A/DA TEMPRO 550 User manual

Operating manual
Infrared Thermometer
Model:TemPro 550
Manufacturer Address: WWW. ADAINSTRUMENTS.COM

3
TemPro 550
Object
Reflected energy
Transmitted energy
Absorbed energy
1. Review
TemPro 550 is IR Thermometer for non-contact temperature measurements at the touch of button. The built-in laser
pointer increases target accuracy while the backlight LCD and handy push-buttons combine for convenient, ergonomic
operation.
TemPro 550 can be used to measure the temperature of objects’ surface that is improper to be measured by traditional
(contact) thermometer (such as moving object, the surface with electricity current or the objects which are uneasy to be
touched).
2. Measurement considerations
Holding the meter by its handle, point the IR Sensor toward the object whose temperature is to be measured. The meter
automatically compensates for temperature deviations from ambient temperature.
Infrared thermometers measure the surface temperature of an object. The unit’s optics sense emitted, reflected, and
transmitted energy, which is collected and focused onto detector. The unit’s electronics translate the information into a
temperature reading, which is displayed on the unit. The laser is used for aiming purposes only.
MEASUREMENT FOUNDATION
Pic.1

MEASUREMENT FOUNDATION
4
TemPro 550
3. Complete set
Thermometer TemPro 550
Battery 9V
Plastic blister
Operating manual
4. Technical data
4.1. Functions
Rapid detection function
Precise non-contact measurements
Built-in laser sighting
Unique flat surface, modern housing design
Automatic Data Hold
Backlight LCD display
Low battery indicator
•
•
•
•
•
•
•

MEASUREMENT FOUNDATION
5
TemPro 550
4.2. Specifications
IR temperature range -50°С to +550°С
Optical resolution, D:S 12:1
Resolution 0.1°С
Accuracy ±1,5°С at 0<t≤550°С
±3°С at t≤0°С
Response time 0.5 sec.
Spectral response, um 8 ~ 14
Emissivity 0.95
Backlight yes
Data hold yes

MEASUREMENT FOUNDATION
6
TemPro 550
Working temperature/relative
humidity
0..40°С / 10-95% at 30°С
Power supply 9V (krona)
Dimensions, mm 175x100x49
Weight, gr 130

MEASUREMENT FOUNDATION
7
TemPro 550
5. Safety requirements
Inaccurate readings will result from measuring shiny or polished metal surfaces (stainless steel, aluminium, etc.). To
compensate, cover the measuring surface with masking tape or flat black paint. Allow time for the tape to reach the
same temperature as the material under it. Measure the temperature of the tape or painted surface.
The unit cannot measure through transparent surfaces such as glass. It will measure the surface temperature of the
glass instead.
Steam, dust, smoke, etc., can prevent accurate measurement by obstructing the unit’s optics.
Make sure that the target is larger than the unit’s spot size. The smaller the target, the closer you should be to it. When
accuracy is critical, make sure the target is at least twice as large as the spot size.

MEASUREMENT FOUNDATION
8
TemPro 550
6. DESCRIPTION OF THE INSTRUMENT
6.1. Features (Pic.2)
Laser pointer
IR sensor
LCD display
MEASUREMENT trigger
Battery compartment
°C/°F button
Laser pointer On/Off button
Backlight On/Off button
6.2. LCD display (Pic.3)
A - Data hold icon (HOLD)
B - Scanning icon (SCAN)
C - Laser “ON” icon
D - Backlight ON icon
E - Low power symbol
F - °C/°F symbol
G - Current temperature value
1.
2.
3.
4.
5.
6.
7.
8.
Pic.2
Pic.3
1
2
4
5
3
87
6

MEASUREMENT FOUNDATION
9
TemPro 550
7. Operation
Preparation before operation
Read the operating manual before use the instrument.
Take the instrument out of case.
Open battery cover and put 9V battery.
Thermometer On/Off
Pull and hold the trigger (4) to turn the meter on and begin testing. The display will light if the battery is good. Replace
the battery if the display does not light. The meter will automatically power down after approximately 20 seconds after
the trigger is released.
°C/°F
To choose the measuring unit press button (6).
EMS adjustment
The emissivity (EMS) - 0.95. To obtain more accurate values see appendix 1.
Laser pointer
Laser pointer is on when you turn on the unit. To turn off the laser pointer, press button (7) LASER.

MEASUREMENT FOUNDATION
10
TemPro 550
Backlight
Backlight is on when you turn on the unit. To turn off the backlight, press button (8) BACKLIT.
Measurement operation
Hold the meter by its handle grip and point it towards the surface to be measured. Pull and hold the trigger (4) to turn
the meter on and begin testing. Release the trigger (4) and HOLD display icon will appear on display indicating that the
reading is being held.
Distance to spot size
When take measurement, pay attention to the Distance to Spot Size. As the Distance (D) from the target surface
increases, the spot size (S) of the area measured by the unit becomes larger. The Distance to Spot size of the unit is
12:1.
This unit is equipped with a laser, which is used for aiming.

MEASUREMENT FOUNDATION
11
TemPro 550
Pic.4
38mm
300mm
75mm
900mm
132mm
1500mm

MEASUREMENT FOUNDATION
12
TemPro 550
8. Maintenance
The maintenance of the thermometer includes the replacement of power supply, cleaning the unit with dry cloth and
also debugging. Periodically, one time per year it is necessary to check settings in authorized service center.
9. Specific reasons of instrument malfunctions
Malfunction Possible reason of malfunction Way of debugging
After pressing and holding the
button MEASUREMENT (5) the
instrument doesn’t turn on.
1.Fully discharged battery
2.Bad contact of battery and jack
of the thermometer
3. Broken jack wire in battery
compartment
Change battery
Recover contacts
Recover power lead
Contact with authorized service center if you have another malfunctions.

MEASUREMENT FOUNDATION
13
TemPro 550
10. Storage and transportation
Storage and transportation of the instrument should be only in case.
Take out the battery if you are not going to use the instrument for a log time.
Don’t expose the instrument to mechanical effects (heating, hits, strong vibrations, humidity, dust ...).
Store the instrument in normal conditions (temperature/humidity).

MEASUREMENT FOUNDATION
14
TemPro 550
WARRANTY
This product is warranted by the manufacturer to the original purchaser to be free from defects in material and work-
manship under normal use for a period of two (2) years from the date of purchase.
During the warranty period, and upon proof of purchase, the product will be repaired or replaced (with the same or
similar model at manufactures option), without charge for either parts of labour.
In case of a defect please contact the dealer where you originally purchased this product. The warranty will not apply to
this product if it has been misused, abused or altered. Withiut limiting the foregoing, leakage of the battery, bending or
dropping the unit are presumed to be defects resulting from misuse or abuse.
EXCEPTIONS FROM RESPONSIBILITY
The user of this product is expected to follow the instructions given in operators’ manual.
Although all instruments left our warehouse in perfect condition and adjustment the user is expected to carry out peri-
odic checks of the product’s accuracy and general performance.
The manufacturer, or its representatives, assumes no responsibility of results of a faulty or intentional usage or misuse
including any direct, indirect, consequential damage, and loss of profits.
The manufacturer, or its representatives, assumes no responsibility for consequential damage, and loss of profits by
any disaster (earthquake, storm, flood ...), fire, accident, or an act of a third party and/or a usage in other than usual
conditions.
The manufacturer, or its representatives, assumes no responsibility for any damage, and loss of profits due to a change
of data, loss of data and interruption of business etc., caused by using the product or an unusable product.
The manufacturer, or its representatives, assumes no responsibility for any damage, and loss of profits caused by usage
other thsn explained in the users’ manual.
The manufacturer, or its representatives, assumes no responsibility for damage caused by wrong movement or action
due to connecting with other products.

WARRANTY CARD
Name and model of the product ________________________________________________
Serial number ________________date of sale_______________________
Name of commercial organization _____________________stamp of commercial organization
Warranty period for the instrument explotation is 24 months after the date of original retail purchase. It extends to the equipment, imported
on the RF territory by official importer.
During this warranty period the owner of the product has the right for free repair of his instrument in case of manufacturing defects.
Warranty is valid only with original warranty card, fully and clear filled (stamp or mark of thr seller is obligatory).
Technical examination of instruments for fault identification which is under the warranty, is made only in the authorized service center.
In no event shall manufacturer be liable before the client for direct or consewuential damages, loss of profit or any other damage which
occur in the result of the instrument outage.
The product is received in the state of operability, without any visible damages, in full completeness. It is tested in my presence. I have no
complaints to the product quality. I am familiar with the conditions of qarranty service and i agree.
purchaser signature _______________________________
Before operating you should read service instruction!
If you have any questions about the warranty service and technical support contact seller of this product

WARRANTY DOESN’T EXTEND TO FOLLOWING CASES:
1. If the standard or serial product number will be changed, erased, removed or wil be unreadable.
2. Periodic maintenance, repair or changing parts as a result of their normal runout.
3. All adaptations and modications with the purpose of improvement and expansion of normal sphere of product ap-
plication, mentioned in the service instruction, without tentative written agreement of the expert provider.
4. Service by anyone other than an authorized service center.
5. Damage to products or parts caused by misuse, including, without limitation, misapplication or nrgligence of the terms
of service instruction.
6. Power supply units, chargers, accessories, wearing parts.
7. Products, damaged from mishandling, faulty adjustment, maintenance with low-quality and non-standard materials,
presence of any liquids and foreign objects inside the product.
8. Acts of God and/or actions of third persons.
9. In case of unwarranted repair till the end of warranty period because of damages during the operation of the product,
it’s transportation and storing, warranty doesn’t resume.
For more information you can visit our website WWW.ADAINSTRUMENTS.COM
or write the letter with your questions on [email protected]

Appendix 1
Emessivity table (ЕТ)
Material Temperature °С Radiation ЕТ
Aluminium: 220...520 0,008-0,062
- oxidated 87...520 0,02-0,33
- foil 100...30 0,04...0,03
Asbestos paper 40...370 0.93...0.95
Asbestos board 25...30 0.94...0.96
Slate 20 0.96
Asphalt 25...30 0.95
Paper:
- white 20 0.70...0.90
- yellow 0.72
- red 0.76
- green 0.85
- blue 0.84
- black 0.90
- covered with black lacquer 0.93
- black dull 0.94
- thin, sticked on the metall 19 0.924
Dressed birch 25...30 0.92
Concrete 20 0.92
Bronze:
aluminium 177...1000 0,03-0,06
oxidated 177...1000 0,08-0,16
Paper cardboard different kinds 25...30 0.89...0.93

Tungsten: 120-500- 0,039-0,081-
1700-3100 0,249-0,345
920-1500- 0,116-0,201
-2000-2700 0,247-0,312
Gypsum 20 0.8...0.9
Alumina 25...30 0.96
Porcelain 70 0.91
Graphite 900-2900 0,77-0,83
Wood :
- white, raw 20 0.7...0.8
- dressed 20 0.8...0.9
- ground 0.5...0.7
Saw dust of conifers 25...30 0.96
Duralumin D 16220-620 0,016-0,03
Lime 0.3...0.4
Silica sand 25...30 0.93
Kerosene 25...30 0,96
Brick :
- fireproof, weak radiant 500...1000 0.65...0.75
- fireproof, strong radiant 500...1000 0.8...0.9
- chamotte brick, glazed 20 0.85
- the same (55 % SiO , 41 % Al O ) 1100 0.75
- the same (55 % SiO , 41 % Al O ) 1230 0.59
- silica, fireproof 1000 0.66
- Unglazed, rough 1000 0.80
- Glazed, rough 1100 0.85
- red, rough 20 0.88...0.93

- fibrolite (33%SiO, 64%Al O) 1500 0.29
- fireproof, corundum 1000 0.46
- fireproof, magnesite 1000...1300 0.38
- the same (80% MgO, 9% Al O ) 1500 0.39
- silicate (95% SiO ) 1230 0.66
Plastered brickwork 20 0.94
Human skin 36 0.98
Tanned skin 0.75...0.80
Paint :
- oil, different colors 100 0.92...0.96
- cobalt, blue 0.70...0.80
- cadmium, yellow 0.28...0.33
- chrome, green 0.65...0.70
- aluminium, after heating 150... 315 0.35
Lacquer:
- black, dull 40...95 0.96...0.98
- black, bright, on metal 25 0.88
- white 40...100 0.80...0.95
- white, enamel on metal 23 0.906
- bakelite 80 0.93
- aluminium 20 0.39
- fireproof 100 0.92
Brass :
- polished 0.05
- polished, very good 220-330 0,02
- in composition - 73.2% Cu, 26.7% Zn 245...355 0.028..0.031
- in composition - 73.2% Cu, 26.7% Zn 200 0.03
- sheet,rolled 22-100
- sheet, finished with emery 22 0.20

Tin: 30- 90 Н 0,05
- bright 25 N 0.043...0.064
Permalloy oxidated 20 N 0.11...0.03
Foam plastic 20 N 0.60...0.05
Plastic 20 N 0.68...0.02
Bank sand clean 25... 30 N 0.95
Plexiglass 25... 30 N 0.95
Rubber soft, grey, rough 24 N 0,86
Mercury clean 0- 100 N 0,09-0,12
Ruberoid 20 N 0.93
Granulated sugar 25... 30 N 0.97
Lead : 30- 260 Н 0,04-0,08
- bright 250 N 0.08
- grey, oxidated 0- 200 Н 0.28
- oxidated at heating 200 Н 0,63
Silver: 170- 830 Н 0,012-0,046
- clean polished 225... 625 N 0.0198-0.0324
Mica :
- thick layer N 0.72
- in powder, agglomerated N 0.81...0.85
in silicate
Resin N 0.79...0.84
Ice -10 0.80...0.85
Carbon steel: 170- 1130 Н 0,06-0,31
- rolled 50 N 0.56
