A/DA AeroTemp IP65 User manual
Features
1. Vane sensor
2. LCD display
3. Air velocity and Temperature
measurement
4. Air velocity and temperature units
5. On/Off / Measurement mode
Display
1. Air Velocity readings
2. Wind speed icon
3. Wind temperature icon
4. Cold wind icon
5. Maximum and average wind speed
6. Air velocity unit icon
7. Low battery icon
8. Temperature unit icon
Functions
High accuracy, fast response
Color LCD display with backlight
Air velocity and temperature measurement
MAX/MIN/Data HOLD
Selectable measurement units: m/s, ft/min, MPH, km/hr or knots
Over range indication
Low battery indication
Enable/Disable auto power off
Battery
Open battery cover and install CR2032 battery into the battery com-
partment.
Note: Remove the battery when the meter is to be stored for long pe-
riods of time to avoid battery leakage. Make sure the wind is entered
into the propeller right from the front side, i.e. LCD screen should be
in face of the user.
Operation
On/Off button
Press and hold button (5) for 2 seconds to switch on the tool. Press
and hold button (5) for 2 seconds to switch off the tool.
Operating manual
Anemometer-thermometer
AeroTemp IP65
1
2
3
4
5
Air velocity and Temperature measurement
Press button (3) to switch between wind speed or temperature.
Air velocity and temperature units
When wind speed icon is switched on, press button (4) to choose the
wind speed unit: m/s, Km/h, ft/min, Knots, mph, bft (Beaufort
scale). When temperature icon is displayed, press button (4) to choose
the temperature unit between °C and °F.
Measurement mode
Press button (5) to select the measurement mode: maximum and aver-
age value of wind speed, wind temperature and real-time value.
MAX icon shows the maximum value.
AVG icon shows the average mode for the average value for last 4
seconds.
Real-time value means when neither MAX nor AVG icon is dis-
played. Start the measurement after setting the measurement mode.
Over range indication
Icon “---” will be displayed when the wind speed exceeds the mea-
surement range.
Backlight
Press any button to switch on the backlight. The backlight will be
automatically switched off if no buttons will be pressed within 10
seconds.
Cold wind indication
If the temperature is below 0°C, icon is shown on the display.
Automatic shut off
The tool will automatically shut off after 15 minutes of inactivity.
Low battery indication
Low battery icon indicates that the battery is low and it’s necessary
to replace the battery with a new one.
Specications
Air velocity
Unit Range Resolution Minimum
wind speed
Accuracy
m/s 0~30 0,1 0,7
±5%
ft/min 0~5860 19 137
knots 0~55 0,2 1,4
km/hr 0~90 0,3 2,5
mph 0~65 0,2 1,6
Temperature
Unit Range Resolution Accuracy
°C -10°C~+45°C0,2 ±2°C
°F 14°F~113°F0,36 ±3.6°F
Operating temperature -10°C~+45°C (14°F~113°F)
Operating humidity >90%RH
Storage temperature -10°C~+45°C (14°F~113°F)
Battery CR2032 3.0V
Thermometer NTC thermometer
Dust/water protection IP65
Current consumption Approx. 3mA
Dimensions 47x21x126 mm
Weight, with battery 84,5 g
1
2
3 4 5 6
7
8
9
