A2Z Ozone Aquatic 2 User manual

Aquatic 2
Operating Manual
*Register your product at a2zozone.com/pages/warranty
Produced for and
Distributed by:
A2Z Ozone, Inc.
Louisville, KY 40299 USA
EPA Est.: 95432-KY-1
Phone: 1+502-499-4977
Active Ingredient: Ozone.
Warning: Do Not Inhale
Ozone. Keep Out of Reach
of Children.
Produced by:
Bluegrass Water
Technology
Shenzhen Co., Ltd
EPA Est.: 95432-CHN-1
Made in China
Version 1.2.3

1
Table of Contents
Important Safety Information .................................................................. 2
Technical Specifications ............................................................................ 3
Aquatic 2 Features ..................................................................................... 5
Installation Instructions ........................................................................... 6
Wiring Diagram ........................................................................................ 8
Operating Instructions .............................................................................9
Maintenance ............................................................................................ 10
Troubleshooting ...................................................................................... 11
Warranty .................................................................................................. 12
IMPORTANT:
WARNING: Do Not Inhale Ozone. Ozone Can Damage Lungs if Inhaled. Remove
Immediately to Fresh Air if exposed. Keep Out of Reach of Children. Hazards
to Humans and Domestic Animals--Do Not Expose Children, People, Pets, Plants
or Valuables to Ozone. Ozone Health lnformation -- If exposed to ozone, get to
fresh air immediately. Seek doctor’s advice if exposed to ozone. HIGH VOLTAGE!
Perform service on ozone generator by certied technicians only! For your safety,
do not store or use gasoline, chemicals or other ammable liquids or vapors near
this or any other appliance. NOTE: Use Only As Directed. Follow All Instructions
Provided in the Manual. Buyer will assume all responsibility for installation, running
and use not in accordance with direction.
For questions, please call 1+502-499-4977 or email [email protected]

2
Important Safety Information
Read and follow this owner’s manual carefully for
important installation, operation and safety information.
Always follow basic safety precautions, including but not limited to the
following:
• All electrical connections should be made by a qualified electrician.
• Follow all applicable electrical codes.
• Be sure the electrical power is shut OFF at the main circuit breaker
before installing the ozone generator.
• If the ozone generator electrical connection is to be attached to
spa controls, be sure the spa controls are protected by a Ground
Fault Circuit Interrupter (GFCI). If the Aquatic 2 is connected to an
independent electrical supply, have a qualified electrician install a
GFCI between the ozone generator and the electrical supply.
• Do not bury the cord.
WARNING – To reduce the risk of electrical shock, replace damaged
cord immediately.
• Per UL spa requirements, the Aquatic 2 must be mounted indoors or
under a cover sheltered from the elements (rain, sun, sprinklers).
• Never attempt servicing when you are wet.
• To reduce the risk of injury, mount the unit where it is inaccessible
to children.
• Plastic ozone supply tubing is available with the Aquatic 2. Never
replace this tubing with metal tubing.
• Do not operate the Aquatic 2 unless sufficient air flow is accessible
to the unit.
• The use of ozone test strips or dissolved ozone monitor is required.
•
PLEASE SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
Caution: In case of accidental leakage, install the ozone generator in a
well-ventilated area.

3
Technical Specications
Model Aquatic 2
Electric 85-250 VAC, 50/60 Hz
Power 6 W
Ozone Output 300 mg/hour*
Size 3.6 x 2.5 x 5.7 inches
92 x 62 x 146 millimeters
Weight .74 lbs
330 grams
Connection AMP Model
Cable 5.5 feet
Check Valve ¼ inch
Tube 5 feet
*Aquatic 2 ozone output is standardized with 1 LPM oxygen ow rate. Because this
unit is run by air, actual ozone concentration is 0.6 mg/L only. Note, the Aquatic 2 does
not have an oxygen hookup.

4
1
2
3
4
Figure 1
(bottom of Unit)

Aquatic 2 Features
1Air Intake Allows air that is needed for producing ozone to pass over
the ozone cell. DO NOT BLOCK
2Power LED Indicates when there is power to the unit. If the power is
supplied, the light will remain a solid red.
3O3Output Ozone leaves the unit through this port.
4Power Cable This cable supplies power to the ozone generator.
5

6
Installation Instructions
Installation Parts
• Aquatic 2 Ozone Generator
• Aquatic 2 user manual
• 1 check valve
• 5 feet of tubing
• 4 hose ties
• 2 screws and plastic anchor for mounting
Required Installation Tools and Materials
• Phillips screwdriver
• Pliers
Unit Assembly
• The Aquatic 2 is pre-assembled and ready to install.
Mounting
• Mount the ozone generator as high as possible.
• Screws are provided for mounting but may not be appropriate for all
surfaces. Substitute proper mounting hardware as required.
Electrical
• Test the GFCI breaker.
• Connect the Aquatic 2 cord to the mating connector(s) on the control
box according to the provided A2Z OzoneTM wiring diagram in Figure
2.
• Where possible, route the power cord away from other electrical
lines. Do not run the power cord parallel to any low voltage signal
wires. Secure the power cord to prevent damage.

7
Operation
• Verify that the ozone generator turns on and off as required by the
controller.
• The red LED light will be visible from the viewing window on the
bottom left.
• Verify that the gas is flowing into the injector.
• Verify that water does not push passed the check valve.
• Check for and correct any leaks.
Installation Complete
• Once properly installed, the ozone generator requires no further user
operation.
• It will operate automatically with the spa system.

8
Wiring Diagram
The unit ships with the wiring as shown. The voltage for either 110V or
240V can be applied to the black and white wires. Match the alignment
of the white wire of the ozone generator connector with the controller
box connector. Keep in mind, the white wire can be moved. Mount the
unit so that the tube, light and wires are toward the ground. Disregard
the front label.
Figure 2

9
Please make sure water will not back into the Aquatic 2 Ozone Generator.
Water will damage the unit and void the warranty.
Please check these:
• Install the Aquatic 2 above water level and as high as possible.
• Mount the unit so the tube, light and wires are toward the ground.
Disregard front label.
• Install the check valve according to the arrow on the check valve.
The arrow is toward the injector.
• You need an injector for injecting ozone into the spa’s water line.
• If you do not have a venturi injector, please contact us to purchase
one.
• This unit does not work without a venturi injector.
• There should be a vacuum at ozone injector suction location.
• This can be felt with your finger when installing.
• Ozone generator should be on only when the spa pump is on.
• If your spa did not have an ozonator, then connect ozone electric
wire to pump wires.
Operating Instructions

Maintenance
10
• Refer to the chart below.
• Renew your ozone generator as needed with a repair kit.
• To keep your Aquatic 2 Ozone Generator operating properly, please
replace the air filter in the unit as needed or wash, dry and reinstall
in unit. (Must be absolutely dry before replacement.)
Daily Use Average Unit Life
2 hour/day ozone cycle 3 years
3 hour/day ozone cycle 2 years
6 hour/day ozone cycle 1 year

Troubleshooting
11
Problem Possible Cause What to Do
Cloudy water
condition even
though the unit
appears to be
operating properly
Unit and pump not operating
long enough
Increase operating time (min. 6
hours is recommended)
Total alkalinity not correct Adjust total alkalinity between 8 and
150 ppm
pH not correctly balanced Check for proper pH between 7.2
and 7.6
Not enough suction Clear any obstruction in the water
lines or return fitting
Dirty, loose or cracked filter Check/replace spa filter as needed
Metals or minerals in the
water
Ozone may react with metals/
minerals in the water causing
cloudy water. Check alkalinity
pH and clean filter. Run filtration
system and ozone 24 hours.
System won’t turn
on/off Water backing into the unit
Mounting the unit as high as
possible in relation to the spa water
level is important. There is also
a one-way check valve provided
to prevent the back flow of water
from reaching it. As a secondary
precaution, a Hartford Loop in
the tubing, also hanging above
water level, will help prevent water
damage to the unit.
The red LED
not lit on ozone
generator
No power to the generator Check the electrical connections
and then the fuse
There is power to the
generator Ozone board needs to be replaced
Not enough
ozone output Clean or replace ozone plate Clean or replace ozone board and plate

12
Warranty
A2Z Ozone Systems Inc. - ONE YEAR LIMITED WARRANTY
The limited warranty set forth below applies to products manufactured by A2Z Ozone Systems Inc. -
and sold by A2Z Ozone Systems or its authorized dealers. This limited warranty is given only to the rst
retail purchaser of such products and is not transferable to any subsequent owners or purchasers of
such products. A2Z Ozone warrants that it or its authorized dealers will repair or replace, at its option,
any part of such products proven to be defective in materials or workmanship within ONE (1) year from
the date of retail purchase of such products. (All parts) ANY REPAIR OR REPLACEMENT WILL BE
WARRANTED ONLY FOR THE BALANCE OF THE ORIGINAL WARRANTY PERIOD. NOTE: USE
ONLY A2Z Ozone AUTHORIZED REPLACEMENT PARTS. USE OF ANY OTHER PART(S) WILL AU-
TOMATICALLY VOID THIS WARRANTY. THIS LIMITED WARRANTY DOES NOT INCLUDE ANY OF
THE FOLLOWING:
(a) Any labor charges for troubleshooting, removal, or installation of such parts;
(b) any repair or replacement of such parts necessitated by faulty installation, improper maintenance,
improper operation, misuse, abuse, negligence, accident, re, repair material, and/or unauthorized
accessories;
(c) Any such products installed without regard to required local codes and accepted trade practices;
(d) ANY IMPLIED WARRANTY OF MERCHANTABILITY OR IMPLIED WARRANTY OF FITNESS FOR
PARTICULAR PURPOSE, AND SUCH WARRANTIES ARE HEREBY DISCLAIMED: AND
(e) A2Z Ozone SHALL NOT BE LIABLE UNDER ANY CIRCUMSTANCES FOR LOSS OF USE OF
SUCH PRODUCTS, LOST PROFITS, DIRECT DAMAGES, INDIRECT DAMAGES, CONSEQUEN-
TIAL DAMAGES AND/OR INCIDENTAL DAMAGES.
TO OBTAIN WARRANTY SERVICE
Contact A2Z Ozone, 1844 Cargo Court Louisville, KY 40299, USA
Customer Service Number: [phone].
When ling a claim, you must provide:
1) Your name, mailing address and telephone number
2) The selling dealer’s name
3) Proof of date of purchase
4) The date of failure
5) A description of the failure.
After this information is provided, A2Z Ozone will release a RETURN GOODS AUTHORIZATION (RAN)
NUMBER. After receiving the RAN number the part in question must be returned to A2Z Ozone, freight
prepaid, with the RAN number clearly marked on the outside of the package. All preauthorized defective
parts must be returned to A2Z Ozone within thirty (30) days. Under no circumstances may any product
be returned to A2Z Ozone without prior authorization. You must call or write prior to returning product
or your returned goods shipment will be refused. Upon receipt of preauthorized returned goods, A2Z
Ozone will repair or replace, at its option, the defective product(s) and return them (shipping is prepaid
for units under warranty for USA customers only). Buyer’s acceptance of the product and use thereof
constitutes acceptance of these terms.

13
A2Z Ozone WARRANTY REGISTRATION CARD
This information can be also send by EMAIL to us. Please provide ALL pertinent information and send
within twenty (20) days to: [email protected]
Otherwise, please ll out completely and return to A2Z Ozone by post within twenty (20) days of
purchase.
Customer Info:
Name__________________________________________________________
Address________________________________________________________
City__________________________________State_________Zip__________
Phone (____ ) ________________
Dealer Info:
Dealer Name______________________________
Dealer Address_______________________________________________________
City_________________________________State_________Zip__________
Phone ( ) ________________
Purchase/Product Info:
Purchased Date: _______________________Date Installed____________________
Product Purchased: AQUATIC 2 OZONE GENERATOR
Comments / Questions:
DO NOT FORGET TO CUT OUT, PLACE IN ENVELOPE AND MAIL TO THE FOLLOWING
ADDRESS FOR INSTANT WARRANTY COVERAGE!
A2Z Ozone Systems Inc.
ATTN: Warranty Dept.
1844 Cargo Court
Louisville, KY 40299, USA
