Aaeon AHP-1154 User manual

Touch Panel PC AHP - 1 154
AHP-1154
Intel®Celeron®
J1900 / N2807 Processor
15” TFT LCD
Touch Panel PC
AHP-1154 Manual 1st Ed.
April 16, 2015

Touch Panel PC AHP - 1 154
Copyright Notice
This document is copyrighted, 2015. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result
from its use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.
i

Touch Panel PC AHP - 1 154
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
•AMI is a trademark of American Megatrends Inc.
•Intel®, and Celeron®are trademarks of Intel®Corporation.
•Microsoft Windows®is a registered trademark of Microsoft
Corp.
•IBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
All other product names or trademarks are properties of their
respective owners.
ii

Touch Panel PC AHP - 1 154
Packing List
Before you begin operating your PC, please make sure that the
following materials are enclosed:
AHP-1154 Touch Panel PC
Phoenix Terminal Block
Mounting brackets and screws
DVD for manual (in PDF format) and drivers
If any of these items should be missing or damaged, please contact
your distributor or sales representative immediately.
iii

Touch Panel PC AHP - 1 154
Safety & Warranty
Please read the following safety instructions carefully. It is advised
that you keep this manual for future references
1. Disconnect this device from any AC supply before cleaning.
2. While cleaning, use a damp cloth instead of liquid or spray
detergents.
3. For any pluggable equipment, the power outlet must be installed
near the device and easily accessible.
4. Keep this device away from humidity.
5. Place this device on a solid surface during installation. Dropping
it or letting it fall could cause damage.
6. The openings on the device’s enclosure are for dissipating heat.
DO NOT COVER THE OPENINGS.
7. Watch out for high temperatures that may occur during system
operation.
8. Make sure the voltage of the power source is correct before
connecting the device to the power outlet.
9. Position the power cord so that people cannot step on it. Do not
place anything over the power cord.
10. All cautions and warnings on the device should be noted.
11. If the device is not to be used for a long time, disconnect it from
the power supply to avoid damage by transient over-voltage.
12. Never pour any liquid into the openings. This could cause fire or
electric shock.
iv

Touch Panel PC AHP - 1 154
13. As most electronic components are sensitive to static electrical
charge, be sure to ground yourself to prevent static charge when
installing the internal components. Use a grounding wrist strap
and contain all electronic components in any static-shielded
devices.
14. If any of the following situations arises, please the contact
our service personnel:
i. Damaged power cord or plug
ii. Liquid intrusion to the device
iii. Exposure to moisture
iv. Device is not working as expected or in a manner
as described in this manual
v. The device is dropped or damaged
vi. Any obvious signs of damage displayed on the
device
15. DO NOTLEAVE THIS DEVICE IN AN UNCONTROLLED
ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS
BELOW -20°C(-4°F) OR ABOVE 70°C(158°F)TO PREVENT
DAMAGE.
v

Touch Panel PC AHP - 1 154
FCC
This device complies with Part 15 FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause
harmful interference, and (2) this device must
accept any interference received including
interference that may cause undesired
operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the
manufacturer’s instructions and your local government’s recycling or
disposal directives.
vi

Touch Panel PC AHP - 1 154
China RoHS Requirements
产品中有毒有害物质或元素名称及含量
AAEON Panel PC/ Workstation
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件
×
○
○
○
○
○
外部信号
连接器及线材
×
○
○
○
○
○
外壳
×
○
○
○
○
○
中央处理器
与内存
×
○
○
○
○
○
硬盘
×
○
○
○
○
○
液晶模块
×
○
○
○
○
○
光驱
×
○
○
○
○
○
触控模块
×
○
○
○
○
○
电源
×
○
○
○
○
○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006
标准规定的限量要求以下。
X
：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006
标准规定的限量要求。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质中央处理器、内存、硬盘、光驱、触控模块为选购品。
vii

Touch Panel PC AHP - 1 154
Contents
Chapter 1 General Information
1.1 Introduction................................................................ 1-2
1.2 Features .................................................................... 1-3
1.3 Specifications ............................................................1-4
1.4 Product Overview...................................................... 1-7
Chapter 2 Hardware Installation
2.1 Panel-mount Installation............................................ 2-2
2.2 COM 1/4 (D-SUB 9) .................................................. 2-4
2.3 COM 2/3 (D-SUB 9) .................................................. 2-4
2.4 Hard Disk Drive Installation....................................... 2-6
Chapter 3 AMI BIOS Setup
3.1 System Test and Initialization ................................... 3-2
3.2 AMI BIOS Setup........................................................3-3
Chapter 4 Driver Installation
4.1 Introduction................................................................ 4-3
Appendix A Programming the Watchdog Timer
A.1 Watchdog Timer Registers ....................................A-2
A.2 Watchdog Sample Program...................................A-4
Appendix B I/O Information
B.1 I/O Address Map....................................................B-2
B.2 Memory Address Map............................................B-4
viii

Touch Panel PC AHP - 1 154
B.3 IRQ Mapping Chart................................................B-6
Appendix C Mating Connector
C.1 List of Mating Connectors and Cables.................. C-2
Appendix D Electrical Specifications for I/O Port
D.1 Electrical Specifications for I/O Port..................... D-2
ix

Touch Panel PC
AHP-1154
Chapter 1 General Information 1- 1
General
Information
Chapter
1

Touch Panel PC
AHP-1154
Chapter 1 General Information 1- 2
1.1 Introduction
Powered by Intel®Celeron®J1900 2GHz and N2807 1.58GHz
processors, the AHP-1154 is a operator panel computer designed
to serve as a human machine interface (HMI). It is a PC-based
system with a 15" color TFT LCD display, onboard Ethernet
controller, and multi-COM port interfaces. With a built-in CFast
socket, the AHP-1154 is as compact and user friendly as a
multi-function computer. In addition, its "fit anywhere" design makes
it very flexible and able to be used in many different kinds of
installations. It can be VESA 75/100 wall mounted.
For system integrators, this simple, complete, compact and highly
integrated system let you easily build an operator panel into your
applications. Common industrial applications include factory
automation systems, precision machinery, and production process
control. It is also suitable for many non-industrial applications,
including vending machine, and car park automation. Our operator
panel is a reliable, cost-effective solution to your application’s
processing requirements.

Touch Panel PC
AHP-1154
Chapter 1 General Information 1-3
1.2 Features
15”450-nits XGA LED Backlight
Intel®Celeron® J1900 2GHz/ N2807 1.58GHz Processor
IP65-rated front plastic bezel & back metal chassis
Fanless
Supports Windows® 7 32-bit/ Windows® Embedded Standard
7 32-bit/ Linux Kernel 2.6.x or above

Touch Panel PC
AHP-1154
Chapter 1 General Information 1- 4
1.3 Specifications
System
CPU
System Memory
LCD / CRT Controller
Ethernet
I/O Port
Storage Disk Drive
Expansion
OS Support
Intel®Celeron® J1900 2GHz/ N2807
1.58GHz Processor
204-pin DDR3L 1333MHz SODIMM x 1,
up to 8GB (J1900)/ 4GB (N2807)
2GB build-in system RAM
Integrated in Processor
10/100/1000Base-TX, RJ-45 x 2
USB 3.0 x 1
USB 2.0 x 3
RS-232 x 2
RS-232/422/485 x 2 (COM2, COM3)
LAN x 2
VGA x 1
3-pin terminal block for power input
Power button x 1
2.5”SATA Hard Disk Drive x 1
CFast socket x 1
MiniCard x 2 (full-sized x 1, half-sized x
1)
Windows®7 32-bit, Windows®
Embedded Standard 7, Linux Kernel
2.6.x or above

Touch Panel PC
AHP-1154
Chapter 1 General Information 1-5
Mechanical
Construction
IP65-rated front plastic bezel and back
metal chassis
Mounting
Panel, VESA 75/100
Dimension
16.02”(W) x 12.22”(H) x 2.3”(D)
(407mm x 310.5mm x 58.3mm)
Carton Dimension
19.8" (W) x 8.2" (H) x 17.9" (D) (505 mm
x 210 mm x 455 mm)
Cutout Size for panel
mount
394 x 297.5mm
Net Weight
11.02lbs (5kg)
Gross Weight
14.99lbs (6.8kg)
Environmental
Operating Temperature
13.9°F ~ 122°F (-10°C ~ 50°C) with
0.5m/s airflow
Storage Temperature
-4oF~158oF (-20oC~70oC)
Operating Humidity
90%@ 40oC, non-condensing
Vibration
1 g rms/ 5-500Hz/ Operation (HDD)
Shock
20 G peak acceleration (11 msec.
duration)
EMC
CE/FCC Class A
Power Supply
12V DC/ Min 9V –Max 30V input

Touch Panel PC
AHP-1154
Chapter 1 General Information 1- 6
LCD
Display Type
15”XGA TFT LCD
Max. Resolution
1024x768
Max. Colors
16.8M (8-bit/color)
Luminance (cd/m2)
450 nits
Viewing Angle
160o(H),140o(V)
Backlight
LED
Backlight MTBF (Hours)
100,000
Touch Screen
Type
5-wire analog resistive
Light Transmission
80%
Lifetime
10 million activations

Touch Panel PC
AHP-1154
Chapter 1 General Information 1-7
1.4 Product Overview

Touch Panel PC
AHP-1154
Chapter 1 General Information 1- 8

Touch Panel PC AHP-1154
Hardware
Installation
Chapter
2
Chapter 2 Quick Installation Guide 2-1

Touch Panel PC AHP-1154
2.1 Panel-mount Installation
To mount the panel onto a wall, you will need a strong mounting
surface, screws along with the mounting brackets.
Please take a look at the illustration below before starting to
mount the panel.
Step 1: Prepare a 394mm x 297.5mm opening on the surface to
be mounted
Step 2: Place the rear of the panel through the opening
Chapter 2 Quick Installation Guide 2 - 2
