A2Z Ozone Aqua-6 User manual

Aqua-6
OperatingManual
* register your product at a2zozone.com/pages/warranty
Produced for and Distributed by:
A2Z Ozone, Inc.
Louisville, KY 40299
EPA Est.: 95432-KY-1
Active Ingredient: Ozone.
Do Not Inhale Ozone.
Keep Out of Reach of Children.
Produced by:
Bluegrass Water Technology Shenzhen Co., Ltd
China
EPA Est.: 95432-CHN-1

1
Table of Contents
Safety Information (Please Read)..............................................................................................2
Specications..............................................................................................................................3
Operating Instructions................................................................................................................4
Features......................................................................................................................................5
Timer Functions..........................................................................................................................7
Applications................................................................................................................................8
Warranty....................................................................................................................................11

2
Important Safety Information
• Any deviation from the operating manual or induced malfunction such as water damage
or continuous run of the ozone generator is not covered by the terms of the warranty.
• This unit is not made for continuous operation. Do not run the unit without a 15-30
minute pause between run times.
• Place ozonator higher than water level to avoid water backing up into the unit, which will
cause damage and electrical shock.
• Be sure to turn the unit OFF after each use.
Read Before First Use
• Read the safety information above and operating manual carefully before use.
• Do not cover the air inlet on the back of the unit or the ozone outlet at the bottom of the
unit.
• Store ozone generator in a cool, dry area when not in use.
• Do not take the ozone generator apart because mechanical failure may result.
• Return the unit directly to the manufacturer if malfunction occurs.
• Do not breathe in ozone directly.
• Be sure to allow proper ventilation when entering a room after treatment.
In accordance with California Regulations, this ozone generator is solely for industrial use and
must be installed by a professional. Potential health hazard: emits ozone.

Technical Specications
3
Items Included:
• Aqua-6 Ozone Generator
• Aqua-6 Ozone Generator Operating Manual
• Two sets of long tubes for ozonation (each 36” long)
• Two short spare tubes for internal replacement if needed (1.75” and 2.75” long)
• Fine white diffuser stone
• Course gray diffuser stone
• Spare fuse
Aqua-6 Specications
Power Input 110 VAC 50/60 Hz (10w) or
220/240 VAC 50/60 Hz (12W)
Ozone Output 600 mg/hour
Weight 0.865 kg or 1.7 lbs
Dimensions 270 L x 190 W x 75 H (millimeters)
11 L x 8 W x 3 H (inches)

Operating Instructions
• Plug the ozone generator into an electrical outlet
• Attach one end of the ozone supply tubing (36-inch long) into the ozone outlet at the bot-
tom of the generator and attach a stone diffuser into the other end of the tube
* Extend the tubing so that the diffuser stone and the Aqua-6 are as far
apart as possible
• Push in the main power switch located on the face of the unit to the ON position
* The red light above the main power button will illuminate
* The LCD will indicate 00 while blinking
• Use the Plus (+) and Minus (-) Buttons to select the desired function setting from the
table for desired application time
• Operating times will vary according to the size of the room, amount of water being
treated, and amount of odor to be eliminated
• The ozone generator will start 10 seconds after you select the setting on the LCD screen
• Once the generator starts producing ozone, the LCD changes to display the time remain-
ing for the setting you have chosen
• Once the cycle is complete, the LCD screen will change back to the setting number for
repeat settings or (00) for one time run settings
• Remember, settings 1 through 5 are a one-time run setting
• Settings 6 through 10 continuously repeat cycle every hour
• Settings 11 through 15 continuously repeat every 4 hours
• To pause a setting, simply press the pause button below the LCD screen
• The LCD will hold the previously selected function and the time remaining until the
pause button is pressed again
• Press the Plus (+) or Minus (–) Buttons to select another function if desired
• After the function is complete, the air compressor will run for 10 seconds and will auto-
matically shut off
• Please allow the air compressor to shut off and then unplug or cut power to the unit
• This will allow the ozone to purge out and will prolong the unit’s operating life span
• The unit is now powered down and ready for storage or transport
NOTE: This unit is not made for continuous operation. Do not intentionally run the unit
without a 15 minute pause in between each run time.
4

1
8
4
5
6
2
7
3
5

Aqua-6 Features
1Light Indicates when the unit is running. When it is in operation, the
light will remain a solid red.
2On/Off Button Use to turn the unit on and off. When on, the red light will
illuminate.
3Pause Button
Use to pause the unit when it is in operation. The LCD will hold
the previously selected function and the time remaining until the
Pause Button is pressed again.
4LCD Screen
Displays function setting selected and operation time remaining
after the Aqua-6 begins producing ozone. The ozone production
will start 10 seconds after the selection is made on the LCD.
5Minus (-) Button
Use to select desired function setting from the Timer Function
table. The Minus Button will move the Function number down
sequentially.
6Plus (+) Button Use to select desired function setting from the Timer Function
table.
7Tube Input
Where the PTFE tubing is attached to the unit. One end of the
ozone supply tubing is attached to the ozone outlet on the Aqua-6
unit, while the other end is attached to a diffuser stone.
8Power Cord
Where the electrical cord is attached to the unit. Wait for the air
compressor to automatically shut off after each function before
unplugging the unit.
6

Timer Functions
7
Function # Description
1Run 2 minutes and turns off, one time run only
2Run 5 minutes and turns off, one time run only
3Run 10 minutes and turns off, one time run only
4Run 15 minutes and turns off, one time run only
5Run 20 minutes and turns off, one time run only
6Operates for 2 minutes every hour, repeats every hour
7Operates for 5 minutes every hour, repeats every hour
8Operates for 10 minutes every hour, repeats every hour
9Operates for 15 minutes every hour, repeats every hour
10 Operates for 20 minutes every hour, repeats every 4 hours
11 Operates for 2 minutes every 4 hours, repeats every 4 hours
12 Operates for 5 minutes every 4 hours, repeats every 4 hours
13 Operates for 10 minutes every 4 hours, repeats every 4 hours
14 Operates for 20 minutes every 4 hours, repeats every 4 hours
15 Operates for 30 minutes every 4 hours, repeats every 4 hours
Setting 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Run
Time
(min)
OFF 2 5 10 15 20 2 5 10 15 20 2 5 10 20 30
Repeat
Time
(hours)
OFF OFF OFF OFF OFF OFF 1 1 1 1 1 4 4 4 4 4

Applications
8
1 Gallon Glass Jug of Water
• Set on Function #5 and run for 20 minutes
• Do NOT drink water immediately unless directed by a medical professional
• Ozone dissipates within 30 minutes
Treatment of Fruits & Vegetables
• Set on Function #3 and run for 10 minutes
• Then let produce sit for 10 minutes in ozonated water
6 oz - 12 oz Glass
At the right levels, ozone is a safe and effective sanitizer for water. Our units produce
different concentrations of ozone for disinfection, removal of impurities from decomposition
and oxidation, removal of residual chlorine, oxidation of heavy metals, and clarification
through oxidation.
• Set on Function #1 and run for 2 minutes
• Ozone half-life is 30 minutes
• Water will still be clear of bacteria and pathogens after ozone dissipates

9
Treatment of Meat Products
Rinse and soak meat and poultry in ozonated water to kill salmonella, E. coli and other
harmful microbes, as well as to neutralize residual hormones. Preservation time is
increased 2 to 5 times. Rinse and soak fish in ozonated water to kill microbes and remove
fishy odor.
• Set on Function #4 and run for 15 minutes
• Then let meat sit for 15 minutes in ozonated water
Treatment of Cooking Utensils
Meat product benefits
• Set on Function #4 and run for 15 minutes
• Then let meat sit for 15 minutes in ozonated water
American Standard Bath Tub
• Set on Function #15 and run for 30 minutes
• Open a window or circulate air flow in the room with a fan
• Do not sit in the bath while the unit is running
• Only take ozonated baths if directed by a medical professional
