4B USR1V4 User manual

INSTRUCTION
MANUAL
REV121723
Approvals
Speed Relay
Digital Speed Monitor
Part Number: USR1V4, USR1V46

EN
To download the digital version of this instruction manual and to check
other available languages scan the following QR code.
ES
Para descargar la versión digital de este manual de instrucciones y
consultar otros idiomas disponibles, escanee el siguiente código QR.
PT
Para baixar a versão digital deste manual de instruções e verificar outros
idiomas disponíveis, escaneie o seguinte código QR.
FR
Pour télécharger la version numérique de ce manuel d’instructions et pour
vérifier les autres langues disponibles, scannez le code QR suivant.
DE
Um die digitale Version dieser Bedienungsanleitung herunterzuladen und
andere verfügbare Sprachen zu überprüfen, scannen Sie den folgenden
QR-Code.
RU
Чтобы загрузить цифровую версию данного руководства по
эксплуатации и проверить другие доступные языки, отсканируйте
следующий QR-код.
ZH
要下載本說明手冊的數字版本並查看其他可用語言，請掃描以下
二維碼。

4of 31
TABLE OF CONTENTS
CUSTOMER SAFETY RESPONSIBILITIES .......................................................................5
PRODUCT OVERVIEW......................................................................................................8
PACKAGE CONTENT .......................................................................................................8
SPECIFICATIONS .............................................................................................................9
APPROVALS...................................................................................................................10
DIMENSIONS .................................................................................................................10
CONDITIONS OF USE.....................................................................................................11
STANDARD WIRING DIAGRAM .....................................................................................11
INSTALLATION ..............................................................................................................15
GRAPHICAL USER INTERFACE .....................................................................................16
PRODUCT WARRANTY ..................................................................................................30

5of 31
CUSTOMER SAFETY RESPONSIBILITIES
4B appreciates your business and is pleased you have chosen our products to meet
your needs.
Please read in its entirety and understand the literature accompanying the product
before you place the product into service. Please read the safety precautions carefully
before operating the product. With each product you purchase from 4B, there are
some basic but important safety considerations you must follow to be sure your
purchase is permitted to perform its design function and operate properly and safely,
giving you many years of reliable service. Please read and understand the Customer
Safety Responsibilities listed below. Failure to follow this safety directive and the
Operation Manuals and other material furnished or referenced, may result in serious
injury or death.
SAFETY NOTICE TO OUR CUSTOMERS
A. In order to maximize efficiency and safety, selecting the right equipment for
each operation is vital. The proper installation of the equipment, and regular
maintenance and inspection is equally important in continuing the proper
operation and safety of the product. The proper installation and maintenance
of all our products is the responsibility of the user unless you have asked 4B to
perform these tasks.
B. All installation and wiring must be in accordance with Local and National
Electrical Codes and other standards applicable to your industry. (Please see
the article “Hazard Monitoring Equipment Selection, Installation and
Maintenance” at www.go4b.com/usa). The installation of the wiring should be
undertaken by an experienced and qualified professional electrician. Failure to
correctly wire any product and/or machinery can result in the product or
machine failing to operate as intended, and can defeat its design function.
C. Periodic inspection by a qualified person will help assure your 4B product is
performing properly. 4B recommends a documented inspection at least
annually and more frequently under high use conditions.
D. Please see the last page of this manual for all warranty information regarding
this product.
CUSTOMER SAFETY RESPONSIBILITIES
1. READ ALL LITERATURE PROVIDED WITH YOUR PRODUCT
Please read all user, instruction and safety manuals to ensure that you understand
your product operation and are able to safely and effectively use this product. If the

6of 31
equipment is used in a manner not specified in this manual, the protection provided
by the equipment may be impaired.
2. YOU BEST UNDERSTAND YOUR NEEDS
Every customer and operation is unique, and only you best know the specific needs
and capabilities of your operation. Please call the 24-hour hotline at 309-698-5611
for assistance with any questions about the performance of products purchased from
4B. 4B is happy to discuss product performance with you at any time.
3. SELECT A QUALIFIED AND COMPETENT INSTALLER
Correct installation of the product is important for safety and performance. If you
have not asked 4B to perform the installation of the unit on your behalf, it is critical
for the safety of your operation and those who may perform work on your operation
that you select a qualified and competent electrical installer to undertake the
installation. The product must be installed properly to perform its designed functions.
The installer should be qualified, trained, and competent to perform the installation in
accordance with Local and National Electrical Codes, all relevant OSHA Regulations,
as well as any of your own standards and preventive maintenance requirements, and
other product installation information supplied with the product. You should be
prepared to provide the installer with all necessary installation information to assist
in the installation.
4. ESTABLISH AND FOLLOW A REGULAR MAINTENANCE AND INSPECTION
SCHEDULE FOR YOUR 4B PRODUCTS
You should develop a proper maintenance and inspection program to confirm that
your system is in good working order at all times. You will be in the best position to
determine the appropriate frequency for inspection. Many different factors known to
the user will assist you in deciding the frequency of inspection. These factors may
include but are not limited to weather conditions; construction work at the facility;
hours of operation; animal or insect infestation; and the real-world experience of
knowing how your employees perform their jobs. The personnel or person you select
to install, operate, maintain, inspect or perform any work whatsoever, should be
trained and qualified to perform these important functions. Complete and accurate
records of the maintenance and inspection process should be created and retained
by you at all times.
5. RETAIN AND REFER TO THE OPERATION MANUAL FOR 4B’S SUGGESTED
MAINTENANCE AND INSPECTION RECOMMENDATIONS
As all operations are different, please understand that your specific operation may
require additional adjustments in the maintenance and inspection process essential

7of 31
to permit the monitoring device to perform its intended function. Retain the Operation
Manual and other important maintenance and service documents provided by 4B and
have them readily available for people servicing your 4B equipment. Should you have
any questions, please call the 24-hour hotline number 309-698-5611, contact your
local distributor, or use one of the contact ways available in our website
www.go4b.com/usa.
6. SERVICE REQUEST
If you have questions or comments about the operation of your unit or require the unit
to be serviced please call the 24-hour hotline number 309-698-5611, contact your
local distributor, or use one of the ways available in our website www.go4b.com/usa.
Please have available product part numbers, serial numbers, and approximate date of
installation. In order to assist you, after the product has been placed into service,
complete the online product registration section which is accessed via our website
www.go4b.com/usa.
WARNING
Moving parts can crush and cut.
Lockout power before removing guard or servicing.
Do NOT operate with guard removed.

8of 31
PRODUCT OVERVIEW
The Speed Relay is a microprocessor controlled digital speed monitor for use with 2,
3, or 4 wire NPN/PNP sensors or Contact sensor inputs, with a user programable
electromechanical relay and PhotoMOS Solid State Relay (SSR) outputs. The Speed
Relay has a 160x80 pixel LCD display to provide information, and 3 front panel buttons
to program settings.
The Speed Relay reads input pulses and displays the calculated pulse frequency in a
range of selectable units.
The user can set the Electromechanical Relay and PhotoMOS Solid State Relay
outputs independently, with their own thresholds and output behaviors, and have the
Alarm LED indicate the state of one of the outputs. The Electromechanical Relay can
be set to trigger when the input speed is outside the chosen range. The PhotoMOS
Solid State Relay can provide a trigger output or can be configured to provide a pulsed
output that matches the input pulse frequency.
One LED (Input LED) shows input status of the sensor’s pulses, and another LED
(Alarm LED) shows the state of the assigned output.
PACKAGE CONTENT
1x Speed Relay

9of 31
SPECIFICATIONS
Supply Voltage +24VDC (+18 to +28 VDC), 80 mA MAX at 24 VDC
230 VAC (85 to 264 VAC), 50-60 Hz, 35 mA MAX at
230 VAC
Available Sensor Power 24 VDC, 100 mA when powered via mains.
(2-Wire NPN sensors powered from terminal 4 can
draw a maximum of 50mA)
Note: Make sure that the sensor used with the Speed
Relay works within the available sensor power.
Terminal Entry 2.5 mm2 / 12 AWG
C/O Relay Contacts* 30 VDC / 250 VAC, 2.5 A MAX
SSR Output Contacts** 230 V AC/DC, 100 mA
Interlock Input 18 to 28 VDC / 85 to 264 VAC
Indication 1x Red Alarm LED
1x Green Input LED
1x 160x80 LCD display
Sensor Input Frequency
Range
0.1 Hz to 1000 Hz
Max Frequency
Represented using SSR
Output
500 Hz
Pulse Ratio 1 to 1024
Operating Temperature -20 °C to 50 °C (-4 °F to 122 °F)
Dimensions 115mm(H) X 45mm(W) X 80mm(D) (4.5in x 1.8in x
3.1in)
Fixing Centres 35mm DIN rail clip
Enclosure ABS/PC
Protection IP20
Weight 200g / 0.44lb
*Terms used interchangeably: Electromechanical Relay, Relay
**Terms used interchangeably: SSR Output, Solid State Relay

10 of 31
APPROVALS
In Process
DIMENSIONS
ALL DIMENSIONS IN MM

11 of 31
CONDITIONS OF USE
1. The supply circuit of the system to which the equipment is connected shall be
protected by a suitably rated fuse capable of interrupting a prospective short
circuit current of 1.5 kA.
STANDARD WIRING DIAGRAM
All wiring must be in accordance with local and national electrical codes (e.g. NEC,
CEC, EN IEC 60079-14) and should be undertaken by an experienced and qualified
electrician.
All wiring must be in accordance with local and national electrical codes and should
be undertaken by an experienced and qualified electrician. The unit connections and
typical wiring diagrams are given in figures 6.1 to 6.10. The Relay, SSR Output and
Interlock contacts are voltage free.
USR1V46 DC wiring description
USR1V46 AC wiring description
For the USR1V4 Version, terminals 7,8, and 9 are N/C (NOT CONNECTED).

12 of 31
Terminal Description Rating
1 +VDC
Input: +18 to 28 VDC, 80 mA (50 mA for
2-wire NPN sensor)
OR
(USR1V46 Only) Output: +24 VDC, 100
mA, when powered by AC Input
2 0VDC 0 VDC
3 PNP Sensor Input Input: +18 to 28 VDC
4 NPN Sensor Input Output: +24 VDC, 50 mA
5 SSR Output A Input: 230 V AC/DC, 100 mA
6 SSR Output B
7 Earth (USR1V46 Only)
Input: 85 to 264 VAC, 50 to 60 Hz, 0.03A
at 230 VAC
8 AC Neutral
9 AC Live
10 Output Relay COM
Input: 30 VDC/250 VAC, 2.5 A MAX11 Output Relay N/C
12 Output Relay N/O
13 Interlock A Input: 18 to 28 VDC / 85 to 264 VAC
14
Interlock B

13 of 31
2-Wire sensors such as P1003V10AI and P3003V10AI
2-Wire NPN Sensor Wiring
2-Wire PNP Sensor Wiring
3-Wire sensors such as types E (NPN), E2 (PNP), and E3 (NPN/PNP) Rotech Encoders
3-Wire NPN Sensor Wiring
3-Wire PNP Sensor Wiring
4-Wire sensors such as P1003V34AI, P3003V34AI and P8001V34FC
4-Wire NPN Sensor Wiring
4-Wire PNP Sensor Wiring

14 of 31
USR1V46 Powered by AC
Speed Relay Powered by DC
The USR1V46 Speed Relay can be powered from an AC source or a DC source. If the
Speed Relay is powered via AC using terminals 7,8, and 9, then the Speed Relay
provides a +24 VDC supply from pin 1 to power a sensor which is rated for 100 mA.
A 2 wire NPN sensor can be powered from Terminal 4 which is rated for 24 VDC, 50
mA.
If the Speed Relay is powered via DC using terminals 1 and 2, then the sensor should
be powered from the same supply.
Ensure all connections are correct before applying power.
The speed relay can only operate with a single sensor at a time, do NOT attach more
than one sensor simultaneously.

15 of 31
Interlock Wiring
When the interlock setting is set to “USED” the Interlock must be connected for
outputs to trigger. When the Interlock is connected and the start-up delay has elapsed,
the symbol RUN is displayed at the top of the runtime screen.
When the interlock setting is set to “NOT USED” the state of the interlock does not
matter.
INSTALLATION
The Speed Relay should be wired as show in the connection diagrams in Electrical
Setup.
Speed Relay Mounted on 35mm DIN rail
The Speed Relay should be mounted on a 35mm DIN rail in suitable enclosure of
protection rating IP40 or above. The enclosure door should be kept locked when the
system is in operation.
Use a small flathead screwdriver to lower the hook on the rear of the Speed Relay to
install or remove the device.

16 of 31
Mounting Speed Relay with Screwdriver
GRAPHICAL USER INTERFACE
Splash Screen
Splash Screen
Description: Initial screen displayed for 4 seconds on start-up before transitioning to
the runtime screen.
Contents: Device Name, 4B Logo, Version Number.
Controls: None.

17 of 31
Runtime Screen
Runtime Screen
Description: Main screen during use. The Maximum value displayed on the screen is
99,999, or 999.9 when displaying values with decimals.
Alarm Icon (ALM) is displayed when the Alarm LED is triggered, the background also
becomes red. Stop Icon (STP) is displayed when the Relay output is triggered. Start-
up icon (SUD) is displayed during the start-up period. Run icon (RUN) is displayed in
place of start-up icon when the system has the Interlock connected and the start-up
delay has elapsed (or if the interlock is not being used).
Contents: Alarm Icon (ALM), Run Icon (RUN), Stop Icon (STP), Start-up Icon (SUD)
Speed in digits, Units.
Controls: Enter button – Transitions to the main menu.
Main Menu
Main Menu
Description: Menus used to navigate through and select settings for the speed relay.
Contents: Scroll list, Selected Item Indicator.
Controls:
Up button – scrolls the current list up one.
Down button – scrolls the current list down one.
Enter button – activates the selected option.

18 of 31
Options
Details
1.Units
Cycles through the selected unit. PPM, Hz, RPM, FPM, MPS, %
1b.Scale Value
Only displayed when Units are FPM or MPS. Transitions to the
scale value screen
1b.100%=
Only displayed when Units is %. Transitions to the Calibration
point screen
2.No. of Targets
Transitions to the Number of Targets screen
3.Start Delay
Transitions to the Start Delay Screen
4.Interlock
Toggles between USED, and NOT USED
5.RELAY
Transitions to the threshold menu for the Relay output
6.SSR OUTPUT
Transitions to the threshold menu for the SSR output.
7.ALARM LED
Transitions to the threshold menu for the alarm LED output.
8.Latching
Toggles between ON, and OFF
9.Output Delay
Transitions to the Output Delay screen
10.Save Profile
Transitions to the Save Profile Screen
11.Load Profile
Transitions to the Load Profile Screen.
12.Test Outputs
Transitions to the Test Screen
13.Manual QR
code
Transitions to the QR code screen
14.Factory Reset
Transitions to the Factory Reset Screen
15.Screen Sleep
Cycles through the screen sleep delay settings. Never, 1 minute,
5 minutes, 10 minutes, 30 minutes, 60 minutes.
16.Temp
Displays the current unit temperature.
17.Version
Displays the version number
Confirm
Saves all currently selected settings and transitions to the
runtime screen
Cancel
Discards any selected but not saved settings and transitions to
the runtime screen
NOTE: When changing units in the Units Menu, ensure the output setpoints are at the
desired values in relation to the new units.
Scale Value Screen
Scale Value
Description: The screen for setting the scale value for MPS and FPM units (i.e. the
distance 1 pulse is equal to.)
Contents: Scale title, digit selection indicator, scale value, units.

19 of 31
Controls:
Up button – Increases the selected digit by 1, to a maximum value of 99.99.
Down button – Decreases the selected digit by 1, to a minimum value of 0.
Enter button – selects the next digit or confirms the scale value and transitions back
to the menu screen if the last digit is already selected.
Calibration point Screen
Calibration point Screen
Description: The calibration point screen allows the user to select a value in PPM for
to be equal to 100% speed.
Contents: 100% Speed text, selected digit indicator, calibration point value, PPM
Controls:
Up button – increases the selected digit by 1, to a maximum PPM of 60000
Down button – decreases the selected digit by 1, to a minimum PPM of 0
Enter button – selects the next digit or confirms the calibration point and returns to
the system menu.
Number of Targets Screen
Number of Targets
Description: The screen for setting the number of targets equal to 1 pulse (i.e. the
number of input pulses it takes to register as 1 pulse.)
Contents: Screen title, digit selection indicator, number of targets.
Controls:
Up button – Increases the selected digit by 1, to a maximum of 1024.
Down button – Decreases the selected digit by 1, to a minimum of 1.

20 of 31
Enter button – selects the next digit or confirms the number of targets and
transitions to the menu screen if the last digit is already selected.
Threshold Menu
Threshold Menu
Description: The threshold menu is used to select the settings for the chosen output,
each output has its own settings.
Contents: Scroll list, selected item indicator.
Controls:
Up button – scrolls the current list up one.
Down button – scrolls the current list down one.
Enter button – activates the selected option.
Setting
Details
Option
Cycles through the selectable options for the current output.
Relay
Range
The Relay triggers outside the selected range
SSR
Output
Range
The SSR Output triggers outside the selected
range
Relay
Follow
SSR Output uses the settings for the relay
output.
Pulse
SSR Output pulses at the measured input
frequency.
Alarm
LED
Relay
follow
Alarm LED uses the same settings as used
for the relay output.
SSR
follow
Alarm LED uses the same settings as used
for the SSR output. Note: if the SSR output is
set for Pulse, the Alarm LED will be off for
this option.
Trip State
Toggles between the output states for when the output it
triggered. ENG – Energised,
D-Eng – Deenergised
Min
Minimum threshold – transitions to the setpoint screen for the
minimum threshold for the current output.
Max
Maximum threshold – transitions to the setpoint screen for the
maximum threshold for the current output.
NOTE: Min and Max will automatically sort themselves when
values are entered.
