INSTRUCTION MANUAL
Aluminum Van Roof Rack With Ladder Stopper
MODEL: AX312 SERIES ( WHITE / BLACK )
MODEL: AX302 SERIES ( WHITE / BLACK )

WARNING!
Read, understand and follow all warnings and instructions before using this product. Failure to follow these directions may
result in property damage, serious bodily injury, and/or death. AA Products Inc. is not responsible for any property damage,
personal injury, or death occurred while using any AA-Racks products. Retain these instructions for future reference.
Any modification or unintended use of this product voids any warranty and could create a hazardous condition.
Loads must be secure according to local height and deification regulations and or laws.
Secured loads and connections must be re-checked periodically for tightness.
In order to prevent installation problems, any consultation or use of certified installer or installation service company is
recommended.
TABLE OF CONTENTS
Assembling The Mounting Bases & Cross-Bar 5~6
PAGE 1
PART LIST
Chevy City Express & Nissan NV200 Series Vans A.
Ford Transit Series Vans(Transit-Connect) A &B.
Mercedes Benz Metris Series Vans C &D.
Dodge Ram Promaster City Series Vans C &E.
Dodge Ram Promaster Full-size Cargo Van Series Vans F.
Ford Transit Cargo Van Series Vans F &G.
Nissan NV1500/ 2500/ 3500 Series Vans H.
APPLICATION GUIDE
The AA-Racks AX302 Series & AX312 Seriesis a roof-rack systemwhich requires no drillingfor installation. ( AX302 Series
available with 3”x1.5” cross bars; AX312 Series available with 2”x1.2” cross bar ). The rack is made of aluminumwhich
features aRust-Free material. Hardware package comes withStainless Steel madebolts, nuts & washers; a pair of ladder
stopper comes standard with each bar set.
We offer Eight different of Shelf Units for different customers’ need:
Chevy City Express
Model No Applicable Van Type Installable Of Cross-Bar
AX302/AX312-50/60-CH
AX302/AX312-50/60-NV
AX302/AX312-50/60-TR
AX302/AX312-60-ME
AX302/AX312-50/60-PR
Nissan NV200
Ford Transit Vans (Transit-Connect)
Mercedes Benz Metris
Dodge Ram Promaster City
1BAR; 2BAR; 3BAR
1BAR; 2BAR; 3BAR
1BAR; 2BAR; 3BAR
1BAR; 2BAR; 3BAR
1BAR; 2BAR; 3BAR
AX302/AX312-72-NV Nissan NV1500/ 2500/ 3500 1BAR; 2BAR; 3BAR; 4BAR
AX302/AX312-72-PR
AX302/AX312-72-TR
Dodge Ram Promaster Full-size Cargo Van
Ford Transit Cargo Van
1BAR; 2BAR; 3BAR; 4BAR
1BAR; 2BAR; 3BAR; 4BAR
APPLICATION GUIDE 1
7Chevy City Express & Nissan NV200 Series Vans
8Ford Transit Series Vans (Transit-Connect)
9Mercedes Benz Metris Series Vans
10Dodge Ram Promaster City Series Vans
11Dodge Ram Promaster Full-size Cargo Van Series Vans
12Ford Transit Cargo Van Series Vans
13Nissan NV1500/ 2500/ 3500 Series Vans
INSTALLATION DIAGRAM 5~13
PART LIST 1~5
ACCESSDRIES FOR OPTIONAL UPGRADES 14
PART LIST GUIDE: Hardware package vary by vehicle type. Verify that you have received the correct parts using the
attached Assembly Drawing and Packing Checklist.( A ~ H )

PAGE 2
INSTRUCTION MANUAL
AAPRODUCTS INC.
For Technical Support Call:1-888-806-3972 / 626-332-4245
A ( Use for Chevy City Express &Nissan NV200 Series Vans &Ford Transit Series Vans(Transit-Connect) )
B( Use for Ford Transit Series Vans(Transit-Connect) )
PART# ITEMS
Mounting Base
Mounting Base-Lower
Cross-Bar
Tubular-Cap
Tie Down
1 BAR
2
0
1
2
2
2 BAR
4
0
2
4
4
3 BAR
4
2
3
6
6
Rubber Sealing Strip
Plastic Adjust-Knob
Adapter Base
Base Bracket
T-Bolt M8*25
Bolt M8 * 45
Carriage Bolt M8 * 30
Nut
2
2
6
2
2
2
4
8
12
4
4
12
4
4
4
8
16
24
6
6
18
6
6
6
12
24
36Washer M8
48 12Spring Washer M8
246Rubber Seal
1 1 1Allen-Wrench
PART# ITEMS
1 BAR
2 BAR 3 BAR
246Rubber Seal
Nut 2
2
4
4
6
6Washer M8
(Middle-Bar Only)

PAGE 3
INSTRUCTION MANUAL
AAPRODUCTS INC.
For Technical Support Call:1-888-806-3972 / 626-332-4245
C( Use for Mercedes Benz Metris Series Vans &Dodge Ram Promaster City Series Vans )
D( Use for Mercedes Benz Metris Series Vans )
E( Use for Dodge Ram Promaster City Series Vans )
PART# ITEMS
Bolt M6*30
Gasket
1 BAR
4
2
2 BAR
8
4
3 BAR
10
6
PART# ITEMS
Mounting Base
Mounting Base-Lower
Cross-Bar
Tubular-Cap
Tie Down
1 BAR
2
0
1
2
2
2 BAR
4
0
2
4
4
3 BAR
4
2
3
6
6
Rubber Sealing Strip
Plastic Adjust-Knob
T-Bolt M8*25
Rubber Seal
Spring Washer M6
Spring Washer M8
6
2
2
4
4
2
1
12
4
4
8
8
4
1
18
6
6
12
12
6
1Allen-Wrench
Nut 4
4
8
8
12
12Washer M6
6 1218Washer M8
246Adapter Base
48 12Blot M6*40
PART# ITEMS
1 BAR
2 BAR 3 BAR
(Middle-Bar Only)

PAGE 4
INSTRUCTION MANUAL
AAPRODUCTS INC.
For Technical Support Call:1-888-806-3972 / 626-332-4245
F( Use for Dodge Ram Promaster Full-size Cargo Van Series Vans &Ford Transit Cargo Van Series Vans)
G( Use for Ford Transit Cargo Van Series Vans )
PART# ITEMS
Mounting Base
Cross-Bar
Tubular-Cap
Tie Down
Rubber Sealing Strip
Plastic Adjust-Knob
T-Bolt M8*25
Base Bracket
Carriage Bolt M8*30
Spring Washer M8
1 BAR
2
1
2
2
6
2
2
2
4
2
2
2 BAR
4
2
4
4
12
4
4
4
8
4
4
3 BAR
6
3
6
6
18
6
6
6
12
6
6
4 BAR
8
4
8
8
PART# ITEMS
Bolt M8*45
Washer M8
Spring Washer M8
Rubber Seal
1 BAR
2
2
2
2
2 BAR
4
4
4
4
3 BAR
6
6
6
6
4 BAR
8
8
8
8
24
Nut 8 16 24 32
Washer M8 10 20 30 40
8
8
8
16
8
8Adapter Base
Allen-Wrench 1 1 1 1

PAGE 5
INSTRUCTION MANUAL
AAPRODUCTS INC.
For Technical Support Call:1-888-806-3972 / 626-332-4245
PART# ITEMS
Mounting Base
Cross-Bar
Tubular-Cap
Tie Down
Rubber Sealing Strip
Plastic Adjust-Knob
T-Bolt M8*25
Bolt M8*20
Spring Washer M8
Allen-Wrench
Nut
1 BAR
2
1
2
2
6
2
2
4
6
1
4
10
2 BAR
4
2
4
4
12
4
4
8
12
1
8
20
3 BAR
6
3
6
6
18
6
6
12
18
1
12
30
4 BAR
8
4
8
8
24
Nut-Clip 4 8 1216
8
8
16
24
1
16
40Washer M8
H( Use for Nissan NV1500/ 2500/ 3500 Series Vans )
INSTALLATION DIAGRAM
Assembling The Mounting Bases & Cross-Bar:
T-Bolt M8*25
T-Bolt M8*25
Nut &Washer M8
Slide 4 T-Bolts M8*25 into the Cross-Bar’s slot, connect each Mounting Base with Washers M8 and Nuts ( DO NOT
tighten them at this moment ). ( See FIG 1 )
FIG 1
2 T-Bolts M8*25 on both sides
of each Cross-Bar
STEP 1
1

PAGE 6
INSTRUCTION MANUAL
AAPRODUCTS INC.
For Technical Support Call:1-888-806-3972 / 626-332-4245
STEP 2
Slide the Tie Down ( two for each bar ) into the Cross-Bar’s slot with 2 T-Bolts M8*25 follow-by, then tighten
with a Plastic Adjust-Knob, Washer M8 & Spring Washer M8. ( Installation of the ladder stoppers is optional for
customers’ personal preference. See FIG 2-1 & 2-2 ). Seal the Cross-Bar with two Tubular-Caps. ( See FIG 2-3 )
FIG 2-1
STEP 3
Use a ladder or any assistance tools, put the assembled rack set onto the vehicle’s roof. Be careful!
As your van type, adjust the Mounting Base on both side of rack to the appropriate position. Make sure that the
distance from the Tubular-Caps to the Mounting Bases is the same. ( See FIG 3-1 )
TIP: FOR THREE-BAR SET OF AX302 & AX312 ASSEMBLY, please begin with the middle mounting base set ( the
one with the lower Mounting Base ) for the better stability of the system. ( See FIG 3-2 )
Tie Down
T-Bolt M8*25
Plastic Adjust-Knob &
Spring Washer M8 &Washer M8
FIG 2-2
Tubular-Cap
FIG 2-3
Adjust as needed
A B
A=B
FIG 3-1
FIG 3-2 FOR THREE-BAR SET OF AX302 & AX312 ASSEMBLY
Mounting Base-Lower
FRONT BAR REAR BARMIDDLE BAR
The use of Mounting Base-Lower is to compensate the curved roof of the vehicle.

PAGE 7
INSTRUCTION MANUAL
AAPRODUCTS INC.
For Technical Support Call:1-888-806-3972 / 626-332-4245
Installation Onto Van ( Find type of vehicle install instructions below) :
2
CHEVY CITY EXPRESS & NISSAN NV200
STEP 1
Use the proper tool, take off the cover on the roof top to locate the M8 threaded hole. Place a Rubber Seal for each hole.
Installing the Base Bracket: Put two Carriage Bolts M8*30 on the Base Bracket upside down. Align the middle hole to the
vehicle’s M8 threaded hole. ( See FIG 4 )
Carriage Bolt M8 * 30
Optional: Place a Rubber
Seal for each hole
STEP 2
Set position for the Adapter Base. Two of the upside down bolts should also goes through the Adapter Base.( See FIG 5-1 )
Installing the rack set onto the roof: Connecting the Mounting Bases with the Adapter Bases. Set the Bolt M8*45 on the Mounting
Base’s middle hole; Align all three holes then connect the Mounting Bases and Adapter Kit together; Tighten the Bolt M8*45 to
secure the rack with the vehicle. Tighten the other two Carriage Bolts M8*30 on the Adapter with Nuts & Washers( See FIG 5-2 ).
After installing the rack set, adjust all the Cross-Bars to align with each other and tighten all fasteners. Insert the Rubber Sealing
Strip into the Cross-Bar’s upper & lower channel to reduce wind-noise. Cut the right length as needed.( See FIG 5-3 ).
FIG 4
Insert the Rubber Sealing Strip into the
Cross-Bar’s Upper & Lower Channel to reduce
wind-noise. Cut the right length as needed.
FIG 5-1
FIG 5-3
Nut &Washer M8
FIG 5-2
M8 Threaded Hole
Bolt M8 *45 & Spring Washer M8 &Washer M8

PAGE 8
INSTRUCTION MANUAL
AAPRODUCTS INC.
For Technical Support Call:1-888-806-3972 / 626-332-4245
STEP 1
Use the proper tool, take off the cover on the roof top to locate a hole (thread / non-thread). Place a Rubber
Seal for each hole. Set position for the Adapter Base: Connect the Base Bracket, Adapter Base and the
Mounting Base with two Carriage Bolts M8*30 upside down, tighten with Nuts & Washers M8. ( See FIG 6 )
Nut
Alignment Hole
Optional: Place a Rubber
Seal for each hole.
FIG 6
STEP 2
Align the middle hole of the Mounting Base to the vehicle’s roof hole (thread / non-thread): With thread, put the Bolt M8*45
through and tighten the bolt( See FIG 7-1 ); Non-threaded, put the Bolt M8*45 through and tighten with Nut, Washer and the
Rubber Seal. ( See FIG 7-1,7-2 )
After installing the rack set, adjust all the Cross-Bars to align with each other and tighten all fasteners. Insert the Rubber
Sealing Strip into the Cross-Bar’s upper & lower channel to reduce wind-noise. Cut the right length as needed.( See FIG 7-3 ).
Carriage Bolt M8 * 30
WasherM8
OUTSIDE OF THE ROOF INNER OF THE ROOF
Bolt M8 * 45
&Spring Washer M8
&Washer M8
Rubber Seal
&Washer M8
& Nut
FIG 7-1
FIG 7-3
FIG 7-2
Insert the Rubber Sealing Strip into the
Cross-Bar’s Upper & Lower Channel to reduce
wind-noise. Cut the right length as needed.
FORD TRANSIT CONNECT

PAGE 9
INSTRUCTION MANUAL
AAPRODUCTS INC.
For Technical Support Call:1-888-806-3972 / 626-332-4245
STEP 1
Find the threaded holes on the roof. They are a pair of M6 threaded holes on each corner. Take out the covers ( if any ).
Optional: Put a Rubber Seal on each hole to improve sealing. ( See FIG 8 ). Set position for the Adapter Base: Align both
side-holes of the Adapter Base to the roof’s pre-thread holes. ( See FIG 8-1 )
FIG 8
STEP 2
Align both side-holes then connect the Mounting Bases and Adapter Bases, put two M6*40 Bolts through and tighten
the bolts to secure the rack with the vehicle, tighten the bolts with Washers M6 & Spring Washers M6. ( See FIG 9-1 ).
After installing the rack set, adjust all the Cross-Bars to align with each other and tighten all fasteners. Insert the
Rubber Sealing Strip into the Cross-Bar’s upper & lower channel to reduce wind-noise. Cut the right length as needed.(
See FIG 9-2 ).
Optional: Place a Rubber
Seal for each hole.
Alignment Hole
FIG 9-1
Bolt M6 * 40
Spring Washer M6
Washer M6
VAN ROOF
Insert the Rubber Sealing Strip into the
Cross-Bar’s Upper & Lower Channel to reduce
wind-noise. Cut the right length as needed.
FIG 9-2
MERCEDES BENZ METRIS
