
100fps@1080p
120fps@1080p
100fps@1080p
240fps@1080p
200fps@1080p
240fps@1080p
200fps@1080p
480fps@1080p
400fps@1080p
480fps@1080p
400fps@1080p
PAL
area
100fps@1080p
100fps@1080p
200fps@1080p
200fps@1080p
400fps@1080p
400fps@1080p
Playback
Display 1,4 1,4 1,4,8 1,4,8 1,4,6,8,9,13,16
Search mode Calendar, Event ,POS , Panorama, Thumbnail
Speed NTSC area
PAL area
60fps@1080p
100fps@1080p
60fps@1080p
100fps@1080p
120fps@1080p
200fps@1080p
120fps@1080p
200fps@1080p
120fps@1080p
200fps@1080p
480fps@1080p
400fps@1080p
Fast/Slow speed Normal, REW & FF [recorded speed x2, x4, x8, x16,x32,x64,x1/2,x1/4], Frame to frame, P
ause
Network
Network Interface Gigabit Ethernet
Speed 15fps@1080p 60fps@1080p 120fps@1080p
Protocol TCP/IP, HTTP, DHCP
Application Windows 2000 / XP / Vista / 7 / 8 (PC Client system& IE)/MAC
Web Browser Internet Explorer
Smart phone App Android, iPhone for live and search
Interface USB 2.0 X 2 USB 2.0 X 3
7
Backup Backup device External HDD, CD&DVD-RW, Network, Thumb Drive
The number of HDD 2 SATA(No capacity limit ; 4TB of more) 4 SATA + 1 eSATA(upto 12 bays, No capaci
ty limit ; 4TB or more)

1-2. Specifications(Continued)
CH 1 Product Introduction
EYEON S i
Model
EYEON
S
er
i
es
EYEON 4 EYEON 4+ EYEON 8 EYEON 8R EYEON 16R EYEON 16R+
Compact case 19” rack type
•Full GUI with alpha blending
•Individual setting of resolution, frame rates and picture quality
•Instant Replay
•Digital Zoom
•Mouse Control
•Weekly scheduler with holiday by 10 minutes setting
•Covert, Disable and Private function of cameras
•Motion Detection with 352 area setting
•Relay alarm output
•
PTZ control by RS
-
485
Function
PTZ
control
by
RS
485
•Daylight Saving Time and Network Time Setting
•Multi User Authority up to 8 Users
•Deinterlacer upon live and playback
•17 languages with full graphic
•Individual Network port setting
•Auto Deletion
•Import and Export the configuration
•Mirroring
•POS Interface
•Dual CODEC engine for independent video transmission
•Interactive setup via network
Others
Power Consumption 60W 150W
Operating Temperature 5 ~40℃(41~104F)
Relative Humidity Maximum 80% non-condensing
Dimension 340(W)×250(D)×60(H) mm 430(W)×420(D)×88(H)
8

1-3. Product Characteristics
1
)
Full HD real time and All H
y
brid
CH 1 Product Introduction
)
y
This DVR can record HD and Full HD video with extreme quality. Also it displays
real HD(1920X1080) resolution, and therefore it provides the most clear image
quality and the best security level. Furthermore, EYEON series can mix any input
such as analog, 960H and HD-SDI. All video input is detected automatically. (Patent)
2) High reliability
With Embedded hardware and software design, this maintains higher product
r
eliability
r
eliability
.
3) Simple usage
This allows users to use it conveniently by placing control buttons similar to existing
ones on VCR, and users can easily learn the usage.
4) Pentaplex System
Pentaplex System allows live, recording, backup, networking and playback
simultaneously
simultaneously
.
5) Selectable recording setup
For recording methods, users can select the frame rate, resolution and video quality
individually in order to be appropriate for user's environment.
6) Remote monitoring
With using exclusive line or Internet network, you can search or monitor recorded
im
a
ges remotely by installing exclusive client program on
Windows PC or Mac
im
a
ges
remotely
by
installing
exclusive
client
program
on
Windows
PC
or
Mac
.
7) Backup
You can backup with a versitile external USB devices.
8) Audio recording
You can record 4 sound inputs simultaneously. Moreover, you can listen to the
sound in search and live monitoring and play mode.
9) Various recording methods
This provides convenient use with manual recording, recording by dates and days,
hourly schedule recording, sensor and motion detection event recording and others to
enable unmanned monitoring.
10) Various total monitoring features
You can cover any security scenario through various sensor inputs and contact output
l
9
contro
l
.

11) Display information in easy-to-understand information method
Thi h d i f b di l i i f ti (d t ti di
CH 1 Product Introduction
Thi
s en
h
ance
d
conven
i
ence o
f
user
b
y
di
sp
l
ay
i
ng
i
n
f
orma
ti
on
(d
a
t
e,
ti
me, recor
di
ng
method, recording frame number, HDD capacity and others) in monitoring, recording
and playing mode in easy-to-understand way.
12) P/T/Z control
By built in RS485, various P/T/Z cameras can be used.
13) Dual CODEC for video transmission
d f (b d ) dl f h l l di d i i
DVR can sen
d
120
f
ps
(b
ase
d
on CIF
)
regar
dl
ess o
f
t
h
e
l
oca
l
recor
di
ng an
d
v
i
ew
i
ng
setup regardless with recording setup.
14) Web browser support
You can monitor and playback the video and control the PTZ camera by internet
explorer.
15) Built in S.M.A.R.T.
You can automatically check the health of the hard disk drives.
16) Language pack
Basically DVR has multiple language set, furthermore you can choose the language
set if you want.
17) Mirroring by internal HDD
If you install two HDDs, you can use the second HDD for backup for maximum
fault tolerance.
18) Spot monitoring
Spot out can be enable to monitor sequentially in other place.
19) Touch LED Switch
You can operate with touch LED switch in front panel.
20) Text inserter(POS Interface)
You can operate with the POS and ATM.
