A2Z Ozone A-3500 User manual

A-3500 Ozone Generator, 220V
Operating Manual
*Register your product at a2zozone.com/pages/warranty
Produced for and
Distributed by:
A2Z Ozone, Inc
1844 Cargo Court.
Louisville, KY 40299
USA
1+502-499-4977
EPA Est.: 95432-KY-1
Active Ingredient:
Ozone.
Warning: Do Not Inhale
Ozone.
Keep Out of Reach of
Children.
Produced by:
Bluegrass Water
Technology Shenzhen
Co., Ltd.
Shenzhen, Guangdong
EPA Est.: 95432-CHN-1
Made in China
Version 1.2.4

1
Table of Contents
Important Safety Information ................................................................2
Technical Specifications ........................................................................3
A-3500 Features ....................................................................................4
Operating Instructions ...........................................................................6
Timer Functions .....................................................................................7
Maintenance ..........................................................................................8
Troubleshooting ...................................................................................10
Warranty ...............................................................................................11
IMPORTANT:
When operating an ozone generator, please remember
to remove people, pets, and plants from the area. Be
sure to leave the area being treated immediately and
only return once the ozone has dissipated. Under most
conditions, the treated area should be safe to return
to in 12-24 hours after the unit stops producing ozone.
Ozone has a half-life of 30 minutes. Treated spaces or
buildings should be well-ventilated prior to re-entry.
Do not use around ammable substances or solvents.
For questions, please call 1+ [phone] OR email [email protected]
This unit is designed to remove pet odor, smoke odor, cooking odor
and skunk odor. Do not use this unit for odor caused by ammable
items or solvents.

2
Important Safety Information
READ AND FOLLOW ALL INSTRUCTIONS
• Before using this product, read the instruction manual carefully.
• Do not cover the air inlets/outlets of the unit. Improper ventilation
while operating will result in mechanical failure.
• Store the ozone generator in a cool and dry area
• Do not take the ozone generator apart. This unit creates a very high
voltage. If mechanical failure occurs, return the unit directly to A2Z
Ozone for repair
• Do NOT breathe in ozone directly. Breathing in ozone may cause
shortness of breath, headaches or lead to long term respiratory
issues.
• DO NOT open the protective casing. There is a risk of electric shock.
If there is a problem, contact the manufacturer immediately.
• DO NOT run generator in an occupied room.
• DO NOT enter the unoccupied room until 12-24 hours after the
machine has turned off. Make sure the room is properly ventilated
(for example: opening windows) after the appropriate amount of time.
• Be sure to remove all oils, gasoline or other flammable chemicals
from the treatment area as they are an extreme fire hazard.
• Do not use this unit to remove odor that comes from flammable
fluids or solvents. This is an extreme health hazard. Some chemical
solvents react with ozone and create harmful substances. Do not
ozonate a freshly painted room as it can have an adverse reaction
with chemicals in the paint.
• Be sure to remove all people, pets and plants from any area being
treated. Exposure to ozone may cause lung damage.
PLEASE SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
Please note: In the state of California, ozone generators are
for industrial use only. Use only in unoccupied spaces.
Health hazard: Emits ozone

Technical Specications
3
Items Included:
• A-3500 ozone generator
• A-3500 operation manual
• Spare fuse (3 AMP)
Model A-3500
Voltage 220/120 V, 50/60 Hz
Power 95W
Ozone Output 3.5 g/hour
Timer 0-4 hours
Dimensions 9 x 7.6 x 7.1 inches 230
x 195 x 181 mm
Weight
7.59 lbs
3.43 kg

A-3500 Features
1Power Light Indicates when there is power to the unit. If the
power is supplied, the light will remain a solid red.
2Timer Used to set desired run time. (15 minutes - 4
hours)
3Handle For easy carrying. Folds against unit for easy
storage.
4Air-in Grill This is where the unit will intake ambient air.
5Rubber Feet Rubber feet protect your counter tops and tables
from scratches.
4

5
1
2
3
4
5

6
Operating Instructions
• Plug ozone generator into an AC outlet
• Set the timer and leave the area immediately.
• Come back at least 12-24 hours after the ozone generator stops.
• Be sure to ventilate the room after the A-3500 has stopped producing
ozone and the appropriate amount of time has passed.
For Best Results
• Before beginning ozone treatment, make sure the room is sealed
completely, including vents.
• Place the unit in the center of the room to ensure ozone is dispersed
evenly.
• As room size increases, treatment time should also increase.
• Ozone plates should be replaced after 2 years or 2000 hours of use
or as needed.

7
Timer Functions
Follow the guidelines below for shock treating rooms with the A-3500:
• Keep in mind, ozone half-life is 30 minutes.
• If the smell of ozone is too strong when you return, be sure to open
windows to air out the building.
• The A-3500 has a timer function option that can be set at 15
minutes - 4 hours.
• Turn the timer knob clockwise to set the unit’s timer.
• Keep in mind, this unit does not have a repeat timer option.
Room Size Estimated Time
Large Sized Room (< 3500 sq ft) 3 to 4 hours
Medium Sized Room (< 2500 sq ft) 1 to 2 hours
Small Room or Closet (< 1500 sq ft) 30 minutes to 1 hour

Maintenance
8
Fuse Change
Fuses are located on the back left side. The A-3500 uses a 3 AMP
glass fuse.
1Power Cord Plug into appropriate outlet to supply power to the
unit.
2Main Fuse The only fuse on the unit.

9
1
2

10
Troubleshooting
Problem Possible Cause What To Do
No Ozone
Fan Malfunction
If the fan has decreased
in speed you will have less
ozone produced. If the fan
quits completely you will not
get any ozone production.
Replace Fan (Check Voltage)
Bad Plates
If you have no ozone, it is
most likely due to oxidization
on the ozone plate. The plates
will only glow purple in some
spots or not at all. Fix with
replacement 3.5G/hour plates.
Transformer
If you have had this unit for a
while there is a higher chance
of this malfunction, but this
malfunction isn’t normal.
Replace transformer.
Low Ozone Bad Plates
You will see purple glowing in
some parts of the plate, but
not all will be glowing. Fixed
with replacement 3.5G/hour
plates.
No Power Bad Fuse
First, check plug outlet.
If problem persists, check the
fuse holder that is located
next to the power cord.

11
Warranty
A2Z Ozone Systems Inc. - ONE YEAR LIMITED WARRANTY
e limited warranty set forth below applies to products manufactured by A2Z Ozone Systems Inc. - and
sold by A2Z Ozone Systems or its authorized dealers. is limited warranty is given only to the rst retail
purchaser of such products and is not transferable to any subsequent owners or purchasers of such prod-
ucts. A2Z Ozone warrants that it or its authorized dealers will repair or replace, at its option, any part of
such products proven to be defective in materials or workmanship within ONE (1) year from the date of
retail purchase of such products. (All parts) ANY REPAIR OR REPLACEMENT WILL BE WARRANT-
ED ONLY FOR THE BALANCE OF THE ORIGINAL WARRANTY PERIOD. NOTE: USE ONLY A2Z
Ozone AUTHORIZED REPLACEMENT PARTS. USE OF ANY OTHER PART(S) WILL AUTOMATI-
CALLY VOID THIS WARRANTY. THIS LIMITED WARRANTY DOES NOT INCLUDE ANY OF THE
FOLLOWING:
(a) Any labor charges for troubleshooting, removal, or installation of such parts;
(b) any repair or replacement of such parts necessitated by faulty installation, improper maintenance,
improper operation, misuse, abuse, negligence, accident, re, repair material, and/or unauthorized acces-
sories;
(c) Any such products installed without regard to required local codes and accepted trade practices;
(d) ANY IMPLIED WARRANTY OF MERCHANTABILITY OR IMPLIED WARRANTY OF FITNESS
FOR PARTICULAR PURPOSE, AND SUCH WARRANTIES ARE HEREBY DISCLAIMED: AND
(e) A2Z Ozone SHALL NOT BE LIABLE UNDER ANY CIRCUMSTANCES FOR LOSS OF USE OF
SUCH PRODUCTS, LOST PROFITS, DIRECT DAMAGES, INDIRECT DAMAGES, CONSEQUEN-
TIAL DAMAGES AND/OR INCIDENTAL DAMAGES.
TO OBTAIN WARRANTY SERVICE
Contact A2Z Ozone, 1844 Cargo Court Louisville, KY 40299, USA
Customer Service Number: [phone].
When ling a claim, you must provide:
1) Your name, mailing address and telephone number
2) e selling dealer’s name
3) Proof of date of purchase
4) e date of failure
5) A description of the failure.
Aer this information is provided, A2Z Ozone will release a RETURN GOODS AUTHORIZATION
(RAN) NUMBER. Aer receiving the RAN number the part in question must be returned to A2Z Ozone,
freight prepaid, with the RAN number clearly marked on the outside of the package. All preauthorized
defective parts must be returned to A2Z Ozone within thirty (30) days. Under no circumstances may any
product be returned to A2Z Ozone without prior authorization. You must call or write prior to returning
product or your returned goods shipment will be refused. Upon receipt of preauthorized returned goods,
A2Z Ozone will repair or replace, at its option, the defective product(s) and return them (shipping is pre-
paid for units under warranty for USA customers only). Buyer’s acceptance of the product and use thereof
constitutes acceptance of these terms.

12
A2Z Ozone WARRANTY REGISTRATION CARD
This information can be also send by EMAIL to us. Please provide ALL pertinent information and send
within twenty (20) days to: ser[email protected]
Otherwise, please ll out completely and return to A2Z Ozone by post within twenty (20) days of
purchase.
Customer Info:
Name__________________________________________________________
Address________________________________________________________
City__________________________________State_________Zip__________
Phone (____ ) ________________
Dealer Info:
Dealer Name______________________________
Dealer Address_______________________________________________________
City_________________________________State_________Zip__________
Phone ( ) ________________
Purchase/Product Info:
Purchased Date: _______________________Date Installed____________________
Product Purchased: A-3500 OZONE GENERATOR
Comments / Questions:
DO NOT FORGET TO CUT OUT, PLACE IN ENVELOPE AND MAIL TO THE FOLLOWING ADDRESS FOR
INSTANT WARRANTY COVERAGE!
A2Z Ozone Systems Inc.
ATTN: Warranty Dept.
1844 Cargo Court
Louisville, KY 40299, USA
