7th Sense NanoR Installation manual

Copyright © 7thSense Design Ltd : M282-6 August 2019
Specification
Environmental Characteristics Operating Non-operating
Temperature +15 to +30 °C -10 to +50 °C
Humidity (non-condensing) 10 to 90% 5 to 95%
Altitude <2000 m <10000 m
End of Service Life
Dispose of the equipment and any components in accordance with all local and national
safety and environmental requirements.
Regulatory Compliance Statements
FCC
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with this user guide, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
European Union
This is a Class A product. In a domestic environment, this product may cause radio interference, in
which case the user may be required to take adequate measures.
Delta Media Server
Hardware User Guide
For NanoR, NanoSDI, Proton, Nucleus, Infinity
Customer Support Portal: https://portal.7thsense.one
Support
If your Delta Media Server was purchased through one of our regional distributors, please contact
your supplier directly for support.
Visit our customer support portal where you can find a wide range of support documentation and
video tutorials, together with contact information.
Warranty
Standard warranty is 24 months, return-to-supplier. Please contact your supplier if you require an
extended warranty. Please ask for instructions and request authorisation before returning a server
to your supplier.
Operating Instructions
Operating instructions for your server can be found in the Online User Guides section of the
customer support portal.
Handling and Installation
Unpacking
Unpack your server carefully onto a clean and level surface and examine it for any signs of transit
damage. Contact your supplier immediately if anything appears to be damaged, or any parts
missing. Please retain all packaging in case of future need to return a server.
Lifting
Delta Media Server weight depends on model, the weight is stated below and on the server’s
product label. Larger servers may require a two-person lift, especially when manoeuvring them into
a rack. Observe your internal manual handling recommendations to avoid injury.
Rack mounting
Delta 2U and 3U servers are supplied with rack mount slide rails and fixings, installation
instructions are included with the slide rails.
Delta 1U servers should be installed in a rack using a minimum of an M6 rack mount bolt in each of
the top and bottom mounting holes on each side of the server’s front panel.
Ensure that each server is properly secured to the rack cabinet.
Rack stability warnings:
•Ensure the rack is stable (e.g. bolted to the floor) before sliding out the server.
•Do not place objects on equipment projecting from a rack (e.g. do not use as a shelf).
•Only slide out one piece of equipment from the rack at a time.
Product Electrical Rating Weight (kg) Dimensions (H ×W ×D)
NanoR 100-240V, 3-1.3A, 60-50Hz 4.5 1U ×483 mm ×241 mm
NanoSDI 100-240V, 4.5-2A, 60-50Hz 6 1U ×483 mm ×321 mm
Proton 100-240V, 7-3.5A, 60-50Hz 13 2U ×483 mm ×545 mm
Nucleus 100-240V, 10-5A, 60-50Hz 15 3U ×483 mm ×497 mm
Infinity 100-240V, 10-5A, 60-50Hz 21 3U ×483 mm ×603 mm
7thSense Design Ltd : 2 The Courtyard, Shoreham Road, Upper Beeding, BN44 3TN, UK
www.7thsense.one

Connecting External Equipment
To ensure best performance from the server and compliance with relevant EMC regulations, this
equipment should only be used with high-quality shielded data and signal cables.
Only equipment and accessories approved to IEC 60950-1 and SELV circuits may be connected to
the server. All equipment and accessories shall comply to the relevant standard for the server’s
port to which it is connected.
Environment
General
Delta Media Servers are intended for use in a commercial (not domestic) environment and should
be operated in a clean, dust free area (e.g. a server room).
The server is intended for operation in benign environments; that is, not subject to corrosive or
explosive atmospheres, moisture or flammable gases. The server is non-protected against ingress
of liquid (IPx0). The server is not designed to be subject to excessive mechanical shock or
vibration.
Only used at altitude
not exceeding 2000
m
Only used in not
-tropical
climate regions
Thermal
Do not block any of the server’s air vents and ensure the ambient temperature around the server is
compatible with the environmental characteristics stated below.
Particularly when mounted in a rack cabinet with front or rear doors the ambient temperature
around the server may be higher than the ambient room temperature.
Electrical
Before connecting power to the server, ensure the electricity supply is compatible with the
electrical ratings shown here and on the server product label. The server shall not be connected to
an IT (unearthed neutral) power distribution system and the mains socket-outlet used shall
connect to the building installation ground.
The server is connected to and disconnected from the mains supply with the IEC 60320 power
connector on the rear of the unit.
Maintenance
Air Filter
A user-serviceable air filter is located on the server’s front panel. It is important to remove and
clean or replace the filter periodically to avoid overheating.
Delta Media Servers are supplied with one spare filter pad, others can be provided by your supplier.
Servers should not be run without filters, since accumulations of dust inside the server can affect
performance.
Cleaning
External casing and the front panel should be carefully wiped with a soft cloth and antistatic
solution.
Server internal maintenance
Internal maintenance must only be undertaken by suitable qualified service personnel.
Warning: Do not operate the server with any covers removed as the air flow through the
unit may be compromised leading to overheating.
The lid of the NanoR forms an integral part of the CPU’s cooling circuit. Operation of the
NanoR with the lid removed will cause the CPU to overheat.
Warning: Motherboard CMOS battery replacement: Danger of explosion if incorrect
battery used or battery incorrectly installed. Contact your supplier for further instructions.
Any alterations to the product’s specification, including additional/alternative components, BIOS
changes, overclocking, etc., may invalidate the warranty or impact the server’s performance.
Additionally, such changes or modifications could cause equipment no longer to comply with the
relevant EMC regulations, and void the user’s authority to operate the equipment. If in doubt,
please contact your supplier.
Electrostatic discharge (ESD)
When handling electronic assemblies, take precautions to avoid electrostatic discharge (ESD)
causing damage. Precautions should include the wearing of an ESD protective wrist strap and
using antistatic bags for electronic assemblies when not installed in a server.
PSU removal
Delta Media Servers (3U models only) are fitted with a removable power supply unit (PSU). This
can be replaced as follows:
•To remove: Power down the server. Remove the IEC 60320 power connector from the server’s
PSU. Press the PSU’s release tab and pull the handle to slide the power supply out of the
server.
•To replace: Slide the replacement power supply into the server until it is fully clicks home. Refit
the IEC 60320 power connector and power on the server.
Warning: The IEC 60320 power connector should never be inserted into the PSU when
the PSU is not fitted in a server.
