INSTRUCTION MANUAL
MODEL NUMBER: RB0008
SIDE STEP RAILS

Model Number: RB0008
WARNING!
PRODUCT DESCRIPTION
Read, understand and follow all warnings and instructions before using this product. Failure to follow these directions
may result in property damage, serious bodily injury, and/or death. AA Products Inc. is not responsible for any property
damage, personal injury, or death occurred while using any AA-Racks products. Retain these instructions for future
reference.
Any modification or unintended use of this product voids any warranty and could create a hazardous condition.
Loads must be secure according to local height and deification regulations and or laws.
Secured loads and connections must be re-checked periodically for tightness.
In order to prevent installation problems, any consultation or use of certified installer or installation service company
is recommended.
The pair of side nerf bar is compatible with 07-Up Toyota Tundra Crew MAX.
Made with quality steel with textured black finish, good quality and long lasting slip-resistant, makes getting on
& off vehicle easily.
Slip-proof plate pad design, Providing a secure, comfortable step for the whole family. Door to door hoop style
drop step nerf bars crew cab.
Simple installation without drilling required.
INSTRUCTION MANUAL
AAPRODUCTS INC.
For Technical Support Call:1-888-806- 3972 / 626-332-4245

PART LIST
Washer M10
Hex Head Bolt M10 QTY: 12 Hex Head Bolt M8 QTY: 12
Washer M8 QTY: 12
QTY: 12
Spring Washer M10 QTY: 12 Spring Washer M8 QTY: 12
Step Rail( Driver Side ) QTY: 1Step Rail( Passenger Side ) QTY: 1
Rear Bracket QTY: 1
Center Bracket QTY: 1
Front Bracket QTY: 1
Rear Bracket QTY: 1
Center Bracket QTY: 1
Front Bracket QTY: 1
PASSENGER SIDE DRIVER SIDE
*There are screw spare parts attached to the package.
INSTRUCTION MANUAL
AAPRODUCTS INC.
For Technical Support Call:1-888-806- 3972 / 626-332-4245

INSTALLATION DIAGRAM
STEP 1
STEP 2
Reference picture of bracket positions for later steps. Locate and align brackets base on the following picture.
There are four sets of threaded holes in the side panel. Starting from the front of the vehicle, use the First, Third and
Fourth set of holes.
Remove the existing factory bolts, (if equipped) on the side panel located by the front tire opening, (Fig 1). NOTE: There is
a threaded hole next to the factory bolt, (if equipped). This will be the mounting location for the driver side front Mounting
Bracket. Partially attach the driver side front Mounting Bracket to the vehicle using the included Hex Head Bolt M8 ,
Washers M8 and Spring Washers M8(Fig 2).Do not tighten at this time.
FIG1
Rear Bracket
Center Bracket
Front Bracket
Rear Bracket
Center Bracket
Front Bracket
PASSENGER SIDE DRIVER SIDE
DRIVER SIDE
FRONT OF VEHICLE REAR OF VEHICLE
Remove this
factory bolt
Front Bracket
Mounting Location
FIG2
BRACKET FACING REAR OF VEHICLE
Hex Hea Bolt(M8)
&Spring Washer(M8)
&Washer(M8)
INSTRUCTION MANUAL
AAPRODUCTS INC.
For Technical Support Call:1-888-806- 3972 / 626-332-4245

STEP 3
Remove the two factory bolts(Fig1), (if equipped), along the side panel find the Third Set of the threaded holes to mount the
center Bracket, and the very last two factory bolts, (if equipped), along the side panel to mount the rear Bracket. Partially attach
center and rear Brackets to the vehicle with Hex Head Bolt M8 , Spring Washers M8 and Washers M8(Fig2).
Repeat procedure for other side.
Complete your installation. Enjoy!
STEP 4
Now install Step Rail on the brackets. Place the Step Rail on the installed mounting brackets.
Align the holes of Step Rail with the holes on the brackets and drop them into place. Next thread the provided Hex Head Bolt
( M10 ) & washer ( M10) & Spring washer (M10) to hold the Step Rail and leave loose. Adjust the Step Rail in place to your
liking, tighten all fasteners on the brackets. Front and rear first and then the center brackets finally the Step Rail.
Hex Hea Bolt(M10)
&Spring Washer(M10)
& Washer(M10)
BRACKET
INSTRUCTION MANUAL
AAPRODUCTS INC.
For Technical Support Call:1-888-806- 3972 / 626-332-4245
Remove two
factory bolts
FIG1 FIG2
Hex Hea Bolt(M8) &Spring Washer(M8)
&Washer(M8)
BRACKET FACING
REAR OF VEHICLE
