A.O. Smith HSE-VAS-X User manual

Front SideSize: 420 mm (W) x 297 mm (H)Red Line Mark are for Folding. Not to be Printed
Pre-instruction Literature
On Receipt
It is our policy to promote safe delivery of all orders. This product shipment has been
thoroughly checked, packed and quality certied before leaving our factory.
Visible Loss or Damage
If any of the goods called for on the bill of lading or express receipt are damaged or the
quantity is short, do not accept them until the freight or express delivery agent makes
an appropriate notation on your freight bill or receipt.
Concealed Loss or Damage
When a shipment has been delivered to you in apparent good condition, but upon
opening the packaging if any loss or damage has taken place while in transit, inform
the carrier’s agent / A. O. Smith representative immediately.
About this manual
This manual is a guide to good practice for operating and periodic maintenance of
the A. O. Smith HSE-VAS-X / HSE-VBS-X Water Heater. Do not operate the Water Heater
before reading the user manual.
Please follow instructions in this manual to ensure personal safety and proper
operation of this product. Always install, operate, inspect and maintain this product in
accordance with all applicable standards. Please store this user manual carefully for any
future reference.
Disposal of this Product
(Waste Electrical and Electronic Equipment)
This marking on the product, accessories or User Manual indicates that the product
and its electronic accessories (e.g. Remote, batteries and other replaceable electronic
accessories) should not be disposed of with other household waste at the end of their
working life. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate these items from other types of waste
and recycle them responsibly to promote the sustainable re-use of material resources.
Household users should contact their local government oce, for details of where and
how they can take these items for environmentally safe recycling. This product and its
electronic accessories should not be mixed with other commercial wastes for disposal.
1 2
General Instructions
Safety
Your safety and the safety of your loved ones is paramount. There are several safety
related messages in this manual, which have been provided during various steps
such as the installation, operation and maintenance of your HSE-VAS-X / HSE-VBS-X
Water Heater. These messages point out potential hazards and also educate on how
to reduce any potential risks. Please always read and follow all safety messages as
provided in this user manual.
This is the safety alert symbol. This symbol alerts you to
potential hazards that can hurt you and others. All safety
messages will follow the safety alert symbol and either the
word “DANGER” or “WARNING”.
DANGER Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation, which if not
avoided, could result in death or serious injury.
CAUTION Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury or property
damage.
WARNING
Do not use this Water Heater if any part has been under water. Immediately contact
an Authorised Service Technician to inspect the Water Heater and replace any part of
the control system which has been under water. Failure to follow this instruction can
result in property damage, serious injury or death.
IMPORTANT
These instructions have been written as a guide for the proper installation and
operation of your Water Heater. A. O. Smith will not accept any liability where these
instructions have not been followed. However, for your safety and to avoid damage
caused by improper installation, it is recommended that Water Heater must be
installed by an Authorised Service Technician.
Before proceeding with the installation instructions:
1. Inspect the Water Heater and its component parts for possible damage. Do Not
install or attempt to repair any damaged component parts. If you detect any
damage in the Water Heater, please contact the dealer where the Water Heater
was purchased or call Customer Care Centre.
2. Verify that the voltage being supplied corresponds to that which is marked on the
Water Heater manual.
Specications
Model HSE-VAS-X HSE-VAS-X
HSE-VBS-X
Volume [L] 15 25 35 50
Power [W] HSE-VAS-X 2000 2000 2000 2000
HSE-VBS-X NA NA 3000 3000
Voltage/Frequency [V/Hz] 230~/50
Actual Stdg. Loss [kWh/24h/45°C di.] 0.419 0.511 0.540 0.650
Reheating time
for 35°C rise [in
min.]
HSE-VAS-X 15 29 38 54
HSE-VBS-X NA NA 24 35
Temperature range [°C] 25-75*
Rated water
pressure
N/cm280
Water head (metres) 80
Inlet/Outlet connections [inch] ½ BSP
Net Weight (kgs.) 11.8 15.8 17.2 22
*The maximum set temperature may vary ± 5 °C.
Dimensions
Model 15 L 25 L 35 L 50 L Model 15 L 25 L 35 L 50 L
A (mm) 440 644 615 832 D (mm) 123 123 152 152
B (mm) 338 338 395 395 E (mm) 173 191 193 193
C (mm) 100 100 100 100
Figure 1
A
C
E
D
ØB
Figure 2
Without Service Cove
r
With Service Cover
5
49
10
2
1
5A
7 6
8
11
3
PART DESCRIPTION PART DESCRIPTION
1 Cold water inlet 7 Red sticker
2 Hot water outlet 8 Heating element and Anode
3 Multi-function safety valve 9 Thermostat
4 Temperature control knob 10 Thermal cut-out
5 Front Service cover 11 Wall mount bracket
5A Bottom Service cover 12 Glass wool
6 Blue sticker 13 Wire harness and routing
Not illustrated for clarity purpose.
Safety Precautions
During Installation
Do not install the Water Heater where
there is direct sunlight or rain. It is has
to be installed indoor only.
Figure 3
CAUTION
Do not install the Water Heater where
water splashes on the Water Heater.
Figure 4
CAUTIO
N
Installation
Before installing, ensure the tools Adjustable wrench, Teon tape, Measuring tape,
Hammer, Bubble level indicator and Impact drill tool are available.
Mounting the Water Heater
•It is recommended as per IS302-1 to
have 6 inches clearance from wall.
•Select a place to mount Water Heater
vertically with water connection at the
bottom.
Figure 5
Water
Heater
6 inch.
6 inch.
CeilingCeiling
Wall
Wall
•Water Heater must be located within
3 ft. (approx.) from a 230 V electrical
outlet with proper grounding.
•Make sure that the wall can withstand
at least twice the weight of the Water
Heater when completely lled with
water.
Figure 6
False
Wall
Solid
Concrete
Wall
Solid
Concrete
Wall
3 ft.
Installation (contd...)
Use a drill bit with diameter of 12 mm
to drill 2 holes at least 90 mm deep in
the wall (Step 3). The two holes should
be aligned horizontally. The horizontal
distance between 2 holes is 150 mm.
Figure 7
3
1
2
Hole
90 mm
Drilling
Tool
150 mm
150 mm
Concrete
Wall
Concrete
Wall
•Insert the Expansion Anchor into the
hole (Step 1).
•Insert the Hanging screw over the
Expansion Anchor and tighten the
Hanging screw by rotating it till it gets
xed steadily (Step 2).
Figure 8
Expansion
Anchor
Hole
1
2
Concrete
Wall
Concrete
Wall
Hanging
Screw
Concrete
Wall
Concrete
Wall
Mount the Water Heater on the Hanging screw through Wall mount bracket. Tug
downwards on the Water Heater to ensure that the Water Heater is xed steadily.
Figure 9
Water
Heater
Water
Heater
3
Wall mount
bracket
Hanging
Screw
Concrete
Wall
Concrete
Wall
Wall
Wall
1
Water
Heater
WallWall
2
3 4 5 6
User Manual
Water Heater
HSE-VAS-X / HSE-VBS-X
15, 25, 35 and 50 Litres
A. O. Smith Advantage...
Blue Diamond® Glass Lining
2X Corrosion Resistance, enhanced durability.
Glass Coated Heating Element
Resistant to scale formation, longer life for the Heating Element.
Temperature Control
Choice of bathing water 25°C - 75°C.
Express Heat (Only on VBS-X)
33%* faster heating, Save your time.
Long-Lasting Anode Rod
2X lifespan compared to normal magnesium anode. A customised alloy
that works even in harsh water conditions.
Thermal Cut-out and Multi-function Safety valve
Ensure safety of your family.
Note: A. O. Smith reserves the right to amend or modify the specications and features
at any time, as and when required without any prior notication.
ISO
9001:2015
CERTIFIED
Product colour and image shown may vary from the actual product.
Part No. : 335271-086_A Date: 10-08-2020

Front SideSize: 420 mm (W) x 297 mm (H)Red Line Mark are for Folding. Not to be Printed
7
11 12 13 14
8 9 10
Connecting Multi-function Safety valve
Wrap the threaded part of the cold water
inlet pipe with Teon tape in clockwise
direction.
Figure 10
Cold water
inlet pipe
Teflon
Connect the Multi-function Safety valve
to cold water inlet pipe and rotate it in
clockwise direction till it gets xed.
Figure 11
Discharg
e
Outlet
Multi-function
Safety valve
Note: The Multi-function Safety valve may drip during the usage of the heater. As
the water is heated, it expands and tries to ow back through the inlet pipe but is
prevented by the presence of the non-return valve (an external valve provided before
cold water tap). Hence water may drip from the Multi-function Safety valve. Therefore,
Discharge Outlet is provided to discharge water from the Water Heater. To avoid
dripping, it is recommended to install non-return valve at a distance of at least 40 feet
away from the inlet of the Water Heater.
CAUTION
•The Multi-function Safety valve should never be removed or blocked by any means
to prevent it from dripping or releasing the excess pressure inside the heater.
Failure to do so may result in damage to the Water Heater and injuries to the user.
This will also make the warranty null and void.
•Discharge Outlet is provided to release the discharge from the Water Heater in
case excessive pressure is developed. The contents of the discharge from the
Multi-function Safety valve may be hot and may cause burns to the users and
damage nearby objects, therefore it is recommended to take pre-cautions while
discharging water from the Water Heater.
•It is recommended to operate the Discharge lever in the Multi-function Safety valve
on a regular basis to ensure that there are no blockages and also to remove any
lime deposits that would have been formed inside the Water Heater.
•Ensure that the Water Heater is in power OFF condition when the Discharge Lever
is being operated. Ensure that the water is lled completely in the Water Heater
before switching it ON.
•Ensure that the Multi-function Safety valve is not damaged while tightening.
Connecting to Water Supply
Figure 12 Installation Diagram
Cold Water
Ta p
*Flexible Hose
Hot Water
Tap
*Flexible
Hose
Multi-function
Safety Valve
Discharge Lever
Discharge Outlet
*Flexible Hoses to be procured by the customer, not part of standard product.
1. Wrap the Teon tape around the inlet and outlet connections of the Water Heater to
prevent leakage.
2. Make necessary plumbing with reference to the Installation Diagram (Refer
“Installation Diagram”).
3. Connect the cold water pipe to the inlet [Blue Sticker].
4. Connect the hot water pipe to the outlet [Red Sticker].
Note: A. O. Smith recommends Nylon/ Stainless Steel (SS) braided hoses (Flexible
Hoses) having a minimum pressure rating of 8 Bar and hoses should be compatible for
hot water applications.
CAUTION
•Make sure a suitable Teon tape is used for all plumbing connections to prevent
leakage.
•Use only Nylon/ Stainless Steel (SS) braided hoses (Flexible Hoses) having a
minimum pressure rating of 8 Bar and hoses should be compatible for hot water
applications.
•Failure to follow this instruction can result in property damage.
Operation
Filling the Water Heater Tank
Figure 13 1. Open a nearby hot water faucet to
permit air to escape.
2. Open the cold water inlet valve fully,
lling the Water Heater and the
piping.
3. Close hot water faucet when water
ows.
4. Check all the connections to see
if there is any leakage. In case of a
leakage, drain the water completely,
repair the leaking joint and then rell
the Water Heater.
CAUTION
•This Water Heater should not be operated with insucient amount of water. Failure
to do so may result in damage to the Water Heater and injuries to the user. This will
also make the warranty null and void.
•Once the Mounting, Multi-function Safety valve, Plumbing and Water lling is
completed, then only the power supply should be switched ON.
•Do not splash water directly or clean with benzene, pesticides, thinner, alcohol, etc.,
but use a soft, dry cloth to clean the Water Heater.
Connecting to Electrical Supply
Figure 14 The power cord and plug are connected
with this Water Heater. Find a separate
socket for power plug and make sure
the socket is in rm contact with the
plug. Ensure that reliable earthing has
been done.
CAUTION
•Connect the Water Heater using independent sockets, do not use any adapters. Use
multimeter to check whether the live line and neutral line are not reverse, to ensure
complete safety.
•Before installing the Water Heater, conrm that the power of Water Heater matches
electric meter capacity and supply wire.
•The Water Heater should be earthed reliably. It is prohibited to connect the earth
wire to neutral wire or faucet water pipe.
Temperature Control Knob
Figure 15
Heating
indicator
lamp
Power
indicato
r
lamp
Switch on the Water Heater’s power supply. The Power indicator lamp glows.
Temperature Setting
Turn the Temperature control knob clockwise for the device to commence heating and
change the set temperature [The set temperature increases if the Temperature control
knob is turned clockwise]. Temperature can be adjusted from 25°C to maximum 75°C.
Modes
There are two types of modes depending on the actual water temperature inside the
inner tank of the Water Heater:
Heating mode Standby mode
When the actual temperature of the
water is less than the set temperature, it
enters into Heating mode. The Heating
indicator lamp glows as shown in“Figure
16”.
Figure 16
Powe
rH
eating
After the Water Heater reaches set
temperature, it will enter into the
Standby mode due to the thermostat
cut-o, the Power indicator lamp glows
and Heating indicator lamp switch o as
shown in “Figure 17”.
Figure 17
Powe
rH
eating
When the temperature of the water drops by 5°C from the set temperature due to
usage of water, the Water Heater again enters into the Heating mode.
Draining the Water Heater Tank
Whenever the Water Heater is not used for an extended period or if the product is
below freezing temperature, you will need to unplug the unit and drain it.
Figure 18
Discharg
e
Lever
Discharge
Outlet
1. Switch OFF the electric supply to the
Water Heater.
2. Open the hot water faucet until the
water runs cool.
3. Close cold water supply.
4. Drain the water by lifting the
Discharge Lever of the Multi-function
Safety valve upwards. (Refer“Figure
18”)
CAUTION
Please turn o the power supply to the Water Heater prior to draining the Water
Heater.
DANGER
HOT
Scalding
Hot water is dangerous, especially for the young children,
aged or the disabled. The Water Heater allows you to control
the temperature of your hot water. Water temperatures
over 52°C can cause severe burns instantly or death from
scalds. Do not leave a child or an inrm person in the bath
unsupervised.
Troubleshooting
The Water Heater may not operate as desired if used incorrectly or there is a minor
cause, even though the product has no fault. In these cases, check the following issues
to solve simple problems without the help from the Customer Care Centre. If the
problem does not solve after checking the following issues, call Customer Care Centre.
Problems Possible Cause(s) Solution
Power indicator
lamp and Heating
indicator lamp
does not glow.
No power supply to the Water
Heater.
Check power supply and
switch ON electrical switch.
Thermal Cut-out has tripped or
problem in internal wiring error.
Call Customer Care Centre.
Power indicator
lamp and Heating
indicator lamp
glow but no hot
water.
Heating Element breakdown or
internal wiring error.
Call Customer Care Centre.
Water
temperature is
too high.
Improper thermostat operation. Call Customer Care Centre.
Thermal cut-out not operating. Call Customer Care Centre.
Water heats
slowly.
Low voltage at supply mains. Call Customer Care Centre.
Scale deposition. Call Customer Care Centre.
Piping
connection leaks.
Connection not sealed. Re-connect piping, using
Teon tape.
Water leakage
from product.
Leakage in tank or other parts. Switch OFF power
immediately and call
Customer Care Centre.
Water dripping
from Multi-
function Safety
valve during
heating.
Non-return valve is installed
close to the inlet of the Water
Heater.
Install Non-return valve at a
distance of at least 40 feet
from the inlet of the Water
Heater (Refer page 7), if
problem still persists call
Customer Care Centre.
Problems Possible Cause(s) Solution
Foul smell from
hot water.
Presence of organic matter in
input water.
Provide treated water at
the input.
No usage of hot water for a long
time period
If the Water Heater is not
used for an extended period
of time, drain the water
from the Water Heater.
Ensure water is lled back
before use of Water Heater.
High electrical conductivity of
water due to dissolved solids in
input water.
Call Customer Care Centre.
Anode options available for
highly conductive water.
Note: Call Customer Care No. 1800-103-2468/1860-500-2468.
Circuit Diagram
Figure 19
Heating
Element
L
PE
N
Black
Thermostat
Green/Yellow
Black
Tank
Blue
Blue
White
White
Thermal cutout
Brown
Red Red
Red lightGreen light

Front SideSize: 210 mm (W) x 297 mm (H)
Warranty Terms and Conditions
Product Warranty
Your A. O. Smith Water Heater is warranted against defects arising from faulty design,
workmanship and materials for a period of 24 months from the date of the invoice,
subject to the following conditions:
1.The customer will notify the Company promptly about defects noticed and give the
Company or its Authorised Service Provider adequate opportunity to inspect, test
and remedy them, for which the customer will deposit the goods, if necessary, with
the Company’s Oce/Authorised Service Provider along with the original invoice.
2.Special warranty from the date of purchase is only applicable for the below
mentioned components:
Tank 7 Years
Glass-Coated
Heating Element
2 + 2 Years*
Product Warranty 2 Years Extended
Warranty*
4YEARS
Warranty
on tank
7YEARS
* Register your product with the A. O. Smith Customer Care Centre [1800-103-2468/1860-
500-2468] within 60 days of purchase and you will get an extended warranty on the
element [from 2 years to 4 years].
3.Inspection and Test Report of the Company’s Oce/Authorised Service Provider
will be treated as nal and binding under the warranty for determining the defects,
repairs/alterations required or carried out, or certifying working of the goods
thereafter.
4.The Company or its Authorised Service Provider will be entitled to retain any
defective part replaced under the warranty.
5.The Company’s liability under the warranty will be limited only to defects which
occur under conditions of proper installation, normal operation and under proper
use. It excludes defects occurring because of abuse, faulty care or maintenance and
repairs/alterations to product or the parts by an unauthorised person.
6.The Water Heater should not be operated without water inside the tank. This will
make the warranty null and void.
7.In case of dry heating (Water Heater operated without water inside the tank), if the
Water Heater or any component of the Water Heater is damaged, then it will be
repaired/changed on a chargeable basis. After any repair or part replacement in the
Water Heater, the basic warranty continues as per the actual date of purchase.
8.The customer will have no claim under this warranty in respect of any personal
injury, damage of property or consequential damages, or for utilisation of the goods
not in accordance with the user guide.
9.The inner tank and Heating Element need to be cleaned for any deposits/scales
periodically from an Authorised Service Technician. This will ensure your Water
Heater works eciently for longer time.
10. Anode is not included under warranty, the service life of the Anode is determined
by the quality and quantity of the water owing through. If the Anode is consumed,
it needs to be replaced by an Authorised Service Technician for ecient protection
of the Water Heater. The warranty on the tank will be null and void,
•If the Anode is removed.
•If the Anode is not replaced as and when required.
11. Warranty does not cover:
•Plastic parts.
•Cleaning of scale deposits inside Water Heater tank as a general service.
•Any damages to Water Heater occurring due to site conditions like electrical works
and plumbing works.
•Damage to Water Heater or its surroundings due to non usage of Multi-function
Safety valve, Pressure Reducing Valve or non-recommended reducing valve in
plumbing lines.
•Product installed in direct sunlight exposure or rain or non-serviceable areas (Refer
User Manual).
•Damage to Water Heater at customer house during installation or serviceable
procedures by Unauthorised Service Technician.
•Any service related issues/replacements due to non A. O. Smith connecting hoses.
12. Calls which are related to the site e.g. plumbing, tap leakage, electricity etc., but
not related to the product functionality will be charged to the customer as per rate
card* (even during the warranty period).
*Refer rate card www.aosmithindia.com
1 2
Part No. : 335311-019_A Date: 20-02-2020
Warranty Card
Water Heater
HSE-VAS–X / HSE-VBS–X
35 and 50 Litres
Registered Oce
A. O. SMITH INDIA WATER PRODUCTS PRIVATE LIMITED
Plot 300, Phase - II, KIADB Industrial Area, Harohalli, Kanakapura Taluk,
Ramanagara District, Karnataka – 562 112, India.
CIN: U31909KA2006PTC040282
• Customer Care No. 1800-103-2468 / 1860-500-2468
• E-MAIL: [email protected]

Front SideSize: 210 mm (W) x 297 mm (H)
General Terms of Warranty
1.The “goods”shall mean the goods described in the purchase agreement.
2.“The customer” shall mean the original purchaser under the purchase agreement.
3.“The Company” shall mean A. O. Smith India Water Products Private Limited.4.The “Purchase Agreement”shall mean the General Terms and Conditions of Sale
agreed upon by the customer and the Company as printed on the Invoice.
5.“Invoice”shall mean the Invoice issued for the Unit by the Company or Authorised
Dealer to the customer describing the goods and indicating, inter alia, the total
purchase price thereof, the name of the customer and the place where the goods are
to be installed.
6.“User Guide”shall mean the instructions for installation leaet published by the
Company and delivered to the customer.
Note: Follow any one for registration of the Extended Warranty.
•Call our dedicated Customer Care No. 1800-103-2468/1860-500-2468.
•To register for the warranty details of your Water Heater, visit www.aosmithindia.
com.
Post Warranty
1.The customer may be oered a yearly Service Contract at the prevailing Company
rates and terms.
2.In case the customer does not wish to enter the Service Contract, he has an option
to call our Customer Care Centre and get A. O. Smith Water Heater unit serviced
on an actual basis, i.e. by paying the Labour Cost and Spares needed to attend to that Service or Complaint Call at the prevailing Company rates. Such service will be
rendered by the Company in towns or places where the Company has its Authorised
Service Providers.
3.In case of product repair after warranty by Authorised Service Provider, all expenses
of transporting the goods to and from the Authorised Service Provider shall be
borne by the customer directly.
4.If, during such service, it is necessary for the Company or Authorised Service Provider
to replace or repair defective components or parts, the customer shall be required to
pay for the same as per the Company’s prevailing price list.
Jurisdiction
The courts of competent jurisdiction at Kanakapura, Karnataka shall have exclusive
jurisdiction over all matters arising out of any disputes in relation to the product.
Expert Company Service - Power of 1
1.Dierent models have dierent service delivery levels.
2.Service level mentioned for particular models are applicable for metros and‘A’
Class cities, e.g. Delhi and NCR, Bengaluru, Hyderabad, Kolkata, Pune, Goa, Cochin,
Chennai, Chandigarh and Ahmedabad.
3.Service level deliverables are valid up to city municipal limit only.
4.Service level may dier in case of public holidays and unavoidable conditions due to
natural calamities, any political and regional regulations.
5. Power of 1 valid service is applicable for calls registered at A. O. Smith Call Centre
before 4 p.m. only.
Customer Copy to be retained by the Customer
Dealer’s Stamp and Signature
Warranty Card
Invoice Number: ________________________________ Dated: __________________________ Unit Serial Number: __________________________________ Model: _________________________ Capacity: ______________________ Customer's Name and Address: ____________________________________________________
______________________________________________________________________________ ______________________________________________________________________________ Ph: __________________ Mobile: _____________________ E-mail: ______________________
Company Copy to be sent back to the Company
Dealer’s Stamp and Signature
Warranty Card
Invoice Number: ________________________________ Ph: __________________ Mobile: _____________________ E-mail: ______________________
3 4
