INSTRUCTION MANUAL
Model Number: APX2503
Extendable Aluminum Low Profile Truck Bed Rack

WARNING!
PRODUCT DESCRIPTION
Read, understand and follow all warnings and instructions before using this product. Failure to follow these directions
may result in property damage, serious bodily injury, and/or death. AA Products Inc. is not responsible for any property
damage, personal injury, or death occurred while using any AA-Racks products. Retain these instructions for future
reference.
Any modification or unintended use of this product voids any warranty and could create a hazardous condition.
Loads must be secure according to local height and deification regulations and or laws.
Secured loads and connections must be re-checked periodically for tightness.
In order to prevent installation problems, any consultation or use of certified installer or installation service company
is recommended.
The APX2503 is a Low-profile utility rack built for the purpose of Carry bikes, skis, cargo boxes or the Rooftop Tent all
while preserving valuable cooler-carrying capacity underneath.
This pairs low profile racks delivers a 300-lb. on-road capacity and Off-Road Rating for up to 180 lbs. all without the
need to drill into the truck bed.
This low-profile cargo rack can effectively reduce wind noise. It features the rust-free material of aluminum. It also
comes with eight aluminum C-clamps for non-drilling installation, making it compatible with a variety different truck
models. This unit is Powder-coated with weather resistant paint. Built to work & last.
Model Number: APX2503
Extendable Aluminum Low Profile Truck Bed Rack
INSTALLATION INSTRUCTION
1. Slide 4 of the T-Bolts ( M8 * 25 ) into the cross-bar slot. Flip both the uprights and connect the bolts with washers &
nuts. Note: Do NOT tighten the nuts during this process.
2. Slide the Tie Down ( two for each bar ) into the Cross-Bar’ s slot with 2 T-bolts ( M8 * 25 ) follow-by; connect with
Washers & Spring Washers & Plastic Adjust-Knob. ( Installation of the Tie Down is optional for customers’ personal
preference ).
3. Clean bedrails. Insert two Rubber Gaskets at the bottom of rack, put the rack set onto the vehicle’s truck bed.
4. Install the semi-assemble rack set on the truck bed with C-Clamps ( two for each ). Make sure both uprights aligned then
tighten all the bolts for security.
5. Put the Tubular-Cabs on each cross-bar’s end. Then measure the position for both “Tie Down” and Upright, mark the
position and cut the Sealing Strip accordingly for the Cross-Bar, insert the Rubber Sealing Strip into the Cross-Bar ‘s upper
& lower channel to reduce wind-noise.
6. Check all mounting hardware to insure tightness, you are now done!
INSTRUCTION MANUAL
AAPRODUCTS INC.
For Technical Support Call:1-888-806- 3972 / 626-332-4245

PART LIST
Upright Pole - L QTY: 2
Upright Pole - R QTY: 2
Cross-Bar
QTY: 2
Clamp QTY: 8
Rubber Gasket QTY: 4
T-Bolt M8*25 QTY: 12
Lock Nut M8 QTY: 8
Washer QTY: 12
Spring Washer M8 QTY: 4
Tubular-Cab
QTY: 4
Tie Down
QTY: 4
Plastic Adjust-Knob
QTY: 4
Rubber Sealing Strip
QTY: 4
INSTRUCTION MANUAL
AAPRODUCTS INC.
For Technical Support Call:1-888-806- 3972 / 626-332-4245

INSTALLATION DIAGRAM
STEP 1
STEP 2
STEP 3
T-Bolt M8*25 T-Bolt M8*25
Upright Pole
Lock Nut M8
& Washer
T-Bolt M8*25
Tie Down
Plastic Adjust-Knob &
Spring Washer &Washer
Rubber Gasket
Tighten knob firmly to set
Tie-down position.
INSTRUCTION MANUAL
AAPRODUCTS INC.
For Technical Support Call:1-888-806- 3972 / 626-332-4245

Insert the Rubber Sealing Strip into the Cross-Bar‘s Lower
channel to reduce wind-noise. Cut the right length as needed.
STEP 4
STEP 5
STEP 6
ASSEMBLY
COMPLETION
Check all mounting hardware to
insure tightness, you are now done!
Make sure both uprights aligned then tighten all the
bolts for security.
Insert the Rubber Sealing Strip into the Cross-Bar‘s Upper & Lower
channel to reduce wind-noise. Cut the right length as needed.
Tubular-Cab
