4DSP AD484 User manual

AD484 user manual V1.2
AD484
User Manual
4DSP Inc.
955 S Virginia Street, Suite 214, Reno, NV 89502, USA
Email: [e-mail]
This document is the property of 4DSP Inc. and may not be copied nor communicated to a
third party without the written permission of 4DSP Inc.
©
4DSP
Inc. 200
7
id4651869 pdfMachine by Broadgun Software - a great PDF writer! - a great PDF creator! - http://www.pdfmachine.com http://www.broadgun.com

AD484 user manual V1.2
AD484 User manual
February 2007 www.4dsp.com - 2 -
Revision History
Date Revision Version
02-03-07 First release 1.0
03-29-07 Corrected typos 1.1
04-12-07 Added more details regarding clock synchronization 1.2

AD484 user manual V1.2
AD484 User manual
February 2007 www.4dsp.com - 3 -
Table of Contents
1 Acronyms and related documents ............................................................................. 4
1.1 Acronyms............................................................................................................... 4
1.2 Related Documents ............................................................................................... 4
1.3 General description................................................................................................ 5
2 Installation ................................................................................................................... 6
2.1 Requirements and handling instructions ................................................................ 6
2.2 Firmware and software........................................................................................... 6
3 Design .......................................................................................................................... 6
3.1 FPGA devices........................................................................................................ 6
3.1.1 Virtex-4 device A............................................................................................ 6
3.1.2 Virtex-4 device B............................................................................................ 9
3.2 FPGA devices configuration..................................................................................10
3.2.1 Flash storage ................................................................................................10
3.2.2 CPLD device.................................................................................................10
3.2.3 JTAG.............................................................................................................12
3.3 Clock tree..............................................................................................................13
3.4 Memory resources................................................................................................13
3.4.1 QDR2 SRAM.................................................................................................13
3.4.2 DDR2 SDRAM ..............................................................................................13
3.5 A/D inputs and outputs main characteristics..........................................................14
3.5.1 Analog inputs ................................................................................................15
3.5.2 Clock input and reference clock distribution ..................................................15
3.5.3 Multi-module Synchronization .......................................................................15
3.6 Front Panel optical transceivers............................................................................16
4 Power requirements ...................................................................................................17
4.1 External power connector for stand alone mode ...................................................18
5 System Side view........................................................................................................19
6 Environment................................................................................................................19
6.1 Temperature.........................................................................................................19
6.2 Convection cooling................................................................................................19
6.3 Conduction cooling ...............................................................................................19
7 Safety...........................................................................................................................19
8 EMC .............................................................................................................................20
9 Warranty......................................................................................................................20

AD484 user manual V1.2
AD484 User manual
February 2007 www.4dsp.com - 4 -
1 Acronyms and related documents
1.1 Acronyms
ADC Analog to Digital Converter
DAC Digital to Analog Converter
DCI Digitally Controlled Impedance
DDR Double Data Rate
DSP Digital Signal Processing
EPROM Erasable Programmable Read-Only Memory
FBGA Fineline Ball Grid Array
FPDP Front Panel Data Port
FPGA Field Programmable Gate Array
JTAG Join Test Action Group
LED Light Emitting Diode
LVTTL Low Voltage Transistor Logic level
LVDS Low Differential Data Signaling
LSB Least Significant Bit(s)
LVDS Low Voltage Differential Signaling
MGT Multi-Gigabit Transceiver
MSB Most Significant Bit(s)
PCB Printed Circuit Board
PCI Peripheral Component Interconnect
PCI-e PCI Express
PLL Phase Locked Loop
PMC PCI Mezzanine Card
QDR Quadruple Data rate
SDRAM Synchronous Dynamic Random Access memory
SRAM Synchronous Random Access memory
Table 1: Glossary
1.2 Related Documents
IEEE Std 1386.1-2001 : IEEE Standard Physical and Environmental Layers for PCI
Mezzanine Cards (PMC).
ANSI/VITA 32-2003 : Processor PMC.
ANSI/VITA 39-2003 : PCI-X for PMC and Processor PMC.
ANSI/VITA 42.0-2005 : XMC Switched Mezzanine Card Auxiliary Standard.
IEEE Std 1386-2001 : IEEE Standard for a Common Mezzanine Card (CMC) Family.
Xilinx Virtex-4 user guide
Xilinx PCI-X core datasheet
Xilinx Virtex-4 Rocket I/O guide

AD484 user manual V1.2
AD484 User manual
February 2007 www.4dsp.com - 5 -
1.3 General description
The AD484 is a high performance PMC/XMC digitizer module dedicated to digital signal
processing applications with high bandwidth and complex algorithms requirements. The
AD484 can interface to a PCI-express, PCI-X and/or PCI bus. In addition to four 125MSPS
A/D channels, the AD484 offers fast on-board memory resources and two Virtex-4 FPGAs.
Up to 4x 2.5Gbps optical transceivers for serial FPDP or gigabit Ethernet applications are
available for communication with external systems. The AD484 is mechanically and
electrically compliant to the standard and specifications listed in section 1.2 of this document.
The AD484 implements a comprehensive clock circuitry that allows synchronisation among
the converters and cascading modules for multiple receiver systems as well as the use of an
external reference clock. It provides a complete conversion solution and stands as a platform
that can be part of a receive base station.
Figure 1: AD484 block diagram

AD484 user manual V1.2
AD484 User manual
February 2007 www.4dsp.com - 6 -
The AD484 converts 4 analogue signals into four 14-bit resolution digital data flows with a
sampling frequency up to 125MHz. The clock source can be set to external or internal using
the software and firmware settings available to users. Please note that the clock generation
on board is using low-jitter clock synthesizers.
2 Installation
2.1 Requirements and handling instructions
The AD484 must be installed on a motherboard compliant to the IEEE Std 1386-2001
standard for 3.3V PMC or on a motherboard compliant to the XMC Switched
Mezzanine Card Auxiliary Standard
Do not flex the board
Observe SSD precautions when handling the board to prevent electrostatic
discharges.
Do not install the AD484 while the motherboard is powered up.
2.2 Firmware and software
Drivers, API libraries and a program example working in combination with a pre-programmed
firmware for both FPGAs are provided. The AD484 is delivered with an interface to the Xilinx
PCI core in the Virtex-4 device A and an example VHDL design in the Virtex-4 device B so
users can start digitizing and performing data manipulation right out of the box. For more
information about software installation and FPGA firmware, please refer the AD484 Get
Started Guide and to the Programmer’s guide available online.
3 Design
3.1 FPGA devices
The Virtex-4 FPGA devices interface to the various resources on the AD484 as shown on
Figure 1. They also interconnect to each other via 86 general purpose pins and 2 clock pins.
3.1.1 Virtex-4 device A
3.1.1.1 Virtex-4 device A family and package
The Virtex-4 device A is from the Virtex-4 FX family. It can be either an XC4VFX20 or
XC4VFX60 in a Fineline Ball Grid array with 672 balls (FF672).
3.1.1.2 Power PC embedded processor
Up to two IBM PowerPC RISC processor cores are available in the Virtex-4 device A. This
core can be used to execute C based algorithms and control the logic resources
implemented in the FPGA.
3.1.1.3 Virtex-4 device A external memory interfaces
The Virtex-4 device A is connected to a 128Mbytes SDRAM bank with a 32-bit data bus
width. This memory resource can be used by the PowerPC core or can serve as data buffer.

AD484 user manual V1.2
AD484 User manual
February 2007 www.4dsp.com - 7 -
3.1.1.4 PCI interface
The Virtex-4 device A interfaces directly to the PCI bus via the PMC Pn1, Pn2 and Pn3
connectors or to the PCI-e bus via the Pn5. An embedded PCI core from Xilinx is used to
communicate over the PCI bus with the host system on the motherboard. PCI-e 4 lanes, PCI-
X 64-bit 66MHz/133MHz, PCI 64-bit 66MHz and PCI 32-bit 33MHz are supported on the
AD484. The bus type must be communicated at the time of the order so the right Virtex-4
device A firmware can be loaded into the flash prior to delivery.
The following performances have been recorded with the AD484 transferring data on the
bus:
PCI-X 64-bit 133MHz: 750Mbytes/s sustained
PCI-X 64-bit 66MHz: 425Mbytes/s sustained
PCI 32-bit 33MHz: 112Mbytes/s sustained
The PCI-express 4-lane is using the MGT I/Os on the Virtex-4 device A. Power filtering, low
jitter clock and special routing are used to achieve the performances required by this
standard. Please refer to the Front Panel Optical transceivers section of this document for
more details (3.6).
3.1.1.5 LED
Four LEDs are connected to the Virtex-4 device A. In the default FPGA firmware, the LEDs
are driven by the Virtex-4 device B via the Virtex-4 device A/ Virtex-4 device B interface.
The LEDs are located on side 2 of the PCB in the front panel area.
Figure 2: FPGA LED locations

AD484 user manual V1.2
AD484 User manual
February 2007 www.4dsp.com - 8 -
3.1.1.6 Pn4 user I/O connector
The Pn4 connector is wired to the Virtex-4 device A. The 32 lower bits are available only if an
XC4VFX60 device is mounted on board. The 32 higher bits are available only if PCI 32-bit is
used and only if specified at the time of order.
All signals are user-defined 3.3V LVTLL./LVCMOS.
Connector
pin Signal name FPGA pin FPGA
pin Signal name Connector pin
1 Pn4_IO0 M9 M10 Pn4_IO1 2
3 Pn4_IO2 N11 M11 Pn4_IO3 4
5 Pn4_IO4 N7 N8 Pn4_IO5 6
7 Pn4_IO6 N6 P6 Pn4_IO7 8
9 Pn4_IO8 P10 P11 Pn4_IO9 10
11 Pn4_IO10 P9 N9 Pn4_IO11 12
13 Pn4_IO12 R8 P8 Pn4_IO13 14
15 Pn4_IO14 R6 R7 Pn4_IO15 16
17 Pn4_IO16 N21 M21 Pn4_IO17 18
19 Pn4_IO18 M20 M19 Pn4_IO19 20
21 Pn4_IO20 P19 N19 Pn4_IO21 22
23 Pn4_IO22 N18 N17 Pn4_IO23 24
25 Pn4_IO24 P16 N16 Pn4_IO25 26
27 Pn4_IO26 R18 P18 Pn4_IO27 28
29 Pn4_IO28 P21 P20 Pn4_IO29 30
31 Pn4_IO30 R17 R16 Pn4_IO31 32
33 Pn4_IO32 L9 M5 Pn4_IO33 34
35 Pn4_IO34 L5 AD11 Pn4_IO35 36
37 Pn4_IO36 AD10 L4 Pn4_IO37 38
39 Pn4_IO38 L3 AB11 Pn4_IO39 40
41 Pn4_IO40 AC11 M4 Pn4_IO41 42
43 Pn4_IO42 N4 T9 Pn4_IO43 44
45 Pn4_IO44 T8 P5 Pn4_IO45 46
47 Pn4_IO46 R5 AA10 Pn4_IO47 48
49 Pn4_IO48 AB10 P4 Pn4_IO49 50
51 Pn4_IO50 R3 W10 Pn4_IO51 52
53 Pn4_IO52 Y10 N3 Pn4_IO53 54
55 Pn4_IO54 P3 U6 Pn4_IO55 56
57 Pn4_IO56 U5 T4 Pn4_IO57 58
59 Pn4_IO58 T3 U7 Pn4_IO59 60
61 Pn4_IO60 V6 U4 Pn4_IO61 62
63 Pn4_IO62 V4 U9 Pn4_IO63 64
Table 2 : Pn4 pin assignment

AD484 user manual V1.2
AD484 User manual
February 2007 www.4dsp.com - 9 -
3.1.2 Virtex-4 device B
3.1.2.1 Virtex-4 device B family and package
The Virtex-4 device B is dedicated to interfacing to the A/D circuitry and can also perform
Digital Signal Processing algorithms. It is available in the Virtex-4 SX or LX family devices
and is packaged in a 1148-ball Fineline Ball Grid array. In terms of logic and dedicated DSP
resources, The FPGA B can be chosen in 5 different sizes: SX55, LX40, LX60, LX80, LX100
and LX160.
3.1.2.2 Virtex-4 device B external memory interfaces
The Virtex-4 device B interfaces to four 8Mbytes QDR2 SRAM devices with 32-bit data bus,
Please note that the four QDR2 SRAM devices are only available with the LX80, LX100 and
LX160 devices. For smaller Virtex-4 FPGAs (LX40, LX60 and SX55) only three QDR2 SRAM
devices are connected to the FPGA.

AD484 user manual V1.2
AD484 User manual
February 2007 www.4dsp.com - 10 -
3.2 FPGA devices configuration
3.2.1 Flash storage
The FPGA firmware is stored on board in a flash device. The 128Mbit device is partly
used to store the configuration for both FPGAs. In the default CPLD firmware
configuration, the Virtex-4 devices A and B are directly configured from flash if a valid
bitstream is stored in the flash for each FPGA. The flash is pre-programmed in factory
with the default firmware example for both FPGAs.
Figure 3 : Configuration circuit
3.2.2 CPLD device
As shown on Figure 2, a CPLD is present on board to interface between the flash device and
the FPGA devices. It is of type CoolRunner-II. The CPLD is used to program and read the
flash. The data stored in the flash are transferred from the host motherboard via the PCI bus
to the Virtex-4 device A and then to the CPLD that writes the required bit stream to the
storage device. A 31.25 MHz clock connects to the CPLD and is used to generate the
configuration clock sent to the FPGA devices. At power up, if the CPLD detects that an
FPGA configuration bitstream is stored in the flash for both FPGA devices, it will start reading
programming the devices in SelecMap mode.
Do NOT reprogram the CPLD without 4DSP approval
The CPLD configuration is achieved by loading with a Xilinx download cable a bitstream from
a host computer via the JTAG connector. The FPGA devices configuration can also be
performed using the JTAG.
3.2.2.1 DIP Switch
A switch (J1) is located next to the JTAG programming connector (J6) see Figure 4. The
switch positions are defined as follows:

AD484 user manual V1.2
AD484 User manual
February 2007 www.4dsp.com - 11 -
Figure 4: switch (J1) location
OFF Default setting. The Virtex-4 device A configuration is loaded from the flash at
power up.
Sw1
ON Virtex-4 device A safety configuration loaded from the flash at power up. To be
used only if the Virtex-4 device A cannot be configured or does not perform
properly with the switch in the OFF position.
Sw2 Reserved
Sw3 Reserved
Sw4 Reserved
Table 3: Switch description
3.2.2.2 LED and board status
Four LEDs connect to the CPLD and give information about the board status.
Flashing FPGA A or B bitstream or user_ROM_register is currently
being written to the flash
ON FPGA A not configured
LED 0
OFF FPGA A configured
Flashing FPGA A or B bitstream or user_ROM_register is currently
being written to the flash
ON FPGA B not configured
LED 1
OFF FPGA B configured
Flashing The Virtex-4 device A has been configured with the safety
configuration bitstream programmed in the flash at factory.
Please write a valid Virtex-4 device A bitstream to the flash.
ON Flash is busy writing or erasing
LED 2
OFF Flash device is not busy
ON CRC error. Presumably a wrong or corrupted FPGA bitstream
has been written to the flash. Once on this LED remains on
LED 3
LED 3 OFF No CRC error detected
Table 4: LED board status

AD484 user manual V1.2
AD484 User manual
February 2007 www.4dsp.com - 12 -
Figure 5: CPLD LED locations
3.2.3 JTAG
A JTAG connector is available on the AD484 for configuration purposes. The JTAG can also
be used to debug the FPGA design with the Xilinx Chipscope.
The JTAG connector is located on side 1 of the PCB in front (see Figure 6).
-7$*%FRQQHFWRU
YFF
JQG
WFN
WPV
WGL
WGR
Figure 6: JTAG connector (J6) location
The JTAG connector pinout is as follows:
Pin # Signal Signal Pin #
1 1.8V TMS 4
2 GND TDI 5
3 TCK TDO 6
Table 5 : JTAG pin assignment

AD484 user manual V1.2
AD484 User manual
February 2007 www.4dsp.com - 13 -
3.3 Clock tree
The AD484 clock architecture offers an efficient distribution of low jitter clocks. In addition to
the PCI Express bus, the MGT reference clocks of 106.25MHz and 125MHz (Epson
EG2121CA) make it possible to implement several standards over the MGT I/Os connected
to the optical transceivers.
Both FPGAs receive a low jitter 125MHz clock. A low jitter programmable clock able to
generate frequencies from 62.5MHz to 255.5MHz in steps of 0.5MHz is also available. This
clock management approach ensures maximum flexibility to efficiently implement multi-clock
domains algorithms and use the memory devices at different frequencies. Both clock buffer
devices (CDM1804) and the frequency synthesizer (ICS8430-61) are controlled by the
Virtex-4 device A.
Figure 7 : Clock tree
3.4 Memory resources
3.4.1 QDR2 SRAM
Four independent QDR2 SRAM devices are connected to the Virtex-4 device B. The QDR2
SRAM devices available on the AD484 are 2M words deep (8Mbytes per memory device).
Please note that only three QDR SRAM devices are available to the user if the XC4VLX40,
XC4VLX60 or XC4VSX55 FPGA device is mounted on board.
3.4.2 DDR2 SDRAM
Two 16-bit DDR2 SDRAM devices of 128MBytes each are connected to Virtex-4 device A.
The two memories share the same address and control bus and have their own data bus.
This memory resource can be accessed by the PowerPC processor in the Virtex-4 device A
or can be used as a data buffer for custom user logic.

AD484 user manual V1.2
AD484 User manual
February 2007 www.4dsp.com - 14 -
3.5 A/D inputs and outputs main characteristics
Analogue inputs
Input voltage range
AC coupled option. 2.4 Vp-p (11.5 dbm –50 Ohm) Full scale - AC
coupled via RF transformer. DC coupled option. 1.15 Vp-p (Gain
amplifier 6dB) centered around 0. DC coupled via amplifier. Gain
can be adjusted to a required input amplitude centered around 0.
Minimm gain 6dBs, which should allow input swing +/-0.575V as
full scale.
Impedance
ADC single-ended inputs are to be connected to a 50Ùsource.
Source impedance matching implemented between RF transformers
and ADC.
Bandwidth ADC bandwidth: 750 MHz.
External Reference input
Input voltage level
0.5 –3.3 Volts peak-to-peak (AC-coupled)
Input impedance
50-Ohm (Termination implemented at the connector)
Frequency range
0-100MHz
External Reference output
Output voltage level
1.6 Volts peak-to-peak (AC-coupled)
Output impedance
50-Ohm (Termination implemented at the connector)
External sampling clock input
Input voltage level
0.5 –3.3 Volts peak-to-peak (AC-coupled)
Input format
Single-ended or differential on option (3.3V LVPECL).
Frequency range
10-125MHz
External Trigger inputs
Format
DC-coupled and Single-ended (Termination implemented at the
connector). Differential on option (3.3 V PECL).
Input Voltage range
1.5-3.3 Volts peak-to-peak.
Impedance 50-ohm
Frequency range 62.5MHz maximum
ADC Output
Output Data Width 14-bit
Data Format 2’s Compliment or offset binary (Changeable via control
register)
SFDR
82dBs maximum (manufacturer)
SNR
70dBs maximum (manufacturer)
Maximum Sampling Frequency 125MHz.
Table 6: AD484 A/D characteristics

AD484 user manual V1.2
AD484 User manual
February 2007 www.4dsp.com - 15 -
3.5.1 Analog inputs
The module is built around four TI ADS5500 14-bit sampling analog-to-digital. ADCs: Analog
data enters the module via four SMA connectors on the front panel, one for each channel.
Both signals are then conditioned (AC coupling as standard via RF transformers; DC optional
via Texas Instrument amplifier THS4509) before being digitized.
3.5.2 Clock input and reference clock distribution
The ADC devices get their own sampling clock, which can be either on-board generated or
from an external reference or an external clock, common to all ADCs via an SMA connector
on the front panel. All samplings clocks are generated by the same chip. It allows having
them all synchronized to a single reference clock. The on-board clock uses the VCXO locked
on an on-board 10MHz reference. The reference clock also can be external. In that case the
VCXO is still used. It is also possible to input an external clock that is directly used to sample
the analog signals. In all cases, all sampling clocks are synchronized to the same clock
source.
3.5.3 Multi-module Synchronization
Several AD484 cards can be cascaded and still be synchronized since either the external
reference or the external clock can be passed to the next module in the chain. The external
reference goes through a 0-delay buffer and is then output via an SMA connector on the front
panel. Please note that synchronisation is in frequency and not in phase.

AD484 user manual V1.2
AD484 User manual
February 2007 www.4dsp.com - 16 -
3.6 Front Panel optical transceivers
Four 2.5Gb/s optical transceivers (LTP-ST11M) are available on the AD484 in the front panel
area. They are connected to the MGT I/Os of the Virtex-4 device A. Infiniband protocols as
well as Gigabit Ethernet and Fibre channel (sFPDP) can be implemented over the
transceivers. Lower rate optical transceivers (2.125Gb/s and 1.0625Gb/s) are available in the
same form factor.
Two low jitter clocks (106.25MHz and 125MHz) are directly connected to the MGT clock
inputs so multi-rate applications can be implemented on the AD484.
The MGT banks have power supplies independent from the digital supply provided to the
FPGAs in order to insure low noise and data integrity. The LT1963 device will be used to
generate the 1.2V, 1.5V and 2.5V necessary for the MGT to operate. The power filtering
network includes a 220nF decoupling capacitor and ferrite bead (MP21608S221A) per power
pin.
The signal differential pairs are routed on a specific inner layer with one reference GND
plane on each side of the layer stack up.
The optical transceivers are an ideal communication link to transfer digitized and processed
data to a remote system (eg, storage system) by offering an aggregate bandwidth of
1.25GBytes/s.
Figure 8: Optical transceivers

AD484 user manual V1.2
AD484 User manual
February 2007 www.4dsp.com - 17 -
4 Power requirements
The power is supplied to the AD484 via the PMC and/or XMC connectors. Several DC-DC
converters generate the appropriate voltage rails for the different devices and interfaces
present on board.
The AD484 power consumption depends mainly on the FPGA devices work load. By using
high efficiency power converters, all care has been taken to ensure that power consumption
will remain as low as possible for any given algorithm.
After power up the AD484 typically consumes 5W of power. For precise power
measurements it is recommended to use the Xilinx power estimation tools for both FPGA A
and B. The maximum current rating given in the table below is the maximum current that can
be drawn from each voltage rail in the case resources are used to their maximum level.
Device/Interface Voltage Maximum
current rating
DCI and memory reference
voltage 0.9V 5 A
Virtex-4 device A & B core 1.2V 12A
QDR2, DDR2 SDRAM core and
I/O banks, Virtex-4 devices I/O
banks
1.8V 10A
Virtex-4 device B I/O bank
connected to the front panel
daughter card
1.8V/2.5/3.3V 1.5A
Virtex-4 device A I/O bank
connected to the PCI bus, Flash,
CPLD, front Panel I/O daughter
card, A/D circuitry
3.3V 4A
MGT power supply 1.2V, 1.5V, 2.5V 1.7A, 0.5A, 0.01A
respectively
Table 7 : Power supply

AD484 user manual V1.2
AD484 User manual
February 2007 www.4dsp.com - 18 -
Figure 9 : Power supply
An ADT7411 device is used to monitor the power on the different voltage rails as well as the
temperature. The ADT7411 data are constantly passed to the Virtex-4 device A.
Measurements can be accessed from the host computer via the PCI bus. A software utility
delivered with the board allows the monitoring of the voltage on the 2.5V, 1.8V, 1.2V and
0.9V rails. It also displays the Virtex-4 device B junction temperature.
4.1 External power connector for stand alone mode
An external power connector (J2) is available on side 2 of the PMC, next to the PMC
connectors. It is used to power the board when it is in stand alone mode. This is a right
angled connector and it will be mounted on board only if the card is ordered in its stand alone
version (AD484-SA). The height and placement of this connector on the PCB breaches the
PMC specifications and the module should not be used in an enclosed chassis compliant to
PMC specifications if the external power connector is present on board.
Do not connect an external power source to J2 if the board is powered via the
PMC connectors. Doing so will result in damaging the board.
The external power connector is of type Molex 43045-1021. Each circuit can carry a
maximum current of 5A. The connector pin assignment is as follows:
Pin # Signal Signal Pin #
1 3.3V 3.3V 2
3 5V 5V 4
5 GND GND 6
7 GND GND 8
9 -12V 12V 10
Table 8 : External power connector pin assignment

AD484 user manual V1.2
AD484 User manual
February 2007 www.4dsp.com - 19 -
5 System Side view
The following diagram shows a side view of the AD484 mounted a motherboard.
Figure 10: System side view
6 Environment
6.1 Temperature
Operating temperature
0°C to +60°C (Commercial)
-40°C to +85°C (Industrial)
Storage temperature:
-40°C to +120°C
6.2 Convection cooling
600LFM minimum
6.3 Conduction cooling
The AD484 can optionally be delivered as conduction cooled PMC. The AD484 is compliant
to ANSI/VITA 20-2001 standard for conduction cooled PMC.
7 Safety
This module presents no hazard to the user.

AD484 user manual V1.2
AD484 User manual
February 2007 www.4dsp.com - 20 -
8 EMC
This module is designed to operate from within an enclosed host system, which is build to
provide EMC shielding. Operation within the EU EMC guidelines is not guaranteed unless it
is installed within an adequate host system. This module is protected from damage by fast
voltage transients originating from outside the host system which may be introduced through
the system.
9 Warranty
Hardware Software/Firmware
Basic Warranty (included) 1 Year from Date of Shipment 90 Days from Date of Shipment
Extended Warranty (optional) 2 Years from Date of Shipment 1 Year from Date of Shipment
